Vax C85-TO-Be User manual

vax.co.uk
C85-TO-Be/C85-TO-Pe
C85-TO series
Let’s get started

Let’s talk safety
This vacuum cleaner is intended for household use only and
NOT for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces and
keep the area you’re cleaning well lit.
• Keep ngers, hair and loose clothing away from moving parts
and openings whilst using the vacuum cleaner.
• Don’t use this vacuum cleaner if it has been dropped, damaged
or left outdoors or the lters not in their original place.
• Don’t run over the power cord or use vacuum cleaner if the
power cord or plug is damaged. Please contact our Customer
Care Line on: 0330 026 8455 (Mon-Fri 8.30am-6-30pm Sat
9.00am-5.00pm).
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
• Don’t use the power cord as a handle, pull the power cord
around corners, sharp edges or close a door over the
power cord.
• Don’t unplug vacuum cleaner by pulling on the power cord.
• Don’t lift or carry the vacuum cleaner by the dirt
container handle.
• Turn o all controls on the vacuum cleaner before
disconnecting or connecting the power cord.
• Always make sure both the pre-motor/post-motor lters are in
place before use.
• Always switch o the vacuum cleaner before disconnecting or
connecting the hose and accessories.
• Keep all openings clear and free from debris as this may aect
the airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse.
• Always protect the power cable from heated surfaces and
open ames.
Basic
safety
precautions
Don’ts
Do’s

• This vacuum cleaner can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the vacuum cleaner in a safe way and understand the
hazards involved. Children shall not play with the vacuum cleaner. Cleaning
and user maintenance shall not be made by children without supervision.
• Only Vax recommend tools and accessories should be used with this
vacuum cleaner.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,
kerosene etc.) or use the vacuum cleaner in an area with explosive vapours
or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws
or coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result
in damage or injury to the user. The correct voltage is listed on the
ratings label.
• Take extra care when positioning and using the vacuum cleaner on the stairs.
• Use only CE approved 13amp extension cords, non-approved extension cords
may overheat. Care should be taken to arrange the extension cord as it can be
a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned as
per user guide instructions ensure they are thoroughly dry before
storing away.
Please keep instructions for further use.

Thank you for buying this C85-TO series.
Taking care of your carpets and hard oors
The C85-TO series is designed to make vacuuming carpets and hard oors regularly, as eective
and ecient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer.
You’ve chosen carpets and hard oors for your home for a reason and Vax will help you take
good care of them.
Taking care of your C85-TO series
Also inside this guide are instructions on maintaining your new machine, so that it’s always ready
when you are to tackle your carpets and hard oors.
Let us know what you think @VaxUK
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8.30am to 6.30pm, Saturday 9.00am to 5.00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd, Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwitch, WR9 OLW, UK
This User Guide can be found online at: vax.co.uk/support

Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Getting in touch
C85-TO-Be
Included with
your machine
C85-TO-Pe
+
Initial Setup for normal operation
1. Use the base accessories.
a. Shortest hose
b. Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All Bleeds must be closed.
5. Floor heads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floor heads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation turned OFF for hard oor cleaning.
Accessory hose and handle
2 pc extension tube
Combination oorhead
Crevice tool
Upholstery tool
Post-motor lter
Pre-motor lter
Frame Foam
TurboTool
Tool connector

Getting to know your machine
Name C85-TO-Be/C85-TO-Pe
Voltage 220-240~50Hz
Wattage 700watts
Cord Length 5m
Weight 4.9kg
Technical Specication
Subject to technical change without notice.
Filter Kit (Type 109)
1-1-134393-00
TurboTool (Type 6)
1-1-134419-00
Tool Connector (Type 1)
1-1-133838-00
Crevice Tool (Type 10)
1-9-128020-00
Combination Floor Tool (Type 6)
1-1-134330-00
Upholstery Tool (Type 4)
1-9-128019-00
Accessories & Consumables
*To purchase consumables and accessories, please visit vax.co.uk
On/O button
Post-motor
lter cover
Floorhead
parking slot
Cord rewind
button
Dirt container
release button
Dirt container handle
Shroud
Carry handle
Post-motor lter
release button
Hose entry point

Getting started
Assembling your upright
Press both buttons at end
of hose and insert into
hose entry point.
Insert hose grip into
extension tube.
Insert the other end of the
telescopic tube into the
oorhead.
Before you begin cleaning
IMPORTANT: The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does
overheat the thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner
o and unplug. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum
cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters to fully dry
before putting back into the machine).
For best cleaning results clean the pre-motor lter every time the dirt container is emptied and replace
the post-motor lter every 12 months.
If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
CAUTION
Always switch o the vacuum
cleaner before connecting
or disconnecting the hose
/attachments, or removing and
emptying the dirt container.

TIP
Brushes on the oorhead
should be visible when using
on hard oors.
Unwind the power cord.
Do not pull further than the
yellow marker.
Plug into mains and push
the On/O button to turn
your machine on.
IMPORTANT: The base of the vacuum cleaner should always be positioned at on the oor when starting and in use.
CAUTION: When unwinding the power cord do not pull further than the yellow marker.
Using your machine
For use on carpets, click
rocker switch forward. For
use on hard oors click rocker
switch back.
Slide vent cover on hose grip open
to reduce suction if required.
Lower brushes for hard oors.Raise brushes for carpets.

Using your machine
Using your machine
Emptying and cleaning the dirt container
Using your tools
Taking care of your machine
Always use the carry handle to lift and
carry the machine. Do not use the dirt
container handle.
Choose an accessory and
push onto the telescopic
extension tube or hose.
Press dirt container
release button and lift
to remove.
Press the button at the
top of the dirt container
to release lter.
Hold dirt container over
a bin allowing dirt/debris
to fall out.
Replace lid, making sure
central protruding (part A) is
over outer protruding piece
(part B) to complete the hinge.
Attach accessory to hose end. If required use tool connector.
Carrying your machine
IMPORTANT: Unplug and switch o vacuum cleaner before performing maintenance or troubleshooting checks.
A
B

Don’t over ll the dirt container
to avoid blocking the air ow
through the vacuum cleaner.
CAUTION
Cleaning the shroud
Taking care of your machine
Let’s talk technical
Rinse both dirt container and shroud under water
(Max 40°C). Leave to dry for 24 hours or until fully
dry before placing back in the machine.
IMPORTANT: The shroud cannot be removed from the dirt container.
Cleaning the pre-motor lter
Press dirt container release
button and lift to remove.
Leave to dry for 24
hours or until fully dry
before placing back in
the machine.
Line up the pre-motor lter frame with dirt container,
push into place.
If the pre-motor lter is not correctly tted the pre-
motor latch will prevent the dirt container from locking
into place.
Tap the lter frame and
foam over a bin to remove
any dirt/debris.
Remove the pre-motor
lter together with frame
and foam.
Rinse both the frame
and foam under water
(Max 40°C).
IMPORTANT: Do not wash the pre-motor lter in the washing machine or dishwasher.
For best cleaning results clean the pre-motor lter every time the dirt container is emptied.

Taking care of your machine
Let’s talk technical
Press button on post-
motor lter cover pull
to remove.
For best cleaning results,
replace the post-motor lter every 12 months.
Check the post-motor
lter for discolouration.
Pull tabs on post-motor
lter to remove.
Press cord rewind button
to retract cord into
vacuum cleaner.
Place oorhead into
parking slot located at rear
of vacuum cleaner
for storage and carrying.
Post-motor lter maintenance
Storing your vacuum cleaner
Do not wash the post-motor lter.
CAUTION
!
40˚C
MAX
24hr
IMPORTANT: The exhaust lter is designed to oer long life with no maintenance. The lter should be checked
periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the lter as
this will damage the delicate lter media.

Let’s talk technical
Accessories
IMPORTANT: Remove accessory from hose or telescopic extension tube before performing maintenance or
trouble shooting checks.
Removing blockages from the TurboTool*
Tabs
Slide the locking ring
to remove.
Lift and separate
the housing.
Using a pair of scissors,
remove any threads
or hair caught around
the brushbar.
Line up the tabs on front of
housing and push together
to ret. Slide locking ring
into groove to secure.
34
1
2
34
1
23
4
12
3
4
12
TIP
To test for a blockage in hose,
drop a small ball of paper into the
hose. The paper will drop through
if the hose is clear.
Remove the hose from the vacuum
cleaner and telescopic extension tube.
Remove any blockage by inserting wire
coat hanger in to hose.
Removing a blockage from the hose

Accessories
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
Pro Cleaning Kit (Type 2)
1-1-133326-00
All our best tools all in one kit that makes cleaning
your home quicker, easier and with even better results.
We’ve taken care of cleaning all of the hard to reach
areas such as on top of cupboards and in between
blinds to the dust that collates behind and
within the radiator.
TurboTool (Type 6)
1-1-134419-00
Use the TurboTool for vacuuming your stairs, upholstery
and car interiors. It’s great for picking up stubborn pet hair.
Fur ‘n’ Flu Tool
1-1-131392-00
Specically designed to remove extra stubborn
pet hair from upholstery, furniture and carpets.

• Check the ‘This pack contains’ panel on the box to make sure
the part is included with your vacuum cleaner.
• The dirt container may not be correctly tted, remove the dirt container
from the vacuum cleaner and check pre-motor lter and dirt container
are assembled correctly, ret ensuring it’s locked into place. Go to
‘Taking care of your machine’.
• The lter may be clogged, clean the lter. Go to ‘Taking care of your
machine’.
• The dirt container may be blocked, empty the dirt container. Go to
‘Taking care of your machine’.
• There may be a blockage in the hose/tube. Disconnect from the vacuum
cleaner and carefully remove any blockages. Go to ‘Let’s talk technical’.
• The lters may be clogged, clean the lter.
Go to ‘Taking care of your machine’.
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace with
a 13amp fuse.
• The motor thermostat may have tripped. If this has happened, unplug
the vacuum cleaner. Remove and empty the dirt container and check
the hose for blockages. Clean the lters and allow the vacuum cleaner
to cool for approximately 1 hour (if you have washed the lters you will
need to wait 24 hours for the lters to fully dry before putting them back
into the vacuum cleaner).
SolutionProblem
CAUTION: To reduce the risk of personal injury, unplug the vacuum cleaner before performing maintenance
/troubleshooting checks.
What to do if it goes wrong
Getting in touch
Is there an accessory
missing?
Why won’t the vacuum
cleaner pick up?
Why does my vacuum
cleaner have no power?
Why is dust escaping
from the vacuum?

Getting in touch
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the vacuum cleaner
before calling.

Vax Ltd., 5th Floor 2 Colmore Square, 38 Colmore Circus, Queensway, Birmingham, B4 6BN, UK
email: inf[email protected] website: vax.co.uk
Version 1.0
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility,
declare that the C85-TO-(Be/Pe) series is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive. EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
@VaxUK
© 2014 All rights reserved. VAX®, VAX Lozenge are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
