Velleman SHE16 User manual

SHE16
HEART RATE MONITOR + PEDOMETER
-
RING
PEDOMETER MET HARTSLAGWEERGAVE
-
RING
BAGUE
-
PODOMÈTRE AVEC INDICATION DE RYTHME CARDIAQUE
PODÓMETRO CON INDICACIÓN DEL RITMO CARDÍACO
–
ANILLO
SCHRITTZÄHLER MIT HERZFREQUENZANZEIGE
–
RING
RO OMIERZ Z POMIAREM TĘTNA
-
W FORMIE PIERŚCIENIA
USER MANUAL
2
GEBRUI ERSHANDLEIDING 5
NOTICE D’EMPLOI 8
MANUAL DEL USUARIO 11
BEDIENUNGSANLEITUNG 14

SHE16
   
USER MANUAL
1. Introduction
To all residents of the European Union
Important en ironmental information about this product
This symbol on the device or the package indicates that disposal of the
device after its lifecycle could harm the environment. Do not dispose of the
unit (or batteries) as unsorted municipal waste; it should be taken to a
specialized company for recycling. This device should be returned to your
distributor or to a local recycling service. Respect the local environmental
rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly before bringing
this device into service. If the device was damaged in transit, don't install or use it and
contact your dealer.
For more info concerning this product and the latest ersion of this user manual,
please isit our website www. elleman.eu.
2. Safety Instructions
eep the device away from children and unauthorised users.
The
SHE16
is
NO
professional medical equipment.
Do not
solely rely on the
measuring results of this device to follow up on your physical health and
condition.

SHE16
   
3. General Guidelines
Refer to the Velleman
®
Ser ice and Quality Warranty on the final pages of this
manual.
• Protect this device from shocks and abuse. Avoid brute force when operating the
device.
• Protect the device against extreme heat and dust.
• Familiarise yourself with the functions of the device before actually using it.
• Damage caused by user modifications to the device is not covered by the
warranty.
• Only use the device for its intended purpose. Using the device in an unauthorised
way will void the warranty.
• Damage caused by disregard of certain guidelines in this manual is not covered by
the warranty and the dealer will not accept responsibility for any ensuing defects
or problems.
4. O er iew
Refer to the illustration on page 2 of this manual.
A
heart beat indicator
E
MODE indicator: stopwatch, step, calorie, distance
B
3
-
digit display
F
5
-
digit display
C
START/STOP button
G
MODE button:
heart rate, stopwatch, step, calories,
distance
D
distance unit
H
max/min indicator
5. Set-up
Refer to the illustration on page 2 of this manual.
Note: if in setup mode nu button is pressed for 60 seconds, the device will go into
standby mode and all default values are applied.
• Press and hold START/STOP [C] and MODE [G] simultaneous for ±5s to reset and
enter setup mode.
• The display shows CL
CLCL
CL (clock,) and ON
ONON
ON. This indicates that the clock is shown during
heart rate measurement. To switch the clock OFF
OFFOFF
OFF, press START/STOP [C].
• Press MODE [G] and set the minutes with START/STOP [C].
• Press MODE [G]to confirm and set the hour with START/STOP [C].
• Press MODE [G] to confirm and select the stopwatch time limit with START/STOP
[C]. Available options: 10, 30 (default) min, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 h. When
expired an alarm will sound.
• Press MODE [G] and set heart rate measuring time (HP
HPHP
HP) with START/STOP [C].
Available options: 1 (default), 3, 10, 20, 30 min, 1h. When expired an alarm will
sound.
• Press MODE [G] and set heart rate lower limit (Min) with START/STOP [C]. Range
from 30~194, default 50. When exceeded an alarm will sound.
• Press MODE [G] and set heart rate upper limit (Max) with START/STOP [C]. Range
from 55~199 (step 5), default 150. When exceeded an alarm will sound.
• Press MODE [G] and set your step length with START/STOP [C]. Range from
15~150cm, default 45cm. To determine your step length, choose a mark on the
floor, place your heel on the mark and take a number of steps. Measure the

SHE16
   
distance between the mark and your heel and divide by the number of steps you
took to get the step length. Repeat this procedure a couple of times and take the
average to get a more accurate measurement.
• Press MODE [G] and set the desired distance unit [D] with START/STOP [C]. =
kilometre, M = miles.
6. Operation
Notes:
• Do not submerge the device in any liquid.
• When the clock is disabled, the device will switch off after 1 minute of
inactivity or no heart beat detected!
Heart rate monitor
• Slide the meter over your finger. Make sure it is not to loose to avoid reading
errors.
• When the meter is OFF, press the START/STOP button [C] until the heart beat
indicator [A] is shown. Press START/STOP [C] again to start measuring heart rate.
• When no heart beat is detected in 30s, an alarm will sound and measurement
stops.
• Whenever a set limit (Min or Max, see §5) is reached, the alarm sounds.
• Measurement automatically stops when the set measuring time (HP
HPHP
HP, see §5) is
reached. The alarm sounds and the average heart beat is shows.
Stopwatch mode
• Press MODE [G] until Tm is indicated [E].
• Press START/STOP [C] to start the timer. Press again to pause and continue.
• Below 1 minute, the 3 digit display [B] shows 1/100
th
of seconds, above 1 minute it
shows the seconds.
• When the preset time limit (see §5) is reached, the timer stops and an alarm
sounds.
• To reset the timer to zero, press and hold START/STOP [C] for ±3s.
Step mode
• Press MODE [G] until Step is indicated [E].
• Press START/STOP [C] to start measuring. Press again to pause. Max. count is
99999 steps.
• To reset the step count to zero, press and hold START/STOP [C] for ±3s.
Calorie mode
• Press MODE [G] until Cal is indicated [E].
• Calorie measurement starts automatically when step count is activated. It can be
reset to zero by resetting the step count to zero. Range: 0.0~9999.9.
Distance mode
• Press MODE [G] until Dst is indicated [E].
• Distance measurement starts automatically when step count is activated. It can be
reset to zero by resetting the step count to zero. Range 0.00~999.99km/mi.
7. Battery
• To replace the battery, release the two small screws at the back of the display
(tool included) and lift the cover.
• Insert a new 3V lithium battery (CR2032) and firmly close the cover with the two
screws.

SHE16
   
WARNING: Dispose of batteries in accordance with local regulations. Keep batteries
away from children.
8. Technical Specification
heart rate range
30 ~ 199 bpm
pedometer
0 ~ 99999 steps
stopwatch
00:00:00 ~ 10:00:00
clock
00:00:00 ~ 23:59:59
power supply
1 x 3V CR2032 lithium (incl)
weight
35g
Use this de ice with original accessories only. Velleman n cannot be held
responsible in the e ent of damage or injury resulted from (incorrect) use of this
de ice. The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman n . All worldwide rights reserved.
No part of this manual or may be copied, reproduced, translated or reduced to any electronic
medium or otherwise without the prior written consent of the copyright holder.
GEBRUIKERSHANDLEIDING
 Inleiding
Aan alle ingezetenen an de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestel of de verpakking geeft aan dat, als het na zijn
levenscyclus wordt weggeworpen, dit toestel schade kan toebrengen aan
het milieu. Gooi dit toestel (en eventuele batterijen) niet bij het gewone
huishoudelijke afval; het moet bij een gespecialiseerd bedrijf
terechtkomen voor recyclage. U moet dit toestel naar uw verdeler of naar
een lokaal recyclagepunt brengen. Respecteer de plaatselijke
milieuwetgeving.
Hebt u ragen, contacteer dan de plaatselijke autoriteiten betreffende de
erwijdering.
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel in gebruik
neemt. Werd het toestel beschadigd tijdens het transport, installeer het dan niet en
raadpleeg uw dealer.
Voor meer informatie o er dit product en de meest recente ersie an deze
handleiding, zie www. elleman.eu.
 Veiligheidsinstructies
Houd buiten het bereik van kinderen en onbevoegden.
De SHE16 is GEEN professioneel meetapparaat. Ga niet enkel af op de
meetresultaten van dit apparaat maar raadpleeg ook uw huisarts.
