Vax VMAT1400W User manual

Bagless Cylinder
Get Cleaning...
What’s your Vax’s model number?
What’s your serial number? (Located on the base of the machine)
Note these down in case you need them in future. Please keep instructions for further use.
vax.com.au VMAT1400W / VMCB1400W
1 4 0 0
User Guide
Vax Careline: AU: 1300 361 505
NZ: 0800 800 900
V M A T 1 4 0 0 W / V M C B W
Get Cleaning...
™

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900 vax.com.au

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au 2
Machine Overview
4
3
2
11
8
7
6
10
1
5
3
2
9
1
.Machine Overview
T
he Unit
1 On/Off Button
2Dirt Container
3 Cyclone Separator
4 Dirt Container Carry Handle
5 Dirt Container Release Button
6 Auto Cord Rewind
7 Floor Tool Parking Slot
8Plug
9 Dirt Bin Quick Release Button
10 Pre-Motor Filter Cover
11 Hose Inlet
12 Post Motor Filter Cover
.
1 2
18
132-in-1 Tool
14 Crevice Tool
15 Combination Floor Tool (Not inc. on model VMAT1400W)
16 Telescopic Tube
17 TurboTool
18 Standard Hose
19
Stretch Hose
20 Hard Floor Tool
21 Turbo Brush
For pet hair, stair and upholstery cleaning.
NOTE: Do not use the Turbo tool on suede
and leather surfaces
(VMAT1400W ONLY)
(VMAT1400W ONLY)
(VMAT1400W ONLY)
NOTE: The stretch hose should not be used as the
main hose. The stretch hose is recommended to be
used for stair cleaning. The unit should always be
positioned at the bottom of the stairs.
NOTE: Not recommended for hard oors.
For carpeted areas only
22
23
24
22 Foam Pre-Motor Filter
23 Fabric Pre-Motor Filter
24 HEPA Post-motor Filter
Anti bacterial HEPA Post-Motor Filter
14
13a
15
16
17
13b 19
21
20
2. Accessories Overview
( VMAT1400W MODEL ONLY)

General Safety Information
Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au
3
FOR HOUSEHOLD USE ONLY.
When using the vacuum cleaner, basic safety precautions should
always be observed, including the following:
1. Only use the vacuum cleaner indoors on dry surfaces.
2. Turn off the vacuum cleaner controls before disconnecting or
connecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting or
disconnecting the vacuum hose and accessories.
4. Children should be supervised to ensure that they do not play
with the appliance.
5. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
6. Use only as described in this manual. Use only Vax
recommended attachments.
7. Do not use the vacuum cleaner if it has been dropped,
damaged, left outdoors or dropped into water. Do not use the
vacuum cleaner with a damaged cord or plug. If the supply
cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a
hazard.
8. Do not pull or carry by cord. Do not use the cord as a handle,
close a door on the cord or pull cord around sharp edges or
corners. Do not run the vacuum cleaner over the cord. Keep
the cord away from heated surfaces.
9. Do not handle the plug or vacuum cleaner with wet hands.
Do not use outdoors or on wet surfaces.
10. Do not put any objects into openings. Do not use with any
openings blocked and do not restrict airflow. Keep all openings
free of dust, lint, hair or anything that might reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the body away
from openings and moving parts.
12. Do not pick up hot coals, ash, cigarette butts, matches or any
hot, smoking or burning objects.
13. Do not pick up flammable or combustible materials (lighter
fluid, petrol, kerosene etc.) or use in the presence of explosive
liquids or vapours.
14. Do not vacuum up harmful or toxic material (chlorine, bleach,
ammonia, drain cleaner etc.).
15. Do not vacuum up hard or sharp objects such as glass, nails,
screws, coins, etc.
16. Do not vacuum plaster dust, concrete dust or any other building
or vitreous materials.
17. Do not vacuum baking soda or any other powder-based carpet
refresher or deodoriser.
18. Do not use without ALL of the filters in place or with
blocked filters
19. Take extra care when vacuuming on stairs.
20. Keep vacuuming area well lit.
21. Store the vacuum cleaner in a cool, dry area.
22. Turn off the on/off switch before unplugging the vacuum cleaner.
23. Use only SAA approved 10 amp extension cords. Non-approved
cords may overheat. Care should be taken to arrange the cord
so that the cord cannot be tripped over.
WARNING: Always switch off and unplug the vacuum
cleaner from the electrical outlet before assembling, opening
or emptying the dirt container, or before connecting/
disconnecting the attachments.
CAUTION: The vacuum cleaner is a very powerful unit.
Before plugging the cord into the electrical outlet, make sure
the switch is in the ‘off’ position. Hold the vacuum cleaner
firmly when starting and in use.
IMPORTANT: If the inlet, hose or telescopic tube is blocked,
switch off the vacuum cleaner and remove the blockage(s)
before re-starting the vacuum cleaner.
IMPORTANT: It is very important that filters are kept clean
to obtain maximum performance from your vacuum cleaner.
Not cleaning and not replacing the filters regularly can
reduce the suction power and cause overheating and
permanent damage to the vacuum cleaner. If your filters are
washable make sure they are completely dry before inserting
back into the vacuum cleaner
This machine is intended for household use only, and NOT
for commercial or industrial use.
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER USE.
Damage to the vacuum cleaner as a direct result of not adhering
to the general safety instructions in this user guide invalidates
the warranty.

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au 4
Operation
Filters
Assembling your vacuum cleaner
Choose the attachments for the job
Keep your Vax like new
IMPORTANT: The condition of the lters aects
the performance of your vacuum cleaner.
Please check and wash lters regularly
(depending on level of use). See Maintaining the
Filters on page 7.
IMPORTANT: Do not use the vacuum cleaner
without all the lters in place.

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au
5
Operation
Operating the appliance
WARNING: Always switch o and unplug the
vacuum cleaner from the electrical outlet before
assembling, opening or emptying the dirt container,
or before connecting/disconnecting the attachments.
NOTE: Fully unwind the power cord. A yellow mark on
the power cord indicates the recommended cord length.
Do not exceed the cord length beyond the red mark.
Packing away and storage
IMPORTANT: Always unplug the vacuum from the electrical outlet and rewind the power cord as directed
before storing.
NOTE: When rewinding the power cord, guide the cord with one hand, This will prevent the cord from whipping
which could cause damage or injury.
NOTE: For convenience there is a parking slot located at the rear of the vacuum cleaner where the oor tool and
hose can be parked for carrying and storage.

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au 6
Maintenance (Keep your Vax as good as new)
Dirt Container
IMPORTANT: Always switch o and unplug the vacuum cleaner from the electrical outlet before removing
the dirt container.
IMPORTANT: Do NOT use the vacuum without ALL of the lters in place.
IMPORTANT: Remove the Dirt Container from the unit and dispose of the dirt inside the container
before cleaning.
IMPORTANT: The cyclone separator should not be submerged in water.
When the cyclone separator has been cleaned and dried completely, re-attached the dirt container to the lid of
the separator and return the dirt container to the unit.
Cleaning the Cyclone Separator
Emptying the Dirt Container

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au
7
Maintenance (Keep your Vax as good as new)
IMPORTANT: Your Vax vacuum cleaner is tted with high performance lters it is essential that these are
well maintained and cleaned according to the following instructions.
Maintaining the Filters
NOTE: Do not use any detergents or boiling
water to wash the lters.
Vax recommends that the pre-motor and post-motor lter should be checked and cleaned periodically depending
on the frequency of use and the volume of dirt being picked upon each occasion.
NOTE: Both Pre- and Post-Motor Filters can be rinsed in warm water (max 40°C). Allow to air dry for 24 hours
before replacing. Do NOT use any detergents or boiling water to wash the lters.
Once completely dry, return the lters and case to the vacuum cleaner. Replace all lters covers before restarting
the vacuum cleaner.
IMPORTANT: Even with regular cleaning, lters have a limited lifespan and will eventually need to be
replaced during the lifetime of the vacuum cleaner. If the performance of your vacuum cleaner is
compromised and/or the lters are severely discoloured, the lters may need to be replaced. As a general
guide, Vax recommends lters are replaced every 3-6 months depending on the level of use to ensure
optimum performance of your vacuum cleaner.
Cleaning the Pre-Motor Filter

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au 8
Maintenance (Keep your Vax as good as new)
NOTE: This is located at the base of the vacuum cleaner.
Cleaning the Post-Motor Filter
Cleaning Blockages
Cleaning Debris from the Turbo Tool and Turbo Brush (VMAT1400W MODEL ONLY)
WARNING: To reduce the risk of electric shock, the power cord must be disconnected before performing
maintenance/ troubleshooting checks. Turn the vacuum cleaner o and unplug from the electrical outlet.
NOTE: Switch the cleaner o and disconnect the power plug from the electrical outlet.
The brushbar will stop rotating if it is blocked during operation by vacuuming foreign objects, or if strands of
carpet or hair are wrapped around it.
Switch the vacuum cleaner o and disconnect the power plug from the electrical outlet.
Lay the Turbo Brush oor head on a at surface and turn over to expose the brushbar. Using a pair of scissors,
cut through any threads or hairs caught by the brushbar that have wrapped around the guides.
Hose Blockages
The exible hose may be disconnected from the
vacuum cleaner. Carefully remove any blockages
found and reconnect hose securely.
Accessory Blockages
Remove accessory from hose handle/ tube. Carefully
remove the blockage and return to the cleaner.

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au
9
FAQ’s
Problem Solution
Is there an accessory missing? Check the ‘Machine Overview’ page in this guide to make sure the part is definitely included
in your unit.
If it is missing, we’re here to help. Simply call us on AU: 1300 361 505 / NZ: 0800 800 900
Why won’t the vacuum cleaner
pick up?
The filters may be clogged or need to be replaced: Refer to the Maintenance sections (Pages 6-8).
The dirt container is full or blocked: Refer to the Maintenance sections (Page 6).
The dirt container may be incorrectly installed: Refer to the Maintenance sections (Page 5).
The brushbar may be blocked. Refer to the Maintenance sections (Page 6).
Why is dust escaping from
the vacuum?
The filters may not be installed correctly. Refer to the Maintenance sections (Page 6).
The dirt container may be incorrectly installed: Remove the dirt container from the unit by
pressing the dirt container release button (Page 6) and reattach it to the unit, ensuring it is
locked firmly back into place.
The filters may be clogged or need to be replaced: Refer to the Maintenance sections (Pages 6-8).
What do I do if an accessory/the
unit becomes damaged or broken?
Visit www.vax.com.au for parts and spares.
Please call our Vax careline to purchase new spares or order a replacement:
AU: 1300 361 505 / NZ: 0800 800 900
Why won’t the accessories pick
up properly?
The accessory may be blocked: Refer to the Maintenance section (Page 6).
The accessory may be faulty: call our Vax Careline to order a replacement:
AU: 1300 361 505 / NZ: 0800 800 900
Why will the vacuum cleaner
not run?
It may not be plugged into the electrical outlet correctly. Ensure that the plug is pushed into the
electrical outlet securely.
The electrical outlet may not be working. Check the fuse or breaker and consult an electrician.
WARNING: To reduce the risk of personal injury, unplug the vacuum cleaner before performing
maintenance/troubleshooting checks.

Vax Service line: AU: 1300 361 505
NZ: 0800 800 900
vax.com.au 10
Other Information
Vax Service & Help
Vax Careline:
Australia 1300 361 505
New Zealand 0800 800 900
Monday-Friday 8.30am to 5.00pm
If you have queries or concerns about using your Vax, call the Vax Careline. Calls are charged at the standard
local rate. Please make a note of the serial number and model number of the vacuum cleaner before calling.
For the nearest Service Agent, please call the Vax Customer Careline or visit vax.com.au
Technical Specication
Voltage: 220-240V ~50Hz
Wattage: 1400W
Capacity: 2.2 Litres
Filter: Cyclone separator – wipe clean
Pre-motor lter – washable sponge
HEPA Post-motor lter – washable
Cord length: 5m
Weight: VMAT1400W: 8.5kg
VMCB1400W: 7.6kg
Subject to technical change without notice.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
N197
Double
Insulated
Indoor
Use
Read
Instructions

Distributed by Techtronic Industries Pty. Ltd.
Level 1, 660 Doncaster Road, Doncaster, Australia 3108.
www.vax.com.au Service Line: AU: 1300 361 505 / NZ: 0800 800 900
