Veldink4kids Kiddo Space User manual

Kiddo Space
Instructions for use

Kiddo Space 2
These instructions for use have been compiled with the greatest possible care and are based on
the information known to Veldink4kids at the time of publication.
The information in these instructions for use applies to the standard product version. Veld-
ink4kids assumes no liability for potential damage caused by the product being modified or
manipulated after sale. In addition, Veldink4kids cannot be held liable for damage caused by the
actions of third parties. Therefore, no rights can be derived from this text. Changes reserved.
Date of last update: 2023-01-12
Veldink4kids team

Kiddo Space 3
Contents
1Foreword...................................................................................................................................5
2Intended use.............................................................................................................................5
2.1Indications for use............................................................................................. 5
2.2Indications ....................................................................................................... 5
2.3Contraindications.............................................................................................. 6
2.3.1Absolute contraindications ................................................................................. 6
2.3.2Relative contraindications .................................................................................. 6
3Safety provisions .....................................................................................................................6
3.1Explanation of warning symbols .......................................................................... 6
3.2Safety notices ................................................................................................... 6
3.3Explanation of symbols .................................................................................... 10
3.4Positioning of the stickers ................................................................................ 11
4Side effects.............................................................................................................................11
5Warranty..................................................................................................................................11
5.1.1Terms and conditions ...................................................................................... 11
6Technical data ........................................................................................................................13
7Product overview ...................................................................................................................15
8Handing over the product .....................................................................................................16
9Settings ...................................................................................................................................16
9.1Seat depth, back support height and back support angle .................................... 17
9.1.1Adjusting the seat depth .................................................................................. 17
9.1.2Adjusting the back support height..................................................................... 18
9.1.3Adjusting the back support angle...................................................................... 19
9.2Seat height, seat angle .................................................................................... 19
9.2.1Adjusting the seat height.................................................................................. 19
9.2.2Adjusting the seat angle................................................................................... 20
9.3Knee and foot angle ........................................................................................ 22
9.3.1Adjusting the knee angle.................................................................................. 22
9.3.2Adjusting the lower leg length........................................................................... 22
9.3.3Adjusting the foot angle ................................................................................... 22
9.3.4Attaching the foot plate .................................................................................... 23
9.4Head support (optional) ................................................................................... 23
9.4.1Adjusting or removing the head support height................................................... 23
9.4.2Adjusting the head support .............................................................................. 24
9.5Tray (optional) ................................................................................................ 25
9.5.1Attaching/removing the tray .............................................................................. 25
9.5.2Adjusting the height of the tray.......................................................................... 26
10General operation ..................................................................................................................27
10.1Disassembly and weight of the Kiddo Space ...................................................... 27
10.2Wheel assembly and function of the wheel lock .................................................. 27
10.2.1Removing/attaching the drive wheel .................................................................. 27
10.2.2Operating the push-to-lock wheel lock............................................................... 28
10.3Anti-tipper ...................................................................................................... 28
10.3.1Deactivating the anti-tipper............................................................................... 28
10.3.2Activating the anti-tipper .................................................................................. 29

Kiddo Space 4
10.3.3Adjusting the length of the anti-tipper ................................................................ 29
11Using the product ..................................................................................................................30
11.1Water, sand, scraps of food, litter, etc............................................................... 30
11.2Assistance by an attendant............................................................................... 30
11.3User .............................................................................................................. 30
11.4Centre of gravity ............................................................................................. 30
11.5Getting dressed and changed .......................................................................... 31
11.6Wheelies (balancing on the drive wheels) .......................................................... 31
11.7Stretching out your arms or leaning out ............................................................. 31
11.8Hills and slopes .............................................................................................. 32
11.9Transferring (from the wheelchair to another seat or vice versa) ........................... 32
11.10Curbs and steps ............................................................................................. 33
11.11Using stairs .................................................................................................... 33
11.12Safety locks.................................................................................................... 34
11.13Surfaces ........................................................................................................ 34
12Transport.................................................................................................................................34
12.1Transport without the user................................................................................ 34
12.2Use in vehicles for transporting persons with reduced mobility ............................. 34
12.2.1Positioning belt ............................................................................................... 37
12.2.2Restrictions for use ......................................................................................... 37
13Malfunctions and maintenance............................................................................................38
14Cleaning and care ..................................................................................................................39
15Recycling and the environment............................................................................................39
16Information on re-use............................................................................................................40
17Lifetime ...................................................................................................................................40
18Environmental conditions .....................................................................................................40
19Appendices.............................................................................................................................41

Kiddo Space 5
1Foreword
The Kiddo Space wheelchair has been built in line with the requirements and wishes of future
users following extensive adaptations. It is made to measure. Numerous options and accessories
are available. This enables a precise, custom fit to be achieved. The wheelchair is easy to adjust
and adapt. As a rule, the wheelchair can grow with the user starting from the size supplied.
The manufacturer recommends checking the product settings regularly to ensure optimal fitting
over the long term. A six-monthly review is recommended for children and adolescents in par-
ticular.
The Kiddo Space is manufactured in accordance with the Medical Device Regulation (MDR)
2017/745.
The wheelchair has been tested and approved for the safe transport of children in vehicles ac-
cording to ISO 7176-19 and tested in accordance with the applicable requirements of the Euro-
pean wheelchair standards EN 12182 and EN 12183 with positive results.
Report each serious incident related to the product to the manufacturer and to the relevant
authority in your country. This is particularly important when there is any worsening of the state
of health.
New information regarding product safety and product recalls as well as the declaration of con-
formity can be obtained from the manufacturer's service department.
You can request this document as a PDF file from the manufacturer's service department. The
PDF file can also be displayed in a larger size.
Veldink4kids is sure this product will meet your expectations and hopes you will enjoy using it.
2Intended use
The safe use of the product can be ensured only if it is used as intended in accordance with the
information contained in these instructions for use. The user is ultimately responsible for acci-
dent-free operation.
2.1 Indications for use
The wheelchair is intended for everyday indoor and outdoor use, by the user or an attendant, of
people with temporary or permanent limitations of the ability to walk, inability to walk or diffi-
culty standing up.
The wheelchair is suitable for users with intact skin whose anatomy (such as body dimensions
and weight) permits the intended use of the product.
The maximum user weight is 50 kg.
The wheelchair may be used only with the options listed on the product order form.
Veldink4kids assumes no liability for combinations with medical devices and/or accessories for
a medical device from other manufacturers outside the modular system.
Combinations that have been evaluated for effectiveness and safety based on a combination
agreement, for example, are an exception to this.
2.2 Indications
Minor to pronounced or complete restrictions of mobility

Kiddo Space 6
2.3 Contraindications
2.3.1 Absolute contraindications
None known
2.3.2 Relative contraindications
Failure to meet physical or mental requirements
3Safety provisions
3.1 Explanation of warning symbols
Caution: Warning regarding possible risks of accident or injury.
Warning: Warning regarding possible serious risks of accident or injury.
3.2 Safety notices
Please read these instructions for use carefully before putting the product into use. All users
and/or their attendants must be instructed in the use of the product by qualified personnel. In
particular, users and/or attendants must be informed of the residual risks with the aid of the
safety notices in these instructions for use.
Failure to follow the safety regulations, instructions, warnings and advice may adversely affect
the functionality of the product and result in physical injury to the user or damage to the product
or the environment.
Warning
The Kiddo Space has been tested and approved for the safe transport of children in
vehicles according to ISO 7176-19.
If possible, we recommend using a properly approved seat in the vehicle during
transport and storing the product securely in the vehicle's cargo compartment.
Use an approved 4-point restraint system to secure the seat and its occupant in a
transport vehicle. The optional seat belt is not a safety belt.
Also use an approved 3-point safety belt to transport the user safely (in the forward-
facing position).
If you need to sit in the wheelchair for extended periods of time, you should regularly
change your sitting position, move around or try to stand up briefly. Check that there
are no seams, folds or other irregular pressure points on the back support and seat.
This helps prevent sores (pressure ulcers).
Check your skin for intactness before and during use of the product. If skin damage or
other problems occur during use, stop using the product. Consult the qualified per-
sonnel.
Never reach too far out of the product, as you may fall over.
Drive slowly when crossing obstacles (e.g. steps, curbs) and negotiating uphill or down-
hill slopes and inclines.
Never cross obstacles at an angle. Always approach obstacles head on (at an angle of
90°). Raise the caster wheels before crossing obstacles.
Avoid collisions with obstacles and dropping off curbs/ledges.
Avoid driving on unpaved ground.

Kiddo Space 7
Cross railway property and railway tracks only in the designated areas. Negotiate level
crossings so the caster wheels of the product cannot get caught in the gap between
the rail and the road surface.
Speeds above 5 km/h can be dangerous if you have not had enough practice.
Never drive at too high a speed through a bend or swerve quickly and sharply. This
could make you fall over.
Do not cross obstacles unless you are sure you can perform the manoeuvre safely.
Attaching loads (e.g. backpacks) can adversely affect stability. Therefore, suspending
additional loads on the product is not permitted.
Use an anti-tipper unless you are an experienced wheelchair user.
Never lift the product by its moving or removable parts. Only lift the product by firmly
mounted components.
If your wheelchair is equipped with height-adjustable push handles, ensure that the
clamping levers are always firmly tightened.
The seat and back support upholstery as well as seat cushions, pads and covers comply
with the normative requirements for flame resistance. However, they may still ignite if
fire is handled improperly or negligently. Keep away from all ignition sources.
The upholstery and the frame can become very hot during prolonged exposure to sun-
light. Do not expose the product to any extreme temperatures (e.g. direct sunlight,
sauna, extreme cold). Do not leave the product in the immediate vicinity of heaters.
When negotiating an incline, the centre of gravity shifts to the rear and the product
tilts more easily.
When ascending slopes or ramps, or when crossing obstacles on upward slopes, always
lean your upper body far forward. If users cannot lean their body forward, attendants
must secure the rear.
When descending a slope, the centre of gravity shifts forward and the user can more
easily fall forward out of the product.
Do not reach into the spokes of the rotating drive wheel.
Pay attention not to pinch parts of your body at the wheel lock lever or between the
side or frame parts.
Do not reach between the drive wheel and wheel lock or drive wheel and side panel
when driving the product.
Never change the design of the product.
The product has labels, safety symbols and instructions attached to it. They must not
be covered or removed. They must remain in place and be clearly legible throughout
the lifetime of the product.
Before using the product, verify that all parts of the product are properly assembled
and tightened.
Check the product for safety and functionality after changing the settings. In case of
problems with the settings, please contact the qualified personnel who adjusted your
product.
Keep packaging materials out of the reach of children.
Note that the product includes small parts that can be loosened and removed without
tools. Ensure that small children, for example, do not swallow them.
Using the product beyond the specified expected lifetime leads to increased residual
risk. Observe the specified lifetime.

Kiddo Space 8
Ensure that examinations and treatments are carried out only under the prescribed
conditions in order to avoid impairing the examination results or the effectiveness of
treatment due to interactions of the product with devices that are used.
When using public transit, always observe the currently applicable legal requirements
and the safety notices of the public transit operator. Use the permanently installed
seats in the vehicle. If you depend on using your product as a seat, please use the
designated wheelchair spaces and safety securing equipment provided. Always ensure
that you are held in place securely.
Putting the belt or positioning aid on incorrectly can lead to strangulation and suffoca-
tion. Follow the instructions for putting these on properly so that the user cannot slip
into a position that would endanger them. Note that the user's back must be up against
the back support pad when securing the belt or positioning aid and during use of the
product.
Caution
When manoeuvring in confined spaces, make sure you do not get stuck. If you do get
stuck, try to drive the same route in the opposite direction. Make sure there's help
around.
The product has protruding parts that could cause injury or damage in the event of a
collision. Avoid collisions for this reason.
The seat is more than 420 mm wide and the wheels have a camber of 7°, which can
cause problems in terms of the passage width.
Always have attendants help you negotiate steps and other obstacles. Use equipment
(e.g. ramps or lifts). If such equipment is not available, have 2 assistants carry you over
the obstacle.
Do not exceed the max. load (see nameplate and section 6 Technical data).
Please note that certain accessories and add-on components will reduce the remaining
load capacity.
The product may be used by one person only.
As a wheelchair user, you are particularly at risk on the road. Make sure you are always
seen by other road users. Observe the applicable traffic rules. Wear bright clothing or
clothing with reflectors.
Install active lighting on your product. Ensure that the reflectors on the product are
clearly visible.
If the product is stored for an extended period of time, it must be kept in a dry room.
The checklist in section 13 must be followed when it is time to start using the product
again.
Make sure that the push bar, back support height, forearm supports, lower leg length
and possibly the head support are set to the correct height.
Maintain a minimum distance of 5 cm between the foot plate and the floor.
Wear wheelchair gloves when travelling at high speeds in order to protect yourself
against burns while braking using the handrims.
If any faults, defects or other hazards that could lead to personal injury are detected,
the product must be taken out of service immediately. This includes uncontrolled
movements as well as unexpected or previously not noted sounds or odours that devi-
ate significantly from the state of the product at the time of delivery.

Kiddo Space 9
Additional information
Veldink4kids assumes no liability for damage or injury caused by negligence or failure
to observe safety notices. Depending on the particular circumstances or the accessories
used, additional safety notices may be required.
Ensure that the product is always in good condition.
Practise on level, open ground first.
With the support of an assistant, learn how the product reacts to changes in centre of
gravity, e.g. on downward or upward slopes, inclines or when crossing obstacles.
The maximum tyre pressure for the drive wheels is 6 bar (87 psi). If this is exceeded,
the tyre can run off the rim. The information about tyre pressure stated on the tyre
itself may differ from the maximum tyre pressure recommended by Veldink4kids. A
tyre pressure of 6 bar means less wear and tear and better driving comfort.
You can repair a flat tyre yourself or have it repaired at your local bicycle shop or by
your distributor. After repair, the tyre can be inflated by connecting the bicycle pump
to the valve nipple and pumping it.
Check the dimensions and adjust them optimally as described in these instructions for
use.
In case of problems with the settings, please contact the qualified personnel who ad-
justed your product.
Only use original parts and accessories from Veldink4kids. These have been tested and
are safe.

Kiddo Space 10
3.3 Explanation of symbols
On this page and the next, you will find explanations of the stickers used on the product and
their positions on it.
Label Meaning
1CE marking
2WARNING! Read the instructions for use be-
fore using the product. Observe important
safety-related information (e.g. warnings,
precautions).
3Max. load belonging to the serial number
4Manufacturer information/address
5Category (model name)
6Data matrix of the Unique Device Identifier
7Symbol for medical device
8Unique Device Identifier (UDI)
(01) = fixed sequence of numbers per "serial
number category"
(11) = date of manufacture: YYMMDD
(21) = serial number
9Serial number
10 Year of manufacture
This sticker shows what type of product it is.
The product has not been approved by the man-
ufacturer for use as a seat in vehicles for trans-
porting persons with reduced mobility.
1)
Tested to ISO 7176-19; the product has been ap-
proved by the manufacturer for use as a seat in
vehicles for transporting persons with reduced
mobility.
1)
Fixation point to attach the product in vehicles
for transporting persons with reduced mobility
The positions of the four attachment points on
the product are indicated by this hook symbol.
1)
Only one of these two stickers is attached to the product.

Kiddo Space 11
3.4 Positioning of the stickers
Figure 1: Signage on the product
If a sticker on the Kiddo Space is unusable or no longer legible, a new sticker can be requested
from [email protected]. The affixed CE marking can also be replaced via the customer file.
4Side effects
The following side effects may occur during use of the product:
Neck, muscle and joint pain
Circulatory disorders, risk of pressure sores
Contact a doctor or therapist in case of problems.
5Warranty
Veldink4kids products are assembled with passion and care, and are carefully checked before
they leave the factory. Should a product fail to meet your expectations, you can contact the
distributor from whom you purchased the product.
The expected lifetime of the Kiddo Space is 5 years. Veldink4kids provides a 5-year warranty on
its Kiddo wheelchairs against frame breaks. Wear and tear parts such as upholstery, tyres, colour
varnish, etc. are excluded from the warranty/statutory rights (unless these are manufacturing
defects that are reported to the manufacturer within 3 months of delivery).
5.1.1 Terms and conditions
Repairs and/or replacements of spare parts must be carried out by a distributor authorised by
Veldink4kids.
The warranty/statutory rights are only valid if, in the event of a complaint, the distributor re-
ceives information about the nature of the problem and the circumstances under which the prob-
lem occurred.
For repair or replacement, the manufacturer must be provided with the serial number together
with the correct specifications.
Within the warranty/statutory rights period, the part in question will be repaired or replaced free
of charge.

Kiddo Space 12
The warranty/statutory rights do not apply if the cause of the damage is due to any of the fol-
lowing:
If the product is not maintained accordingto the instructions provided.
If any parts used are not original parts supplied by the manufacturer. These are avail-
able from stock and can be ordered from the manufacturer.
Damage due to improper handling, negligence or accident.
Changes and/or adaptations made by third parties to the product originally supplied
by the factory without the manufacturer's express written consent.
The product described in the instructions for use is not necessarily the version that was deliv-
ered. The deviations are due to individual requests and/or changes. However, the instructions
apply universally to every version.
The manufacturer reserves the right, without prior notice, to make changes to the design, di-
mensions, etc. in order to improve the product.
Important:
The information in these instructions for use refers to the standard product version. Veld-
ink4kids assumes no liability for damage caused by the product being changed or modified after
the date it was first sold.
Furthermore, Veldink4kids cannot be held responsible for damage caused by the work of third
parties.
Important:
The Kiddo Space is supplied without spare parts. Spare parts can be ordered from Veldink4kids
and installed by Veldink4kids authorised dealers.
Important:
Veldink4kids can contact you through its contact database in case of unforeseen events. All
Veldink4kids customers are included in this telephone contact database. You will be informed
of any necessary notifications relating to the warranty or safety.

Kiddo Space 13
6Technical data
The following information applies to the Kiddo Space:
Max. load [kg] 50
Weight [kg] From 7.4
Weight of the product without wheels
[kg]
From 4.8
Weight of the heaviest part [kg] From 4.8
Seat width [mm] 160–320 *
Front seat height [mm] 370–460**
Rear seat height [mm] 360–450**
Seat depth [mm] 160–350
Overall length [mm] From 650
Overall width [mm] From 420 ***
Overall height [mm] From 520
Back support angle [°] 10

Kiddo Space 14
Back support height [mm] 160–400
Lower leg length [mm] 140–350
Angle between leg support and seat
bottom [°]
Up to 10
Horizontal axle position [mm] 255, 280 or 305
Ground clearance [mm] 30
Wheel camber [°] 7
Seat inclination [°] -10 to +10
Drive wheels ["] 20, 22, 24
Caster wheels ["] 4, 5
Permissible tyre type Air
Min. tyre pressure [bar] 4.5
Minimum turning radius [mm] 400
Handrim diameter [mm] 504, 554, 604
Max. permissible inclination [°] 10
*:Theseatwidthcanbeadjustedinincrementsof2cm.
**:Theseatheightshavebeenmeasuredincludingananatomicalseatcushion.Theseatcushionis50mmthickattheback.
***:ValuesmaybehigherthanthoserecommendedinAnnexA.1.1ofEN12183andAnnexMofthe"Technicalspecificationsforinterop‐
erabilityrelatingtoaccessibilityforpersonswithreducedmobility"(PRMTSI).Considerthenegativeeffectsthismayhaveintermsofdriv‐
ingthroughdoorwaysandalongescaperoutes,aswellasduringtransport.

Kiddo Space 15
7Product overview
Below is an illustration of the Kiddo Space.
Figure 2: Kiddo Space
1 Caster wheel 5 Seat cushion
2
Frame 6 Back support pad
3
Leg support 7 Anti-tipper
4
Braking system 8 Drive wheel with aluminium handrim

Kiddo Space 16
8Handing over the product
The following steps must be performed for the safe handover of the product:
A sitting test has to be conducted with the user of the product. Pay special attention to
proper positioning according to medical considerations.
The user and any attendants must be instructed by qualified personnel on how to use
the product safely. In particular, the enclosed instructions for use are to be used.
The instructions for use must be given to the user/attendant when the product is
handed over.
Depending on equipment: the supplied instructions for use for accessories must be
handed over as well.
9Settings
Based on the instructions, the user can adapt the product to changed conditions without con-
sulting the manufacturer.
Since everyone is built differently and there are large differences in the degree and extent of
people's disabilities, the product has been designed so it can be adapted to the person in ques-
tion.
The many settings that can be adjusted on a wheelchair like this offer numerous advantages
when it comes to achieving an optimal sitting posture and position.
Observe the following instructions for all settings:
Warning:
Incorrect settings may reduce the level of comfort when sitting in the product and stop it
being used as intended! In case of problems with the settings, please contact the qualified
personnel who adjusted your product.
Initial adjustments have been made to the product prior to delivery. However, further adaptations
may be required if the user has grown taller or for medical reasons. Practical experience has also
shown it is desirable to adjust the setting slightly.
Follow the step-by-step instructions below to set the product correctly in the most logical and
effective way. To adapt the product to the user properly, the steps must be performed correctly.
Each adaptation is dealt with separately. In practice, each setting has a greater or lesser impact
on the sitting posture and/or centre of gravity. Therefore, check after each adjustment whether
these factors have been affected and need to be corrected.
The descriptions of the various settings refer to the tightening of screws and nuts until they are
"finger-tight". This corresponds to a tightening torque of 10 Nm.

Kiddo Space 17
9.1 Seat depth, back support height and back support angle
9.1.1 Adjusting the seat depth
The seat depth corresponds to the thigh length and is measured from the front edge of the seat
to the back support.
Figure 3: Seat depth
It is important that the user is supported sufficiently over the entire seat depth if they are to
remain stable in the seat when sitting at an angle or swivelling their legs. The seat depth can be
adjusted by 45 mm from the base size.
Option 1
1. Slightly loosen the four hexagon socket screws (see Figure 4, item 1) on both sides of the
wheelchair until the seat can be pushed forward or backward.
2. After making the adjustments, tighten the four hexagon socket screws on both sides of the
wheelchair so they are finger-tight again.
Figure 4: Adjusting the seat depth
Option 2
The seat depth can also be adjusted by sliding the entire seat forward or back using the hole
pattern in the clothing guard.
1. Remove the nuts and screws from the seat brackets on both sides of the wheelchair (see Fi-
gure 5, item 1).

Kiddo Space 18
2. Reposition the seat brackets according to the hole pattern in the clothing guard (see Fig-
ure 6).
3. Reattach the seat brackets on both sides of the wheelchair using the existing nuts and
screws.
Figure 5: Repositioning the seat brackets
Figure 6: Hole pattern in the clothing guard for adjusting the seat depth
You should be able to fit 2–3 fingers in the gap between the front edge of the seat and the hollow
of the knee. This space is necessary to ensure good blood circulation in the legs and to prevent
nerves and blood vessels being pinched.
Warning: Adjusting the seat depth may affect the position of the feet in relation to the
foot support. This may need to be corrected (see section Fehler! Verweisquelle konnte nicht
gefunden werden. Fehler! Verweisquelle konnte nicht gefunden werden.) before the seat angle
is adjusted (see section 9.2.2 Adjusting the seat angle).
9.1.2 Adjusting the back support height
1. Fully loosen the two nuts on both sides of the wheelchair (see Figure 7, item 1) and remove
the carriage screws from the holes.
2. Slide the back support up or down (see Figure 10).
3. Insert the carriage screws into the holes in the new position, then tighten the two nuts (1)
on both sides of the wheelchair so they are finger-tight.

Kiddo Space 19
Figure 7: Removing the carriage screws
Figure 8: Adjusting the back support height
9.1.3 Adjusting the back support angle
1. Fully loosen the upper nut on both sides of the wheelchair (see Figure 7, item 1) and remove
the carriage screw from the hole.
2. Tilt the back support to the desired position.
3. Insert the carriage screw into the hole in the new position, then tighten the nuts on both
sides of the wheelchair so they are finger-tight again.
The positions of the rear mounting options are shown in Figure 10.
9.2 Seat height, seat angle
9.2.1 Adjusting the seat height
The seat height is the distance between the top edge of the seat and the floor. Together with
the wheel size, this distance determines how well the child can reach the handrims of the drive
wheels and is therefore very important. The seat height can be adjusted in 30 mm increments
over a range of 90 mm. Before starting the adjustment, check how much adjustment is required.
As a rule of thumb, the distance from the shoulder to the top of the tyre should be at least 2/3
and at most 3/4 of the arm length. To make adjustments, the child must get out of the wheel-
chair and both drive wheels and the seating unit must be removed.
The seat height can be adjusted by sliding the entire seat up or down using the hole pattern in
the clothing guards.

Kiddo Space 20
1. Unscrew the nuts on both sides of the wheelchair (see Figure 9, item 1) and remove the
screws from the seat brackets.
2. Slide the seat brackets along the hole pattern of the clothing guards to the new position.
The possible positions for attaching the seat brackets are shown in Figure 10.
3. Use the screws and nuts to attach the seat bracket in the new position.
Figure 9: Screw connection of the seat bracket
Figure 10: Hole pattern in the clothing guard
9.2.2 Adjusting the seat angle
The seat angle is the angle that the seat forms with a horizontal line. This angle can be set to
between -10° and +10° on the Kiddo Space. In general, a seat angle of +5° is considered comfort-
able. If the child drives primarily by themselves, a higher seat angle combined with a low seat
height is often selected. This helps to achieve stable driving behaviour and a late tilting moment
for the seat.
For example, if a child works behind a worktop for extended periods of time, a lower or even a
negative seat angle may be desirable because it activates a better sitting posture.
If a negative seat angle is desired, both seat brackets have to be replaced.
9.2.2.1 Adjusting the positive seat angle
1. Slightly loosen the four hexagon socket nuts on both sides of the wheelchair (see Figure 11,
item 1).
2. Slide the front of the seat up or down.
