Varytec Event Par IP65 4in1 14x8W User manual

Event Par IP65 4in1 14x8W,
Event Par IP65 4in1 14x8W WDMX
LED PAR
User manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
25.02.2019, ID: 452127_435626

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety............................................................................................................................................................ 11
3 Features....................................................................................................................................................... 16
4 Installation.................................................................................................................................................. 18
5 Starting up.................................................................................................................................................. 22
6 Connections and controls................................................................................................................... 26
7 Operating.................................................................................................................................................... 32
7.1 Starting the device........................................................................................................................... 32
7.2 Main menu.......................................................................................................................................... 32
7.3 Menu overview................................................................................................................................. 36
7.4 Functions in 4-channel DMX mode........................................................................................... 38
7.5 Functions in 7-channel DMX mode........................................................................................... 38
Table of contents
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 3
LED PAR

7.6 Functions in 9-channel DMX mode........................................................................................... 40
7.7 Remote control................................................................................................................................. 42
8 Technical specications....................................................................................................................... 45
9 Plug and connection assignments.................................................................................................. 48
10 Troubleshooting...................................................................................................................................... 49
11 Cleaning....................................................................................................................................................... 51
12 Protecting the environment.............................................................................................................. 52
Table of contents
4Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 5
LED PAR

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
6Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
Letterings
Displays
General information
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 7
LED PAR

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Instructions
General information
8Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – hot surface.
General information
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 9
LED PAR

Warning signs Type of danger
Warning – dangerous optical radiation.
Warning – suspended load.
Warning – danger zone.
General information
10 Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

2 Safety
This device is intended for use as an electronic lighting eect by means of LED technology. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Extend the life of the device by regular breaks in operation and avoid switching it on and o
frequently. This device is not suitable for continuous use.
Intended use
Safety
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 11
LED PAR

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric
shock/death or re. If in doubt, seek advice from a registered electrician.
Safety
Safety
12 Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
Safety
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 13
LED PAR

WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
WARNING!
Risk of burns
The surface of the device can become very hot during operation.
Do not touch the device with bare hands during operation, and after switching
o wait for at least 15 minutes.
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
Safety
14 Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or re.
Safety
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 15
LED PAR

3 Features
Silent stage spotlight, ideal for use on stages and in noise-sensitive environments.
Special features of the device:
n14 × 4in1-LEDs (RGBW, 8 W each)
nControl via DMX, buttons and display on the unit as well as via remote control (included)
nBuilt-in automatic show programmes
nMaster / Slave operation
nProtection class IP65
nSturdy double bracket for secure attachment to trusses or rm footing on the ground
nRugged die-cast aluminium housing
Varytec Event Par IP65 4in1 14x8W WDMX also:
nBuilt-in wireless solution receiver module (G5) for wireless control
nW-DMX transmitter optionally available (item number 366876)
Features
16 Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

Equipment with protection class IP65 are dust-tight and completely protected against contact
(rst code number). They are also protected against splash water from any angle (second code
digit). That is why this equipment can also be used outdoors. Event technology equipment is
generally only designed for temporary use however (event lighting) and not for permanent
use outdoors.
The specied protection class does not make a statement about the weather resistance of the
equipment (resistance to changing ambient conditions as well as against the eects of sun‐
light and UV rays).
The seals and screw connections of the equipment must be checked regularly to ensure a
fault-free operation. In cases of doubt, consult a specialist workshop in due time.
For technological reasons, the light output of LEDs decreases over their lifetime. This eect
increases with higher operating temperature. You can extend the service life of the illuminants
by providing adequate ventilation and operating the LEDs with the lowest possible brightness.
Information about protection
class IP65
Features
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 17
LED PAR

4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Installation
18 Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX
LED PAR

NOTICE!
Risk of overheating
Always ensure sucient ventilation.
The ambient temperature must not exceed the limits stated in the chapter Tech‐
nical Specications of the User Manual.
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
Installation
Event Par IP65 4in1 14x8W, Event Par IP65 4in1 14x8W WDMX 19
LED PAR

NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
NOTICE!
Possible damage due to moisture
Moisture entering into open connectors (plugs and couplers) of DMX or power
cords can cause short circuits.
Close unused connectors with end caps intended for this purpose
(www.thomann.de).
Installation
