Veeder-Root TLS-IB User manual

Manual No: 577013-719 ●Revision: G
Site Prep Manual
TLS-IB

Notice
Veeder-Root makes no warranty of any kind with regard to this publication, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this publication.
Veeder-Root reserves the right to change system options or features, or the information contained in this publication.
This publication contains proprietary information which is protected by copyright. All rights reserved. No part of this publication
may be photocopied, reproduced, or translated to another language without the prior written consent of Veeder-Root.
DAMAGE CLAIMS
1. Thoroughly examine all components and units as soon as they are received. If damaged, write a complete and detailed
description of the damage on the face of the freight bill. The carrier's agent must verify the inspection and sign the description.
2. Immediately notify the delivering carrier of damage or loss. This notification may be given either in person or by telephone.
Written confirmation must be mailed within 48 hours. Railroads and motor carriers are reluctant to make adjustments for
damaged merchandise unless inspected and reported promptly.
3. Risk of loss, or damage to merchandise remains with the buyer. It is the buyer's responsibility to file a claim with the carrier
involved.
RETURN SHIPPING
For the parts return procedure, please follow the appropriate instructions in the "General Returned Goods Policy" and "Parts
Return" pages in the "Policies and Literature" section of the Veeder-Root North American Environmental Products price list.
© Veeder-Root 2006. All rights reserved .

Table of Contents
iii
Introduction
Related Manuals ............................................................................................................1
Contractor Certification Requirements ...........................................................................1
Safety Symbols ..............................................................................................................1
Control Drawing .............................................................................................................3
Site Prep - International Installations
General ..........................................................................................................................4
Installation Levels .................................................................................................4
In–Tank Probes .....................................................................................................5
Health and Safety ...........................................................................................................5
Safety Symbols .....................................................................................................5
General .................................................................................................................5
Danger Areas ........................................................................................................6
Intrinsic Safety ......................................................................................................6
Tank Lid Access Chambers ...........................................................................................6
Access Chamber Installation ................................................................................6
Provision for Probe Risers ....................................................................................7
European Probe and Riser Installation Criteria (Non-PTB) ............................................8
General Notes .......................................................................................................8
Probe Riser Pipe Installation (Level 1 Installation Only) ..............................................10
PTB Compliant Installation ...........................................................................................11
Probe Entry .........................................................................................................11
Determining the Correct Probe Length ...............................................................11
Determining the Minimum Access Chamber Depth ............................................12
TLS-IB Location ...........................................................................................................12
Mounting the TLS-IB ....................................................................................................14
Cable Specifications .....................................................................................................15
Field Wiring ..................................................................................................................16
Probe to TLS-IB Location (Level 1 Installations Only) ........................................16
Maximum Cable Lengths ....................................................................................16
Ducting Entry to TLS-IB Location ........................................................................16
Equipment Connected To The RS-232 Port .................................................................16
Site Prep - U.S and Canadian Installations
National Electrical Code Compliance ...........................................................................17
Probe-to-Console Wiring .....................................................................................17
Power Wiring .......................................................................................................17
Probe Junction Boxes .........................................................................................17
Probe Wiring Safety Issues ..........................................................................................18
Probe Manhole Installation ...........................................................................................18
Determining Length of Probe When Used in a Dedicated Riser ..................................18
Optional Kits for Series Mag Probe Installations ..........................................................20
Kit Required for an AST Installation ....................................................................20
Riser Cap Kit for Mag Probe Installations ....................................................................21
Cap and Cord Grip Kit .........................................................................................21
Metal Cap and Ring Kit .......................................................................................21
Mag Probe Installation .................................................................................................23
Special Instructions for UST’s with Metal Riser Caps .........................................23
Probe Conduit Installation ............................................................................................25
Buried Rigid Conduit ....................................................................................................25
Pulling Wires for Probes .....................................................................................25
Probe Field Wiring ........................................................................................................26
Sealing Field Connections ...........................................................................................26

Table of Contents
iv
Wiring Run Through Rigid Conduit .....................................................................26
Mounting the TLS-IB ....................................................................................................27
Connecting Wiring to the TLS-IB
Probe Wiring Precautions ............................................................................................28
Probe Wiring Positions and Labeling ..................................................................28
Connecting Probes to the TLS-IB ................................................................................28
Auto Probe Configuration ....................................................................................29
Manual Probe Configuration ...............................................................................29
Connecting IFSF Wiring to TLS-IB ...............................................................................30
Connecting Serial Communication Wiring to the TLS-IB ..............................................31
Connecting Power Wiring to TLS-IB .............................................................................32
Troubleshooting
Replacing the CPU Board ............................................................................................34
PROM Chip Replacement (Software Upgrade) ............................................................35
Replacing the Power Supply Board .............................................................................37
When to Replace the Power Supply Board .........................................................37
How to Replace the Power Supply Board ...........................................................37
Neuron Service Switch .................................................................................................38
TLS-IB Specifications
Physical Specifications .................................................................................................39
Environmental Specifications .......................................................................................39
Electrical Specifications ...............................................................................................39
Software Specifications ................................................................................................39
IFSF Interface ..............................................................................................................39
Optional RS-232 Serial Interface .................................................................................40
Signal Input Specifications ...........................................................................................41
TLS-IB IFSF Commands ..............................................................................................41
Figures Figure 1. Control Drawing Showing an Example TLS-IB System Site Layout...........3
Figure 2. Typical Tank Lid Access Chamber Installation .......................................7
Figure 3. Tank Lid Access Chamber — Critical Dimensions .................................7
Figure 4. Typical Probe Installations ......................................................................8
Figure 5. Minimum clearance above probe canister ..............................................8
Figure 6. Probe canister sleeve kit installation .......................................................9
Figure 7. Canister clearance for 2-inch entries ......................................................9
Figure 8. Dimensions needed to calculate custom probes and risers .................10
Figure 9. The Veeder-Root Riser Cap Assembly and Fitting Tool .......................10
Figure 10. PTB Compliant Installation of a Mag Probe ..........................................11
Figure 11. Typical TLS-IB Installation ....................................................................13
Figure 12. TLS-IB Dimensions and Designated Conduit Knockouts .....................14
Figure 13. Calculating the Correct Mag Probe Length ...........................................19
Figure 14. Standard and Custom Mag Probe Lengths ..........................................19
Figure 15. Mag Probe AST Installation Kit .............................................................20
Figure 16. Cap and Cord Grip Kit ..........................................................................21
Figure 17. Metal Cap and Ring Kit .........................................................................22
Figure 18. Modifying an existing metal riser cap ....................................................22
Figure 19. Mag Probe UST Example Installation ...................................................23

Table of Contents
v
Figure 20. Mag Probe AST Example Installation ...................................................24
Figure 21. Installing a riser adaptor beneath the metal cap and adapter ring...........24
Figure 22. Example Probe Wiring Run in Buried Rigid Conduit .............................25
Figure 23. Field Wiring probes to TLS-IB Cables ..................................................26
Figure 24. Epoxy Sealing probe Field Connections ...............................................27
Figure 25. Connecting Mag Probe wiring to TLS-IB ..............................................29
Figure 26. Connecting IFSF Network wiring to TLS-IB ..........................................30
Figure 27. Connecting serial communication wiring to TLS-IB ..............................32
Figure 28. Wiring AC Power to the TLS-IB ............................................................33
Figure 29. TLS-IB CPU board ................................................................................34
Figure 30. Clearing RAM .......................................................................................35
Figure 31. Removing PROM Chip .........................................................................36
Figure 32. Replacing PROM Chip ..........................................................................37
Figure 33. Manually transmitting neuron ID ...........................................................38
Tables Table 1. “PTB” Compliant Installation — Calculation sheet for
determining the correct probe length.................................................... 12
Table 2. Probe Cable Specification (V-R P/N 222–001–0029) -
Maximum of 305 metres per probe ...................................................... 15
Table 3. Data Transmission Cable Specification (V-R P/N 4034-0147)............. 15
Table 4. Mag Probe AST Installation Kit (Part No. 312020-984)........................ 20
Table 5. Cord Grip and Cap Kit (Part No. 330020-282) ..................................... 21
Table 6. Metal Cap and Ring Kit (Part No. 312020-952).................................... 21
Table 7. TLS-IB Serial Communication / IFSF Node Address Selections.......... 31
Table 8. TLS-IB Serial Interface Connections.................................................... 40
Table 9. TLS-IB Serial Commands..................................................................... 40
Table 10. Tank Level Gauge Database................................................................ 41
Table 11. Tank Level Gauge Error Code Database............................................. 41
Table 12. Tank Probe Database .......................................................................... 42
Table 13. Tank Temperature Table Database ..................................................... 42
Table 14. Tank Probe Error Code Database........................................................ 42

1
Introduction
This manual describes site preparation and installation procedures for the TLS-IB and Mag Probes. Site preparation is
divided into International and U.S./Canadian installations. The sections that describe how to connect probe, IFSF, and
Serial Comm wiring to the TLS-IB, and troubleshooting/maintenance procedures are common to all locations.
The TLS-IB is mounted in a non-hazardous area of the site and monitors up to eight in-tank Mag Probes located in the
hazardous area of the site.
This manual assumes that you installing the TLS-IB in a new site (before pavement is put down and with no wiring runs
in place). After the TLS-IB is installed, you should setup and configure the unit via the IFSF network.
Related Manuals
576013-635 Veeder-Root RS-232 Serial Interface Manual
576013-858 Direct Burial Cable Installation Instructions
577013-578 Contractor’s Site Prep Guide
Contractor Certification Requirements
Veeder-Root requires the following minimum training certifications for contractors who will install and setup the
equipment discussed in this manual:
Level 1 Contractors holding valid Level 1 Certification are approved to perform wiring and conduit routing,
equipment mounting, probe and sensor installation, tank and line preparation, and line leak detector
installation.
Level 2/3 Contractors holding valid Level 2 or 3 Certifications are approved to perform installation checkout, startup,
programming and operations training, troubleshooting and servicing for all Veeder-Root Tank Monitoring
Systems, including Line Leak Detection and associated accessories.
Warranty Registrations may only be submitted by selected Distributors.
Safety Symbols
The following safety symbols may be used throughout this manual to alert you to important safety hazards and
precautions.
EXPLOSIVE
Fuels and their vapors are extremely
explosive if ignited.
FLAMMABLE
Fuels and their vapors are extremely
flammable.
ELECTRICITY
High voltage exists in, and is supplied
to, the device. A potential shock haz-
ard exists.
TURN POWER OFF
Live power to a device creates a
potential shock hazard. Turn Off
power to the device and associated
accessories when servicing the unit.
OFF

TLS-IB Site Prep Manual Safety Symbols
2
WEAR EYE PROTECTION
Fuel spray from residual pressure in
the lines can cause serious eye inju-
ries. Always wear eye protection.
INJURY
Careless or improper handling of
materials can result in bodily injury.
GLOVES
Wear gloves to protect hands from
irritation or injury.
READ ALL RELATED MANUALS
Knowledge of all related procedures
before you begin work is important.
Read and understand all manuals
thoroughly. If you do not understand
a procedure, ask someone who does.
WARNING
Heed the adjacent instructions to
avoid equipment damage or personal
injury.
STATIC SENSITIVE COMPONENTS
Wear grounded anti-static wrist strap
before handling a TLS-IB CPU board.

TLS-IB Site Prep Manual Control Drawing
3
Control Drawing
Figure 1. Control Drawing Showing an Example TLS-IB System Site Layout
MP
MP
Non-Hazardous Area
120 OR 240 VAC
MP
Magnetostrictive Probe
tlsnt\sysdia.eps
Hazardous
Area
DISPENSERS
Forecourt
Epoxy Sealed Connection in
a Weatherproof Junction Box
Seal-Off
LEGEND
Rigid Conduit (Ducting)
IS
IS
PA
Conduit Enters Console in an
Intrinsically Safe Area Knockout
Conduit Enters Console in a
Power Area Knockout
IS
PA
Product piping
Double Wall Tank
Single Wall Tank
Single Wall Tank
MP
DP
Intrinsically safe wiring shall be installed in accordance with Article
504-20 of the latest National Electrical Code (NFPA 70).
Note: Conduit (ducting) requirements are dependent on local electrical
regulations. For probe-to-console wiring, shielded cable is required
regardless of conduit requirements.
WARNING:
Substitution of components may impair intrinsic safety.
Circuitry within the TLS-IB Console barrier forms an intrinsically safe,
energy-limited system. This system makes TLS-IB probes safe for use
in a Class I, Group D hazardous location. TLS-IB probe wiring is
intrinsically safe only when connected to Veeder-Root's TLS-IB
Consoles. Reference Form Number 8466 TLS-IB Console and Form
Numbers 8462, 8463, 8473, and 8493 (Probes).
Circuit breaker panel
or Fused, switched,
neon indication spur
VEEDER-ROOT
INTERCONNECTION BOX
TLS-IB
TLS-IB

4
Site Prep - International Installations
General
This document describes the procedures necessary to prepare the site, ready for the installation of the Veeder–Root TLS
Series Underground Storage Tank Monitoring Systems.
This manual does not cover the site preparation necessary for the installation of Veeder–Root Delivery Information
Systems (DIS). For information on these products please refer to the relevant manuals for DIS-500, DIS-100, DIS-50,
and DIS-T systems.
Veeder–Root maintains a continuous process of product development and therefore product specifications may not be as
described in this manual. Please contact the Veeder-Root office nearest you, or visit our website at www.veeder.com for
information on new or updated products. Changes affecting products or procedures described in this manual will be
reported in subsequent revisions. Veeder–Root has taken every care in the compilation of this manual; however it is the
installers' responsibility to take every precaution to safeguard themselves and others.
Every person working with Veeder–Root equipment is expected to take every safety precaution possible and to have read
this manual, particularly the sections referring to health and safety.
Deviation from the specifications contained in this manual can result in rework, delays in system installation and
additional installation charges.
Contractors are advised to contact their nearest Veeder–Root office where local conditions may preclude using the
specifications contained in this manual.
INSTALLATION LEVELS
Veeder–Root require that certain facilities are installed by contractors, nominated by the customer, prior to Veeder–Root
attending the site for the installation of a TLS-IB system. These facilities vary dependent on the installation contract
agreed between Veeder–Root and the customer. Two levels of site preparation exist and are described below:
Level 1 Installation
The customer or his elected contractor will supply (unless stated otherwise) and install the following:
Console power supply and earth.
External devices power supply and cabling.
Peripheral devices cabling.
Probe cable ducting
Probe field cables
Probe risers
The contractor will seal all ducting after system testing has been carried out.
Level 2 Installation
The contractor will install the following:
TLS-IB power supply and earth
External devices power supply and cabling
Probe cable ducting
The contractor will seal all ducting after system testing has been carried out.
NOTE

TLS-IB Site Prep Manual Health and Safety
5
IMPORTANT! Unless stated otherwise, instructions in this manual refer to both levels of site preparation .
IN–TANK PROBES
Magnetostrictive Probes are capable of performing precision tank testing as described by the United States
Environmental Protection Agency [0.38 litres per hour (0.1 gph) and 0.76 litres per hour (0.2 gph)] when combined with
the in-tank leak testing features of a TLS Console.
For further information on the performance and specification of in-tank probes, please contact your local Veeder-Root
representative.
Health and Safety
SAFETY SYMBOLS
The following safety symbols may be used throughout this manual to alert you to important safety hazards and
precautions.
GENERAL
Ensure that all local council, U.K. and E.C. laws and regulations are complied with. Also ensure that all recognised
safety codes are followed.
Every person working with Veeder–Root equipment is expected to take every safety precaution possible in the
installation of the TLS-IB and probes.
Contractors must ensure that supervisory personnel on the installation site are aware of their presence and requirements,
especially the provision of safe working areas and isolation from AC electrical power.
Leaking underground tanks can create serious environmental and health hazards. It is the contractor's responsibility to
comply with the instructions and warnings found in this manual.
Reference manual number 577013-578 for additional product safety information.
Explosive
Fuels and their vapors are extremely explosive if ignited.
Read All Related Materials
Knowledge of all related procedures before you begin work is important. Read and understand
all manuals thoroughly. If you do not understand a procedure, ask someone who does.

TLS-IB Site Prep Manual Tank Lid Access Chambers
6
DANGER AREAS
If the underground storage tank to be fitted with a TLS system either contains or at any time has contained petroleum
products then the tank inspection chamber must be considered a hazardous environment as defined in IEC EN 60079-10
Classification of Hazardous Areas. Suitable working practices for this environment must be observed.
INTRINSIC SAFETY
The design of Veeder-Root products limits the power in the wiring to the in-tank probes and keeps this wiring physically
separated from any other. It is the responsibility of the contractor to maintain the effectiveness of these safety features by
preparing the installation site in accordance with the instructions and warnings which follow. Failure to do so could
create danger to life and property.
Circuitry within the probe and console barrier forms an intrinsically safe, energy limited system. This system makes the
probes suitable for use in hazardous locations. Probe wiring is intrinsically safe only when connected to the TLS-IB unit.
IMPORTANT! Substitution of specified components may impair intrinsic safety.
All probe wiring must be contained in dedicated ducts.
Tank Lid Access Chambers
ACCESS CHAMBER INSTALLATION
The installation of the tank access chamber is the responsibility of the customer or their local site contractor and not that
of Veeder-Root Environmental Systems Limited. However, there are certain requirements which need to be met to allow
the correct installation of Veeder-Root in–tank monitoring probes. A typical installation is illustrated in Figure 2.
WARNING
TLS System products will be operated near the highly combustible
environment of a fuel storage tank.
Failure to install these products according to the instructions contained in this
manual may result in explosion and personal injury.
It is essential that the warnings and instructions in this manual are carefully
read and followed to protect both the installer and others from serious or
fatal injury.
WARNING
An explosion could occur if other wires share ducts with intrinsically safe
probe wiring. Ducting from probes must not contain any other wiring circuits.
Failure to comply with this warning could result in explosion, death, serious
personal injury, property loss or equipment damage.

TLS-IB Site Prep Manual Tank Lid Access Chambers
7
.
Figure 2. Typical Tank Lid Access Chamber Installation
IMPORTANT! To allow adequate space for probe installation and servicing, it is recommended that the access chamber
is a minimum 750 mm deep and 600 mm wide at the base (see Figure 3 on page 7).
Veeder–Root are able to make special provision for tank lid access chambers of restricted depth. Contact your Veeder–
Root Account Administrator at the address given on page 4.
PROVISION FOR PROBE RISERS
A dedicated Probe tapping of either 2-inch BSP, 3-inch BSP (preferred) or 4-inch BSP must be provided. For maximum
height–to–volume accuracy, the probe socket must be as close as possible to the longitudinal axis of the tank.
IMPORTANT! The probe entry must not be obstructed by other pipe work. A free area above the probe socket of at least
100 mm radius from its centre must be provided. For Level 2 Installations probe entry plugs must be loosened and
readily removable. Failure to provide sufficient access or to loosen plugs will cause delays in system installation and
could result in additional charges.
Figure 3. Tank Lid Access Chamber — Critical Dimensions
Veeder-Root
Riser Assembly
Mag Probe
Foam Plug
Dedicating Ducting
Probe Cable
to TLS-IB
uk\tls\tnklidnt.eps
Veeder-Root
Probe Riser
Assembly
Min. 100 mm dia.
Rigid PVC Ducting
Sealed for min.300 m
m
100 mm rad.
min. clear
Minimum 600 mm
Bottom of tank lid Bottom of tank lid
Minimum 750 mm
uk\tls\tklddmnt.eps

TLS-IB Site Prep Manual European Probe and Riser Installation Criteria (Non-PTB)
8
Where mechanical overfill prevention devices are installed, contractors must ensure that no part of these devices
will be obstructed when the probe and riser assembly is installed. Failure to comply with this warning may result
in the overfill prevention device not operating correctly.
European Probe and Riser Installation Criteria (Non-PTB)
All Mag Probes require installation using a 3-inch riser, regardless of tank entry size. All entry sizes, other than 3 inches,
must be adapted to 3 inches with suitable fittings. The minimum probe entry size that can be used is 2 inches.
Where possible, the canister of the probe should be completely contained within the 3-inch riser. In all cases, the probe
must rest on the bottom of the tank (see Figure 4).
IMPORTANT! Incorrect readings will result if the probe is not resting on the bottom of the tank.
Figure 4. Typical Probe Installations
GENERAL NOTES
• 3-inch risers, when fitted, should be a minimum of 100 mm above the probe canister (see Figure 5).
Figure 5. Minimum clearance above probe canister
probes\euro5.eps
2" Riser
Riser must be
2" ID and free
of burrs.
3" Riser 3" Riser
4"- 3" Reducing
bushing
4" Entry3" Entry2" Entry
Probe on tank bottom
Probe on tank botto
m
Fitted riser
1
00 mm minimum
probes\euro3.eps

TLS-IB Site Prep Manual European Probe and Riser Installation Criteria (Non-PTB)
9
• Wherever possible, the probe canister should be completely contained within the 3-inch riser. If this is not possible, a
probe sleeve kit must be used. Probe sleeve kits provide both electrical insulation and lateral stability for the probe
(see Figure 6).
Figure 6. Probe canister sleeve kit installation
IMPORTANT! When using probe sleeve kits, a minimum length of 75 mm of probe canister must be contained within
the 3-inch riser. Check also that the full safe working capacity of the tank can be measured by the probe chosen.
• Probes specified for tanks with entries smaller than 3 inches must always be long enough to rest on the tank bottom
and not ‘hang’ in the riser adaptor (see Figure 7).
Figure 7. Canister clearance for 2-inch entries
• Veeder-Root make special provision for tank lid access chambers of restricted depth. Contact Veeder-Root Technical
Support or your Sales Administrator for details on custom length Mag Probes and low profile riser kits, having the
dimensions listed in Figure 8 available.
1
00 mm minimum
probes\euro4.eps
Probe sleev
e
kit
Sleeve kit
not required
Probe
insulators
75 mm
minimum
Probe on tank bottom
3" Riser
Adequate clearance required
between base of probe caniste
r
and adaptor reduction.
3
" to 2" Reducing socket
2" Barrel nipple
2" entry
100 mm minimum
probes\euro2.eps

TLS-IB Site Prep Manual Probe Riser Pipe Installation (Level 1 Installation Only)
10
Figure 8. Dimensions needed to calculate custom probes and risers
Probe Riser Pipe Installation (Level 1 Installation Only)
A Veeder-Root riser kit (see Figure 9) consisting of a riser and a cap assembly, designed specifically for the efficient
installation of Veeder-Root Magnetostrictive Probes, is available (Part No 705-100-1204). The riser cap assembly is
normally fitted at the time of probe installation by Veeder-Root authorised engineers. An optional cable shield is
available, if required (Part No 705-100-4115).
Figure 9. The Veeder-Root Riser Cap Assembly and Fitting Tool
IMPORTANT! Veeder–Root strongly recommend the use of this riser assembly.
Non–standard risers may be made from 3-inch nominal bore galvanised steel pipe threaded 3-inch BSPT at each end.
"B"
"E"
"A"
"D"
"C"
probes\euro1.eps
A - Tank diameter (internal)
B - Tank bottom to top of tank lid
C - Height of probe entry
D - Probe entry size
E - Vertical clearance for riser assy, above tank lid at probe entry
Dimensions
Shield (if required)
Probe leader cable gland
Use fitting tool 705-100-3033
to install or remove the cap
3-inch BSP riser cap
Label

TLS-IB Site Prep Manual PTB Compliant Installation
11
Remove the plug from the tank socket. Install a 3-inch (80 mm nominal bore) riser using an appropriate thread sealing
compound. Reducers are available for 4-inch (110 mm nominal bore) and 2-inch (50 mm nominal bore) sockets. If the
probes are not to be installed immediately, cap the riser.
PTB Compliant Installation
Applicable only where Physicalisch–Technishe Bundesanstalt (PTB) regulations are in force.
PROBE ENTRY
Certain markets require a modified probe fixing arrangement consisting of a gland mounted directly to the tank lid.
Either a dedicated tapping or a suitable flange tapped G2inch 11tpi to DIN 2999 (BS2779) must be provided. The probe
installation arrangement is illustrated in Figure 10. Veeder-Root recommend the use of a riser to provide protection to the
Mag Probe Canister.
Figure 10. PTB Compliant Installation of a Mag Probe
DETERMINING THE CORRECT PROBE LENGTH
Refer to Figure 8 on page 10 and carry out the following procedure.
1. Enter dimensions A, B, C, and E in Table 1 below.
2. Add dimensions B + C and enter this in column “F”.
3. Add a 50mm allowance for the PTB gland to the dimension in column “F” and enter the result in column “G”.
4. Select a standard probe length that is equal to or greater than the dimension in column “G”.
5. Enter the Standard Probe Length in column “H”.
Probe leader cable
Probe canister
Encapsulated connectio
n
Field cables to console
2-inch BSP thread for
fitting a protective riser
(recommended)
Gland assembly
Flange
Tank lid

TLS-IB Site Prep Manual TLS-IB Location
12
DETERMINING THE MINIMUM ACCESS CHAMBER DEPTH
The minimum access chamber depth, is calculated as follows:
1. To the chosen Standard Probe Length (“H”), add 450mm, this is the overall probe length, enter this in column “I”.
2. From the Overall Probe Length subtract dimension “B + C” (bottom of tank to top of probe flange); the result is the
minimum access chamber depth. Enter in column “J”.
3. Calculate the actual access chamber depth, Dimension “E” minus dimension “C” and enter in column “K”.
4. Calculate the probe clearance (“K” – “J”) and enter in column “L”.
IMPORTANT! Column “L” must be zero or a positive number. If the result is a negative number contact your
Veeder–Root Account Administrator.
TLS-IB Location
The TLS-IB should be located on an inside wall of the forecourt building Be sure the console will be protected from
vibration, extremes in temperature and humidity, rain and other conditions that could cause equipment malfunction.
The equipment is designed to operate safely under the following range of conditions:
• Altitude up to 2000 m.
• Temperature range of 0 to 40°C.
• A maximum relative humidity of 95% RH (non-condensing) at temperatures up to 40°C.
• Main supply voltage fluctuations not exceeding +/- 10%
• Pollution Degree Category 2 Installation Category II
IMPORTANT! The TLS-IB unit must be installed within the interior of buildings.This unit is not suitable for any
external location.
Ensure that the TLS-IB is located where neither it nor its associated cabling will be damaged by doors, furniture,
barrows, etc. Consider the ease of routing wiring, ducting and probe cables to the unit.
Overall dimensions and weight of the TLS-IB are: height - 163 mm, width - 188 mm, depth - 50 mm, weight - 1.8 kg.
Table 1. “PTB” Compliant Installation — Calculation sheet for determining the correct probe length
TANK
No.
ABCE F
Bottom of
Tank to
Top of
Probe
Entry
“B”+“C”
G
Probe
Minimum
Active
Length
“F”+50mm
H
Standard
Probe
Length
I
Overall
Probe
Length
“H”+450mm
J
Minimum
Access
Chamber
Depth
“I”-”F”
K
Actual
Access
Chamber
Depth
“E”-”C”
L
Probe
Clearance
“K”-”J”
1
2
3
4
5
6
7
8

TLS-IB Site Prep Manual TLS-IB Location
13
To allow for maintenance ensure that the console is in an accessible area, even when the console doors are open.
IMPORTANT! If the unit requires cleaning, do not use any liquid materials (e.g. cleaning solvents). It is recommended
that the unit be wiped with a clean dry cloth when necessary.
Ensure that all relevant subcontractors and other personnel are aware of the selected location.
The TLS-IB is installed by Veeder–Root authorised engineers.
TLS-IB power must come from a dedicated circuit via a fused, switched, neon indication spur within 1 metre of the
console position. The spur must be clearly marked to identify it as the means for disconnecting the console. Input power
must be a 24-hour clean supply. A typical installation is shown in Figure 11.
Figure 11. Typical TLS-IB Installation
tlsnt\tlsibmnt.eps
1000 mm
(Maximum)
1500 mm
(Maximum)
One 5 ampere fused,
switched, neon indication
spur (for 240 Vac), or a
dedicated circuit breaker
rated for 15 amperes, 120 Vac
or 240 Vac. NOTE, circuit breaker
must be marked as the power
disconnect for the TLS-IB Console.
IFSF cable
Conduit for probe
field cables
Alternative knockouts
for cable entries
VEEDER-ROOT
INTERCONNECTION BOX
TLS-IB
TLS-IB

TLS-IB Site Prep Manual Mounting the TLS-IB
14
Mounting the TLS-IB
Install the TLS-IB fastening devices to the mounting surface using the hole pattern 170 x 145mm (6.7 x 5.7 inches)
shown in Figure 12. Mounting screws up to 4.7mm (3/16-inch) diameter may be used.
Mount the TLS-IB to the mounting surface using the four mounting flanges on the back of the unit. Install ducting or
conduit between the TLS-IB and the power panel. Figure 12 shows the three designated knockouts (one each on top, left
side, and bottom) through which power wiring can safely enter the TLS-IB.
Figure 12. TLS-IB Dimensions and Designated Conduit Knockouts
0.34'' (8,6) typ.
0.34'' (8,6) typ.
7.4" (188)
6.4''
(163) 5.7'' (145)
2" (50)
5.3'' (135)
1.24''
(31)
5.3'' (135)
0.54" inside (M12 conduit),
1/2'' I.P.S. (International Pipe Size) outside (PG7 conduit)
knockouts 4 places - bottom (2), left side (1), and top (1)
1/2", 3/4'', & 1'' I.P.S.
conduit knockout pattern (2 place
s)
Cover (shown open
for reference)
tlsnt\ibdim.eps
0.22'' (5,6) dia.
mounting holes (4 places)
0.93'' (23)
0.93'' (23)
3''
(73)
0
.7''
(
17)
0.93''
(23)
6.7" (170)
NOTE: Numbers
in parenthesis are
in millimetres.
0.93''
(23)

TLS-IB Site Prep Manual Cable Specifications
15
Cable Specifications
The cable type tables listed below form part of the individual system ATEX approval. Substitution of cable may
impair intrinsic safety and may invalidate system approval.
All specifications are in free air at +30°C:
Table 2. Probe Cable Specification (V-R P/N 222–001–0029) - Maximum of 305 metres per probe
Number of Cores 2
Conductors Bare copper, 24/0.20mm, diameter 1.1mm
Insulation PVC R2 to CEI 20-11, colour black 1/black 2, radial thickness 0.54mm, twisting 1x 2, lay pitch 76mm
Shielding Aluminium polyester tape, tinned copper drain wire 7/0.30mm
Sheath PVC RZ FR hydrocarbon resistant, colour blue, radial thickness 0.80mm
Diameter 6.10mm
Conductor Resistance 25 ohm/km
Drain Wire Resistance 15 ohm/km
Capacitance 0.14
μ F/km (140 pF/m)
Inductance 0.65 mH/km (0.65
μ H/m)
LR Ratio 17
μ H/ohm
Insulation Resistance 1050 Mohm/km
Voltage Core to Core 500
Voltage Core to Screen 500
Voltage Earth to Screen 500
Voltage Test 1kV/1 minute
Standard IEC 227-74
Table 3. Data Transmission Cable Specification (V-R P/N 4034-0147)
Cable Type 2 x twisted pair, PVC insulated, foil wrapped, common drain
Conductor Stranding 7/0.25mm
Characteristic Impedance 58 ohms
Capacitance 203 pF per metre
Attenuation 5.6 dB per 100 m
Operating Temp. Range –30°C to +70°C
Insulation PVC
Sheath Polyethylene
