Owner's Manual
Audio/VideoSatelliteandSurroundSystem
CHT
Front Row System
Velodyne Acoustics, Inc.
1070 Commercial St. Suite #101
San Jose, CA 95112
408.436.7270 voice
408.436.7276 fax
Web Site: www.velodyne.com
E-mail: [email protected]
"...theCT-120isoneofthefewsubwoofersI'vetestedatanypricethatcould
produce clean output at 20 Hz..."
- Tom Nousaine
Stereo Review, June 1998
"...it is an excellent sub..., it compares favorably with even the best...it is
definitely superior...."
- Howard Ferster
Sensible Sound, February/March 2000
Printed on recycled paper.
6-01, #63-CHT FRS
Rev. A
Other Velodyne Subwoofer Products:
HGSSeries
HGS-10
HGS-12
HGS-15
HGS-18
SPLSeries
SPL-800
SPL-1000
SPL-1200
VLFSeries
VLF-810
VLF-1012
FSeries
FSX-12IIBV

☞
1
FOR YOUR RECORDS. . .
DATEPURCHASED ____________________________________
DEALER __________________________________________________
SERIAL# ______________________________________________
*NOTE: Please complete and return your warranty card within ten (10) days of
purchase.
Specifications are subject to change without notice.
SPECIFICATIONS:ClassicHomeTheaterFrontRowSystem
Cabinet(H,W,D) 8.5"x5.5"x6.25"(L/R,FandR)
Cabinet(H,W,D) 5.5"x13"x6.25"(center)
Frequency Response 90Hz-22kHz+/-2dB(L/R,FandR)
90Hz-22kHz+/-1.5dB(center)
High Pass Crossover 3rdorder(18dB/oct)withequalization
Low Pass Crossover 2ndorder(12dB/oct)with equalization
Protection Momentary over power protection
(selfresettingmute ~10dB)
Woofer 4"longthrowwith11 oz.magnet(x2center)
WooferVoiceCoil 1.2" two layer copper
Tweeter 3/4"soft domewith neodymium magnet
Ferro-fluidcooledvoicecoil
Inputs GoldPlated Binding Posts
(accepts bare wire and banana plugs)
Warranty Two years (parts and labor)
Weight 40lbs.(entiresystem,approx.)
☞
10
Safety First
1. Read instructions. All safety and operating instructions should be
read before the speaker is operated.
2. Retain instructions. The safety and operating instructions should
be retained for future reference.
3. Heed Warnings. All warnings on the speakers and in the operating
instructions should be adhered to.
4. Follow instructions. For optimum performance, all operating and
use instructions should be followed.
5. Water and moisture. The speakers should not be used near water.
For example, near bathtub, washbowl, sink, laundry tub, pool,
outdoors, or in an extremely damp environment.
6. Stands. Ifstandsareused,theyshouldbesturdyenoughtoprevent
accidental tipping and resulting damage of the speaker.
7. Wallorceilingmounting. Thespeaker should be mounted to a wall
or ceiling using hardware suited to fastening an object of the
speakers weight or damage may result. Consult your dealer for
specific recommendations.
8. Heat. The speaker should be situated away from any direct heat
sources such as radiators, stoves, or any other appliances that
produce heat.
9. Cleaning. The speaker should be cleaned only with a damp cloth.
Harsh abrasives or cleaning solutions may damage the finish and
should not be used.
10. Foreign object or liquid entry. Care should be taken so that objects/
liquids do not fall onto any part of the speaker.
11. Damage requiring service. The speaker should be serviced only
by a qualified technician when:
a. Objects have fallen or liquid has been spilled into the speaker
b. The speaker has been exposed to rain or severe moisture
c. The speaker does not appear to operate normally or exhibits a
marked change in performance
d. The speaker has been dropped, or the enclosure damaged
12. Servicing. Theusershouldnot attempt to service the speaker beyond
cleaning and making signal connections. All servicing should be
referred to a qualified service technician.
CAUTION:
To reduce the risk of electric shock, do not attempt
to open or disassemble speaker cabinet. There
are no user serviceable parts inside.

Congratulations!
Congratulations on your purchase of the CHT Front Row System. This
system represents the state of the art in home audio reproduction and will
provideyouwithyearsoflisteningpleasurewhen properlyusedandcared
for. Read and follow this instruction manual to insure safe and proper
system connection and operation.
This speaker system was designed to offer seamless integration with any
of our CHT Series subwoofers. It is essential that you use a Velodyne
subwooferwiththeCHTFrontRowSystemtoachieveoptimalperformance.
TheadditionofaVelodyneSubwooferwillallowyourloudspeakersystem
to reproduce the bass frequencies from approximately 80Hz and below.
With the CHT Front Row System and a Velodyne subwoofer, working
togetherasa system,thesoundquality,outputlevels,andvaluewillexceed
most other systems.
Please unpack the system carefully. Remove all staples used to seal the
carton as they can scratch the cabinets. Please save the carton and all
packagingmaterialsforfutureuse. Recordtheserialnumberinthespace
provided on the warranty card for future reference.
Product Features
Woofer
● 4" diameter with cast aluminum basket
● Moisture resistant treated fiber cone
● Inverted dustcap for smoother response
● Rubber surround for long life and lower distortion
● Magnetically shielded to allow placement near TV's
Tweeter
●3/4"diameterSilkDomeTweeterwithneodymiummagnet
●Ferro-fluidcooled
● Magnetically shielded to allow placement near TV's
Crossover
● Woofer (12 dB/octave), Tweeter (18 dB/octave)
● Frequency and impedance equalization
● Protection circuit to prevent driver damage
General
●Removablegrille
● Sealedenclosure. 5/8"MDFenclosuretoreducecabinetresonanceand
sound coloration
continued. . .
2☞
9☞
Troubleshooting and Service
Before seeking service for your Front Row Speaker System, please check
all the components in your system for proper operation. Following is a
simple troubleshooting guide to assist you.
1. Verify speakers are properly connected to receiver/amplifier and that
electronics are switched on and functioning properly.
2. Is the speaker selector switch of the receiver in the proper position?
3. Areall speaker cables in good condition andmaking good contact with
allterminals?
4. Is your receiver getting a signal from your source device?
5. Is your receiver sending a signal to the speakers?
6. If speakers have been running at high levels, the protection circuit may
beengagedwhichreducesvolumeforashortperiodoftime. First,reduce
the volume setting of your equipment. The volume should return to
normalafterafewmoments.
The following conditions require service by a qualified technician:
1. The enclosure has become damaged or broken.
2. Theunitdoesnotappeartooperatenormallyorexhibitsamarkedchange
inperformance.
3. The unit has been exposed to water.
4. Some part of the speaker (woofer or tweeter) is physically damaged.
Thank you for purchasing a Velodyne!

Prepare for Installation
YournewFrontRowSystemprovidesforanumberofinstallationoptions,
especially when combined with a Velodyne subwoofer. Read all the
installation information below in order to determine which installation
option is best for your system. Remember to perform all installation
procedureswithsystempowerturnedofftopreventpossibledamage.
Placement
Your new Velodyne speaker system, like any good speaker system,
requiresproperpositioningwithinthelisteningspacetoprovidemaximum
performance.Improperly placedspeakers maydegrade the sound quality
and reduce your listening pleasure. Depending on the size and type of
furnishings in the room, perfect placement may not be possible. Finding
the best location for your environment will likely require some
experimentation. We suggest observing the following guidelines, then
experimentwith thelocation duringsetup to find what sounds best toyou
when seated in your typical listening position.
While the optimum location for a subwoofer (typically) is tucked away
inacornerofyourlisteningroom,thefrontLeft,Center,andRightsatellite
speakers should be placed so the speakers are at the same height as your
ears when seated in your typical listening spot. The center speaker will
typicallybeplacedaboveorbelowtheTVinthedirectcenterofthescreen.
The left and right front speakers should be placed at equal distance from
thecenterand closetothe sameheightand closetothe heightofyour ears
when seated (Figure 1). The rear surround speakers are not as critical of
placement and should be placed behind the listeners. Mount the rear
speakersslightlyabovelistenersears. Theymaybeaimedstraightahead,
or angled inward toward the listener.
●●
●●
●Find your space
Select an area of the room which gives you an unobstructed line of sight to
the speakers.
●●
●●
●Achieve proper tonal response
Your speakers will perform best when they are placed at least 1-2 feet from
any back or side walls.
●●
●●
●Speaker height
Inthefront,speakersshouldbeclose,ifnotequaltotheheightofthelisteners
ears.
3☞
continued. . .
8☞
Interconnect Cables
When installing your new Velodyne speaker system with a subwoofer
using the line level connections, you should always use shielded phono
cables. There are many cables available today, any of which will work
perfectlywell. Wedorecommendthatyoukeepthelengthofcableasshort
as possible to avoid any potential noise problems.
Forspeakerlevelconnections,usea16-gaugeorlargerspeakercablethat
mateswellwiththeconnectors. Beverycarefultoavoidanyloosestrands
or frayed wires which may result in a short, causing damage to your
equipment. Cables of extremely large size are typically not required.
Oversizewiremaynotproperlyfitinthebindingposts,resultinginapoor
connection and possible short circuits.
Care of your speaker system
YourVelodynespeakersystemdoesnotrequireanyregularmaintenance.
Normaldusting orcleaning ofthe surfacefor appearancepurposes areall
that is required. We do suggest you avoid any harsh detergents or
chemicals when cleaning the cabinet. Abrasives, detergents, or cleaning
solutionsmaydamagethefinishonthecabinet. Werecommendusingonly
a damp cloth to clean the cabinet.

continued. . .
4☞
7☞
●●
●●
●Speaker separation
The distance between the speakers will have a considerable effect on the
stereoimageandapparentplacementofsound. Agoodruleofthumbformost
listening rooms is to have the left and right speakers between 6-9 feet apart.
●●
●●
●Fine tune position (up/down)
Ifthe speakers are ata different height than the listener, it may bebeneficial
totiltthespeakersupordowntoaimthemmoredirectlyatthelisteningarea.
●●
●●
●Fine tune position (left/right)
Once general position of the speakers is selected, adjust the angle of the
speakers. Insomeinstallationsyoumayneedto"toein"thespeakersto aim
them at the listeners.
●●
●●
●Tone control adjustment
Thesespeakersaredesignedtoprovideaverysmoothandaccuratefrequency
response, in most rooms, without any extra equalization. This makes
adjusting the tone controls (bass/treble) unnecessary in most installations.
●●
●●
●Room furnishings
The type and location of furnishings in your room may greatly affect the
sound you hear. Rooms with hardwood floors and minimal upholstered
surfaces may sound very bright and live from an extra amount of reflected
sound. Other rooms with heavily padded floors and carpeting, along with
thickdrape tendtomakethesoundwarmandsofter. Keepthisinmindwhen
setting up your audio/video listening room.
Figure 1. Optimal Speaker Height and Separation
3-4 ft. typical 3-4 ft. typical
Tweeters on same planeTweeters on same plane
Height equal to
listeners ears
Connection Thru Subwoofer (line-level)
Figure 4 illustrates how to connect your new satellite speakers through
your Velodyne subwoofer's line level crossover. This is only possible if
your receiver has in/out loop connections that separate the amp and pre-
ampstages. Consult the manual for your receiver for further information
onthiscapability. Thiswillremovethelowerbassfromyourfrontsatellite
speakersonly. Otherspeakerswillstillreceivefullrangeinformation. This
method should only be used if your receiver does not have high pass
crossover functions built into the surround sound processor.
Figure 4. Connecting thru Velodyne subwoofer's line level high pass
crossover
LEFT
-+
RECEIVER
SPEAKER OUTPUTS
REAR
L - R L - R
+
-+
-
FRONT
CENTER
-+
RIGHT
-+
LEFT
-+
RIGHT
-+
RED(+)POSITIVEAMP ☛☛ RED(+)POSITIVESPEAKER
BLACK (-) NEGATIVE AMP ☛☛ BLACK (-) NEGATIVE SPEAKER
REAR
SUBWOOFER
(line level)
L - R
IN OUT
L - R
PRE-AMP TO AMP
FRONT (line-level)
L - R
OUT IN
L - R
FRONT
+
-
CENTER

5☞
Connection Direct From Receiver
Figure 2 illustrates how to connect your Velodyne speaker system
directly to your receiver or amplifier. This is the preferred connection
method for most systems that have a "subwoofer out" connection and
electronicfilteraspartofthesurroundsoundprocessor. Itisrecommended
that you activate your receiver/processor's high pass filter function. We
recommendsetting this crossover in your receiver orprocessor to 80 Hz.
Todothis,select"small"modeonthespeakersetupmenuofyourreceiver.
Thisis nominal for most systemsand will allowyour satellite speakers to
go reasonably low and provide good imaging while allowing your sub to
blend in perfectly. The higher the crossover frequency between your
speakers and subwoofer, the easier it will be to locate sound from the
subwoofer. This is undesirable, as it will degrade the imaging of your
system. Ifyourequipmentdoesnothavetherequiredoutputsforthistype
of installation, consult the following two installation methods for more
options. Ifnoneof themethodsshown will workinyour system,orif you
should have further questions, please consult your dealer or call our
technical support department for more help.
continued. . .
6☞
Figure 2. Connections direct from power amp/receiver with electronic
crossover
Connection Thru Subwoofer (speaker-level)
Figure 3 illustrates how to connect your new satellite speakers through
yourVelodynesubwoofer'sspeakerlevelcrossover. Thiswillremovethe
lowerbassfromyourfrontsatellitespeakersonly. Otherspeakerswillstill
receive full range information. This method should only be used if your
receiver does not have high pass crossover functions built into the
surround sound processor. Be careful to connect the positive + (red)
terminals on your receiver to the + (red) terminals of your subwoofer.
Reversing these connections may damage your subwoofer.
LEFT
-+
RECEIVER / AMPLIFIER
MAIN SPEAKER OUTPUTS
FRONT CENTER REAR
L - R L - R
+
-+ -+ -
Figure3. ConnectingthruVelodynesubwoofer'sspeakerlevelhighpass
crossover
FRONT
CENTER
-+
RIGHT
-+
LEFT
-+
RIGHT
-+
RED(+)POSITIVEAMP ☛☛ RED(+)POSITIVESPEAKER
BLACK (-) NEGATIVE AMP ☛☛ BLACK (-) NEGATIVE SPEAKER
REAR
SUBWOOFER
(speaker level)
L - R
+
-
IN OUT
L - R+
-
LEFT
-+
RIGHT
-+
LEFT
-+
RIGHT
-+
CENTER
-+
FRONT
RED (+) POSITIVE AMP ☛☛ RED (+) POSITIVE SPEAKER
BLACK (-) NEGATIVE AMP ☛☛ BLACK (-) NEGATIVE SPEAKER
REAR
RECEIVER / AMPLIFIER
MAIN SPEAKER OUTPUTS
FRONT CENTER REAR
L - R L - R
+
-+ -+ -
Line level sub out to
Velodyne sub line in
SUB OUT
