Vax h85-ga-b10 Installation instructions

H85-GA-B10
H85-GA-P18
HCGRV1B1
CORDLESS CONVENIENCE FOR
QUICK EVERYDAY CLEAN UPS
LET’S GET STARTED.
Gator
HANDHELD

Let’s talk safety
Basic
safety
precautions
This handheld is intended for household use only and NOT for
commercial or industrial use.
• This handheld is for indoor use only.
• For dry debris only - not to be used on wet surfaces.
• Keep ngers, hair and loose clothing from moving parts
and openings whilst using the handheld.
Don’ts
• Don’t charge the handheld outdoors
• Don’t use this handheld if it has been dropped, damaged,
immersed in water or left outdoors.
• Don’t run over the charger cord or use handheld if the charger
cord or plug is damaged.
• Don’t handle the plug or use the handheld with wet hands.
• Don’t throw the handheld into re or expose to high
temperatures, as the handheld contains a rechargeable nickel
cadmium battery which may cause damage or burst.
• Don’t pull or carry this handheld by the charger cord.
Do’s
• Always make sure the lter and dirt container are tted correctly
before using your handheld.
• Always turn o the handheld and disconnect the charger before
carrying out any maintenance.
• Turn o all controls on the handheld before disconnecting
or connecting the charger.
• Take extra care when cleaning on the stairs.
• Always replace the fuse in the plug with a 13amp fuse.

• Only Vax recommend charger, tools and accessories should be used with
this handheld.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Don’t use the charger cord as a handle, pull the charger cord around corners
or sharp edges, or close a door over the charger cord. Don’t unplug handheld
by pulling on the charger cord.
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your handheld.
• Don’t use the handheld charger with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Always protect the charger cable from heated surfaces or near open ames.
• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it can
be a trip hazard.
• Always carry the handheld by the handle.
• Store your handheld in a cool, dry area.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.

Thank you for buying this Gator.
Taking care of small cleaning tasks
The Gator range is designed to make cleaning as quick and convenient as possible and this user
guide will help you get the most out of your machine.
The Gator range is perfect for small cleaning tasks on surfaces and upholstery.
Taking care of your Gator
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you need to tackle those small jobs.
We’re here if you need us
Instead of taking your machine back to the shop,
simply visit our online support:
vax.co.uk/support
Still need to get in touch?
Our UK based Customer Care Team are here to support you.
For help with assembly, operational or performance problems, or buying and tting new accessories,
you can nd all our contact details at vax.co.uk/contact
This user guide can be found online at: vax.co.uk/support

Gator 10.8V
Filter
Included with
your machine
Motorised Tool
Charger
Name Gator Gator
10.8V 18V
Weight 1.24kg 1.8kg
Capacity 0.3L 0.3L
Cleaning
Time 15 mins 20 mins
Charging
Time 12 hrs 12 hrs
Technical Specication
Subject to technical change without notice.
Accessories & Consumables
Gator 18V
Handle
On/O switch
Charging indicator
(red LED)
Dirt container
release button
Retractable crevice tool
Filter release button
Gator 10.8V
Charger
1-5-131865-00
Pre-motor Filter (Type 67)
1-7-131574-00
Gator 18v
Charger
1-5-132794-00
Pre-motor Filter (Type 67)
1-7-131574-00
Motorised Turbohead
1-2-132797-00
To purchase consumables and accessories, please visit vax.co.uk

Plug charger into the mains and insert lead into back
of machine. Initial charging time is 24 hours.
Getting started Using your machine
The charging light will illuminate continuously
whilst the charger is connected.
On/o switch: 0 O I On
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USEPLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Failure to initially charge
the battery for 24 hours,
may result in poor
battery performance.
CAUTION
NOTE: The power switch must be in the o position to charge the battery. Only use the charger provided with your
handheld to charge the battery.
CAUTION: The battery used in this device may present a risk of re or chemical burn if mistreated. Do not
disassemble or heat above manufacturer’s maximum temperature limit (60°C/140°F) or incinerate. Use of another
battery may present a risk of re or explosion. Dispose of used battery promptly. Keep away from children. Do not
disassemble and do not dispose of in a re. Do not attempt to disassemble the battery or remove any component
projecting from the battery terminals. The battery and charger have no user serviceable parts. Fire or injury may
result. Prior to disposal, protect exposed terminals with heavy insulating tape to prevent shorting. The battery is to
be disposed of safely at your local battery recycling centre.
Do not attempt to recharge non-rechargeable batteries. The battery must be removed from the appliance before it
is scrapped. The appliance must be disconnected from the charger/supply mains before use and when removing
or installing the battery into the machine. In case of battery leakages avoid any contact with the skin.

Getting started Using your machine
Gently pull the crevice tool. Push the crevice tool to retract.
To empty the dirt container, press both buttons either side of the dirt container to release lid.
Empty dirt and
debris over a bin.
TIP
We recommend to
empty the dirt container
after each use.

Taking care of your machine
Press the lter removal button and pull dirt container
from machine.
Whilst holding the dirt container over a bin, grasp the
lter gently and pull out.
Shake any excess dirt or debris from the dirt container. Tap lter against bin.
tap
Wash the lter under running water and leave to
fully dry for a least 24 hours before replacing.
24hr
40oC max
!
!
!
!
TIP
Do not use the
handheld without
the lter in place.

Taking care of your machine
Gently push lter back into the dirt container. To re-attach the dirt container, align bottom of the dirt
container and push until it locks into place.
To remove the Motorised Tool (18v Gator only) for cleaning
or when not in use, gently twist down and pull to detach.
To attach the Motorised Tool (18v Gator only),
align with dirt container and push until it locks in place.
TIP
Always unplug the
charging lead from the
machine before carrying
out any maintenance.

• Battery may not be fully charged. If using the handheld for
the rst time the initial charge should be 24 hours.
The charging light will illuminate continuously when charger
is connected.
• The nozzle or crevice tool may be blocked, check and clear
any blockage. The lter may be clogged, clean the lter.
Go to ‘Taking care of your machine’. The battery is getting
weak, let the battery run until it stops and recharge.
The dirt container may be full, empty the dirt container.
Go to ‘Using your machine’.
• The charger may not be inserted correctly.
SolutionProblem
What to do if it goes wrong
Why does the handheld
have no power?
Why won’t the
handheld pick up?
Why won’t the battery
recharge?
Getting in touch

Getting in touch
†Registration required. Terms and conditions apply, see vax.co.uk for details.

GET IN TOUCH
[email protected] vax.co.uk
EU Statement of Compliance:Manufacturer/EU importer: Vax Limited, hereby on our own responsibility, declare that the
H85-GA-B10, H85-GA-P18 and HCGRV1B1 are manufactured in compliance with the following Directives: Safety: 2014/35/EU
Low Voltage Directive. EMC: 2014/30/EU Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
© 2018 Vax Limited. All rights reserved. The VAX trade mark and Vax lozenge is the property of Techtronic Floor Care
Technology Ltd and is registered in the EU and may be pending or registered in other countries.
Vax Ltd, Pointon Way, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 OLW, UK
