Velleman DVM345DI User manual

DVM345DI
DIGITAL MULTIMETER
DIGITALE MULTIMETER
MULTIMETRE NUMERIQUE
DIGITALES MULTIMETER
User Manual
Gebruikershandleiding
Manuel d’utilisation
Gebrauchsanleitung

DVM345DI GB
1
DVM345DI -- DIGITAL MULTIMETER
1. INTRODUCTION
Thank you for buying the DVM345DI. This device enables the user to measure AC and DC
voltages, AC and DC currents, resistance, capacitance and temperature. The device can be
interfaced with a computer and the user can also test diodes, transistors and audible continuity.
2. SAFETY
The meter has been designed according to IEC-1010 concerning the safety requirements for
electronic measuring instruments with an overvoltage category (CAT II) and pollution 2.
Respect the following safety instructions to ensure maximum personal safety and to keep the
device itself in good working order :
• Protect yourself against electroshocks.
• Do not use this device for any other application than those described in this manual.
• Full compliance with safety standards can only be guaranteed if the device is used with the
supplied test leads. If necessary, they should be replaced with identical leads or leads with
identical electric ratings. All test leads should be in good working order.
2.1. Use
• Never exceed the specified limit values for the various measurement ranges.
• Do not touch unused terminals when the meter is connected to a circuit.
• Place the range selector switch in the highest position if the value to be measured is
unknown beforehand.
• Disconnect all test leads from the circuit to be tested prior to selecting a different function.
• When performing measurements on TV’s or switching power circuits, the user should keep in
mind that voltage surges may occur at test points. These surges may damage the meter.
• Never perform resistance measurements on live circuits.
• Exercise extreme caution when working with voltages in excess of 60VDC or 30Vrms AC.
Keep your fingers behind the probe barriers while using the device.
2.2. Symbols
Important information with reference to safety, consult the manual !
Dangerous voltage may be present
Earth ground
Double insulation (Protection class II)

DVM345DI GB
2
2.3. Maintenance
• Always disconnect the test leads from all current sources before opening the meter.
• Replace blown fuses with an identical one or a fuse with identical voltage and current ratings
(15A/250V).
• Do not use the device and have it checked by qualified personnel if anomalies are observed
or in case of malfunction.
• Use a damp cloth and a mild detergent to clean the device. Never apply abrasives or
solvents to the meter.
3. DESCRIPTION
This device is a professional auto-ranging measuring instrument. All measured values are
displayed on a 3 ¾ digit LCD. The device is equipped with a 38-segment bar graph and can be
used to measure DC & AC voltages (both auto-ranging), DC & AC current, temperature,
resistance (auto-ranging) and capacitance. The user can also test diodes, transistors and
audible continuity.
3.1. "ON/OFF"-push button
Used to turn the device ON or OFF. The beeper sounds when this button is pushed.
3.2. DC/AC-RU -button
8VHGWRVHOHFW'&RU$&YROWDJHUDQJH'&RU$&FXUUHQWUDQJH RU range. The beeper
sounds when this button is pushed.
3.3. "R-H" button
Press this button to switch to manual operation when the device is in the auto-ranging mode. "R-H"
will be displayed. Hold the button for more than one second to return to the auto-ranging mode.
Push this button to change the voltage ranges as follows : 4V →40V →400V →1000V.
3XVKWKLVEXWWRQWRFKDQJHWKHUHVLVWDQFHUDQJHVDVIROORZV0 →0 →N →N 
→N →
3.4. "B/L"-button
Press this button to turn the back light ON or OFF.
3.5. Input Jacks
This meter has 4 input jacks with overload protection. Connect the black test lead to the "COM"-
jack and the red test lead to the following input jacks :
Function Red Lead Connection Input Limit
VDC/VAC 9 1000VDC or 750Vrms AC
9 250VDC or 250Vrms AC
9 250VDC or 250Vrms AC
mA mA 400mA DC or rms AC
10A 10A 10A DC or rms AC

DVM345DI GB
3
3.6. Description of the Front Panel
Display
"ON/OFF" push button
Transistor socket
Function switch
Capacitance or temperature socket
Input jacks
RS232C socket
"B/L"-button
"R-H" button
DC/AC- or -button
4. OPERATION
4.1. Voltage Measurements
1. Connect the black test lead to the "COM"-MDFNDQGWKHUHGWHVWOHDGWRWKH9 -jack.
2. Place the function switch in the -position and connect the test leads to the source you wish
to measure.
3. Select the VDC- or VAC-mode with the "DC/AC"-button (push "R-H" for manual range
selection).
4. The measured value will be displayed on the LCD. The polarity of the red test lead is
indicated with DC measurements.
4.2. Current Measurements
1. Connect the black test lead to the "COM"-jack and the red test lead to the "mA"-jack for
measurements up to 400mA. Switch the red test lead to the "10A"-jack for measurements up
to 10A.
2. Place the function switch in the "4mA"-, "400mA"- or "10A"-position and use the "DC/AC"-
button to select either the DCA- or the ACA-mode.
3. Connect the test leads in series with the load in which the current is to be measured.
4. The measured value will be displayed on the LCD. The polarity of the red test lead is
indicated with DC measurements.

DVM345DI GB
4
4.3. Resistance Measurements
1. Connect the black test lead to the "COM"-jack and the red test lead to the "V/ -jack. The
polarity of the red test lead is positive (+).
2. 3ODFHWKHIXQFWLRQVZLWFKLQWKH -range to be used and connect the test leads to the
resistance you wish to measure.
NOTE :
v The device may need a few seconds to produce a stable reading when measuring
UHVLVWDQFHVLQH[FHVVRI0 7KLVLVHQWLUHO\QRUPDO
v The message "OL" and the full bar graph will be displayed if the input is not connected, e.g.
with an open circuit.
v Disconnect the circuit to be tested and make sure that all capacitors have been fully
discharged before measuring the in-circuit resistance.
4.4. Capacitance Measurements
1. Place the function switch in the "nF"-position.
2. Make sure that the capacitor has been fully discharged prior to connecting the capacitor to
the capacitance socket.
WARNING :
Disconnect all test leads from the circuit to be tested before inserting the capacitor in the
capacitance socket. Make sure that no components are connected to this socket when
performing voltage measurements with test leads.
4.5. Temperature Measurements
1. Place the function switch in the "TEMP"-position.
2. Connect the "K"-type thermocouple with the temperature socket on the front panel and
contact the object in question with the thermocouple.
WARNING :
Remove the thermocouple before selecting a different function in order to avoid electroshocks.
Do not connect the thermocouple to the "TEMP"-socket unless all test leads have been
disconnected from the circuits you wish to test.
4.6. Audible Continuity Test
1. Connect the black test lead to the "COM"-jack and the red test lead to the 9 -jack. The
polarity of the red test lead is positive (+).
2. Place the function switch in the " "-position and push the " "-button on the front panel.
3. Connect the test leads with two points of the circuit you wish to test. The built-in buzzer will
sound if continuity exists (for resistances < 30 

DVM345DI GB
5
4.7. Diode Test
1. Connect the black test lead to the "COM"-MDFNDQGWKHUHGWHVWOHDGWRWKH9 -jack. The
polarity of the red test lead is positive (+).
2. Place the function switch in the " "-position.
3. Connect the red test lead to the anode and the black test lead to the cathode of the diode to
be tested.
4. The forward voltage drop of the diode will be displayed on the LCD.
4.8. Transistor Test
1. Place the function switch in the "hFE"-position.
2. Determine whether the transistor is NPN or PNP and locate the emitter, base and collector
leads. Insert the leads into the proper holes of the hFE-socket on the front panel.
3. The display will show the approximate hFE-value at the moment of testing. Base current
10µA, Vce 3.0V.
WARNING :
Disconnect all test leads from the circuit to be tested before connecting the transistor with the
hFE-socket. Make sure that no components are connected to the hFE-socket when performing
voltage measurements with test leads.
4.9. Interfacing the Meter with a PC
1. Run the RS232C-cable from the computer's serial ports to the meter.
2. Press "ON/OFF" to activate the meter and turn on the computer.
WARNING :
1. Only use a RS232C serial interface cable. Do not attempt to modify the length of this cable.
2. Please read the information on the supplied disk.
5. SPECIFICATIONS
Max. accuracy is achieved during a one-year period after calibration. Ideal circumstances
require a temperature of 18 to 28°C (64 to 82°F) and a max. relative humidity of 75%.
5.1. General Specifications
Max. Voltage between
Terminals and Earth Ground : 1000VDC or 750 Vrms AC (sine wave)
Power Supply : 9V-battery (NEDA1604 or 6F22)
Ranging Method : Auto/Manual
Display : 3 ¾ digit LCD, 38-segment bar graph
Overrange Indication : "OL" appears on display
Polarity Indication : "-" is displayed automatically
Battery-Low Indication : The " "-symbol is displayed
Operating Temperature : 5 to 35°C (41 to 95°F)

DVM345DI GB
6
Storage Temperature : -10 to 60°C (14 to 140°F)
Dimensions : 78 x 186 x 35mm
Weight : 300g (including battery)
5.2. DC Voltage
Range Resolution Accuracy
4V 1mV
40V 10mV
400V 0.1V
±0.5% of rdg ± 3 digits
1000V 1V ±0.8% of rdg ± 3 digits
Input impedance : 10MΩ.
5.3. AC Voltage
Range Resolution Accuracy
4V 1mV
40V 10mV
400V 0.1V
±1.2% of rdg ± 5 digits
750V 1V ±1.5% of rdg ± 5 digits
Input impedance : 10MΩ
Response : average response, calibration in rms of a sine wave.
Frequency range: 40Hz – 400Hz.
5.4. Resistance
Range Resolution Accuracy
4000.1
4k1
40k10
400k0.1k
4M1k
±1.2% of rdg ± 3 digits
40M10k±3.0% of rdg ± 5 digits
Max. open-circuit voltage : 3.0V.
Overload protection : 250VDC or 250Vrms AC for all ranges.
5.5. DC Current
Range Resolution Accuracy
4mA 1µA ±1.2% of rdg ± 3 digits
400mA 0.1mA ±1.2% of rdg ± 3 digits
10A 10mA ±2.0% of rdg ± 8 digits
Overload protection : 15A/250V-fuse for the 10A-range.
5.6. AC Current
Range Resolution Accuracy
4mA 1µA ±1.5% of rdg ± 8 digits
400mA 0.1mA ±1.5% of rdg ± 8 digits
10A 10mA ±3.0% of rdg ± 8 digits
Overload protection : 15A/250V-fuse for the 10A-range.

DVM345DI GB
7
Frequency range : 40 to 400Hz
Response : average response, calibration in rms of a sine wave.
5.7. Capacitance
Range Resolution Accuracy
4nF 1pF ±4.0% of rdg ± 5 digits
400nF 0.1nF ±4.0% of rdg ± 5 digits
5.8. Temperature
Range Resolution Accuracy
0 to 400°C 1°C ±3.0% of rdg ± 3 digits
401 to 750°C 1°C ±3.0% of rdg ± 5 digits
5.9. Audible Continuity
Function Description
Built-in buzzer sounds if continuity exists (< 30Ω)
5.10.Diode
Function Resolution Test Current Open-Circuit Voltage
1mV 25µA 3.0V
5.11.Transistor
Function Range Base Current Vce
hFE 1 to 1000 10µA 3.0V
6. ACCESSORIES
- User manual
- Set of test leads
- 9V-battery (NEDA1604 or 6F22)
- "K"-type thermocouple
- Holster
- RS232C-cable
- 1 disk of 1.44MB
