USER MANUAL - H6500H HALF LENGTH BED RAILS
GENERAL EXPLANATION
ASSEMBLY INSTRUCTIONS
WEIGHT
SOLD IN PAIRS
9 lbs each
Screw Knob to attach
Bed Rail to bed frame
Installing Half Length Bed Rail
Spring Loaded Knob to
raise and lower Bed Rail
Lower bed to flat position and remove mattress.
Loosely assemble upper Clamp (Figure 1) placing spacer
between the Screw Knob and front side of the Bed Rail.
Adjusting Half Length Bed Rail
To raise or lower the Bed Rail, pull and hold
the Spring loaded Knob while sliding Bed Rail
up or down.
Check Bed Rail weekly to ensure
that Screw Knob is secure.
1
22
1
22
Spring Loaded Knob
Spring Loaded Knob
1
OPERATING INSTRUCTIONS
SPECIFICATIONS
Hook Fixed Lower Clamp under outside edge
of bed frame. (Figure 2)
Hook Upper Clamp on top of bed frame and tighten Screw Knob until secure. (Figure 3)
NOTE: Can be installed at head or foot end of bed.
NOTE: Wiggle the bed rail slightly while tightening so that the upper and lower clamps
are properly seated.
3
4
FIGURE 2
Fixed Lower Clamp & Moveable Upper Clamp
FIGURE 3
Installed Bed Rail
Visit http://www.fda.gov to view the “FDA Entrapment Zones and Guidelines”
to learn about the risks of entrapment.
› DO NOT install or use this equipment without first reading and understanding these instructions.
If you do not understand these instructions, contact your dealer or a health care professional
before attempting to install and use this equipment – Improper installation and/or use of this
product can result in entrapment, serious injury or death.
› Lifestyle Mobility Aids is not liable for personal injury or property damage due to failure to follow
the instructions or recommendations in this manual or improper use of this product.
› The Bed Rails are not to be used as bedside assist handles when getting in or out of bed and
can be damaged if excessive pressure is applied.
› The Bed Rails are to prevent the user from inadvertently rolling out of bed, NOT for
restraint purposes. If restraint is needed, consult a physician or healthcare professional.
› DO NOT use the Bed Rails as push handles when moving the bed.
› Visit http://www.fda.gov to view the “FDA Entrapment Zones and Guidelines” to learn
about the risks of entrapment.
› Clean weekly with soft cloth using mild soap or detergent
› DO NOT use organic solvents, such as acetone, or abrasive cleansers.
› Inspect weekly for wear and to ensure all components are secure. If any component appears worn
or is not working properly, contact your dealer for repair and/or appropriate replacement parts.
Limited Lifetime warranty against manufacturing defects. This warranty does not cover product failure due to misuse,
negligence, improper storage or handling, improper operation or unauthorized modifications.
It is recommended but not required that the product be returned to the Lifestyle Mobility Aids dealer through whom it was
originally purchased. However, all Lifestyle Mobility Aids Dealers are qualified to assist you in obtaining warranty service.
If the product is to be returned to Lifestyle Mobility Aids, prior authorization will be required. In the event of a defect covered
by this warranty, Lifestyle Mobility Aids will determine if the product will be repaired or replaced.
This Lifestyle Mobility Aids product is identified by a serial or lot number at the time of manufacture. Removing or
defacing the serial or lot number label may void this warranty. If you have questions about your Lifestyle Mobility
Aids product or this warranty, please contact us at [e-mail].
SAFETY PRECAUTIONS
MAINTENANCE
WARRANTY
Read entire manual prior to assembly and operation and save for future reference.
FIGURE 1
Upper Clamp & Screw Knob
RAIL WIDTH
RAIL HEIGHT
32”
18” (16” above deck)
