Vax Performance C91-PF Series User manual

User Guide
vax.co.uk
GB
Vax Careline 0870 606 1248
Bagless Cylinder
Get Cleaning...
What’s your Vax’s model number? What’s your serial number?
( ocated on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
C91-PF Series
C91 - PF - -
performance
Vax C91-PF Performa ce Series User Guide.qxd:User guide 18/3/09 16:58 Page 1

---
1
Machine Overview
3
2
4
10
13
9
7
6
5
12 11 8
1 On/off button
2 Post-motor filter cover
3 Plug
4 Floor tool parking slot
5 Pre-motor filter (hidden)
6 Dirt container
7 Hose inlet
8 Carry handle
9 Auto cord rewind
10 Variable power
11 Dirt container release button
12 Dirt container carry handle
13 Blockage indicator
14 Dirt container quick-release
button
Unit
15 Hose (with tool caddy to hold
crevice tool and dusting
brush)
16 Dusting brush
17 Crevice tool
18 Upholstery tool (loose in box)
19 Combination floor tool
20 Telescopic extension tube
21 HEPA pre-motor filter
22 Foam pre-motor filter
23 Fabric post-motor filter
Accessories
14
19
20
15
17
16
18
21
23
22
2Vax Helpline
0870 606 1248
Filters
Vax C91-PF Performa ce Series User Guide.qxd:User guide 18/3/09 16:58 Page 2

FOR HOUSEHOLD USE O LY.
When using the vacuum cleaner, basic safety precautions
should always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry
surfaces.
2. Turn off the vacuum cleaner controls before
disconnecting or connecting from the mains supply.
3. Always unplug the vacuum cleaner before
connecting or disconnecting the vacuum hose and
accessories.
4. Children should be supervised to ensure that they
do not play with the appliance.
5. This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into
water. Do not use the vacuum cleaner with a
damaged cord or plug. If the supply cord is
damaged return the vacuum cleaner to a Vax
Authorised Service Agent or a suitably qualified
person for examination, repair or adjustment.
8. Do not pull or carry by cord. Do not use the cord
as a handle, close a door on the cord or pull cord
around sharp edges or corners. Do not run the
vacuum cleaner over the cord. Keep the cord
away from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air-
flow. Keep all openings free of dust, lint, hair or
anything that might reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches
or any hot, smoking or burning objects.
13. Do not pick up flammable or combustible
materials (lighter fluid, petrol, kerosene etc.) or use
in the presence of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material
(chlorine, bleach, ammonia, drain cleaner etc.).
15. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
16. Do not use without A of the filters in place.
17. Take extra care when vacuuming on stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner in a cool, dry area.
20. Turn off the on/off switch before unplugging the
vacuum cleaner
21. Use only CE-approved 13 amp extension cords.
Non-approved cords may overheat. Care should
be taken to arrange the cord so that the cord
cannot be tripped over.
WAR I G: Always switch off and unplug the
vacuum cleaner from the electrical outlet before
assembling, opening or emptying the dirt container, or before
connecting/disconnecting the attachments.
CAUTIO : The vacuum cleaner is a very powerful
unit. Before plugging the cord into the electrical
outlet, make sure the switch is in the ‘off’ position. Hold the
vacuum cleaner firmly when starting and in use.
IMPORTA T: If the inlet, hose or telescopic tube
is blocked, switch off the vacuum cleaner and
remove the blockage(s) before re-starting the vacuum
cleaner.
IMPORTA T: Washing filters improves vacuum
performance. Vax recommends that they should be
checked and cleaned periodically. Make sure all filters are
completely dry before inserting back into the vacuum
cleaner.
IMPORTA T: The motor is equipped with a thermal
cut-out. If for any reason the unit should overheat,
the thermostat will automatically turn the unit off. Should this
occur, unplug the vacuum cleaner from the electrical outlet
and turn off the switch. Remove dirt container and empty.
Clean filters. Allow the unit to cool for approximately one (1)
hour. To re-start, plug into an electrical outlet and switch back
on.
This vacuum cleaner is intended for household use
only and OT for commercial or industrial use.
PLEASE KEEP I STRUCTIO S FOR FURTHER USE.
!
General Safety Information
!
!
!
!
vax.co.uk 3
Vax C91-PF Performa ce Series User Guide.qxd:User guide 18/3/09 16:58 Page 3

---
Operation
Assembling your vacuum cleaner
Operating the appliance
OTE: Fully unwind the
power cord. A yellow
mark on the cord
indicates the
recommended cord
length. Do not exceed
the cord length beyond
the yellow mark.
Packing away and storage
4Vax Helpline
0870 606 1248
OTE: For convenience
there is a parking slot located
at the rear of the vacuum
cleaner where the floor tool
and tubes can be attached
for storage and carrying.
Keep your Vax like new
IMPORTA T: The condition of the filters affects the
performance of your machine. Please check and wash
filters periodically (depending on the level of use). For full
cleaning instructions, see page 5.
!
IMPORTA T: Do not use the vacuum cleaner without
all of the filters in place.
!
OTE: The crevice tool, dusting brush and upholstery tool can all be attached to the telescopic
tube.
Vax C91-PF Performa ce Series User Guide.qxd:User guide 18/3/09 16:59 Page 4

Maintenance (Keep your Vax as good as new)
Emptying and cleaning the dirt container
Cleaning the post-motor filter
vax.co.uk 5
Cleaning the HEPA and foam pre-motor filters
24
24
tap tap
tap
tap
Vax C91-PF Performa ce Series User Guide.qxd:User guide 18/3/09 16:59 Page 5

---
FAQs
!
WAR I G: to reduce the risk of personal injury, unplug the vacuum cleaner
before performing maintenance/troubleshooting checks.
Is there an accessory missing?
•Check the ‘Parts Overview’ page in this
guide to make sure the part is definitely
included in your unit.
•If it is missing, we’re here to help. Simply call
us on 0870 606 1248
Why won’t the vacuum cleaner pick up?
•The dirt container may be incorrectly
installed; remove the dirt container from the
unit by pressing the dirt container release
button [11] and then re-attaching it to the unit,
ensuring it is locked firmly back into place.
If the blockage indicator is lit:
•The filter may be clogged; refer to
‘Maintenance: Cleaning the filters’ on page 5.
•The dirt container may be blocked; refer to
‘Maintenance: Emptying and cleaning the dirt
container’ on page 5.
Why is dust escaping from the vacuum?
•The filter may be clogged; refer to
‘Maintenance: Cleaning the filters’ on page 5.
•The dirt container may be blocked; refer to
‘Maintenance: Emptying and cleaning the dirt
container’ on page 5.
•The dirt container may be incorrectly
installed; remove the dirt container from the
unit by pressing the dirt container release
button [11] and then re-attaching it to the unit,
ensuring it is locked firmly back into place.
What do I do if the unit/an accessory
becomes damaged or broken?
•We’re here to help. Simply call 0870 606
1248 or visit vax.co.uk
Why won’t the accessories pick up
properly?
If the blockage indicator is lit:
•The accessory may be blocked; switch off
and unplug the unit before performing these
checks.
Hose blockages: remove the flexible hose
from the unit. Carefully remove any blockages
found and reconnect hose securely.
Accessory blockages: remove accessory
from handle/tube. Carefully remove blockage
and re-attach to the vacuum cleaner.
•The accessory may be faulty. Simply call us
on 0870 606 1248 for assistance.
Why will the vacuum cleaner not run?
•It may not be plugged into the electrical
outlet correctly; ensure that the plug is
pushed in securely.
•The electrical outlet may not be working
properly; check the fuse or breaker, or consult
an electrician.
•The motor thermostat may have tripped;
switch off and unplug the vacuum cleaner,
and leave for one hour before switching the
cleaner back on.
If none of these questions apply to you,
we’re here to help. Simply call us on
0870 606 1248.
6Vax Helpline
0870 606 1248
Vax C91-PF Performa ce Series User Guide.qxd:User guide 18/3/09 16:59 Page 6

Other Information
UK Service & Help
Vax Customer Careline 0870 6061248
Monday-Friday 8.30am to 6.30pm
Saturday-Sunday 9.00am to 5.00pm
Any queries or concerns about using the Vax, call the Vax Careline. Calls are charged at the UK
national rate.
Please make a note of the serial number and model number of the carpet cleaner before calling.
There are over 400 approved Vax Service Agents in the UK. For the nearest Service Agent, please
call the Vax Customer Careline or visit vax.co.uk
Technical Specification
Voltage: 220-240V ~50Hz
Wattage: 2000 W
Capacity: 2.4
Filters: HEPA pre-motor filter (washable)
Foam pre-motor filter (washable)
Fabric post-motor filter (washable)
Cord length: 6 m (approx)
Weight: 5.7kg
Subject to technical change without notice.
EEC Statement of Compliance
Manufacturer/EEC importer: Vax imited, hereby on our own responsibility, declare that the
C91-PF Performance series is manufactured in compliance with the following Directives:
Safety: 2006/95/EC ow Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your ocal Authority or retailer for recycling advice.
vax.co.uk 7
Vax C91-PF Performa ce Series User Guide.qxd:User guide 18/3/09 16:59 Page 7

---
Vax Ltd., Kingswood Road, Hampton Lovett, Droitwich, Worcestershire, WR9 OQH, UK
email: [email protected] - website: www.vax.co.uk
