Vemco VR2W Installation guide

VR2W BASICS
MANUAL
December 9, 2011
For the latest versions of user
manuals and software, visit
www.vemco.com.

AMIRIX Systems Inc.
Warranty and Disclaimer
WARRANTY
AMIRIX Systems Inc., doing business under its trade name VEMCO, provides a one (1) year warranty period for the Product from date of shipment.
VEMCO warrants that on the date of shipment all Products manufactured by VEMCO are free from defects in material and workmanship under normal use and
service. This warranty applies to the components necessary for equipment upgrades, i.e. the VR1/VR2 to VR2W upgrade. With respect to transmitter products,
while VEMCO is able to predict battery life with some certainty, VEMCO cannot guarantee that these Products will remain functional while submerged for extended
periods of time. This warranty does not apply to any equipment, materials or design supplied by Buyer or a third party; re-battery services provided by VEMCO;
Products for which VEMCO has not received payment; problems that results from: external causes such as accident, abuse, misuse; servicing not authorized by
VEMCO; usage not in accordance with Product instructions; failure to follow the Product instructions or failure to perform preventative maintenance; usage of
accessories, parts or components not supplied by VEMCO.
This warranty shall survive delivery only on the conditions and subject to the limitations set forth below.
NOTICE PERIODS
To receive a warranty remedy for a Product, Buyer must contact VEMCO’s Customer Support Department during the warranty period to receive the Return Material
Authorization (“RMA”) instructions. Each defective Product returned for warranty remedy must be shipped at the Buyer’s expense according to the RMA instructions
and must include reasonable proof that the claimed defect is due to a matter embraced within the warranty set forth above and that such defect did not result from
any act or omission of Buyer, including but not limited to any failure to operate and maintain the Product in accordance with VEMCO’s applicable written
instructions.
REMEDY
VEMCO’s liability, and the Buyer’s exclusive remedy under this warranty, as to a defect in material or workmanship, is limited to the repair of such defect in the
accessory, equipment or part in which the defect appears or, at VEMCO’s option, to the replacement of such accessory, equipment or part with a similar item free
from defect. As to any item repaired by VEMCO or furnished as a replacement by VEMCO, VEMCO’s liability and the Buyer’s exclusive remedy to the repair or
replacement of such item for any further defect in material or workmanship, provided VEMCO receives written notice at Halifax, Nova Scotia, of such further defect
from BUYER within ninety (90) days after the repaired or replaced item is shipped to BUYER and provided that BUYER returns same to VEMCO as provided under
“Notice Periods”.
RETURNED ITEMS
All repairs, replacements and corrections described above shall be performed by VEMCO at its plant at Halifax, Nova Scotia, or at such other place as may be
mutually agreeable, and with reasonable care and dispatch in order that the Product, accessory, equipment or part will not be kept out of service longer than
necessary. Return to BUYER of a repaired, replacement, or corrected accessory, equipment, part or Product shall be at VEMCO’s expense. Title to and risk of loss
of the Product, accessory, equipment, or part returned to VEMCO pursuant hereto shall at all times remain with the BUYER, except that title to a returned
accessory, equipment, part, or Product shall pass to VEMCO concurrently with shipment to BUYER of any item furnished by VEMCO to BUYER as a replacement
therefore. VEMCO shall have only such responsibility for any Product, accessory, equipment, or part owned by the BUYER and in the possession of VEMCO as is
chargeable by law to a bailee for hire, but shall not be chargeable for loss of use thereof.
WEAR AND TEAR
Normal wear and tear and the need for regular maintenance shall not constitute a defect under this warranty.
DISCLAIMER AND RELEASE
THE WARRANTIES, OBLIGATIONS AND LIABILITIES OF VEMCO AND THE REMEDIES OF BUYER SET FORTH HEREIN ARE EXCLUSIVE AND IN
SUBSTITUTION FOR, AND BUYER HEREBY WAIVES AND RENOUNCES, ALL OTHER WARRANTIES AND OBLIGATIONS OF VEMCO AND ANY ASSIGNEE
OF VEMCO AND ALL RIGHTS, CLAIMS AND REMEDIES OF BUYER AGAINST VEMCO, EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, WITH
RESPECT TO ANY NON-PERFORMANCE OR DEFECT IN THE PRODUCT OR IN ANY OTHER THING DELIVERED UNDER THIS AGREEMENT, INCLUDING
BUT NOT LIMITED TO:
(A) ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE;
(B) ANY IMPLIED WARRANTY ARISING OUT OF COURSE OF PERFORMANCE, COURSE OF DEALING OR USAGE OF TRADE;
(C) ANY OBLIGATION, LIABILITY, CLAIM OR REMEDY IN TORT, WHETHER OR NOT ARISING FROM THE NEGLIGENCE OF VEMCO OR ANY ASSIGNEE
OF VEMCO, ACTUAL OR IMPUTED;
(D) ANY OBLIGATION, LIABILITY, RIGHT, CLAIM, OR REMEDY FOR LOSS OF OR DAMAGE TO THE PRODUCT, FOR LOSS OF USE, REVENUE, OR
PROFIT WITH RESPECT TO THE PRODUCT; OR FOR ANY OTHER DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES; AND
(E) VEMCO MAKES NO REPRESENTATION THAT THE PRODUCT WILL NOT INFRINGE ANY PATENT OR OTHER RIGHTS OF ANY PERSON AND BUYER
AGREES TO INDEMNIFY VEMCO AND HOLD VEMCO HARMLESS FROM ANY AND ALL CLAIMS AND LIABILITIES WITH RESPECT TO SAME
TOGETHER WITH ANY CLAIMS AND LIABILITIES WITH RESPECT TO ANY INFRINGEMENT OF ANY PATENT OR OTHER RIGHTS OF ANY PERSON
ARISING AS A RESULT OF BUYER'S PRODUCTS, TECHNOLOGY, ACTIVITIES, OR OTHERWISE.
LICENSE AGREEMENT
VEMCO grants to the Buyer a limited, personal license, with no right to sub-license, to use the Intellectual Property (“IP”) and Embedded Software in the manner
set out in the Documentation. The Embedded Software and IP are not sold to Buyer. All property rights, including Intellectual Property Rights, remain with VEMCO.
All rights related to the Embedded Software not expressly licensed to the Buyer are reserved to VEMCO. BUYER shall not permit any person other than BUYER
and its employees to use or make use of the Embedded Software and/or IP. BUYER shall not, and shall not permit any third party to, modify, adapt, translate,
reverse engineer, decompile, disassemble, or create derivative works based on the Embedded Software and/or IP. This license is assigned to the Product with
which you have acquired the Embedded Software and/or IP. If the Product purchased is a Transmitter product, be advised that the license life is equal to the
operational life.
EXPORT
Products and associated materials supplied or licensed hereunder may be subject to various export laws and regulations. It is the responsibility or BUYER to
comply with such laws and regulations.
NEGOTIATED AGREEMENT
It is fully understood by the parties that the price of the Product and other mutual agreements of the parties set forth in this agreement were arrived at in
consideration of this warranty, SPECIFICALLY INCLUDING THE WAIVER, RELEASE AND RENUNCIATION BY BUYER SET FORTH ABOVE (DISCLAIMER
AND RELEASE).
© (2011) AMIRIX Systems Inc. All rights reserved. The information contained herein
includes information which is confidential and proprietary to AMIRIX Systems Inc. and
may not be used or disclosed without prior written consent of AMIRIX Systems Inc.
DOC-4416-09

VEMCO -VR2W Receiver Battery Installation/Attachment -Page 1
VR2W BATTERY INSTALLATION
This is a quick reference for installing or replacing the VR2W battery, and for attaching
the VR2W receiver to a mooring line. The complete VR2W manual can obtained by
contacting our sales staff or can be viewed at www.vemco.com in PDF format.
BATTERY
The VR2W receiver is powered by a single "D" size 3.6 Volt Lithium battery with a connector
attached – the Tadiran TL-5930/F. The battery is not installed in the VR2W when it is shipped
to prevent battery life loss during shipping. Battery life is consumed from the time the battery
is installed so always remove the battery when the receiver is not being used for an extended
period of time. The battery must be installed before the VR2W can be initialized.
Battery Life
A new Lithium D-cell battery will last approximately 15 months in a VR2W-69kHz and
approximately 8 months in a VR2W-180kHz.
Battery life is consumed from the time the battery is installed, even if
the VR2W is not initialized for a study. Unlike the VR2 receiver, the
VR2W begins recording when the battery is installed.
Battery Installation/Replacement
Inserting or replacing a battery in the VR2W requires three basic steps, opening the case,
inserting/replacing the battery, and closing the case. Each of these steps is dealt with in detail in
the following sections. Two steel rods are necessary to properly open and close the VR2W
case. A pair of rods is included with each shipment of VR2W receivers.
Opening the VR2W Case
1) Make sure there is absolutely no water on or near the VR2W case. If the VR2W is attached
to a wet rope, remove the receiver from the rope before opening the case.
WARNING: It is vitally important that the electronics inside the receiver case do not
come in contact with any water. This also means the electronics cannot be exposed to a
sudden change in temperature and humidity that will cause condensation to develop on
the electronics and destroy the receiver.
2) Place the VR2W on a clean, flat surface so the
transducer is hanging over the edge as shown in the
photo. DO NOT let the receiver fall off the surface.
3) Insert one steel rod into the hole that runs through the
diameter of the case near the flat end of the VR2W.
This rod is labelled "B" in the photo.
4) Insert the other steel rod into the wider end of the probe
hole on the end-cap of the receiver. Make sure the rod
is fully inserted into the hole or damage may occur to
the probe hole. This rod is labelled "A" in the photo.
Opening the VR2W case.
5) Place a hand on the back of the receiver to hold it in place (see photo).

VEMCO -VR2W Receiver Battery Installation/Attachment -Page 2
6) Apply pressure to rod "A" in a downward direction (see arrow in photo) so the end-cap
twists in a counter-clockwise direction when you are facing the transducer. Rod "B" will
act as a brace while you apply pressure.
7) Continue moving the rod in the counter-clockwise direction until turning becomes easier.
8) Remove the steel rods from the VR2W case.
9) Use your hands to continue twisting the end-cap in a counter-clockwise direction until the
end-cap and outer cylinder separate.
10) Slide the end-cap and cylinder apart until the battery compartment has cleared the cylinder.
WARNING: DO NOT impact the threads on the end-cap or they will dent and prevent the
VR2W case from closing. See the Trouble Shooting section of VR2W manual for tips
on thread care.
Inserting / Connecting Battery
STEP 1
Was the battery shipped inside
the receiver? Then connect
the two halves of the battery
connector as shown in Steps 8
and 9 (below) to power the
receiver. If not, then continue
with Step 2
STEP 2
Verify the O-ring inside the
battery
cavity is
still at the
back of
the cavity.
STEP 3
Slide the
Lithium D-cell
battery into
the battery
section at the
end of the
receiver so the battery’s wires are
outside the case.
STEP 4
Insert the battery pin into one
of the holes in the edge
around the battery cavity and
slide the pin across the end of
the battery until the ends of the
pin are both in the receiver
case (see
photo at
right).
Downward
force (see
red arrow)
may be
required on
battery end
to get the pin
started.
STEP 6
Place the battery wires into the
gap in the end of the receiver case
closest to the battery connector on
the case. There are two gaps in
the end of the case.
STEP 5
Check that
both ends of
the pin are
flush with the
case.
STEP 7
Place the O-ring in the O-ring
groove around the end of the
case so the battery wires are
inside the O-ring. This also
holds the battery pin in place.
STEP 8
Connect the two battery
connector halves together
until a “click” is heard and the
VR2W receiver’s light begins
flashing.
STEP 9
Gather any excess battery wire at
the end of the battery cavity and
not along the side of the receiver
casing. This reduces the chance of
damage to the battery wires.

VEMCO -VR2W Receiver Battery Installation/Attachment -Page 3
Closing the VR2W Case
1) Make sure the serial number on the band in the middle of the outer cylinder matches the
serial number on the internal casing. This is particularly important when more than one
VR2W receiver is open at the same time.
2) Inspect the O-ring surfaces to be sure they are clean, undamaged, and debris free.
3) Inspect the two O-rings near the threads on the end-cap to make
sure they have not been damaged and that they are properly
greased (see the Trouble Shooting section of VR2W manual for
proper O-ring care).
4) Place a fresh desiccant pack in the bottom of the cylinder so both
ends of the pack are touching the cylinder’s sides.
5) Slide the end-cap into the cylinder until the first threads are inside
the outer cylinder (see photo).
6) Turn the end-cap in a clockwise direction (when looking at the
transducer) with your hand until it becomes too hard to turn. Desiccant pack in cylinder
7) Place the VR2W on a clean, flat surface so the transducer is hanging over the edge as
shown in the photo. DO NOT let the receiver fall off the surface.
8) Insert one steel rod into the hole that runs through the
diameter of the case near the flat end of the VR2W. This rod
is labelled "B" in the photo.
9) Insert the other steel rod into the wider end of the probe hole
on the end-cap of the receiver. Make sure the rod is fully
inserted or damage may occur to the probe hole. This rod is
labelled "A" in the photo.
10) Place a hand on the back of the receiver to hold it in place
(see photo).
11) Apply pressure to rod "A" in a downward direction (see
arrow in photo) so the end-cap twists in a clockwise direction
when you are facing the transducer. Rod "B" will act as a brace while you apply pressure.
Closing VR2W case.
12) Continue moving the rod until the end-cap suddenly stops turning. DO NOT continue to
apply pressure on the rod or the receiver case will be damaged. The gap between the end-
cap and the outer cylinder will be closed. Do not over tighten the end-cap or the receiver
case will be damaged.
13) Remove the steel rods from the VR2W case.
14) Deploy the VR2W receiver.
CAUTION: It is recommended that the VR2W is tested with a test pinger and the VUE software
prior to deployment to ensure proper operation of the VR2W.
A desiccant pack has been included in the bottom of the
VR2W to reduce the occurrence of condensation in the
VR2W. This pack should remain in the receiver case during
storage and deployment.
We recommend that you replace the desiccant pack with
each deployment and with each battery replacement cycle
(see manual for instructions).
More information on the availability and usage of these packs
is located on our website, www.vemco.com.

VEMCO -VR2W Receiver Battery Installation/Attachment -Page 4
ATTACHMENT METHODS
The common method used to attach a VR2W receiver to a mooring line is to use five cable ties
with certain qualities (cable tie information is found in Appendix E of the VR2W manual). One
set of five cable ties is shipped with the receiver and more may be purchased from VEMCO.
Details for using the cable ties are found in the Cable Tie Attachment Method section.
Additional equipment may be purchased from VEMCO to allow other methods of attachment to
be used, including the traditional mounting rod used with past VR2W receiver cases. Contact
VEMCO for more information on the optional
attachment methods.
For best horizontal range, mount the VR2W
receiver in a vertical position. If the VR2W is
deployed close to the bottom of the water, mount
the VR2W with the transducer pointing up to the
surface. If the VR2W is deployed close to the surface of the water, position the VR2W so the
transducer is pointing down.
The transducer must be kept free of
mooring lines regardless of the
attachment method. Objects around
the transducer will affect the detection
range of the VR2W receiver.
Cable Tie Attachment Method
The VR2W is attached directly to the mooring line with five non-releasing cable ties. Five
cable ties are supplied with the VR2W and replacement cable ties can be purchased from
VEMCO. Follow the instructions listed below to attach the VR2W receiver to the rope used as
the mooring line. A minimum rope size of 3/8" diameter nylon rope is suggested.
1) Open the "warp in the rope":
a) Identify the location on the rope where the bottom of the VR2W receiver will be
attached.
b) Twist the rope so the strands of the rope separate from each other and an opening in the
rope is seen. A photo and description is found in the Glossary section of VR2W manual.
2) Slide one of the cable ties through the center of the rope. This cable tie is identified as
number 5 in the photo below.
3) Place the VR2W receiver against the rope so the hole running through the bottom of the
receiver is lined up with the cable tie.
4) Pass the cable tie through the hole in the bottom of the receiver and latch the cable tie so the
head of the cable tie is next to the rope.
5) Wrap the cable tie labelled 4 in the photo below around the body of the VR2W so the cable
tie is in the bottom half of the lower groove in the VR2W body (see the photo below).
6) Open the "warp in the rope" as described in Step 1 to line up with the #4 cable tie.
7) Slide the cable tie through the center of the rope and latch the cable tie so the head of the
cable tie is next to the rope.
8) Wrap a cable tie around the VR2W receiver and the rope so the cable tie occupies the top
half of the lower groove in the VR2W body (see the photo below).
9) Latch the cable tie so the head of the cable tie is over the rope. This cable tie is #3 in the
photo below.
10) Repeat Steps 5 to 9 to place the cable ties labelled 1 and 2 in the photo below in the upper
groove in the VR2W body.
11) Trim the cable ties so there is no excess cable tie material and no sharp edges.

VEMCO -VR2W Receiver Battery Installation/Attachment -Page 5
3 4 5
1 2
Cable tie locations shown for attaching the VR2W receiver to a mooring line.
IMPORTANT: Cut the cable ties when removing a VR2W from the mooring line. DO
NOT re-use cable ties. Use only new cable ties when deploying a VR2W receiver.
LED FLASHES
The red LED on the side of the VR2W case flashes based on the task being performed or the
status of the receiver. The flashes can be interpreted using the table below.

VR2W LED Flashes Interpretation of Flashes
No flash Battery is disconnected or has depleted
Two quick flashes every 5 seconds VR2W is in record mode (records any
received pings)
Two quick flashes every 10 seconds The VR2W memory full
One short flash An acoustic ping was received
One long flash A complete detection was written to
memory
Continuous long flashes (1 per second) The VR2W is ready for Bluetooth wireless
technology communication
LED on constantly Communicating with VUE software using
Bluetooth wireless technology


VEMCO a Division of AMIRIX Systems Inc.
211 Horseshoe Lake Drive
Halifax, Nova Scotia, Canada B3S 0B9
Phone: [phone] Fax: [phone]
www.vemco.com
