Varytec LED RealBeam 7 RGBW User manual

Manual
LED RealBeam 7 RGBW

Table of content
1. Safety instructions............................................................................................................................ 3
1.1. Instructions for a safe and efficient operation.......................................................................... 3
1.1. Additional Information for safety.............................................................................................. 4
2. Statement......................................................................................................................................... 5
2.1. Product description.................................................................................................................. 5
2.1. Introduction to the product....................................................................................................... 6
2.1.1. Technical Data................................................................................................................. 6
3. Controlling ........................................................................................................................................ 7
3.1. Description of the display ........................................................................................................ 7
3.2. Structure of the menu.............................................................................................................. 7
3.3. DMX chart................................................................................................................................ 8
3.3.1. 9 Channels....................................................................................................................... 8
3.3.2. 12 Channels..................................................................................................................... 8
2 / 12

1. Safety instructions
•This Device is suitable for indoor use only.
•All modifications will void the warranty.
•Repairs have to be carried out by skilled personnel only.
•Only use fuses of the same type and original parts as spare parts.
•Protect the Unit from rain and humidity to avoid fire and electric shocks.
•Make sure to unplug the power supply before opening the housing.
1.1. Instructions for a safe and efficient operation
Be careful with heat and extreme temperature
Only use the device in a place where no extreme temperatures will occur.
Do not keep it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.
Avoid exposing it to direct rays of the sun or near a heating appliance.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with liquid should not be placed on the set.
Avoid placing it on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust. Metall Parts can be cleaned with a wet soft cloth for
stubborn dirt.
If out of work, contact sales agency soon
If any troubles occurs, remove the power plug immediately, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure to hold the plug. When not
using the device for an extended period of time, be sure to disconnect the plug from the receptacle.
IMPORTANT:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not
accept liability for any resulting defects or problems. Make sure the electrical connection is carried out
by qualified personnel. All electrical and mechanical connections have to be carried out according to
the European safety standards.
3 / 12

1.1.Additional Information for safety
Exessive temperature
Ta=40°C
Please do not use the device if the temperature exceeds 40°C/104°F.
Drop safety
To avoid injuries carry the package only by twos. If you install the device the
mounting bracket has the ability to carry the tenfold load of the weight of the
device. Always use a corresponding safety to safe the device additional. While
working at the device the place below has to be vacated
UV protection and lamp explosion
Do not look unprotected directly into the light. The UV radiation is shielded by the
lens and the casing, but without the casing it is possible to cause damages on the
eyes.
Beware of electrical shock
Make sure the electrical connection is carried out by qualified personnel. Before
you plug in the device make sure that the power supply system has the right
voltage. Every device has to be grounded. Unplug the power supply if you want to
change a lamp or you have to open the device. You also have to accomplish this
action if there is a thunderstorm or high humidity.
Fire risk
Make sure that the fuse is in function. It is never allowed to bridge it. If you have to
exchange it only use fuses of the same type.
There must be a distance to lighted things and beam of 0,5m.
It is not allowed to cover fans and air in and outlets.
Make sure that there is a distance between the device and all objects in an area of
0.5m.
Don’t put or mount anything on the lens.
The device has to cool down for 20 minutes before opening.
4 / 12

2. Statement
When we send out the goods, they are well packaged and also at best condition. Every product was
tested before delivery. If you recognize mistakes or damages please contact the delivery agent or the
supplier. Please read this manual faithful. In this manual you can find information about the handling
and the safety regulations of this product. If you disregard this manual we cannot give a warranty for it.
Technical changes, which are for progress, may be possible at any time. They are not mentioned
particularly in this manual, but affixed extra.
2.1.Product description
Thank you for choosing this device. This device is on the current state of technology and has a range
of features and meets the requirements of the DMX512 USITT 1990 standard. This device was
developed for many different purposes e.g. TV studios, discos, nightclubs, bars and concerts.
5 / 12

2.1.Introduction to the product
2.1.1. Technical Data
Power supply
Voltage
110V-240V / 50-60Hz
Light source
Lamp type
LED 4in1
Wattage
105W
Color spectrum
RGBW
Number
7x15W RGBW
Optics
Beam angle
7/13°
Functions
Pan
540°/630°
Tilt
270°
Control
Sound-to-light
Yes
Automatic
Yes
Master-Slave
Yes
DMX
9/12 channels
Artnet
No
RDM
No
Hardware
Protection class
IP44
Skill
indoor
Dimensions (LxBxH)
440 x 340 x 240 mm
Weight
7,55kg
6 / 12

3. Controlling
3.1.Description of the display
By pressing MENU you can get into the menu. You can reach the desired point in the menu by hitting
UP/DOWN. Confirm with ENTER. You can change the settings with the UP/DOWN buttons, too. Store
your setting with ENTER.
3.2.Structure of the menu
Main menu
Submenu 1
Settings
Function
DMX Adress
1-512
Setting the DMX address
System Reset
Reset
Firmware Version
X.XXX
Software version
Fixture Time
Work Time XX
H Operating hours
White Balance
Red
000-255
Dimmer red LEDs
Blue
000-255
Dimmer blue LEDs
Green
000-255
Dimmer green LEDs
Auto Test
Red Test
Test red LEDs
Green Test
Test green LEDs
Blue Test
Test blue LEDs
White Test
Test white LEDs
All Test
Test all LEDs
Tilt Inverse
Yes
Tilt Scan inverse
No
Tilt Scan normal
Pan Inverse
Yes
Pan Scan inverse
No
Pan Scan normal
Pan Angle
540°
Angle 540°
630°
Angle 630°
Backlight LCD
On
Display stays on
Off
Display powers down after 30s
Show Mode
Auto run
Automatic program
Sound
Sound-to-light
Slave Mode
Master
The device acts as Master.
Slave
The device acts as Slave.
Channel
9Ch
DMX mode with 9 channels.
12Ch
DMX mode with 12 channels.
7 / 12

3.3.DMX chart
3.3.1. 9 Channels
Channel
Value
from Value to Description
1
Pan
0
255
Pan movement 0-540°
2
Tilt
0
255
Tilt movement 0-180°
3
Pan fine
0
255
Fine Pan movement
4
Tilt fine
0
255
Fine Tilt movement
5 Dimmer/
Strobe
0
200
Dimmer
201
247
Strobe slow-fast
248
255
Dimmer
6
Red
0
255
Dimmer red LEDs
7
Green
0
255
Dimmer green LEDs
8
Blue
0
255
Dimmer blue LEDs
9
White
0
255
Dimmer white LEDs
3.3.2. 12 Channels
Channel
Value
from Value to Function
1
Dimmer
0
255
Dimmer 0-100%
2 Macro Color
0
9
No function
10
14
Red
15
19
Green
20
24
Blue
25
29
Macro color 1
30
34
Macro color 2
35
38
Macro color 3
39
43
Macro color 4
44
48
Macro color 5
49
53
Macro color 6
54
58
Macro color 7
59
63
Macro color 8
64
67
Macro color 9
68
82
Macro color 10
83
87
Macro color 11
88
91
Macro color 12
92
96
Macro color 13
97
101
Macro color 14
102
106
Macro color 15
107
116
Macro color 16
117
120
Macro color 17
121
130
Macro color 18
8 / 12

131
135
Macro color 19
136
140
Macro color 20
141
145
Macro color 21
146
154
Macro color 22
155
159
Macro color 23
160
164
Macro color 24
165
169
Macro color 25
170
173
Macro color 26
174
178
Macro color 27
179
183
Macro color 28
184
188
Macro color 29
189
193
Macro color 30
194
198
Macro color 31
199
202
Macro color 32
203
207
Macro color 33
208
212
Macro color 34
213
217
Macro color 35
218
222
Macro color 36
223
227
Macro color 37
228
231
Macro color 38
232
236
Macro color 39
237
241
Macro color 40
242
246
Macro color 41
247
251
Macro color 42
252
255
Macro color 43
3
Red
0
255
Dimmer red LEDs
4
Green
0
255
Dimmer green LEDs
5
Blue
0
255
Dimmer blue LEDs
6
White
0
255
Dimmer white LEDs
7 Strobe
0
9
No function
10
255
Strobe slow-fast
8
Pan
0
255
Pan movement 0-630°
9
Pan fine
0
255
Fine Pan movement
10
Tilt
0
255
Tilt movement0-270°
11
Tilt fine
0
255
Fine Tilt movement
12 Function
0
127
No function
128
255
Auto & Master
9 / 12

10 / 12

11 / 12

Importer:
B & K Braun GmbH
Industriestraße 2
D-76307 Karlsbad
www.bkbraun.com
[e-mail]
