Vax ONEPWR Spotless Go CLCW-MSKS User manual

CLCW-MSKS
CLCW-MSBS
USER GUIDE

SAFETY GUIDE 2
support.vax.co.uk
This machine is intended for
household use only and NOT for
commercial or industrial use.
PLEASE KEEP INSTRUCTIONS FOR
FURTHER USE AND USE ONLY AS
INSTRUCTED IN THIS GUIDE.
DON’TS
• Don’t leave the charger plugged in
when unattended.
• Don’t use the machine if it is faulty
or has been dropped, damaged or
left outdoors.
• Don’t use the machine to pick up any
ammable or combustible materials
(lighter uid, petrol, kerosene etc.)
or use the machine in an area with
explosive vapours or liquid.
• Don’t use the machine to pick up hot
coals, cigarette butts, matches or
smoking hot burning items or use in
an area where there may be harmful
uids (chlorine, bleach and ammonia
drain cleaner).
• Don’t handle the charger, battery or
use the machine with wet hands.
• Don’t unplug the charger by pulling
on the power cord.
• Don’t use the charger if the charger
cord or plug is damaged.
• Don’t attempt to remove blockages
with sharp objects as this may cause
damage to the machine.
• Don’t use the machine with the
incorrect battery or charger as this
may result in damage or injury to the
user. The correct battery charger
information is listed on the battery
pack ratings label.
• Don’t charge the battery outdoors, or
leave the charger connected to the
mains when not in use.
• Don’t use the machine with a
damaged battery. If the battery is
damaged contact 08000 927737.
• Don’t carry the machine while it’s
switched on.
DO’S
• Only VAX ONEPWR batteries
(BV15020/BV15030/BV25040) and
charger (BV05100UK) should be
used with this machine.
• Only VAX ONEPWR recommended
tools and accessories should be
used with this machine.
• Refer to the oor/surface
manufacturer’s care
recommendations before use. Test
your ooring/surface - run the
machine over a small hidden area, if
no damage or discolouration occurs
continue cleaning. Not suitable for
use on water sensitive ooring.
• Always remove the battery from the
machine before carrying out any
maintenance or if storing unused for
a long period of time.
• Keep all openings clear and free
from debris as this may aect the
airow/suction.
• Turn o all controls on the machine
before disconnecting or connecting
the battery.
• Always protect the charger power
cord from heated surfaces or near
open ames.
SAFETY GUIDE

SAFETY GUIDE 3
support.vax.co.uk
• Store the machine in a cool, dry
area. Before storing ensure all
water/solution tanks and lters are
thoroughly clean and dry.
• The machine can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the machine
in a safe way and understand the
hazards involved. Children shall not
play with the machine. Cleaning and
user maintenance shall not be made
by children without supervision.
• Only use the machine indoors and
keep the area you’re cleaning well
lit. Keep ngers, hair and loose
clothing away from moving parts and
openings whilst using the machine.
• Use only CE approved 13amp
extension cords, non-approved
extension cords may overheat.
Care should be taken to arrange the
extension cord as it can be a trip
hazard.
• The water/solution tank should be
lled with warm water (max 40°C)
only. Filling the water/solution tank
with hot or boiling water will damage
the machine and invalidate the
guarantee. Always use the machine
with all water/solution tanks and
lters in place.
• Only VAX recommended solution
should be used with the machine.
Using other solutions may invalidate
the guarantee.
• Always use the machine in an
upright position. To prevent motor
damage from dirty water, never hold
the machine upside down or on its
side. Always stand the machine on a
stable, level surface.
BATTERY SAFETY PRECAUTIONS
• Replace the battery with a VAX
ONEPWR battery only. Use of
another battery may present a risk
of re or explosion.
• Do not attempt to disassemble the
battery, remove any component
projecting from the battery terminals
and do not dispose of in a re.
The battery and charger have no
user serviceable parts. Fire or injury
may result.
• Prior to disposal, protect exposed
terminals with heavy insulating tape
to prevent shorting. The battery is to
be disposed of safely at your local
battery recycling centre.
• When the battery pack is not in
use, keep it away from other metal
objects that can make a connection
from one terminal to another.
Shorting the battery terminals
together may cause burns or a re.
• In case of battery leakages, avoid
any contact with skin and contact us
on: 08000 927737.

SAFETY GUIDE 4
support.vax.co.uk
TECHNICAL
EU Statement of Compliance: Manufacturer/EU importer: VAX Limited, hereby on
our own responsibility, declare that the VAX ONEPWR SpotlessGo is manufactured
in compliance with the following Directives:
Safety: 2014/35/EU Low Voltage Directive.
EMC: 2014/30/EU Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.
© 2019 VAX Limited. All rights reserved. The VAX trade mark and VAX lozenge
are the property of Techtronic Floor Care Technology Ltd and are registered in the
EU and may be pending or registered in other countries.
WARRANTY
If a VAX ONEPWR machine is used
in the way it is intended and it breaks
down within the guarantee period, it’s
our responsibility to repair or replace it.
Here’s what isn’t covered:
• Normal wear and tear of consumable
items, for example: belts, lters,
brushbars, fuses etc.
• Batteries which have become faulty
as a result of improper handling.
• Batteries which have a reduced
service life as a result of normal wear.
• Accidental damage
- Damage as a result of use not in
accordance with the product
user guide.
- Damage caused by not carrying out
regular maintenance.
- Damage to the charger cable.
- Blockages caused by misuse.
• Faults caused by:
- Negligent use, misuse, neglect or
careless operation of the machine.
- Use of the machine cleaner which
is not in accordance with the
user guide.
- Use of a VAX ONEPWR machine
for anything other than normal
domestic household purposes
in the country in which it was
purchased.
- Use of parts, accessories and
consumables, which are not
genuine VAX components.
- Faulty installation or repairs –
unless carried out by a qualied
electrician or engineer.
VAX Ltd, Artillery House, Heritage Way, Droitwich, WR9 8YB, UK.

5
support.vax.co.uk
GETTING TO KNOW YOUR MACHINE
1Carry handle
2Power ON/OFF
3Dirty water tank release latch
4Battery dock (hidden)
5Main unit
6Water/solution tank
7Dirty water tank
8Wash tool
9Hose
10 Multi-purpose attachment
11 Squeegee attachment
12 Pet attachment
13 ONEPWR Battery*
14 ONEPWR Charger*
15 250ml Multi-oor Solution
Subject to technical change without notice. Images are illustrative only.
TECHNICAL SPECIFICATION
VAX ONEPWR SpotlessGo
Weight (without battery pack) 2.9kg
Water/solution tank capacity 225ml
Dirty Water Tank capacity 295ml
Run time and charge time dependent on battery pack used.
*Included with model CLCW-MSKS only.
10 11 12
13 14 15
1
5
4
7
8
9
6
2
3

6
support.vax.co.uk
GETTING STARTED
CHARGING THE BATTERY
Slide the battery down on to the charger. The charger light will flash white to
show when the battery is charging.
The light on the charger will stop
flashing and go off when the battery
is fully charged.
Once fully charged, slide the battery off
the charger to remove.
To check the battery charge
level press the battery symbol.
THIS MACHINE IS ONLY TO BE USED WITH VAX ONEPWR BATTERIES AND CHARGER.
PLEASE READ THE SAFETY GUIDE BEFORE USE.
NOTE: Before rst use, ensure the battery is fully charged. Failure to fully charge the battery
before rst use may result in poor battery performance. The life expectancy of the battery will vary
depending on the usage of the machine.
ASSEMBLY
Holding the cover open, slide the battery
into the machine until it clicks into place.
Close the battery cover.Pull to open the battery cover.

7
support.vax.co.uk
GETTING STARTED
Lift to remove the water/solution tank
from the side of the machine.
Press the on/off button to switch the
washer on.
Unscrew the cap and fill to the water
and solution markers on the tank.
Replace the cap and push the tank
down on to the machine until it clicks
into place.
IMPORTANT: Before using the machine to clean dried-on stains and dirt, the ooring should be
vacuumed throughly.
• Test for colourfastness - Wet a white absorbent cloth with the solution. In a small hidden area of
your carpet/rugs/upholstery/hard oors, gently rub with the dampened cloth. Wait ten minutes
and check for colour removal or bleed with white paper towel or cloth. Check all carpets/rugs/
upholstery material before rst use and if your carpet has more than one colour, check all colours.
• Test all carpets/rugs/upholstery/hard oors before use. Test the spot washer on a small hidden
area. If no damage or pile distortion occurs continue cleaning.
• Move furniture out of the area to be cleaned. If the furniture cannot be moved, place aluminium
foil or wax paper under the legs. This will prevent wood nishes from staining your carpet.
Pin up furniture skirts and curtains.
• When using the spot washer, basic safety precautions should always be observed and don’t over
saturate your carpets/rugs/upholstery/hard oors.
• Only use VAX ONEPWR Multi-oor solution. Using other solutions may cause excess foaming and
will invalidate your guarantee.
• The water/solution tank should only be lled with warm water (max 40⁰C). Filling the water/
solution tank with hot/boiling water will damage your washer and invalidate the guarantee.
IMPORTANT: Your dirty water tank is tted with a oat. When
the dirty water tank is full, the oat will shut o the suction on
the spot washer. You will be able to hear if this has happened as
the motor noise on the washer will increase. Once the oat is
activated, empty the dirty water tank if full.
If the dirty water tank is not full then turn o your washer at the
power switch and wait for the oat to settle.
OPERATION

8
support.vax.co.uk
GETTING STARTED
Lift the wash tool and hose out of the
holder to release from the side of the
machine.
Press the trigger on the handle to
release water and solution.
Hook the tabs on the selected attachment
into the wash tool and clip into place.
Use the brush to agitate any stubborn
stains.
Select the desired tool attachment.
Release the trigger to recover the water
and solution.
NOTE: For heavily soiled areas, it may be necessary to repeat the cleaning process.
Make criss-crossing strokes across the original pattern and overlap with each pass.
OPERATION

9
support.vax.co.uk
CLEANING & MAINTENANCE
WARNING: Always switch o the machine and remove the battery before carrying out any
maintenance or troubleshooting.
IMPORTANT: Empty and rinse out the water/solution tank and dirty water tank and leave to air dry
before replacing.
Press the dirty water tank release latch and pull the tank to remove.
Empty the dirty water over the sink.
Rinse the dirty water tank and lid under
water (max 40°C) to remove dirt/debris.
Replace the lid.
Lift the lid to remove from the dirty
water tank.
To re-fit, tilt the dirty water tank and
line the front of the tank up onto spot
washer. Push back until it clicks into
place.
EMPTYING AND CLEANING THE DIRTY WATER TANK

10
support.vax.co.uk
CLEANING & MAINTENANCE
Press the dirty water tank release latch and pull the tank to remove.
Push the button on the wash tool to
release the nozzle.
Rinse the nozzle under water to remove
dirt/debris.
Remove any dirt and debris from the
filter located underneath the dirty
water tank.
CLEANING THE FILTER
CLEANING THE WASH TOOL NOZZLE
WARNING: Always switch o the machine and remove the battery before carrying out any
maintenance or troubleshooting.
IMPORTANT: If the nozzle is tted incorrectly, this will cause poor dirty water pick up.
NOTE: Before using the machine to clean dried-on stains and dirt, the ooring should be
vacuumed throughly. This will prevent a build up of dirt and debris in the hose and nozzle.
40°C
MAX

11
support.vax.co.uk
CLEANING & MAINTENANCE
Press the dirty water tank release latch
and pull the tank to remove.
Release the hose from the side of the
washer.
Pull to remove the hose assembly away
from the base of the washer.
Rinse the hose under warm water
(40⁰C) to remove any dirt and debris.
Lie the washer on to its side and undo
the 3 screws on the base.
CLEANING AND REMOVING BLOCKAGES IN THE HOSE
40°C
MAX

12
support.vax.co.uk
TROUBLESHOOTING
THERE IS AN ACCESSORY MISSING
Check the contents on the back of the box.
WHY DOES THE MACHINE HAVE NO POWER?
• The battery is not tted correctly. See ASSEMBLY page 6.
• The battery has no charge. See CHARGING THE BATTERY page 6.
WHY WON’T THE SOLUTION/WATER DISPENSE?
•Squeeze the trigger on the hose to release solution and water mix.
•Make sure the water/solution tank is tted securely. See OPERATION page 7.
•The water/solution tank valve may be stuck, hold the water/solution tank over the sink
and press the valve underneath to release.
•The water/solution tank is empty. Rell the tank. See OPERATION page 7.
WHY WON’T THE SPOT WASHER PICK UP?
•The oat in the dirty water tank may have been activated. Empty the dirty water tank
and wait for the oat to settle before re-starting your machine.
•Check the hose for blockages and clear. See CLEANING AND REMOVING BLOCKAGES
FROM THE HOSE page 11.
•Check the nozzle for blockages and clear. See CHECKING FOR BLOCKAGES page 10.
•The dirty water tank may not be assembled correctly or the lid may not pushed down
securely. See EMPTYING AND CLEANING THE DIRTY WATER TANK page 9.
•Check the nozzle is correctly tted. See CHECKING FOR BLOCKAGES page 10.
•Check the lter located under the dirty water tank for dirt and debris.
See CLEANING THE FILTER page 10.
