LVP609 Series Quick Using Guide
LVP609 Series Quick Using Guide V1.0
In order to make sure users can quickly use LVP609 serial LED video processor, we prepared
the<LVP609 serial quick user guide>. About LVP609 deeply setup, adjustment and operation,
please refer to <LVP609 serial user manual>.
Front\rear panel button introduction
Front Panel Button
1
2
3
4
5
1LCD display screen: display parameter information
2Input signal selection buttons: select signal from corresponding input port
V1，V2，VGA，DVI，SDI，HDMI
3Output card buttons: Select output cards and ports
K，L，M，N
Output Cards
Selection buttons
Out1，Out2
Output Port selection buttons
4Setup buttons: select output cards and output ports
Setup
Enter setup menu
Knob
Turn Knob to change parameters
of setup item, press know(OK) to
save the parameter.
↑，↓
Select setup item
Menu return button
5Other function buttons
Info
Device Information
checking button
M1，M2，
M3，M4
display mode selection buttons
Lock
Button lock/
button unlock

地址：深圳市南山区科技园北区同方信息港 C栋5B 网址：www.videowall.cn
电话：[phone] 传真：[phone]
LVP609 Series Quick Using Guide
Back Panel
2
3
1
图3-1 后面板信号端口图 Photo 3-1 back panel signal port
①Video Input ports ②video output ports ③communication ports
Step 1: Input, output signal connection
1) Turn off power of all signals’ devices
2) Connect output signals of video source to video input port of LVP609
3) LVP609 DVI output→DVI input port of sending cards, connect one of DVI outputs to LCD
displayer for monitor.
4) Internet cable of sending cards→Receiving cards of LED screen
Refer to connection diagram below:
接线图 Connection Diagram

地址：深圳市南山区科技园北区同方信息港 C栋5B 网址：www.videowall.cn
电话：[phone] 传真：[phone]
LVP609 Series Quick Using Guide
Step 2: Connect power, turn on the processor
1) Confirm the connection of input and output signals correct
2) Plug in the power of LVP609, turn on the LVP609
3) Connect the power of signal source devices
Step 3: Input signal Selection
Turn on LVP609, LCD panel displays as below; at this moment, press input signal buttons to select
corresponding signal sources. If user wants to set the fade-in/fade-out switch time, user could set
the parameters like the manual below: Setup→Input card setup→advanced setup→Fade time.
In(Input Card)
Source： DVI 0s
Status： 1080p_60Hz
Out-K(Output Card K)
Out Pos.&Size： （0,0,1920,1080）
In Pos.&Size： （0,0,3840,2160）
Display Mode： M4
Output Port： Out1
Step 4: PC HDMI2.0 Port output resolution setup
1) Enter control panel of PC graphic card, in setup of several monitors, select setup “Copy mode”,
“Extended Mode” or “double display mode”
2) In the option of changing resolution, select display LVP609-HDMI to resolution
3840*2160_60Hz, at this moment, the panel of LVP609 display signal condition is
“3840*2160_60Hz”.
Step 5: Setup output resolution
Turn on LVP609, press Setup button, Enter setup menu, in the menu, user could select
corresponding item by ↑,↓button, press knob button(OK button) to enter, press to return
last item. Enter setup menu: Setup →Output card setup →LED setup, input LED mosaic

地址：深圳市南山区科技园北区同方信息港 C栋5B 网址：www.videowall.cn
电话：[phone] 传真：[phone]
LVP609 Series Quick Using Guide
parameter to mosaic quickly. The operation steps as below:
LED Setup Out-K/M1/Out2
--------------------------------------
1.LED Total Width 3840
2.LED Total Height 2160
3.Unit Width 1920
4.Unit Height 1080
5.Unit H_Start 0
6.Unit V_Start 0
7.Auto Calculation OK To Apply
--------------------------------------
1) Press mode button to select display mode, then press output card and output port selection
buttons to select output port which needs adjustments.
2) In 1~2 item, input the total width and height of LED screen;
3) In 3~6 item, input LED screen size and position of output port;
4) In 7.Auto Calculation option to select OK button, then the current parameters in output image
setup menu is auto calculation parameters, meanwhile the right side of each setup item
displays the reference value;
5) Adjust according to requirement, enter user menu setup →output card setup →output
image setup to make tiny adjustment on input/output parameters.
6) According to steps 1)~5) , setup other ports and display modes, to complete mosaic setup.

地址：深圳市南山区科技园北区同方信息港 C栋5B 网址：www.videowall.cn
电话：[phone] 传真：[phone]
LVP609 Series Quick Using Guide
Appendix: Adjustment Sheet
Version
Time
Description
Draft
V1.0
2017.5.9
The first release
