Varytec Led accu penta User manual

Manual

LED Accu Penta 9x12W

RGBWAU

2 / 24

Table of contents

1.Safety instructions ............................................................................................................................ 3

1.1.FOR SAFE AND EFFICIENT OPERATION ............................................................................ 3

1.2.Additional Information for safety.............................................................................................. 4

2.Introduction....................................................................................................................................... 5

2.1.Statement ................................................................................................................................ 5

2.2.Product description.................................................................................................................. 5

2.3.Features................................................................................................................................... 5

2.4.Charging and power instruction............................................................................................... 6

3.Packaging......................................................................................................................................... 6

4.Description of the display section..................................................................................................... 7

4.1.Structure of the menu .............................................................................................................. 7

5.DMX Chart........................................................................................................................................ 8

5.1.6 channel mode ....................................................................................................................... 8

5.2.11 channel mode ..................................................................................................................... 8

5.3.15 channel mode ................................................................................................................... 11

5.4.18 channel mode ................................................................................................................... 12

6.IR remote control............................................................................................................................ 15

6.1.Description............................................................................................................................. 15

6.2.Master/Slave.......................................................................................................................... 17

7.Connecting ..................................................................................................................................... 18

7.1.XLR cable .............................................................................................................................. 18

7.2.The Conversion between 3 pin and 5 pin XLR...................................................................... 18

7.3.Example................................................................................................................................. 19

8.Trouble shooting............................................................................................................................. 20

9.Measurements................................................................................................................................ 21

10.Technical Data........................................................................................................................... 22

3 / 24

1. Safety instructions

This device is suitable for indoor use (not outdoors) only.

All modifications to the device will void the warranty.

Repairs are to carry out by skilled personnel only.

Use only fuses of the same type and original parts as spare parts.

Protect the unit from rain and humidity to avoid fire and electric shocks.

Make sure to unplug the power supply before opening the housing.

1.1.FOR SAFE AND EFFICIENT OPERATION

Be careful with heat and extreme temperature

Avoid exposing it to direct rays of the sun or near a heating appliance.

Not put it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.

Keep away from humidity, water and dust

Do not place the set in a location with high humidity or lots of dust.

Containers with water should not be placed on the set.

Keep away from sources of hum and noise

Such as transformer motor, tuner, TV set and amplifier.

To avoid placing on un-stable location

Select a level and stable location to avoid vibration.

Do not use chemicals or volatile liquids for cleaning

Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.

If out of work, contact sales agency immediately

Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,

do not open the cabinet by yourself, it might result a danger of electric shock.

Take care with the power cable

Never pull the power cable to remove the plug from the receptacle, be sure to hold the plug.

When not using the device for an extended period of time, be sure to disconnect the plug

from the receptacle.

4 / 24

Important: Damages caused by the disregard of this user manual are not subject to

warranty. The dealer will not accept liability for any resulting defects or problems. Make sure

the electrical connection is carried out by qualified personnel. All electrical and mechanical

connections have to be carried out according to the European safety standards.

1.2.Additional Information for safety

Exessive temperature

Ta=40°C

Please do not use the device if the temperature exceeds 40°C/104°F.

Drop safety

To avoid injuries carry the package only by twos. If you install the device the

mounting bracket has the ability to carry the tenfold load of the weight of the

device. Always use a corresponding safety to safe the device additional. While

working at the device the place below has to be vacated

Beware of electrical shock

Make sure the electrical connection is carried out by qualified personnel. Before

you plug in the device make sure that the power supply system has the right

voltage and also a crowbar. Every device has to be grounded. Unplug the power

supply if you want to change a lamp or you have to open the device. You also have

to accomplish this action if there is a thunderstorm or high humidity.

Fire risk

Make sure that the fuse functioned. It is never allowed to bridge it. If you have to

exchange it only use fuses of the same type.

It is not allowed cover fans and air in and outlets.

Make sure that there is a distance between the device and all objects in an area of

0.5m.

Don’t put or mount anything on the lens.

The device has to cool down for 20 minutes before opening.

5 / 24

2. Introduction

2.1.Statement

Thank you for purchasing the LED Accu Penta. Please read these instructions carefully before begin

and operate the fixtures according to these instructions to avoid any possible damages and accidents

causes by misusage.

2.2.Product description

This product has a light body and fashion design

It uses high power

6-in-1

LED, which means

each LED is made of R, G, B, A, W

，

V LED chips. Long life span, low power consumption, good

color mixing effect and high brightness are the most prominent features. Each kind of LED can be

independently dimmed. The built-in program includes dimming, strobe, gradual change, fading and so

on.

It uses lithium battery power supply, stable capability and easy to carry.

International standard

DMX 512 signal is requested.

2.3.Features



High quality LED: low consumption, high brightness, stable

capability and long life

Each color of LED with 32-bit, 16666 grades dimming. 600Hz dimming frequency, take

pictures without flicker

DMX512 Controller，4 button set DMX ID address with LCD display

Dim 0%-100%, Strobe、gradual change、jumping change and etc

DMX512 Controller，2 layers LEDs, under layer: 3 pcs. LEDs, upper layer: 6 pcs. LEDs, could

be controlled alone between layers

Auto run/master slave/interconnected multi-machine control

Optional: Wireless DMX control

Electric quantity display



Lithium battery power supply, stable capability and easy to carry



IR remote control function

Power charging indicator

Output mode optional

Lens degree: 25º、45º optional

Output Mode：H (100%), M (75%), S (50%)

DMX Controller channel optional

IP20

6 / 24

2.4.Charging and power instruction

When charging, CHARGE LED red. Full power LED green.

LCD display electric quantity, please off fixture and battery charging when display no power. It is not

good at usage life of battery, please avoid to using fixture when charging. And avoid overcharge,

charging time is about 4 hours. Total 5 bars for power display. One bar = 20% power.

3. Packaging

To every device belong the following accessories.

LED Accu Penta 1 pcs.

DMX signal cable 1 pcs.

Power-in cable 1 pcs.

User manual 1 pcs.

7 / 24

4. Description of the display section

MENU： Access the menu

UP：Menu selection or parameter increments

DOWN：Menu selection or parameters decrease

ENTER：Confirm the current menu option

4.1.Structure of the menu

MenuFunctionsetFunctiondescription

Addr001‐512SettingtheDMXaddress

CHnd6CHDMXmodewith6DMXchannels

11CHDMXmodewith11DMXchannels

15CHDMXmodewith15DMXchannels

18CHDMXmodewith18DMXchannels

AUTO00‐64Automaticprograms

Speed00‐15Adjuststhespeedfortheautomaticprograms.

00=fast,15=slow

Fade00‐15Adjuststhegradualchangingspeed

00=fast,15=slow

Strobe00‐15Adjuststhestrobespeed

00=fast,15=slow

ManualRED000‐255Dimmerred

GREEN000‐255Dimmergreen

BLUE000‐255Dimmerblue

AMBER000‐255Dimmeramber

WHITE000‐255Dimmerwhite

UV000‐255DimmerUV

8 / 24

Sound…Sound‐to‐Light

Dimmer0‐4AdjuststheDMXdimmermode

RF_ID1‐7WirelessIDset

IRMODE  IRreceivemode

OUTMODHOutputmode100%

MOutputmode75%

SOutputmode50%

Press MENU to reach the first menu and use UP/DOWN to get to the submenu. To open the submenu

you have to press ENTER, here you can reach other menu items with UP/DOWN, confirm with

ENTER. Press MENU to store your settings.

5. DMX Chart

5.1.6 channel mode

ChannelValuefromValuetoFunction

1000255Dimmerred0‐100%

2000255Dimmergreen0‐100%

3000255Dimmerblue0‐100%

4000255Dimmeramber0‐100%

5000255Dimmerwhite0‐100%

6000255DimmerUV0‐100%

5.2.11 channel mode

ChannelValuefromValuetoFunction

1000255Dimmer0‐100%

2000255Dimmerred0‐100%

3000255Dimmergreen0‐100%

4000255Dimmerblue0‐100%

5000255Dimmeramber0‐100%

6000255Dimmerwhite0‐100%

7000255DimmerUV0‐100%

9 / 24

8

000010Strobeoff

011255Strobeslow‐fast

9

000015Generaldimming

016018Red

019021Green

022024Blue

025027Amber

028030White

031033UV

034036Red+Green

037039Red+Blue

040042Red+Amber

043045Red+White

046048Red+UV

049051Green+Blue

052054Green+Amber

055057Green+White

058060Green+UV

061063Blue+Amber

064066Blue+White

067069Blue+UV

070072Amber+White

073075Amber+UV

076078White+UV

079081Red+Green+Blue

082084Red+Green+Amber

085087Red+Green+White

088090Red+Green+UV

091093Red+Blue+Amber

094096Red+Blue+White

097099Red+Blue+UV

10 / 24

100102Red+Amber+White

103105Red+Amber+UV

106108Red+White+UV

109111Green+Blue+Amber

112114Green+Blue+White

115117Green+Blue+UV

118120Green+Amber+White

121123Green+Amber+UV

124126Green+white+UV

127129Blue+Amber+White

130132Blue+Amber+UV

133135Blue+White+UV

136138Amber+White+UV

139141Red+Green+Blue+Amber

142144Red+Green+Blue+White

145147Red+Green+Blue+UV

148150Red+Green+Amber+White

151153Red+Green+Amber+UV

154156Red+Green+White+UV

157159Red+Blue+Amber+White

160162Red+Blue+Amber+UV

163165Red+Blue+White+UV

166168Red+Amber+White+UV

169171Green+Blue+Amber+White

172174Green+Blue+Amber+UV

175177Green+Blue+White+UV

178180Green+Amber+WhiteUV

181183Blue+Amber+White+UV

184186Red+Green+Blue+Amber+White

187189Red+Green+Blue+Amber+UV

190192Red+Green+Blue+White+UV

11 / 24

193195Red+Green+Amber+White+UV

196198Red+Blue+Amber+White+UV

199201Green+Blue+Amber+White+UV

202204Red+Green+Blue+Amber+White+UV

205229Autorun1slow‐fast

230255Autorun2slow‐fast

10

000015Nofunction

016255Gradualchangingmodeslow‐fast

11

000005SetbyLEDdisplayDimmer0‐4

006055Dimmer0

056105Dimmer1

106155Dimmer2

156205Dimmer3

206255Dimmer4

5.3.15 channel mode

ChannelValuefromValuetoFunction

1000255DimmerRed1

2000255DimmerGreen1

3000255DimmerBlue1

4000255DimmerAmber1

5000255DimmerWhite1

6000255DimmerUV1

7000255DimmerRed2

8000255DimmerGreen2

9000255DimmerBlue2

10000255DimmerAmber2

11000255DimmerWhite2

12000255DimmerUV2

13

000010Strobeoff(firstlayer)

011255Strobespeedslow‐fast(firstlayer)

12 / 24

14

000010Strobeoff(secondlayer)

011255Strobespeedslow‐fast(secondlayer)

15

000005SetbyLEDdisplaydimmer0‐4

006055Dimmer0

056105Dimmer1

106155Dimmer2

156205Dimmer3

206255Dimmer4

5.4.18 channel mode

ChannelValuefromValuetoFunction

1000255Dimmer0‐100%

2000255DimmerRed1

3000255DimmerGreen1

4000255DimmerBlue1

5000255DimmerAmber1

6000255DimmerWhite1

7000255DimmerUV1

8000255DimmerRed2

9000255DimmerGreen2

10000255DimmerBlue2

11000255DimmerAmber2

12000255DimmerWhite2

13000255DimmerUV2

14

000010Strobeoff(firstlayer)

011255Strobespeedslow‐fast(firstlayer)

15

000010Strobeoff(secondlayer)

011255Strobespeedslow‐fast(secondlayer)

16

000015Generaldimming

016018Red

019021Green

13 / 24

022024Blue

025027Amber

028030White

031033UV

034036Red+Green

037039Red+Blue

040042Red+Amber

043045Red+White

046048Red+UV

049051Green+Blue

052054Green+Amber

055057Green+White

058060Green+UV

061063Blue+Amber

064066Blue+White

067069Blue+UV

070072Amber+White

073075Amber+UV

076078White+UV

079081Red+Green+Blue

082084Red+Green+Amber

085087Red+Green+White

088090Red+Green+UV

091093Red+Blue+Amber

094096Red+Blue+White

097099Red+Blue+UV

100102Red+Amber+White

103105Red+Amber+UV

106108Red+White+UV

109111Green+Blue+Amber

112114Green+Blue+White

14 / 24

115117Green+Blue+UV

118120Green+Amber+White

121123Green+Amber+UV

124126Green+white+UV

127129Blue+Amber+White

130132Blue+Amber+UV

133135Blue+White+UV

136138Amber+White+UV

139141Red+Green+Blue+Amber

142144Red+Green+Blue+White

145147Red+Green+Blue+UV

148150Red+Green+Amber+White

151153Red+Green+Amber+UV

154156Red+Green+White+UV

157159Red+Blue+Amber+White

160162Red+Blue+Amber+UV

163165Red+Blue+White+UV

166168Red+Amber+White+UV

169171Green+Blue+Amber+White

172174Green+Blue+Amber+UV

175177Green+Blue+White+UV

178180Green+Amber+WhiteUV

181183Blue+Amber+White+UV

184186Red+Green+Blue+Amber+White

187189Red+Green+Blue+Amber+UV

190192Red+Green+Blue+White+UV

193195Red+Green+Amber+White+UV

196198Red+Blue+Amber+White+UV

199201Green+Blue+Amber+White+UV

202204Red+Green+Blue+Amber+White+UV

205229Autorun1slow‐fast

15 / 24

230255Autorun2slow‐fast

17

000015Nofunction

016255Gradualchangingmodeslow‐fast

18

000005SetbyLEDdisplayDimmer0‐4

006055Dimmer0

056105Dimmer1

106155Dimmer2

156205Dimmer3

206255Dimmer4

6. IR remote control

6.1.Description

If you want to use the IR remote the device must be set for IR remote control.

16 / 24



Pressthebutton;fixtureoff,readymode



Pressthebutton,autorunmode,andpreSPEED

couldadjusttheautorunspeed



Pressthebutton,soundactivated



Pressthebutton,strobemode,andpressSPEED

couldadjustthestrobespeed



Pressthebutton,builtinprogrammode,could

adjustbuiltinprogrampattern



Pressthebutton,DMXcontrolmode



Pressthebutton,adjustautorunspeedand

strobespeed



Pressthebutton,slavemode



Pressthebutton,setDMXaddresscode,

press”+”and“‐“toadjust,pressENTERtostore;

thenpress”D”,DMXreceivingmode,could

receiveDMXsignal



Pressthebutton,couldchangeDMXaddressand

manualdimmingvalue



Pressthebutton,startLCDbacklight,autooff20

secondslater



Pressthebutton,couldchangeDMXaddressand

manualdimmingvalue



Pressthebuttonand“+”“‐“,couldadjustred
