Varec 2920 User manual

IOM118GVAE4318
Automation Solutions for oil & gas, defense, and aviation applications
Installation and Operations Manual
Dispatch and Fuels Accounting
2920 Float & Tape Transmitter
Precision instrument for remote monitoring of
tank level and temperature information

Varec, Inc. iii
Copyright
© 2018, All rights reserved. Printed in the United States of America.
Except as permitted under the United States Copyright Act of 1976, no part of this publication
may be reproduced, stored in a retrieval system or transmitted in any form or by any means -
electronic, mechanical, photocopying, recording, or otherwise - without the prior written
permission of the Publisher:
Varec, Inc.
5834 Peachtree Corners East
Peachtree Corners (Atlanta), Georgia 30092
Phone: [phone]
Fax: [phone]
Trademarks Acknowledged
Varec, Inc. recognizes all other trademarks. Trademarks of other products mentioned in this
manual are held by the companies producing them.
FuelsManager®, TankView®, and, Varec® are registered trademarks of Varec, Inc.
All other product and service names mentioned are the trademarks of their respective
companies.
Documentation Control
This document and the information provided within are controlled by the approvals agency(s)
listed below. All changes to this document must be submitted to and approved by the agency(s)
before public release.
• FM Approvals (FM)
• ATEX
• IECEx
FCC (US)
This device complies with Part 18 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
Note This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. Any modifications made to this device that are not approved by
Varec, Inc. may void the users authority to operate this equipment.

ICES-003 Class A Notice
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada
Disclaimer of Warranties
The contract between the Seller and the Buyer states the entire obligation of the Seller. The
contents of this instruction manual shall not become part of or modify any prior or existing
agreement, commitment, or relationship between the Seller and Buyer. There are no express or
implied warranties set out in this instruction manual. The only warranties that apply are those
in the existing contract between the Seller and Buyer.
The 2920 Float & Tape Transmitter (FTT) has not been tested by Varec under all possible
operational conditions, and Varec may not have all the data relative to your application. The
information in this instruction manual is not all inclusive and does not and cannot take into
account all unique situations. Consequently, the user should review this product literature in
view of his or her application. If you have any further questions, please contact Varec for
assistance.
Limitations of Seller's Liability
In the event that a court holds that this instruction manual created some new warranties, Seller's
liability shall be limited to repair or replacement under the standard warranty clause. In no case
shall the Seller's liability exceed that stated as Limitations of Remedy in the contract between
the Seller and Buyer.
Use of parts that are not manufactured or supplied by Varec voids any warranty and relieves
Varec of any obligation to service the product under warranty. Varec recommends the use of
only Varec manufactured or supplied parts to maintain or service Varec 2920 Float & Tape
Transmitters.
iv Installation and Operations Manual

Terms of Use
The information provided in this document is provided "as is" without warranty of any kind.
Varec, Inc. disclaim all warranties, either express or implied, including the warranties of
merchantability and fitness for a particular purpose. In no event shall Varec, Inc. or its suppliers
be liable for any damages whatsoever including direct, indirect, incidental, consequential, loss
of business profits or special damages, even if Varec, Inc. or its suppliers have been advised of
the possibility of such damages.
This manual is solely intended to describe product installation and functions and should not be
used for any other purpose. It is subject to change without prior notice. This manual was
prepared with the highest degree of care. However, should you find any errors or have any
questions, contact one of our service offices or your local sales agent.
Safety Precaution Definitions
Caution! Damage to equipment may result if this precaution is disregarded.
Warning! Direct injury to personnel or damage to equipment which can cause injury to
personnel may result if this precaution is not followed.
Note Qualified personnel are required for installation of this product in a hazardous
environment.
Safety Precautions
Read this manual carefully and make sure you understand its contents before using this product.
Follow all instructions and safety guidelines presented in this manual when using this product.
If the user does not follow these instructions properly, Varec cannot guarantee the safety of the
system.
Note Comply with all applicable regulations, codes, and standards. For safety precautions,
the user should refer to the appropriate industry or military standards.
Caution! Electrical Hazard! Read and understand static and lightning electrical protection
and grounding described in API 2003. Make certain that the tank installation, operation,
and maintenance conforms with the practice set forth therein.
Warning! Striking the gaugehead of the transmitter with a metal object could cause a
spark to occur. When removing or replacing the gaugehead in flammable or hazardous
liquid storage areas, take necessary measures to protect the gaugehead from impact.
Warning! Volatile fumes may be present! Ensure that the tank has been leak and pressure
tested as appropriate for the liquid to be stored. Observe appropriate safety precautions in
flammable or hazardous liquid storage areas. Do not enter a tank that has contained
hydrocarbons, vapors, or toxic materials, until a gas-free environment is certified. Carry
breathing equipment when entering a tank where oxygen may be displaced by carbon
dioxide, nitrogen, or other gases. Wear safety glasses as appropriate. Use a hard hat.
Warning! Sparks or static charge could cause fire or explosion! The mechanical
connections between the guide cables, the float, the tape, and the gaugehead provide a
resistance to ground that is adequate for the safe electrical drain of electrostatic charges
that may accumulate in the tank and the product. Worker activity and worker clothing may
accumulate electrostatic charges on the body of a worker. Care should be used in
flammable environments to avoid the hazard.
Varec, Inc. v

vi Installation and Operations Manual
Warning! Broken negator motor spring pieces can cause injury when the back cover of the
gaugehead is removed! Whenever the back cover is removed, stand to one side as the last
bolt is removed.
Warning! Discard plastic conduit entry plugs. Use the metal plugs that are shipped loose
in a bag.
Warning! Explosion and water ingress hazard. Tighten cover and tighten and seal conduit
and plugs with pipe sealant prior to operation. Failure to do so voids manufacturer’s
warranty.
Warning! Possible buildup of electrostatic charges on non-conducting surfaces. To clean,
wipe equipment with a damp cloth.
Caution! Consult the manufacturer if dimensional information on the flameproof joints is
necessary.
Warning! The flamepath joints are not repairable by the end user. Consult the factory for
repair or replacement.
Warning! Conduit seal required within 50 mm of conduit entries to enclosure when
installed.
Attention! Joint de conduit requis à moins de 50 mm aux entrées de conduit à la clôture
une fois installé.
Warning! Install models with I.S. HART per Associated Intrinsically Safe (AIS) (Appareillage
Connexe) Control Drawing 28-013355, Appendix D.
Warning! Improper connections, component substitutions, or tampering may impair
intrinsic safety and create a hazardous condition.
Avertissement! La subsitution de composants peut compromettre la sècuritè intrinséque.
Warning! Do not open the display or expansion junction boxes while energized due to an
explosion hazard.
Note The I.S. HART terminal box is labeled with a light blue sticker. It is intrinsically safe
and may be opened while energized.

Varec, Inc. vii
