Vax Power5 C85-P5-Be Installation instructions

BAGLESS CYCLONIC
CYLINDER VACUUM
C85-P5-Be
C85-P5-Pe
LET’S GET STARTED.
Power5

Let’s talk safety
Basic
safety
precautions
Don’ts
Do’s
This vacuum cleaner is intended for household use only and
NOT for commercial or industrial use.
• Only use the vacuum cleaner indoors on dry surfaces and
keep the area your cleaning well lit.
• Keep ngers, hair and loose clothing from moving parts and
openings whilst using the vacuum cleaner.
• Don’t use this vacuum cleaner if it has been dropped,
damaged or left outdoors.
• Don’t run over the power cord or use vacuum cleaner if the
power cord or plug is damaged. Please contact our Customer
Care Line on: 0330 026 8455 (Mon-Fri: 8:30am to 6:30pm,
Sat: 9:00am to 5:00pm).
• Don’t handle the plug or use the vacuum cleaner with
wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord.
• Don’t use the power cord as a handle, pull the power cord
around corners, sharp edges or close a door over the
power cord.
• Don’t unplug vacuum cleaner by pulling on the power cord.
• Turn o all controls on the vacuum cleaner before
disconnecting or connecting the power cord.
• Always make sure both the pre-motor/post motor lters are
in place before use.
• Always switch o the vacuum cleaner before disconnecting
or connecting the hose and accessories.
• Keep all openings clear and free from debris as this may
aect the airow/suction.
• Always replace the fuse in the plug with a British 13amp fuse.

• This vacuum cleaner can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the vacuum cleaner in a safe way and understand the
hazards involved. Children shall not play with the vacuum cleaner. Cleaning
and user maintenance shall not be made by children without supervision.
• Only Vax recommended tools and accessories should be used with this
vacuum cleaner.
• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,
kerosene etc.) or use the vacuum cleaner in an area with explosive vapours
or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful uids (chlorine, bleach,
and ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.
• Don’t vacuum up hard or sharp objects such as glass, nails, screws or
coins etc.
• Don’t use the vacuum cleaner with incorrect voltage as this may result in
damage or injury to the user. The correct voltage is listed on the ratings label.
• Always protect the power cable from heated surfaces and open ames.
• Take extra care when positioning and using the vacuum cleaner on the stairs.
• Use only CE approved 13amp extension cords, non-approved extension
cords may overheat. Care should be taken to arrange the extension cord as
it can be a trip hazard.
• Store your vacuum cleaner in a cool, dry area. If lters have been cleaned
as per user guide instructions ensure they are thoroughly dry before
storing away.
PLEASE KEEP INSTRUCTIONS FOR FURTHER USE

Thank you for buying this Power 5.
Taking care of your carpets and hard oors
The Power 5 is designed to make vacuuming carpets and hard oors regularly, as eective and
ecient as possible and this user guide will help you get the most out of your machine.
Maintaining your carpets and hard oors will ensure they keep their appearance for longer.
You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you
take good care of them.
Taking care of your Power 5
Also inside this guide are instructions on maintaining your new machine, so that it’s always
ready when you are to tackle your carpets and hard oors.
Let us know what you think @VaxUK
Taking care of you
We’re here if you need us. Instead of taking me back
to the shop, simply visit:
vax.co.uk/support or call:
(UK) 0330 026 8455 (ROI) 1-800 928 308
Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm
Calls are charged at the UK local rate. Please make a note of the serial number and model number
of the product before calling.
Alternatively, you can write to us at:
Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 0LW, UK
This User Guide can be found online at: vax.co.uk/support

Contents
Let’s talk safety
Getting to know your machine
Getting started
Using your machine
Taking care of your machine
Let’s talk technical
Accessories
What to do if it goes wrong
Getting in touch
Included with
your machine
Accessory Hose
Combination
Floorhead
Tool Connector
TurboTool
Telescopic
Extension Tube
Initial Setup for normal operation
1. Use the base accessories.
a. Shortest hose.
b. Extension tube set to shortest practicable length.
2. Clean lters installed.
3. Dust receptacle empty.
4. All Bleeds must be closed.
5. Floorheads/tools set to Carpet Mode for carpet cleaning.
6. Mechanical Agitation turned ON for carpet cleaning.
7. Floorheads/tools set to Hard Floor Mode for hard oor cleaning.
8. Mechanical Agitation turned OFF for hard oor cleaning.
Power 5 Pet
All the above, plus
Power 5
(Included with all models)
3-in-1 Tool

Getting to know your machine
Technical Specication
Name Power 5
Voltage See rating label on machine for details
Wattage See rating label on machine for details
Cord length 5m
Weight 4.7kg
Subject to technical change without notice.
Accessories & Consumables
Filter Kit (Type 95)*
1-1-134231-00
Pro Cleaning Kit (Type 2)
1-1-133326-00
TurboTool (Type 6)
1-1-134419-00
Hard oor tool (Type 3)
1-1-135705-00
*To purchase consumables and accessories, please visit vax.co.uk
Carry handle
Dirt container release button
Cord rewind button
Hose entry point
Power On/O button
Wheel outer
Dirt container lid
Post motor lter
(hidden) and cover
Dirt container
Separator and shroud
Getting started

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE
Getting started
Before you begin cleaning
• Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments,
or removing and emptying the dirt container.
• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the
thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o and unplug
from electrical socket. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the
vacuum cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters
to fully dry before putting back into the vacuum machine).
• Tap the pre-motor lter over a bin every 4-6 uses to remove dirt/debris.
• If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.
Assembling your cylinder
Click!
Press both buttons at the end of the
hose and push hose into the hose
entry point.
Insert the hose grip into the
telescopic extension tube. Press the
button on the telescopic extension
tube and adjust to required length.
Insert the other end of the telescopic
extension tube into the oor head.
Fully unwind the power cord.
A yellow mark on the cord indicates
the recommended cord length.
Do not exceed the cord beyond the
yellow mark.
Plug in and switch the unit on by
pressing the power button.
How to use
When unwinding the
power cord always pull
out to the yellow marker
but no further.
CAUTION

Using your machine
Slide vent cover on hose grip open
to reduce suction if required.
Lower brushes for hard oors.
How to use
IMPORTANT: The base of the vacuum cleaner should always be positioned at on the oor when starting and in use.
The dirt container should be locked into place before lifting the vacuum cleaner by the carry handle.
For use on carpets, click rocker
switch forward.
For use on hard oors click rocker
switch back.
Raise brushes for carpets.
Using your machine
TIP
Brushes on the
oorhead should be
visible when using on
hard oors.

Using your machine
Press the cord rewind button
to retract the cord into the
vacuum cleaner.
Place the oor head into the parking slot on the back of vacuum cleaning for
storage and carrying.
Using your machine
Choose an accessory. Choose an accessory and push onto
the telescopic extension tube or hose.
If required use tool connector.
Using accessories
Storage

Taking care of your machine
Cleaning the pre-motor lter
Remove dirt container
by pushing down the dirt
container release button
and lifting the dirt container.
Hold the dirt container and
twist the lid anti-clockwise.
Tap the pre-motor lter
against a bin to remove
any dirt/debris.
Leave to dry for 24 hours or
until fully dry before placing
back in the machine.
Rinse the pre-motor lter
under water (max 40°C).
TAP
MAX
40˚C
!
MAX
40˚C
24hr
Lift the lid to reveal the
pre-motor lter.
Hold the dirt container over a
bin. Press the dirt release clip
at the bottom of the container,
the dirt release door will open
allowing dirt/debris to fall out.
Lift out the pre-motor lter.
Emptying and cleaning the dirt container
IMPORTANT: Always switch o and unplug the vacuum cleaner from the electrical socket before assembling,
opening or emptying the dirt container, or before connecting/disconnecting the attachments.
Check the pre-motor lter every time you empty the dirt container and tap against a bin to remove
dirt/debris if required.
The motor is equipped with a thermal cut-out. If for any reason the unit should overheat, the thermostat will
automatically turn the unit o.
Taking care of your machine

Hold the dirt container and twist the
lid anti-clockwise.
Cleaning the shroud
Lift the lid to reveal the
pre-motor lter.
Lift out the pre-motor lter.
Twist the separator cap anti-
clockwise to unlock and remove.
Lift and remove the separator from
the dirt container.
Tap the separator against a bin to
remove any dirt/debris.
Make sure the rectangular hole in
the dirt container lines up with the
rectangular hole on the separator.
Replace the separator cap,
twist clockwise to lock.
Replace the pre-motor lter. Close
dirt bin lid making sure it clicks and
locks into place.
Taking care of your machine

Let’s talk technical
Slide the locking ring
to remove.
Lift and separate
the housing.
Using a pair of scissors,
cut any hair or debris free
from around the brushes.
Removing blockages from the TurboTool (some models only)
Tabs
Line up the tabs on front of
housing and push together
to ret. Slide locking ring
into groove to secure.
Removing blockages from the hose
Post-motor lter maintenance
Post-motor lter is located in the
right side wheel. Hold the centre
of the wheel and twist wheel cover
anti-clockwise.
With the wheel cover o the
post-motor lter is easily removed.
IMPORTANT: The exhaust lter is designed to oer long life with no maintenance. The lter should be checked
periodically and when heavily discoloured it should be replaced. Please do not wash, scrub or brush the lter
as this will damage the delicate lter media.
CAUTION: Do not wash the post-motor lter.
Check the post-motor lter
for discolouration.
!
40˚C
MAX
24hr
Remove the hose from the vacuum cleaner and telescopic
extension tube. Insert a broom handle or similar blunt
instrument into the hose to remove blockage.
TIP
To test for a blockage in
the hose, drop a small
ball of paper into the
hose. The paper will
drop through if the
hose is clear.
Accessories

Accessories
Pro Cleaning Kit (Type 2)
1-1-133326-00
All our best tools all in one kit that makes cleaning
your home quicker, easier and with even better
results. We’ve taken care of cleaning all of the hard
to reach areas such as on top of cupboards and in
between blinds to the dust that collates behind and
within the radiator.
Don’t forget your accessories!
Order at: www.vax.co.uk/spares-and-solutions
TurboTool (Type 6)
1-1-134419-00
Use the TurboTool for vacuuming your stairs,
upholstery and car interiors. It’s great for picking
up stubborn pet hair.
Fur ‘n’ Flu Tool
1-1-131392-00
Specically designed to remove extra stubborn
pet hair from upholstery, furniture and carpets.

What to do if it goes wrong
Getting in touch
SolutionProblem
CAUTION: To reduce the risk of personal injury, unplug the product before performing maintenance
/troubleshooting checks.
• Check the ‘This pack contains’ panel on the box to make sure
the part is included with your machine.
There is an
accessory missing.
• The dirt container may not be correctly tted, remove the dirt
container from the vacuum cleaner and check it’s assembled correctly,
ret ensuring it’s locked into place.
• The shroud is blocked. Go to ‘Taking care of your machine’.
• The separator and shroud are incorrectly tted. Go to ‘Taking care
of your machine’.
• The lter may be clogged, clean the lter. Go to ‘Taking care of
your machine’.
• The dirt container may be blocked, empty the dirt container.
Go to ‘Taking care of your machine’.
• There may be a blockage in the hose/tube. Disconnect from the
vacuum cleaner and carefully remove any blockages.
Go to ‘Let’s talk technical’.
Why won’t the
vacuum cleaner
pick up?
• The plug may not be fully pushed into the electrical socket.
• Check the fuse in the plug if this needs replacing, always replace
with a 13amp fuse.
• The motor thermostat may have tripped. If this has happened,
unplug the vacuum cleaner. Remove and empty the dirt container
and check the hose for blockages. Clean the lters and allow the
vacuum cleaner to cool for approximately 1 hour (if you have washed
the lters you will need to wait 24 hours for the lters to fully dry
before putting them back into the vacuum cleaner).
Why does my
vacuum cleaner
have no power?
• The lters may be clogged, clean the lter. Go to ‘Taking care
of your machine’.
Why is dust escaping
from the vacuum?

What to do if it goes wrong
† Registration required. Terms and conditions apply.
* Calls are charged at the UK local rate. Please make a note of the serial number and model number of the product before calling.
Getting in touch

GET IN TOUCH
0330 026 8455 VaxVacuums[email protected].uk vax.co.uk @VaxUK
EEC Statement of Compliance: Manufacturer/EEC importer: Vax Limited, hereby on our own responsibility, declare that the
C85-P5-(Be/Pe) manufactured in compliance with the following Directives: Safety: 2006/95/EC Low Voltage Directive.
EMC: 2004/108/EC Electromagnetic Compatibility Directive.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice.
© 2015 All rights reserved. VAX®, and VAX Lozenge are trade marks or registered trade marks of Techtronic Floor Care
Technology Ltd.
