USER MANUAL
TWO-IN-ONE SMD HOT AIR REWORK STATION
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its
lifecycle could harm the environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a specialized company for recycling.
This device should be returned to your distributor or to a local recycling service. Respect
the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Velleman! Please read the manual thoroughly before bringing
this device into service. If the device was damaged in transit, do not install or use it and
contact your dealer.
2. Safety Instructions
This device can be used by children aged from 8
years and above, and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning the
use of the device in a safe way and understand
the hazards involved. Children shall not play with
the device. Cleaning and user maintenance shall
not be made by children without supervision.
Read and understand this manual and all safety
signs before using this appliance.
Indoor use only. Keep this device away from
rain, moisture, splashing and dripping liquids.
Never put objects filled with liquids on top of or
close to the device.

VTSS230
V. 05 –16/03/2022 4 ©Velleman Group nv
Always disconnect mains power when the device
is not in use or when servicing or maintenance
activities are performed. Handle the power cord
by the plug only.
Caution! After switching off, leave the power
cord plugged in for a few minutes. When you
switch off the unit, the automatic cooling function
blows cooling air through the heater pipe for a
short period. This protects the heater from
damage and extends its lifetime. Do not
disconnect the mains plug during this cooling
process.
Do not crimp the power cord and protect it
against damage.
Warning! If the power cord is damaged, it must
be replaced by the manufacturer, its service
agent, or similarly qualified persons in order to
avoid any hazard.
Make sure that the available voltage does not
exceed the voltage stated in the specifications of
this manual.
Plug the power cord into a suitable, earthed
mains outlet.
Risk of electroshock when opening the cover.
Touching live wires can cause life-threatening
electroshocks. Do not disassemble or open the
housing yourself. Have the device repaired by
qualified personnel.
Do not operate the device with wet hands.
Never use the device on live electronic circuits.
Make sure power to the work piece is cut and
capacitors are discharged.

VTSS230
V. 05 –16/03/2022 5 ©Velleman Group nv
Do not use near inflammable products or in
explosive atmospheres. Heat can cause fire to
inflammable products even when they are not in
sight. Only use in properly ventilated rooms.
Incorrect use may cause fire.
Do not touch the shafts, tips, or hot air gun as
this can cause serious burns. Keep the tips and
hot air away from the body, clothes, or other
flammable material. Do not aim the hot air gun
at the eyes. Use gloves and/or heat-resistant
tools to pick up the PCB assembly to prevent
burns. Always return the irons and gun to their
stands between uses; always let the device cool
down after use and before storage.
Place the device on a level, stable, and fire-
resistant working surface.
WARNING! This tool must be placed on its stand
when not in use; do not leave the tool
unattended when switched on.
Do not inhale solder fumes. The vapours that are
released during soldering are harmful. Therefore,
you shall only use the soldering station in well-
ventilated areas or under an exhaust hood
(solder fume extractor). Dispose of fume filters
and solder residue in accordance with local
regulations.
•Use the soldering iron on a heatproof
workbench.
•Place the soldering iron in its holder after use.
•Let a hot soldering iron cool down naturally
and do not immerse in water.

VTSS230
V. 05 –16/03/2022 6 ©Velleman Group nv
A fire may result if the appliance is not used with
care. Therefore:
•be careful when using the appliance in places
where there are combustible materials;
•do not apply to the same place for a long time;
•do not use in presence of an explosive
atmosphere;
•be aware that heat may be conducted to
combustible materials that are out of sight;
•place the appliance on its stand after use and
allow it to cool down before storage;
•do not leave the appliance unattended when it
is switched on.
3. General Guidelines
•Refer to the Velleman®Service and Quality Warranty on the last pages of this
manual.
•All modifications of the device are forbidden for safety reasons. Damage caused by
user modifications to the device is not covered by the warranty.
•Only use the device for its intended purpose. Using the device in an unauthorised
way will void the warranty.
•Damage caused by disregard of certain guidelines in this manual is not covered by
the warranty and the dealer will not accept responsibility for any ensuing defects or
problems.
•Nor Velleman Group nv nor its dealers can be held responsible for any damage
(extraordinary, incidental or indirect) –of any nature (financial, physical…) arising
from the possession, use or failure of this product.
•Keep this manual for future reference.
4. Overview
Refer to the illustrations on page 2 of this manual.
1
soldering station display +
temperature setting button
5
rework station display +
temperature setting button
2
airflow control
6
temperature unit setting
3
soldering station on-off switch
7
rework station on-off switch
4
soldering station connection
8
rework station connection

VTSS230
V. 05 –16/03/2022 7 ©Velleman Group nv
5. Installation
1. Install the appliance on a flat, stable and fire-resistant surface.
2. Make sure that the power switch at the back of the appliance is in the off
position (0).
3. Connect the soldering iron to the appliance.
4. Plug the power cord into a suitable, earthed mains outlet.
6. Operation
6.1 General Operation
1. To switch on the appliance, set the power switch in the on position (I). The device
starts heating up, the temperature and airflow values will be displayed.
2. Switch on the soldering or rework station with the respective button.
3. Select the temperature unit with the temperature unit setting switch.
4. Set the temperature and airflow value with the respective + and –buttons and the
airflow control knob.
5. After setting, wait for the values to stabilize before starting to solder.
Please refer to chapter How to Solder below for handy tips.
Do not apply to the same place for a long time.
Do not leave the device unattended when switched on.
6.2 Auto Sleep Mode
When the soldering iron is placed in its holder, the switched-on station automatically
lowers the iron temperature (sleep mode). As soon as you pick up the iron, the station
exits the sleep mode.
6.3 Switching Off the Station
After use, place the iron in its holder and switch off the station.
After switching off, leave the power cord plugged in for a few minutes. When you switch
off the unit, the automatic cooling function blows cooling air through the heater pipe for
a short period. This protects the heater from damage and extends its lifetime. Do not
disconnect the mains plug during this cooling process.
Wait until the cooling process has stopped, then disconnect the power plug. The device
uses a small amount of electrical power, even if it is switched off.

VTSS230
V. 05 –16/03/2022 8 ©Velleman Group nv
7. How to Solder
7.1 Precautions
To extend the life of the heating element in the hot air gun, do not use the device
continuously at a low airflow and a high temperature. Allow the heating element to cool
after maximum 20 minutes of usage. Place the hot air gun back in its stand when not in
use.
Make sure that both heater and nozzle are cold before attaching the nozzle.
High temperatures! Both nozzle and airflow are extremely hot and can cause severe
burns. Never touch the nozzle and heater assembly or allow the hot air to blow against
your skin. When used for the first time, the hot air gun may emit some white smoke,
but this will soon dissipate.
Always let the unit cool down after use. After switching off, leave the power cord
plugged in for a few minutes. When you switch off the unit, the automatic cooling
function blows cooling air through the heater pipe for a short period. This protects the
heater from damage and extends its lifetime. Do not disconnect the mains plug during
this cooling process.
7.2 Setup
Do not force the nozzle or pull its edges with pliers.
1. Make sure the appliance is switched off and the iron/air gun is completely cooled
down.
2. Select the air nozzle and slide it onto the air gun.
3. Plug in the power cord and switch on the station.
4. Select the temperature and airflow.
5. Wait until the temperature is stable.
8. Cleaning and Maintenance
8.1 General
Only perform the maintenance as described in this user manual. Contact an authorised
dealer or service agent for any other maintenance or repair.
If the iron or station becomes faulty or, for some reason does not operate normally,
return it to the service department of your authorized dealer or service agent.
Clean the outer cover of the iron and station with a damp cloth and a small amount of
liquid detergent. Never submerge the unit in liquid or allow any liquid to enter the case
of the station. Never use any solvent to clean the case.
Use only original replacement parts.

VTSS230
V. 05 –16/03/2022 9 ©Velleman Group nv
8.2 Storing
Store the appliance, its accessories and this user manual in the original packaging.
Always store in a cool and dry place.
9. Technical Specifications
power supply ............................................................................. 220-240 V~, 50 Hz
power
soldering iron.................................................................................... 24 V, 60 W
hot air pump ........................................................................................... 300 W
temperature range
soldering iron............................................................ 50 ~ 480 °C (122 ~ 896 °F)
hot air pump .......................................................... 100 ~ 500 °C (212 ~ 932 °F)
dimensions ..............................................................................113 x 125 x 175 mm
weight ........................................................................................................... 2 kg
option
soldering iron............................................................ VTSS220/SP1 (not included)
Use this device with original accessories only. Velleman Group nv cannot be
held responsible in the event of damage or injury resulting from (incorrect)
use of this device. For more info concerning this product and the latest version
of this manual, please visit our website www.velleman.eu. The information in
this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman Group nv. All worldwide
rights reserved. No part of this manual may be copied, reproduced, translated or
reduced to any electronic medium or otherwise without the prior written consent of the
copyright holder.

VTSS230
V. 05 –16/03/2022 10 ©Velleman Group nv
HANDLEIDING
2-in-1 SMD-HETELUCHTSTATION
1. Inleiding
Aan alle ingezetenen van de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestel of de verpakking geeft aan dat, als het na zijn levenscyclus
wordt weggeworpen, dit toestel schade kan toebrengen aan het milieu. Gooi dit toestel
(en eventuele batterijen) niet bij het gewone huishoudelijke afval; het moet bij een
gespecialiseerd bedrijf terechtkomen voor recyclage. U moet dit toestel naar uw
verdeler of naar een lokaal recyclagepunt brengen. Respecteer de plaatselijke
milieuwetgeving.
Hebt u vragen, contacteer dan de plaatselijke autoriteiten betreffende de
verwijdering.
Dank u voor uw aankoop! Lees deze handleiding grondig door voor u het toestel in
gebruik neemt. Werd het toestel beschadigd tijdens het transport, installeer het dan
niet en raadpleeg uw dealer.
2. Veiligheidsvoorschriften
Dit toestel is geschikt voor gebruik door kinderen
vanaf 8 jaar, door personen met fysieke,
zintuiglijke of verstandelijke beperkingen, of door
personen met gebrek aan ervaring en kennis, op
voorwaarde dat dit onder toezicht gebeurt van
een persoon die verantwoordelijk is voor hun
veiligheid of hun aanwijzingen heeft gegeven,
hoe zij het toestel moeten gebruiken en zich
bewust zijn van de risico's die het gebruik van
het toestel met zich meebrengt. Kinderen mogen
niet met het toestel spelen. De reiniging en het
onderhoud van het toestel mogen niet worden
uitgevoerd door kinderen, tenzij ze onder
toezicht staan.
Lees en begrijp deze handleiding en de
veiligheidsinstructies vóór ingebruikname.
