Varian HS-32 User manual

HS-32
Diffusion Pump
Instruction Manual
Manual No. 6999-01-132
Revision G
May 2000
Varian Vacuum Technologies
121 Hartwell Avenue
Lexington, MA 02421-3133
[phone]
(800) 8-VARIAN

America
Varian Vacuum Technologies
121 Hartwell Avenue
Lexington, MA 02421,
USA
Tel: [phone]
Fax: [phone]
Toll Free: 1 [phone]
Argentina
Varian Argentina Ltd.
Sucursal Argentina
Av. Ricardo Balbin 2316
1428 Buenos Aires
Argentina
Tel: [phone]
Fax: [phone]
Australia
Varian Australia Pty., Ltd.
6/81 Frenchs Forest Road
Frenchs Forest, NSW 2086
Australia
Tel: [phone]
Fax: [phone]
Brazil
Varian Industria e Comercio Ltda.
Avenida Dr. Cardoso de Mello 1644
Vila Olimpia
Sao Paulo 04548 005
Brazil
Tel: [phone]
Fax: [phone]
Canada
Varian Canada
6705 Millcreek Drive, Unit 5
Mississauga, Ontario L5N 5R9
Canada
Tel: [phone]
Fax: [phone]
China
Varian China Ltd.
Room 1201, Jinyu Mansion
No. 129A Xuanwumen Xidajie
Xicheng District
Beijing 100031
P.R. China
Tel: [phone]
Fax: [phone]
Varian Shanghai
Service Station
716 Yishan Road Shanghai
P.R. China 200233
Tel: [phone]
Fax: [phone]
England
Varian Ltd.
28 Manor Road
Walton-On-Thames
Surrey KT 12 2QF
England
Tel: [phone]
Fax: [phone]
France
Varian s.a.
7 avenue des Tropiques
Z.A. de Courtaboeuf – B.P. 12
Les Ulis cedex (Orsay) 91941
France
Tel: [phone]
Fax: [phone]
Germany
Varian GmbH
Alsfelder Strasse 6
Postfach 11 14 35
64229 Darmstadt
Germany
Tel: [phone]
Fax: [phone]
Hong Kong
Varian Technologies Asia, Ltd.
Rm 2611 Concordia Plaza
New Mandarin Plaza
1 Science Museum Rd.,
Tsimshatsui East, Kowloon
Hong Kong
Tel: [phone]
Fax: [phone]
India
Varian India PVT LTD
1010 Compotent House
7, Nangal Raya Business Centre
New Delhi 110 046
India
Tel: [phone]
Fax: [phone]
Italy
Varian Vacuum Technologies
via Flli Varian 54
10040 Leini, (Torino)
Italy
Tel: [phone]
Fax: [phone]
Japan
Varian Vacuum Technologies
Sumitomo Shibaura
Building, 8th Floor
4-16-36 Shibaura
Minato-ku, Tokyo 108
Japan
Tel: [phone]
Fax: [phone]
Korea
Varian Technologies Korea, Ltd
Shinsa 2nd Bldg. 2F
966-5 Daechi Dong
Kangnam Gu, Seoul
Korea 135-280
Tel: [phone]
Fax: [phone]
Netherlands
Varian Vacuum Technologies
Rijksstraatweg 269 H,
3956 CP Leersum
The Netherlands
Tel: [phone]
Fax: [phone]
Mexico
Varian S.A.
Concepcion Beistegui No 109
Col Del Valle
C.P. 03100
Mexico, D.F.
Tel: [phone]
Fax: [phone]
Singapore
Varian Asia, Ltd.
1123 Serangoon Road
#03-02
Singapore 328207
Tel: [phone]
Fax: [phone]
Spain
Varian Iberica
Avda Pedro Diez 25
28019 Madrid
Spain
Tel: [phone]
Fax: [phone]
Russia
Varian Moscow
19A Khlebny per
121019 Moscow
Russia
Tel: [phone]
Fax: [phone]
Taiwan
Varian Technologies Asia Ltd.,
Taiwan Branch
18F-13 No.79, Hsin Tai Wu Road
Sec. 1, Hsi Chih
Taipei Hsien
Taiwan
Tel: [phone]
Fax: [phone]
Internet Users:
Visit us on the web at:
www.eVarian.com
Representatives in most countries
Sales and Service Offices

ii
SAFE INCORPORATION OF VARIAN DIFFUSION PUMPS INTO VACUUM SYSTEMS IS THE
RESPONSIBILITY OF THE SYSTEMS DESIGNER. TAKE APPROPRIATE ACTION THROUGH
REDUNDANCY, AND/OR OTHER SAFEGUARDS TO PROTECT PERSONNEL AND PROPERTY
FROM THE HAZARDS DESCRIBED BELOW AND IN THE INSTALLATION, OPERATION, AND
MAINTENANCE INSTRUCTION MANUAL. SAFE OPERATION IS THE RESPONSIBILITY OF THE
USING ORGANIZATION AND ITS PERSONNEL. READ THE INSTRUCTION MANUAL AND
UNDERSTAND HOW TO AVOID HAZARDS PRIOR TO OPERATING THE DIFFUSION PUMP. ALL
PERSONS WHO WORK WITH OR ARE EXPOSED TO DIFFUSION PUMPS OR EQUIPMENT
WHICH UTILIZES SUCH PUMPS OR DIFFUSION PUMP FLUID MUST TAKE PRECAUTIONS TO
PROTECT THEMSELVES AGAINST POSSIBLE SERIOUS BODILY INJURY OR DEATH. DO NOT
BE CARELESS AROUND SUCH PRODUCTS.
THESE SHEETS AND THE INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS
CAN HELP YOU TO OPERATE THIS PUMP SAFELY AND EFFICIENTLY. READ THEM. SPECIAL
OPERATING CONSIDERATIONS AND PRECAUTIONS WILL BE FOUND IN THE OPERATION
INSTRUCTIONS. UNINFORMED OR CARELESS OPERATION OF THIS PUMP CAN RESULT IN
POOR PERFORMANCE, DAMAGE TO THE PUMP OR OTHER PROPERTY, SERIOUS BODILY
INJURY, AND POSSIBLE DEATH.
USERS OF THIS EQUIPMENT SHOULD BE ALERT TO TWO LEVELS OF HAZARDS IDENTIFIED
BY THE FOLLOWING SYMBOLS:
Designers of systems which utilize diffusion pumps must design out hazards wherever possible; pro-
vide guards, safety features, and interlocks for hazards which cannot be designed out; warn with
respect to hazards which cannot be designed out and which remain after utilizing guards, safety fea-
tures, and interlocks;and lastly, provide procedures and instructions on proper use, servicing, etc., so
as to minimize risk.
WARNING
Warnings are used when failure to observe instructions or precautions
could result in injury or death to humans.
CAUTION
Cautions are used when failure to observe instructions could result in
significant damage to equipment and/or facilities.

viii
WARNING
High voltages (up to 480 V) can kill. Always break the primary circuit to
the power supply before starting to work on the heater and/or its wiring.
WARNING
Varian has no control over the types of gases passing through this
pump. These are entirely under the control of the process user and/or
the hardware systems integrator. Frequently, process gases are toxic,
flammable, corrosive, explosive, or otherwise reactive. Since these
gases can cause serious injury or death, it is very important to plumb
the exhaust of the pump to the facility’s hazardous gas exhaust system
which incorporates appropriate filters, scrubbers, etc., to insure that the
exhaust meets all air and water pollution control regulations.
WARNING
Diffusion pumps are typically cleaned with acetone, alcohol, or other
solvents.
When heated, sprayed or exposed to high temperature equipment,
these solvents become flammable and explosive, causing serious injury
or death. Do not use near a high-temperature source. Ventilate work-
ing area with a blower and use in large, well-ventilated room. When
heated or sprayed, solvents also becomes 4 to 5 times heavier than air
and will flow down, settling in tanks, pits, and low areas, thus displacing
air which can kill by asphyxiation. Use in a large, well-ventilated room.
Use of a self-contained breathing apparatus may be necessary.
Acetone, alcohol, and other solvents are irritants, narcotics, depres-
sants, and/or carcinogenics. Their inhalation and/or ingestion may pro-
duce serious effects. Prolonged or continued contact with the skin will
result in absorption through the skin and moderate toxicity. Always
ensure that cleaning operations are carried out in large, well-ventilated
rooms, and wear eyeshields, gloves, and protective clothing.
WARNING
Certain gases can become corrosive and toxic when trapped in oil.
Always wear protective gloves when handling dirty pump oil, drain it into
a closable container, and do not breathe the fumes of the oil. Always
use fully self-contained breathing apparatus.

ix
WARNING
When lifting some Varian diffusion pumps, use power-assisted equip-
ment and trained moving/installation personnel to avoid dropping, slip-
ping, and/or overturning the pump and severely injuring personnel.
Check weight of equipment before lifting and do not stand under equip-
ment being moved.
CAUTION
Alcohol, acetone, and other solvents degrade O-ring materials reducing
their ability to hold a vacuum. Do not use acetone or other solvents on
O-rings. If necessary to clean O-rings, wipe with lint-free, clean cloth,
wash in detergent and water, or use a small amount of pump oil.
Note
Always dispose of used or dirty oil properly and in compliance with all
local, state, and federal environmental laws and regulations.
WARNING
If hazardous gas, vapors, chemicals, or combustible mixtures are
pumped, sufficient quantities may exist during operation.This pump may
contain decomposed and/or overheated pump oils or poisonous and/or
overheated pump oils or poisonous and/or corrosive process materials
which are highly toxic and also can be an asphyxiant. Proper operation
will not always ensure that all hazardous materials have been removed.
WARNING
Hot oils can cause serious burns. Wear protective gloves and long
sleeved, loose fitting, heat resistant garments when draining pump oil.

Installation
1-5
1-4 UNPACKING
Pumps are factory-packaged to permit prolonged storage in suitably protected areas without special
precautions.
a. Remove flange covers, blank plugs, protective plugs from water connections, etc. Be careful
not to scratch or otherwise damage or mar the sealing surface – usually an O-ring groove on
top of the large inlet flange.
b. Carefully remove the outer shipping container and save it for evidence if damaged. Notify
the carrier immediately.Visually inspect the pump for damage that may have occurred
during shipping. Discard any internal packing which may have been used to protect the
internal components.
c. For non-critical work, after making sure that there are no foreign materials inside the pump, it
may be charged with fluid and used without disassembly. Otherwise, it should be disassembled
and cleaned. In general, cleaning may be required if the expected vacuum level is to be below
the 10-6 Torr (.000133 Pa) range.
d. Check the internal jet assembly. It should be concentric and firmly seated on the bottom of
the pump.The jet assembly should not rotate because of an indexing pin at the bottom.
1-5 CLEANING A NEW PUMP
a. Read cold cap maintenance and installation data which will be found in Section III,
para.3-4, of this manual. Remove the cold cap in accordance with these instructions.
b. Disassemble the internal jet system from the body of the pump. See Figure 3-2 for a section
drawing of a typical jet assembly.
c. Remove fill and drain plugs and gaskets if supplied.
d. Thoroughly clean all components of the jet assembly and pump casing interior (but not
O-ring gaskets) with acetone followed by an alcohol rinse.
WARNING
When lifting some Varian diffusion pumps, use power-assisted equip-
ment and trained moving/installation personnel to avoid dropping, slip-
ping, and/or overturning the pump and severely injuring personnel.
Check weight of equipment before lifting and do not stand under equip-
ment being moved.

Installation
e. Remove all traces of the cleaning fluid by carefully drying with clean, dry, oil-free
compressed air.
f. For reassembly, reverse the above procedure.
g. Clean the flanges and O-ring grooves thoroughly with alcohol, using clean, lint-free rags.
1-6
WARNING
Diffusion pumps are typically cleaned with acetone, alcohol, or other
solvents.
When heated, sprayed or exposed to high temperature equipment,
these solvents become flammable and explosive, causing serious injury
or death. Do not use near a high-temperature source. Ventilate work-
ing area with a blower and use in large, well-ventilated room. When
heated or sprayed, solvents also become 4 to 5 times heavier than air
and will flow down, settling in tanks, pits, and low areas, thus displacing
air which can kill by asphyxiation. Use in a large, well-ventilated room.
Use of a self-contained breathing apparatus may be necessary.
Acetone, alcohol, and other solvents are irritants, narcotics, depres-
sants, and/or carcinogenics. Their inhalation and/or ingestion may pro-
duce serious effects. Prolonged or continued contact with the skin will
result in absorption through the skin and moderate toxicity. Always
ensure that cleaning operations are carried out in large, well-ventilated
rooms, and wear eyeshields, gloves, and protective clothing.
CAUTION
Acetone, alcohol, and other solvents degrade O-ring materials reducing
their ability to hold a vacuum. Do not use solvents on O-rings. If neces-
sary to clean O-rings, wipe with lint-free, clean cloth, wash in detergent
and water, or use a small amount of pump oil.
h. Remove all traces of acetone or alcohol by carefully drying with clean, dry, oil-free
compressed air. Install O-ring gasket.
1-6 UTILITY AND SYSTEM CONNECTIONS
1-6-1 Safety Considerations and Interlocks
a. Large pumps are equipped with two thermal switches. One is mounted at the body cooling
coils, the other at the center of the boiler plate (at the bottom of the pump).

Installation
These thermal switches are supplied NORMALLY CLOSED. The thermal switches have been
designed so that a cooling water failure or low oil level in the boiler will result in an increase in
temperature, causing the NORMALLY CLOSED contacts of the switches to open. When the
problem has been corrected and the temperature lowered, the thermal switch will automati-
cally reset itself.
1-7
WARNING
Utility failure can cause damage to the equipment, overheating, and
possible explosions. Designers of the equipment using diffusion pumps
must design their system to protect personnel and property from possi-
ble hazards.
b. A small lamp of the same voltage as the diffusion pump heater may be connected across
the terminals of the thermal switch.The lamp will normally be shunted by the contacts.
However, when the contacts open, the lamp will receive full line voltage and give a visual
trouble indication.
1-6-2 Vacuum Connections
a. The pump must be installed with the body vertical and plumb. Check that the mating flange on
the system (to the pump inlet) is horizontal within plus or minus 1 degree. If this condition is
not met, correct the system before installing the pump.The boiler of the pump (especially for
large pumps) must be horizontal to prevent uneven fluid level and avoid local overheating
where the fluid level would be too shallow.
b. Prepare inlet O-ring seals by wiping them with a clean cloth. Do not use solvents.Use a small
amount of diffusion pump oil to wet the cleaning cloth.Install the O-ring in the groove being
careful not to damage the sealing surface with cuts, nicks, or scratches.
c. Using appropriate lifting apparatus, align the bolt holes of the flanges and assemble the bolts.
Tighten the bolts evenly to compress the O-ring seal until light contact is achieved between
metal flanges.
d. Check fill and drain plugs for tightness. Apply light to medium torque, enough to compress
gaskets. Minute leaks through the gaskets may develop with use in this location.They may
be detectable with very sensitive mass spectrometer leak detectors.
1-6-3 CoolingWater Connections (See Figure 1-3)
The following method of external connections is recommended.
a. Water connections are designed for 3⁄8FPT fittings.The cold cap cooling coil and all of the
body and foreline cooling (except the quick cool coil) should be connected in series. A cooling
water supply of 3 to 4 gpm at 60°F to 80°F (16°C to 27°C) should be adequate. A higher flow
than this will not be harmful.

Installation
1-9
The temperature at the discharged cooling water should not exceed 130°F (54°C).If the water supply
pressure is low, it may be necessary to connect the different sections of cooling coils in parallel.This
should be done if the cooling water discharge temperature exceeds 130°F (54°C).The cooling water
discharge should, if possible, be connected to an open drain so that cooling water flow can readily be
checked.
b. The quick-cool coil at the boiler plate MUST be connected to an open drain and the feed line
controlled by a separate water 3-way valve (open, closed, and vent to atmosphere).The drain
must be below the boiler level so that it is drained completely when the quick-cool coil water
supply is shut off and the pump is operating.See Figure 1-3.
1-6-4 Electrical Connections (See Figure 1-4a, b, c, d, or e Diffusion Pump Wiring Diagram)
WARNING
High voltages (up to 480V) can kill. Always break the primary circuit to
the pump before starting to work on the heater and/or its wiring.
a. The pump heater has been designed to operate at a certain voltage. Check the heater for
correct supply voltage and, in the case of multiphase connections, for load balance by
measuring the resistance of each branch.
Heater circuit resistance (all 3-phase, 200V – 3.3 ohms
measured line-to-line) 240V – 4.8 ohms
460V – 17.6 ohms
415V – 14.4 ohms
480V – 19.2 ohms
b. Make connections to the terminals in the junction box (at the foreline).The use of flexible
conduit is recommended to facilitate removal of the pump for service.The pump should not
be operated at more than 5% over the rated voltage. Make connections in accordance with
the wiring diagram provided with each pump.
1-6-5 Thermal Switches
The thermal switches have been pre-set at the factory and should not require adjustment. The lower
thermal switch is set at 550°F; the lower switch is set at 220°F. Should any thermal switch be thrown
out of adjustment, it can be adjusted as follows.
1. Boiler thermal switch
The boiler thermal switch is mounted on a brass block at the center of the boiler.
The thermal switch should be adjusted, with the pump operating, as follows:
a) After several hours operation, disconnect the lead wires and place an
ohmmeter across the terminals of the thermal switch.

Installation
1-16
1-6-6 InitialVacuumTest
The purpose of this test is to establish the leak tightness of the system, specifically the vacuum con-
nections to the diffusion pump. (To eliminate misleading indications and the masking of leaks by the
fluid, the tests should be carried out with the diffusion pump “dry", i.e., before it is charged with the
pumping fluid.)
WARNING
Pumps and their components are designed for vacuum service; they
are not designed to be pressurized which could cause them to burst
possibly expelling shrapnel at lethal velocities. Serious accidents have
been caused by intentional pressurization of vacuum systems and their
components. NEVER PRESSURIZE ANY PART OF A VACUUM SYS-
TEM FOR TEST OR ANY OTHER PURPOSE. Always provide pressure
relief when designing diffusion pumps into systems and ensure that
pressure relief motion is limited to safe envelopes.
a Confirm the vacuum ultimate pressure characteristics of the mechanical pump.This should
closely approximate the value quoted in the manufacturer’s data, if the mechanical pump is
correctly installed, adjusted, and filled with clean oil. Pressure measurements should be made
with a continuously indicating total pressure gauge, such as a thermocouple gauge.This test
can be performed to evaluate either valved or unvalved systems. Connect the outlet or foreline
of the diffusion pump to the inlet of the mechanical backing pump, using appropriate vacuum-
tight connections.
b In the case of a valved system, close the roughing valve and main isolation valve ahead of
the diffusion pump. In the case of unvalved systems, the entire work chamber volume must
be included in the test. Evacuate the entire system with the mechanical pump only.
Let the mechanical pump reach an ultimate pressure in the system.This reading should
approximate the value obtained in step a above (usually 10 to 50 microns (1.33 to 6.65 Pa)). If
it does not, examine for leakage. If leakage is suspected, follow standard procedures for leak
testing.These will depend on the type of vacuum gauges and/or leak detection equipment
available.The most effective are Varian’s helium leak detectors.

Installation
1-17
1-7 ADDING PUMP FLUID
WARNING
The risk of explosion in large pumps is increased by hydrocarbon oils,
low fuel levels, or opening either fill or drain plugs during operation.
Never operate diffusion pumps larger than 6 inches with hydrocarbon
oils without a complete safety analysis for the specific system and appli-
cation. Hydrocarbon oils are more prone to explode than synthetic sili-
cone-based oils, similarly the larger the diffusion pump the greater the
risk of explosion. Running the pump with low oil level causes hot sur-
faces and the oil to be decomposed and very toxic. Such decomposed
oil and any residue from toxic/corrosive materials pumped will be pre-
sent on the dipstick when the fluid level is measured.
a. The recommended fluid charge for the pump is three gallons.The fluid charge will gradually
be depleted through use, but the pump will continue to operate normally.When the charge is
reduced to approximately 60% of the initial amount, the boiler temperature may begin to rise
and under this condition the thermal switch is designed to open the heater circuit.
b. This diffusion pumps is furnished with fill and drain fittings with special Viton elastomer
sealed plugs.
c. If the pump is hot, wait until the pump has cooled then vent it to atmosphere. Remove the
plug from the filling port of the pump and install the specified quantity of fluidup to the FULL
COLD level indicator on the sight glass (see Figure 1-5).The fluid can also be poured in
from the pump inlet or foreline.
d. Replace the fill plug with a newViton gasket.Tighten the fill plug using moderate torque
(75 inch-pounds maximum).Lubricate the O-ring with pump fluid before installation.
e. Once the pump is running, the oil level should be in the FULL HOT operating range as
indicated on the sight glass assembly.
f. It is not recommended that SantoVac 5 Diffusion Pump Fluid be used with the HS-32.
NOTE
________
Fluids must be stored in clean, tightly closed containers and should be
clearly identified in accordance with their type. Do not mix pumping flu-
ids of different types and origins. Generally, it is not a good idea to mix
used and new fluid for a pump charge.

2-1
SECTION II
OPERATION
During initial installation, the newly installed pump fluid may be subjected to a degassing process.This
may result in foreline pressure fluctuations and “bursts”.Such fluctuations are considered normal.
2-1 START-UP PROCEDURE
WARNING
The following conditions increase the risk of explosion:
• any air leaks into the system;
• roughing through a hot diffusion pump may cause some hot hydrocar-
bon fluids to ignite or explode when exposed to air;
• air release or admitting air to a pump with a hot boiler, permit a strong
oxidizer to contact the hot pump oil;
• high (above 1 micron (.133 Pa)) inlet pressure;
• insufficient (or low level of) pump fluid;
• running pump without cooling water circulating to main water cooling
coils;
• trapping water between closed isolation valves at inlet and discharge
of quick cool coils and running diffusion pump;
• foreign matter in the pumping fluid which changes its viscosity and
obstructs flow passages.
CAUTION
• Do not turn on the heater without fluid in the pump.This may ruin the
heaters and damage the pump.
• Do not air-release the pump while the boiler is hot. Most diffusion
pump fluids are heat-sensitive and will break down under these con-
ditions.
• Do not operate the pump without the foreline baffle.This may cause a
greater than normal fluid loss.
• Do not operate the pump for extended periods at an inlet pressure
above 1 micron. High pressure operation may cause excessive
backstreaming.
• Do not operate the pump heater unless the cooling water is circulating.
It will cause the pump and fluid to overheat.
a. Evacuate the diffusion pump by means of the mechanical roughing pump to a pressure level
below 0.5 Torr (66.5 Pa).The diffusion pump will not function unless the discharge pressure is
less than the tolerable forepressure (approximately 0.5 Torr (66.5 Pa)).

Operation
2-2
b. Turn on the cooling water supply to the pump body and check that adequate flow is provided
by examining the amount of water discharged at the visual drain points.
c. Switch on the power to the diffusion pump heater.
d. Check inlet and forepressure performance by means of the system instrumentation.
e. During operation, the gas load at the inlet of the diffusion pump should not exceed the
maximum throughput capability of the pump.This means that the pressure at the inlet flange
should not (except in transient conditions) exceed approximately 1 x 10-3 (.133 Pa) Torr.
During operation, the discharge or fore pressure must be below the specified tolerable
forepressure.
2-2 SHUTDOWN PROCEDURE
a. Switch off the power to the diffusion pump heaters.
b. Admit cooling water to the quick-cool coil if necessary and continue to circulate it until the
pump body just above the boiler heat shield can be touched (approximately 130°F or 54°C).
In valved systems which have tight inlet and foreline connections, it is possible to close valves
to isolate the diffusion pump at inlet and discharge, to air-release the remainder of the
system, shut off the heat to the diffusion pump, and stop the mechanical pump.With this
method, the quick-cool coil does not have to be used. However, the water flow through the
pump must be maintained until the boiler cools down below approximately 300°F (150°C).
CAUTION
Do not operate the quick-cool coil when the pump is cold or out of ser-
vice to prevent harmful collection of condensation on the boiler plate,
heater, and heater terminals.
WARNING
Boiler temperatures reach 530°F (275°C) which can cause serious
burns when touched. Always ensure surfaces have cooled near room
temperature before touching them.
Air release or admitting air to a pump with a hot boiler, especially when
it is under vacuum, permits a strong oxidizer to contact the hot pump oil
and thereby increases the risk of an explosion.

3-1
SECTION III
MAINTENANCE
3-1 GENERAL
Diffusion pumps generally require little attention when correctly operated. However, it is advisable to
perform some periodic checks to insure continued trouble-free operation.
By simple preventive maintenance, costly down-time and cleaning procedures can be avoided. A day-
to-day log of pump and system performance will indicate the condition of the pump and marked vari-
ations will show the need for corrective action.
3-2 PERIODIC INSPECTION
The frequency of inspection will depend on the type of system, its operation and utilization.The maxi-
mum interval between inspections is established on the basis of experience. It is recommended that
the following items be regularly examined.
WARNING
High voltages (up to 480V) can kill. Always break the primary circuits to
the power supply before starting to work on the heater and/or its wiring.
Make sure that the pump is at room temperature before attempting ser-
vice.Serious burns can result if this Warning is not heeded.
Depending on system process, poisonous or corrosive compounds may
be present when opening the fill or drain. Always wear appropriate
gloves and clothing and use a self-contained breathing apparatus.
An explosion could occur if the fill or drain is opened when the pump is
running or when it is hot. Check oil level only when the pump is cold.
a. When the pump is cold, check the condition and level of fluid. These can be inspected by
withdrawing a sample through the drain and by visually checking the level of fluid through the
sight glass respectively. (Use new O-ring gaskets when replacing fill and drain plugs.) Slight
discoloration of the fluid does not affect performance.
b. Loss of the fluid can be caused by the following:
1. incorrect air admittance procedures and/or admittance of excessive air or other gas
to a hot pump,
2. inadequate water cooling, or
3. continuous operation at inlet pressures above 10-3 Torr (.133 Pa).

Maintenance
3-2
c. When the pump is cold, check that the heaters are bolted snugly to the boiler plate and that
all heater terminal connections are tightly fastened inside the junction box.
d. Check the total heater input and balance of load if a multi-phase heater is used.
e. Check to insure that cooling water flow is unobstructed and not below specified quantities.
3-3 CLEANING
Complete cleaning of the pump may be periodically required because of the gradual deterioration of
some pump fluids.Removal of the pump from the system is then necessary.
WARNING
If hazardous gas, vapors, chemicals, or combustible mixtures are
pumped, sufficient quantities may exist during operation. This pump
may contain decomposed and/or overheated pump oils or poisonous
and/or corrosive process materials which are highly toxic and also can
be an asphyxiant. Proper operation will not always ensure that all haz-
ardous materials have been removed.
Diffusion pumps are typically cleaned with acetone, alcohol, or other
solvents.
When heated, sprayed or exposed to high temperature equipment,
these solvents become flammable and explosive, causing serious injury
or death. DO NOT USE NEAR A HIGH-TEMPERATURE SOURCE.
Ventilate working area with a blower and use in large, well-ventilated
room. When heated or sprayed, solvents also become 4 to 5 times
heavier than air and will flow down, settling in tanks, pits, and low
areas, thus displacing air which can kill by asphyxiation. Use in a large,
well-ventilated room. Use of a self-contained breathing apparatus may
be necessary.
Acetone, alcohol, and other solvents are irritants, narcotics, depres-
sants, and/or carcinogenics. Their inhalation and/or ingestion may pro-
duce serious effects. Prolonged or continued contact with the skin will
result in absorption through the skin and moderate toxicity. Always
ensure that cleaning operations are carried out in large, well-ventilated
rooms, and wear eyeshields, gloves, and protective clothing.
CAUTION
Acetone and other solvents degrade O-ring materials reducing their
ability to hold a vacuum. Do not use solvents on O-rings.If necessary to
clean O-rings, wipe with a lint-free, clean cloth or use a small amount of
diffusion pump oil.

Maintenance
3-5 DISASSEMBLING AND REASSEMBLINGTHE JET ASSEMBLY
1. To disassemble the jet assembly:
a Disassemble the cold cap water line feedthrough compression seals by
removing the nut, follower, gasket, and female coupling located at the side of the
pump.(See figure 3-2 for a section drawing of a typical jet assembly)
b Remove the block which secures the cold cap to the jet assembly.
c Lift out the cold cap.
d Unscrew the hex nut above the top cap and remove it.
e Lift the jet assembly out with a chain fall attached to the cross member now
visible in the jet.
f Once the jet is out of the pump, unscrew the two nuts on the cross member to
release the lower jet stages.
g Disassemble and clean as required.
2. To assemble the jet assembly:
a Reverse the steps outlined above.
3-6 HEATER REPLACEMENT
3-5
CAUTION
Poor clamping resulting in inadequate thermal contact may result in
reduced heater life and poor pump performance. Tighten nuts finger-
tight on clamping plate, then gradually and evenly tighten them to 250
in-pounds.
WARNING
High voltages (up to 480V) can kill. Always break the primary circuit to
the power supply before starting to work on the heater and/or its wiring.
a Determine which heater element has failed at the junction box, then disconnect the two
corresponding leads from the terminal strip. Pull the leads out of the terminal box then out
the elbow cover plate.

Maintenance
3-7
b Remove the heater cover and insulation from the bottom of the diffusion pump.
c Remove the nuts holding the clamping plate.
d Lower the entire heating unit (heater element, clamping plate and heater shield, see
Figure 3-3) until it is off the mounting studs.
e Coat the boiler studs with anti-seize compound such as FEL-PRO-C-5A or common milk
of magnesia.
f Assemble the new unit (heater element, clamping plate, and crush plate).
g. Support the heating unit by the clamping plate, line up the holes with the boiler studs, and
push the unit up against the boiler plate.Use two nuts finger-tight to hold it in place.
h. Screw on the remainder of the nuts finger-tight, then tighten the nuts evenly up to 250 inch-
pounds of torque.
i Label the heater leads according to the schematic diagram, then run the wires around the
periphery of the pump, under the wire retaining clips, into the conduit, and up into the junction
box. Connect the leads to the terminal strip then replace the elbow cover plate.
j Replace the heater cover and insulation.
CAUTION
Should it be necessary to use a new wire in the following step, it is
important that no. 10 stranded nickel wire with high-temperature insula-
tion is used.The terminal lugs must be solid nickel. If copper or copper-
plated wire and/or lugs are used, they will oxidize rapidly because of the
high temperature and the terminals will overheat and fail.
Figure 3-3. Heater Element Assembly

Health and Safety Clearance
Return Authorization Policy
In compliance with Federal OSHA Safety Standard 1910.1200, Hazard Communications “Right to
Know”, Varian is enforcing that standard to preclude the potential health risk to its service person-
nel that can occur when receiving, disassembling, or repairing potentially contaminated products.
Returned products not accompanied by this completed certificate will be held until the completed
certificate is received; failure to provide this completed certificate within 30 days of notification
will result in the return of held product(s) unprocessed.
If a product is received at Varian in a contaminated condition, the customer will be held respon-
sible for all costs incurred to ensure the safe handling of the product.
Company Name:
__________ Hereby certify that the product(s) listed below have been cleaned of all hazardous
residue and that the residue remaining is of a non-hazardous nature.
__________ Hereby certify that the product(s) listed below have been contaminated by the fol-
lowing toxic or hazardous materials:
RA Number Model Number Serial Number
________________________ ______________________ ______________________
________________________________________ _______________________________ ___________
Authorized Signature Title Date
Note: Varian Service will only accept contaminated Turbo or Mechanical Pumps. All other
products must be decontaminated by the customer beforeVarian Vacuum Products
Lexington will assign a Return Authorization (RA) number and authorize the return of
the product (refer to the attached Return Authorization Report on the next page).
Note:Varian Vacuum Products Lexington cannot accept any biological hazards,
radioactive material, organic metals, or mercury at its facility.
Varian Vacuum Products
121 Hartwell Avenue
Lexington Massachusetts 02421
Telephone [phone]
FAX [phone]
November 1995

Returned Material Report
This report must accompany all products returned for repair, replacement, or warranty evaluation. Full informa-
tion regarding reasons for return of the product will expedite repair or adjustment. Please fill in all blanks below
and furnish any other information which will help identify the nature and cause of failure.
Reason for Return (check appropriate box)
❒Paid Repair ❒Advance Exchange ❒Shipping Error ❒Credit
❒Warranty Evaluation ❒Loaner Return ❒Shipping Damage
Product Information (use separate forms if more than one model no.)
Varian Model No. _______________________ Serial No. __________________ Quantity ___________________
Part Description
Purchase Information (if product is being returned for warranty evaluation, show your original purchase order
number and date purchased)
Varian Sales Order No. (if available) ________________________ Machine # ___________________________
Original Purchase Order No. _________________________ Purchase Order Date _______________________
Company Name ___________________________________________ Contact _______________________________________
Address
City ______________________________________________________________ State _________________ Zip _____________
Telephone
Failure Report (describe in detail suspected cause or nature of malfunction)
Returned Products
All products returned to Varian/VPD Service Operation for warranty evaluation must be sent prepaid and
customer must comply with the warranty replacement and adjustment provision set forth in the warranty.
Ship directly to:Varian Vacuum Products
Vacuum Products Service Center
121 Hartwell Avenue
Lexington, MA 02421
All products sold byVarian and returned by customer are subject toVarianVacuum Products standard
terms and conditions of sale including, but not limited to, the warranty and damages and liability provi-
sions set forth in the warranty.
November 1995
VPD Service Operation
