VARMILO MACA 100 G-2 User manual

INST：MA CA 100 G -2

先用拔键器拔掉键帽，然后倒置键盘，轻轻拍打键盘背面，将残渣倒出。再用毛刷清理键盘上粘
附的残渣、灰尘。若还有残留，用干净的抹布蘸酒精进行擦拭，直到干净为止。然后放至阴凉通风处，
晾干。使用过程中，请勿频繁拔插、拉扯、弯折键盘线，尤其是线键分离的键盘，容易造成键盘插口处
松动或脱落。
Varmilo音译即为“阿米洛”，取自世界语“Via”“armilo”。寓意：为您定制的专属装备。阿米
洛在保证优良做工的同时，希望能够满足顾客的个性化定制需求。此外阿米洛也坚持在有限的键盘空间
内进行创作，试图让用户的桌面更加丰富多彩。
⸺键盘艺术家·阿米洛
全新系列的阿米洛静电容机械键盘均采用阿米洛自主研发的静电容机械轴，具有稳定的内部结构与触感。
前言
产品特征
日常保养
1

标准包装配件列表
2

阿米洛静电容机械轴触发方式
阿米洛静电容机械轴优点
阿米洛静电容轴在被按动时，电场感应极片之间的电容量
会发生变化，键盘通过C=Q/U公式计算电容量大小，达到
一定电容量后触发。
无物理触点，理论寿命无限。
轴体手感一致性好，不会因为磨损而影响使用体验。
采用静电容触发原理，同时又能保证纯粹的机械键盘手感。
3

4
·键盘出厂默认为Windows模式。
·Fn+A，长按3秒，Caps Lock灯闪三下，键盘切换为Mac模式。
·Fn+W，长按3秒，Caps Lock灯闪三下，键盘切换为Windows模式。
·若Fn+A，长按3秒，Caps Lock灯不闪，说明键盘已处于Mac模式下。
·若Fn+W，长按3秒，Caps Lock灯不闪，说明键盘已处于Windows模式下。
·Fn+Esc，长按3秒，Caps Lock灯闪三下，键盘恢复为出厂设置（Windows模式）。
·关机断电及休眠后，会自动记忆之前所有设定功能，启动后自动回到设定的模式。
模式切换
Mac模式-多媒体按键
音量加
提高键盘灯光亮度
上一曲 暂停/播放 下一曲 静音 音量减
降低屏幕亮度 提高屏幕亮度 降低键盘灯光亮度显示所有窗口 显示应用程序
MA109C-S型号的键盘没有Mac模式功能（型号可在键盘背面铭牌处查询）

5
·Fn+→可在常亮和呼吸两种模式中进行切换。
·Caps Lock、Scroll Lock、Number Lock不参与灯光效果。
·在呼吸模式中按Fn+↓减缓灯效速度，Fn+↑加快灯效速度。
·在常亮模式中按Fn+↓降低灯光亮度，Fn+↑提高灯光亮度。
·上述功能仅对装有LED的键盘有效。
·Fn+X可关闭背光灯。
Windows模式-灯效调节
Windows模式-多媒体功能
阿米洛键盘拥有丰富的多媒体功能，按住Fn以及对应的按键即可实现。

6
Windows模式-计算器功能
① Numlock灯不亮时，为键盘功能模式，也就是常规键盘“没有打开Numlock功能”。
·输入字符在显示屏上面显示，字母大小写，数字，符号或单独功能键。
② Numlock灯亮蓝色灯时，为键盘+数字模式，即打开键盘Numlock功能。
·屏幕显示打字速度，每敲击一下增加一个次数，超过1分钟清零重新开始。
·屏幕上保存前2次的静态记录和一次实时动态记录，当动态记录1分钟记录完成后，那么第一次
记录清除，依次类推。
③ Numlock灯亮红色灯时，键盘为计算器模式。
·Page Up为计算器删除功能（←）。
·Page Dn为计算器的彻底清除功能（AC）。
·End键为计算器的更正当前输入内容功能（CE）。
·Home键为百分号功能（%）。
·Pause键为正负号切换键功能（+/-）。
·Enter键为等号功能（=）。
·Fn+Enter把计算结果输入到电脑当前窗口。
MAC系统目前没有计算器功能，仅有普通键盘功能。
购买老款计算器键盘的，Home和End键在计算器模式下没有新增%和CE功能，可联系客服或售后通过升级固件实现%和CE功能。

7
·Fn+右Ctrl，按一次，为菜单。
·Fn+任意Win，按一次，锁定或开启Win。
·Fn+左Win，长按3秒，Caps Lock灯闪三下，Fn和左Win功能调换。
·Fn+左Ctrl，长按3秒，Caps Lock灯闪三下，Caps Lock和左Ctrl功能调换。
·Fn+Esc，长按3秒，Caps Lock灯闪三下，键盘恢复为出厂设置（Windows模式）。
·在Windows模式下支持全键无冲。
Windows模式-其他功能

1.尊敬的用户，感谢您对Varmilo阿米洛的信任和支持。为了保护您的合法权益，更好的为您服务，我公司严格按照中华人民共和国相关法
律，为您提供三包售后服务。
2.若你购买的产品，因为人为原因损坏（自行拆卸，进水与烟灰，输入电流电压不当等）与自然灾害（如水灾，火灾，鼠害等）引起的损
害，不在免费保修范围，您仍可享有Varmilo阿米洛提供的有偿维修服务，以使您的产品能够继续使用。
3.消耗品（如脚垫、防滑贴）及赠品配件，不在三包的保修范围内。
4.在您向Varmilo阿米洛提出维修和更换服务之前，请先参阅Varmilo阿米洛官网的产品疑难解答，网址为：Varmilo.com或致电Varmilo阿
米洛售后服务电话：[phone]，若疑难解答无法帮您排除故障，您可将产品或配件交付至授权经销商或Varmilo阿米洛官方进行检测，
我们会尽快为您提供相关服务。在将产品或配件送检之前，务必将非标准配件、定制配件提前取下，以免遗失或损坏。如：定制键帽，其
他厂商的配件，私人LOGO等。
5. 本说明书的最终解释权和所有权属阿米洛品牌所有，后续产品升级请用户自行留意，持续关注，谢谢您一路的支持与配合！
保修卡
8

To clean a keyboard, pull out the keycaps using a key puller, put the keyboard upside down, pat the back of the keyboard to pour
out impurity, and brush off the impurity and dust that are adhered to the keys. If residuals exist, wipe them off using a clean cloth
with some alcohol. After that, dry the keyboard in a cool and ventilated place.To avoid a loose or fallen USB port, do not frequently
plug,unplug, drag or bend a keyboard cable, especially for a keyboard with separate cable and keys.
Varmilo comes from Esperanto ‘Via’ ‘armilo’, which means the unique keyboard customized for you. We were born to
meet customer's personality and variety as well as keep good craftsmanship and stable quality. Varmilo is aiming at
beautifying your desk setup by the endless improvement and boundless innovation!
By keyboard artist Varmilo
The brand-new Varmilo EC switch mechanical keyboard uses the electrostatic capacitive mechanical switch which developed by
Varmilo, it has very stable inner structure and good typing feel.
Preface
Product Feature
Daily Maintenance
9

Standard accessories list
10

The Actuation of Varmilo EC switch
Advantages of Varmilo EC switch
When pressing Varmilo EC switch, the capacitance between
field induction electrodes will change, the keyboard could
calculate the capacitor volume through formula C = Q / U,
and may trigger out when capacitance big enough.
No physical contact means no fatigue, theoretically speaking,
it means unlimited service life.
Longer consistency of the switch touch, better using
experience.
Adopting static capacitive triggering principle while ensuring
pure mechanical keyboard feel.
11

Last song Pause/Play Next song Mute Volume - Volume +
Keyboard backlight
brightness+
Brightness ‒ Brightness+ Keyboard backlight
brightness-
Display all interfaces Display all apps
·Keyboard defaulted mode is Windows.
·By pressing Fn + A for about 3 seconds until Caps Lock flashes, the keyboard will swap to Mac mode.
·By pressing Fn + W for about 3 seconds until Caps Lock flashes, the keyboard will swap to Windows mode.
·If Caps Lock key does not flash when pressing Fn+A, it means the keyboard was already in Mac mode.
·If Caps Lock key does not flash when pressing Fn+W, it means the keyboard was already in Windows mode.
·By pressing Fn+Esc for about 3 seconds until Caps Lock flashes, the keyboard will turn to be default mode.
·When the computer is restarted after shutdown or hibernation, previous keyboard settings will be resumed.
Modes Swapping
Mac Mode-Multi-Media Keys
12
MA109C-S model keyboard does not support MacOS. ( You can check the model
at the back steel plate )

·Fn+→swapping between “full backlit” mode and “breathing” mode.
·Caps Lock、Scroll Lock、Number Lock do not operate in light effects.
·Under Breath, press Fn+↓ to slow down a light effect or Fn+↑ to speed it up.
·Under Always On, press Fn+↓ to decrease light brightness or Fn+↑ to increase it.
·The above functions are available only for the keyboards with LEDs.
·Turn off the backlit by Fn+X.
Windows Mode-Backlight Adjustment
Windows Mode-Multi-Media Functions
Varmilo mechanical keyboards are featured with rich multi-media functions. To enable a multi-media
function, press Fn and the keycorresponding to the function.
13

Windows Mode-Calculator function
① When the Numlock's LED is off, means the keyboard is under function mode. Like the regular
keyboard “does not open the Numlock function”
·Characters inputed will be displayed on the display, letters, numbers, symbols or individual
function keys.
② When the Numlock's LED is in blue, means the keyboard is under keyboards and number
mode, like the Numlock function is turned on.
·The screen displays the typing speed, increasing the number of times per tap, and clearing again
after more than 1 minute.
·The screen will save the first 2 static records and one real-time dynamic record. When the dynamic
recording is completed for 1 minute, then the the first record will be cleared, and so on.
14

·Fn+ right Ctrl: Menu.
·Fn+Win : Enable/Disable Win key.
·Fn+left Win( more than 3 seconds), Caps Lock flashes three times, Fn and Win key swapped.
·Fn+left Ctrl ( more than 3 seconds), Caps Lock flashes three times, Caps Lock and left Ctrl key swapped.
·Pressing FN+ Esc three seconds, keyboard will become defaulted version (Caps Lock will flash 3 times)
·NKRO under Windows mode.
Windows Mode-Other Functions
③ When the Numlock's LED is in red, the keyboard is in calculator mode.
·Page Up is the delete function of calculator (←).
·Page Dn is the All Clear function (AC) of the calculator.
·End is the Clear Entry function (CE) of the calculator.
·Home button is a percent function (%).
·Pause key is the function of switching plus/minus (+/-).
·Enter key is equal function of calculator (=).
·Fn+Enter to input the calculation result into the current window of the computer.
15
The calculator function cannot work on MacOS, under MacOS it will only work as a normal mechanical keyboard.
Customers who bought the old model Calculator keyboards, the End key and Home key does not have any related calculator functions,
can contact our customer services to get the firmware upgrade and get the % and CE functions.

Warranty card
1.Dear users,thank you for great trust and support to Varmilo.In order to protect your legal rights and offer the best service,our company provides
you with the after-sales service strictly in accordance with the laws of People's Republic of China.
2.The purchased product will be no longer under free warranty with the following conditions:
a:Exceed 1 year warranty period.
b:Damage caused by man-made(self-demolition,water splash,ash contamination,input current and voltage inappropriate)
c:Natural disasters(such as floods,fire,rodents)However,you will still be entitled to the paid maintenance service provided by Varmilo.
3.Consumables(such as the foot pad,anti-skid stickers,ect.)and gifts accessories are not under free warranty.
4.Please refer to the Varmilo Product Troubleshooting at http://www.varmilo.com or contact Varmilo sales representative before you request
repair and replacement service.If the mentioned solutions can not solve your problem,you can deliver the product or accessory to an authorized
dealer or Varmilo for testing.We will provide you with relevant services as soon as possible.Before submitting the product or accessories,please
be sure to remove the non-standard parts and the customized parts in advance to avoid any lost or damage,such as:customized keycap,
accessories from other manufactures,private logo and so on.
5.Varmilo reserves the right of final interpretation and ownership of this manual. Please pay close attention to subsequent product update.
Thank you!
16

引抜工具でキーキャップを取り外し、キーボードを反転させて背面を軽く叩くと、ゴミやホコリが落ちてきます。更に
ブラシでキーボード本体上についたゴミやチリを取り除いて下さい。まだ汚れが取れない場合は、きれいな布にアルコール
を塗布して、綺麗になるまで拭いて下さい。その後風通しの良い場所に置き、乾燥させます。ご使用中はケーブルを頻
繁に抜き差ししたり、引っ張ったり、曲げたりしないで下さい。ケーブル分離式のキーボードの場合、ケーブルが抜けやす
くなる原因となります。
Varmiloの音訳は"アミロ"、エスペラント語の"Via"と"armilo"を組み合わせ、「あなただけの装置」という意味
を持ちます。Varmiloは高品質でありながらお客様一人ひとりにご満足いただける製品をご提供することを目指して
います。また、キーボードという限られたスペースの中でイノベーションを絶えず促し、お客様のデスクトップをカラフルで楽
しくするためのチャレンジを続けています。
——キーボードアーティスト Varmilo
新しいVarmiloのECスイッチメカニカルキーボードは、Varmilo製静電容量メカニカルスイッチを採用し、安定した
内部構造と良い打鍵感を有しています。
はじめに
製品の特長
日常のメンテナンス
17

18

Varmilo ECスイッチの動作
Varmilo ECスイッチの利点
Varmilo静電容量式キースイッチを押すことで電界誘導電極が変
化し、キーボードが静電容量を式（C=Q/V)によって計算するこ
とで、静電容量が十分であればトリガー送信（trigger out）
されます。
物理的な接触をしないということは、疲労することがなく、理論
的には、無限の耐用年数。
スイッチの感触が一貫性をより長く保つことでユーザにとっ
て快適な使用性が実現されます。
メカニカルキーボードの使用感を保ちながら、静電容量
トリガーの原理を採用。
