Walker Edison W52C2DW User manual

Item #: W52C2DW
Assembly Instructions
For our most current instructions, to request missing, lost or broken parts, or for any other Customer
Service issues, please visit our website at www.walkeredison.com or call us at 877-207-5906.
Revised 04/2012

General Assembly Guidelines
I. Insure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to Insure the proper assembly of this product.
III. Two people are recommended for ease in the assembly of this product.
IV. The main types of hardware used to assemble this product are wood dowels, cam
bolts and locks, bolts and screws.
V. The provided glue is to secure wood dowels in place. When first inserting dowels,
locate the appropriate hole for the dowel, place a small amount of glue in the hole
and insert the dowel. Wipe away excess glue immediately.
In future assembly steps when dowels are necessary to attach assembly parts
together, place a small amount of glue on the end of the dowel before attaching
parts together. Wipe away excess glue immediately.
VI. A Phillips head screwdriver is required for the assembly of this product.
VII. Power tools should not be used to assemble this product.
P.2

Parts List

Hardware List

Insert large dowels (A) into panels (1,2). Screw cam bolts (C) into panels (1,2).
Insert small dowels (B) into panels (7,8) and slats (3,9). Insert large dowels (A) into slat (3). Attach drawer
stopper (M) to slat (9) using screw (P).

Insert large dowels (A) into slat (6). Screw cam bolts (D) into slat (6). Insert small dowels (B) into panel (4).
Attach slat (6) to panel (4) using cam bolts and dowels as guides. Insert cam locks (E) into panel (4) and
tighten with a screwdriver. Screw leg (5) into panel (4).

Screw cam bolts (C) into panel (4). Attach drawer stopper (M) to panel (4) using screw (P).
Join panels (7,8) together with slat (9) using dowels as guides.

Attach panel assembly (7,8) to panel (4) using cam bolts and dowels as guides. Insert cam locks (E) into
panels (7.8) and tighten with a screwdriver. Two cam locks (E) will be inserted into each panel (7,8).
Attach slat (3) to the stand assembly using dowels as guides.

Attach panel (1) to the stand assembly using cam bolts and dowels as guides. Insert cam locks (E) into
panel (4) and slats (3,6) and tighten with a screwdriver.
Attach panel (2) to the opposite side of the stand assembly using cam bolts and dowels as guides. Insert
cam locks (E) into panel (4) and slats (3,6) and tighten with a screwdriver.

Screw cam bolts (C) into panel (10).
Insert cam locks (E) into the stand assembly as shown above. Attach top panel (10) to the stand assembly
using cam bolts and dowels as guides. Tighten cam locks (E) with a screwdriver.

Attach panels (11,12) to the back of the stand assembly using screws (F). Note that panels (12) will overlap
panel (11).
Carefully place glass panes (16) into door frames (14,15).

Secure glass panes (16) by attaching metal washers (K) to door frames (14,15) with screws (Q). The curve
of metal washers (K) will arc into glass panes (16).
Attach drawer sides (18,19) to drawer back (20) using screws (R). The thin grooves at the base of each
drawer piece will align along the interior of the drawer assembly. Repeat this step for the second drawer.

Slide drawer bottom (21) into place along the thin grooves of the drawer assembly. Fit drawer front (17) into
place. Repeat this step for the second drawer.
R
R
Secure drawer front (17) to the drawer assembly using screws (R). Attach handle (H) to drawer front (17)
using bolt (J). Repeat this step for the second drawer.

Carefully slide both drawers into the stand assembly.
Attach hinges (L) to the interior of the assembly, then to doors (14,15) using screws (N). Attach handles (H)
to doors (14,15) using bolts (J).

Insert shelf support pins (G) into the stand assembly at desired shelf heights. Place shelves (13) on shelf
support pins (G).
