Venesta Vepps User manual

Vepps
We know washrooms
Installation Instructions
627-191-17
(12/20)
T: 01782 277 200 | e: [email protected]
Technical Help

2
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Recommendations for Solid Grade Laminate (SGL)
• Pilot hole diameters for screw fixing to SGL to be
0.5mm less than diameter of screw.
Generally; • No 6 screw - 3.5mm
• No 8 screw - 4mm
• No 10 screw - 4.5mm
• No 12 screw - 5mm
• ALL pilot hole diameters should be screw tested
before finalising.
Cut-Outs
• Square cut-outs:
Drill four corners (at least a 10mm diameter hole),
start from one of the holes, use a jigsaw with metal
cutting blade, cut the holes & square into the
corners. Finish with metal file (semi-soft), ensure all
sharp arrises are removed to avoid injury.
• Oval or circular cut-outs:
E.g, cutting a basin hole into a vanity top. Drill one
10mm diameter hole, start from the hole, cut
according to template, use a jigsaw with metal
cutting blade. Finish with metal file (semi-soft),
ensure all sharp arrises are removed to avoid injury.
Resizing & re-edging previously finished panels
• We recommend the panel is cut as previously
described, trim to size using a ‘TREND’ sunk bead
router cutter running at 18,000 to 22,000 rpm, finish
with 300 grit sand paper.
• Polish as described below.
Finish edges
• To eliminate machine-cutting imperfections at
edges, sand with 300 grit sand paper to fine finish.
• To obtain darker edges, rub edge with cloth soaked
in linseed oil or wax. Leave to dry for 30 minutes &
wipe off.
• Sharp edges must be smoothed to avoid injury.
Machining
• Use tungsten carbide tipped blades/cutters or metal
cutting tools.
Cutting
• For a clean cut, use carbide tipped saw blades with
trapezoidal & as many teeth as possible or jigsaw
with metal cutting blade.
• Alternating teeth may be suitable, but the cut will
not be as clean.
• For best results, use horizontally fixed saws.
Precision Cutting
• A clean edge without flaking can be obtained.
• For best quality cut:
1. Saw the panel slightly oversize
2. Re-cut edge to precise measurement using a
tungsten carbide tipped router cutter of required
profile at 18,000 to 22,000 rpm.
Grooving
• SGL can be grooved; use a saw blade or router
cutter with tungsten carbide tips.
• Groove depth must not exceed 1/3 of SGL
thickness.
Drilling
• For best results use carbide bits with 3 prongs
(helicoidal bits) in preference to high-speed steel
drills.
• Holes can be drilled through part or whole of
thickness
• For stopped holes, minimum thickness of 1.5mm to
2mm of laminate must remain (maximum depth of
hole = 11mm). Minimum of 1mm space must remain
between tenon, screw tip or insert & bottom of hole
(otherwise, risk of laminate cracking when fitting)

3
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Introduction
Secure Fixing
It is vital that the structural integrity of walls, ceilings
and floors is capable of taking the dynamic and static
loads imposed by the fixings to support the product.
Insufficient structural integrity will invalidate
guarantees and cause product instability.
The surfaces being fixed into should be firm and
stable, without deflection and have good fixing
retention properties over the length and width of the
bearing surface.
Particular care should be taken with studwork walls
and suspended ceilings which will usually require the
inclusion of a pattress to sufficiently strengthen the
structure.
Poor security of fixings will compromise performance
and could lead to failure of the product.
Screws and Fixings supplied to fix components to the
floor or wall structural material should be tested to
ensure they are suited and have sufficient holding
power to accept the static and dynamic loads
required to support our products. Due to the
multitude of floor and wall constructions, it should not
be assumed that the fixings supplied are suitable for
all installations. If you are uncertain contact your
local specialist fastening supplier.
Do NOT overtighten fasteners, if using power drivers
make sure that the torque settings are correct.
Cleaning & Maintenance
Please consult our cleaning & maintenance guide.
Panel Storage & Conditioning
• To ensure panels and doors remain flat ambient
site conditions must be stable prior to delivery.
Variable temperature and humidity can cause panels
to bow and twist irreversibly.
• Before, during and after installation, temperature
and humidity must be maintained between 18 - 25˚C.
• Panels should not be stored outside or in areas
where they may be exposed to water or humidity.
• Wet trades and forced-drying procedures should be
complete and the building fully dried out.
• Use supports and spacers to elevate panels off the
floor and keep space between panels; air must be
able to circulate around each panel evenly.
• The ideal base is a slatted pallet with base board;
however, if these are not available, panels should be
carefully stacked on bearers suitably spaced to
maintain flatness. Spacing of bearers should not
exceed 400mm.
• Avoid storage conditions where extremes of
temperature and humidity can occur.
• Panels must be allowed to equalise to levels
approximating to those that will prevail during
building use.
• BS EN438 recommendations should be adhered to:
Temperature – 18 to 25˚C
Air humidity – 40 to 60%
BS 4965 Flatness: Flatness to BS 4965 can only be
guaranteed at the time of delivery.
PrerequisitesSafety
Toolbox

4
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Contents
9page 16
Subframe Connection
8page 15
Subframe Preparation
7page 13 - 14
Return End & Top Flashgap Fixing
Headrail Tie-Back to Wall/Ceiling Fixing
End Flashgap and Return End Panel Fixing
6page 11 - 12
Headrail Fixing: Shelf Height Option
5page 9 - 10
Headrail Fixing: Solid Ceiling Option
4page 8
Headrail Fixing: Suspended Ceiling Option
3page 7Corner Channel Fixing
Headrail & Tie-Back Preparation
2page 6Baserail Fixing
1page 5Layout & Levelling
12 page 21 - 22
Plumbing
11 page 18 - 20
Secondary Subframe Fixing
10 page 17
Flashgap to Subframe Fixing
13 page 23
Panel Fixing
14 page 24
15 page 25
Shelf Fixing
17 page 27
16 page 26

5
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Layout & Levelling
1
!Before installation, if in any doubt about how to install these products please contact
our technical department.
!PPE: Wear personal protection equipment at all times.
!Setting Out: Use layout drawings.
!Unit Dimensions:
Refer to layout drawings.
Any tolerances can be made up with the flashgaps.
!Installers should be highly experienced and be qualified to a carpentry joiner level.
Back-to-Wall Tie
Wall/corner
channel
Top flashgap
Headrail
Vertical
flashgaps
Return end
panel
Hinged &
lockable panels
Panels
Subframe
Corner
moulding
Baserail

6
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
*refer to layout
drawing
Baserail Fixing
2
3
2
refer to layout drawing
If using corner
moulding, cut
the extrusion
23mm shorter
and mitre the
rear leg of the
baserail
23
23
1
5mm ø
minimum
600mm centres
4Corner detail
(if required)
2
ø to suit
3
1
Plugs and screws
not supplied
Inside
view
5
Baserail must be level:
pack where necessary
!

7
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
3
3
4
Corner Channel Fixing
3
3 Wall end detail
Plugs and
screws
not supplied
ø to suit
3
1
2
Inside
view
*If no space in duct
OR for SGL
flashgaps:
Fix flashgaps to
corner channel before
fixing channel to wall
(see 10, page 17)
!
*SGL ONLY:
ensure packer
is fitted
1
refer to layout drawing
3
3
3
4
3 4 5
5
MFC/HPL Flashgaps
3 4 5
*SGL Flashgaps can be fixed to the corner channel before
fixing to the wall /positioning return ends. The corner channel
will sit above the baserail. (see 10, page 17)
2
3mm ø
1
2
mm
16
3mm ø
1
2
mm
16
Inside
view
4 Corner detail
(if required)
3mm ø
1
2
mm
16
3mm ø
1
2
mm
16
Inside
view
3mm ø
1
2
mm
16
If no space in duct:
fix from outside
Outside
view
5 Internal corner detail
(if required)

8
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
3
refer to layout drawing
5
Secure tie-backs
TIGHTLY to the
headrail
!
2
8mm ø
1
8mm ø
*Top drilling only required
for suspended ceilings (B)
2
4
Standard
assembly
Shelf height unit
assembly
Headrail & Tie-Back Preparation
4
1
refer to layout drawing
*Headrail drilling positions for tie-backs
Solid ceiling option Shelf height option
A
B
Suspended ceiling option
Tie-backs can be used either to tie to the wall (A) or ceiling (B).
6 SGL ONLY:
Ensure SGL packers are fitted to headrail
Headrail
Elevation View

9
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
2 If joint is required:
1
2
3
3mm ø
1
2
mm
16
Screw the
extrusions
together from
the rear
Headrail Fixing: Suspended Ceiling Option
5
1
top flashgap
refer to layout drawing
Flashgap Arrangement
Wall
end
Return
end
Headrail Arrangement
Suspended ceiling option
100 50
15
Structural ceiling
Suspended ceiling
Tie-backs can be
used either to tie
to the wall (A) or
ceiling (B).
A
B
600mm centres
(or to suit)
3.5mm ø
½”
No.8
⅜”
No.8
2mm ø
11mm deep
5mm deep
4
3
13mm
SGL
18mm
MFC/
HPL
18mm
MFC/HPL
13mm
SGL
1
2
5mm ø
12mm ø
through front
flange ONLY
3
Variable
Level
Screws not
supplied
SGL ONLY
ensure packers
are fitted
!

10
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Headrail Fixing: Suspended Ceiling Option (Continued)
5
3mm ø
1
2
mm
16
Inside
view
4 Wall End Fixing
Inside
view
3mm ø
1
2
mm
16
5 Return End Fixing

11
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Headrail Fixing: Solid Ceiling Option
6
Headrail Arrangement
Solid ceiling option
65 varies
15
*
*
*baton to suit (not supplied)
Flashgap Arrangement
Wall
end
Return
end
top flashgap
refer to layout drawing
length to match
headrail
baton to suit
(not supplied)
1
3
3
1
2
4
Plugs and
screws
not supplied
ø to suit
baton to suit
(not supplied)
600mm centres (or to suit)
2Screws
not supplied
41
5mm ø
Headrail must
be level: pack
where necessary
!
2 If joint is required:
1
2
3
3mm ø
1
2
mm
16
Screw the
extrusions
together from
the rear

12
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Headrail Fixing: Solid Ceiling Option (Continued)
6
1
2
5mm ø
12mm ø
through front
flange ONLY
600mm centres
(or to suit)
½”
No.8
⅜”
No.8
4
3
13mm
SGL
18mm
MFC/
HPL
18mm
MFC/HPL
13mm
SGL
2mm ø
11mm deep
5mm deep
3.5mm ø
5
Screws not
supplied
Screw
through
trimmed
packer
SGL ONLY
ensure packers
are fitted
!
Variable
Level
3mm ø
1
2
mm
16
Inside
view
6 Wall End Fixing
Inside
view
3mm ø
1
2
mm
16
7 Return End Fixing

13
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Headrail Fixing: Shelf Height Option
7
600mm centres
(or to suit)
Screws not
supplied
4
3.5mm ø
½”
No.8
⅜”
No.8
2mm ø
11mm deep
5mm deep
4
3
13mm
SGL
18mm
MFC/
HPL
18mm
MFC/HPL
13mm
SGL
SGL ONLY
ensure packers
are fitted
!
Variable
Level
1
top flashgap
refer to layout drawing
Flashgap Arrangement
Wall
end
Return
end
Option 3
50
65 *
*
*Baton to suit (not supplied):
to be fixed to underside of
shelf if required.
Option 2
65
80
Headrail Arrangement
Shelf height
Option 1
25
40
2 If joint is required:
1
2
3
3mm ø
1
2
mm
16
Screw the
extrusions
together from
the rear
3
1
2
5mm ø
12mm ø
through front
flange ONLY
3
ø to suit
1
2
Plugs and screws
not supplied
WALL
5

14
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Headrail Fixing: Shelf Height Option (Continued)
7
3mm ø
1
2
mm
16
Inside
view
6 Wall End Fixing
Inside
view
3mm ø
1
2
mm
16
7 Return End Fixing

15
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Return End & Top Flashgap Fixing
8
Lipped
flashgap
*SGL ONLY:
Ensure SGL packers are fitted to headrail
!
Headrail
Elevation View
1 Return end flashgaps
Return end
flashgap
arrangement
Lipped flashgap
3.5mm ø
½”
No.8
⅜”
No.8
2mm ø
11mm deep
5mm deep
4
3
18mm
MFC/HPL
13mm
SGL
18mm
MFC/HPL
13mm
SGL
SGL ONLY
ensure
packers are
fitted
!
Inside
view
2 Return End Fixing
3.5mm ø
¾
”
No.8
⅝
”
No.8
2mm ø
4
2
18mm
MFC/HPL
13mm
SGL
18mm
MFC/HPL
13mm
SGL
Countersink
3
600mm centres
(or to suit)
Lipped
flashgap
Return end
shown
3 Return end & top
flashgap fixing
NOTE: screws must be
positioned to be hidden
when panels are in place
Screws not supplied
SGL ONLY
ensure packers
are fitted
!

16
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Headrail Tie-Back to Wall/Ceiling Fixing
9
Plugs and screws
not supplied
ø to suit
3
1
2
WALL or
CEILING
1
WALL or
CEILING
Tighten as
required
2

17
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
End Flashgap & Return End Panel Fixing
10
1
refer to layout drawing
Flashgap Length
Bottom face of
top flashgap to
top edge of
baserail +10mm
2
tight butt
joint
3.5mm ø
½”
No.8
⅜”
No.8
2mm ø
11mm deep
5mm deep
4
3
13mm
SGL
18mm
MFC/
HPL
18mm
MFC/HPL
13mm
SGL
3
Inside
view
Screws not
supplied
Wall end detail shown
Please fix all flashgaps/
end panels to corner
channels in this way
*If no space in duct:
OR for SGL flashgaps
Fix flashgaps to corner
channel before fixing
channel to wall
(see 3, page 7)
SGL ONLY
ensure packers
are fitted
!

18
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Subframe Preparation
11
2
2
1
1
1Unlock panels
2Lift off top panel
(if applicable)
3Pull off lower lift-off
and push/pull panels
(if applicable)
Hinged Hinged Hinged
Lift-off
Push/pull
(or lift-down
if lockable)
Push/pull
(or lift-down
if lockable)
Lift-off
Hinged
Lift-off
(sliding)
Lift-off
(sliding)
Lift-off
(sliding)
Lift-off
(sliding)
Fixed
Fixed
Fixed Lift-off
FixedUrinal Back-to-Wall WC Wall Hung WC
For Multi-Panel
units subframes
are supplied in two
pieces to be joined
when connecting
subframe - see
step 12, page 21

19
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
Inside
view
3
4
secure
inside
subframe
secure
outside
subframe
2
1
5
duct depth - 20mm
(refer to layout drawing)
Subframe Preparation (Continued)
11
For Multi-Panel
units tie-backs
are required on
top & bottom
subframe
assemblies
2
1

20
T: 01782 277 200 | e: [email protected]
Technical Help
627-191-17 (12/20)
duct depth - 20mm
(refer to layout drawing)
1
3
Inside
view
Secure threads
TIGHTLY to the
carrier
!
2
Subframe Preparation (Continued)
FOR WALL HUNG WCs ONLY
11
