INSTRUCTION MANUAL • ENGLISH & ESPAÑOL
BACK WRAP TENS + Heat
Pain Management Solution
Model 22-033BW
Model 22-051; Wrap only
PLEASE READ THESE INSTRUCTIONS COMPLETELY BEFORE
USING YOUR TENS DEVICE
Intention for Use:
To be used for temporary relief of pain associated with sore and aching muscles in the
lower back due to strain from exercise or normal household and work activities.
It is also intended for symptomatic relief and management of chronic, intractable pain
and relief of pain associated with arthritis.
See pg 5 of this manual for further details.

2 • ENGLISH
STOP! PLEASE ENSURE YOU HAVE ALL OF
THE FOLLOWING COMPONENTS BEFORE
USING YOUR TENS DEVICE
IF YOU ARE MISSING ANY PARTS, INCLUDING
INSERTS OR INSTRUCTION MANUALS, DO NOT
RETURN TO PLACE OF PURCHASE.
CONTACT CUSTOMER CARE AT 8663261313.
Instruction Manual
Replacement
Parts Order Form
USB Cable
Belt Wrap plus Extender
(22-051 includes wrap + extender only)
Electric Stimulator

ENGLISH • 3
Introduction/Indications for Use ............................................................................................................4–5
Care and Safety Information..................................................................................................................6–13
Product Features.................................................................................................................................... 14–15
Charging the Device ............................................................................................................................. 16–17
Preparing Your Device ........................................................................................................................... 18-19
Placement & Treatment............................................................................................................................... 20
Pulse Program Descriptions................................................................................................................ 20–21
Instructions for Use............................................................................................................................... 22–25
Optional Accessory —Gel Pads .......................................................................................................... 26-29
Cleaning and Storage.................................................................................................................................. 30
Troubleshooting ........................................................................................................................................... 31
Device & Label Symbols.............................................................................................................................. 32
Electromagentic Compatibility........................................................................................................... 33-36
Product Specications........................................................................................................................... 37-38
Warranty Information............................................................................................................................ 39-40
Español...................................................................................................................................................... 41-80
Toll-Free Customer Care Help Line:
1-866-326-1313
Monday – Friday
8:30 a.m. – 4:30 p.m. CST
INDEX
Distributed by
Veridian Healthcare
1175 Lakeside Drive
Gurnee, IL 60031
www.veridianhealthcare.com
Made in China
#93-1369 08/17
©2017 Veridian Healthcare, LLC

4 • ENGLISH
INTRODUCTION
Electronic Stimulator delivers electric pulses and heat generated to
the user’s skin through the electrodes. The portable and compact
device has multiple modes of dierent pulse frequencies, covering
Transcutaneous Electrical Nerve Stimulation (TENS) and Electrical
Muscle Stimulation (EMS). It includes operating elements of POWER–
ON/OFF button, intensity increase button, intensity decrease button,
mode button, timer button, and heat button, and can be attached and
detached to the electrode through the four magnetic connectors.

ENGLISH • 5
INDICATIONS FOR USE
TENS (Modes 1, 2, 4, 5, 6, 8)
To be used for temporary relief of pain associated with sore and aching
muscles in the shoulder, waist, back, arm, and leg, due to strain from
exercise or normal household and work activities.
It is also intended for symptomatic relief and management of chronic,
intractable pain and relief of pain associated with arthritis.
EMS (Modes 1, 3, 7)
To stimulate healthy muscles in order to improve and facilitate muscle
performance. To be used for the improvement of muscle tone and
rmness, and for strengthening muscles in the arms, abdomen, legs,
and buttocks. Not intended for use in any therapy or for the treatment
of any medical conditions or diseases.
It is also intended to temporarily increase local blood circulation in the
healthy muscles of lower extremities.
Heating Mode
Temporary relief of minor aches and pain
Consult with your physician before using electrical stimulation and
heat simultaneously.

6 • ENGLISH
IMPORTANT SAFEGUARDS
WARNINGS & CAUTIONS
NOTE: Read all instructions and inserts included with this device
carefully before use. The following basic precautions are needed when
using an electrical product.
Consult with your physician before using electrical stimulation and
heat simultaneously.
CAUTION: Failure to read and observe all precautions could result in
injury or equipment damage.
Improper care or use of your device may result in injury, damage to the
unit or ineective treatment. Following these instructions will ensure
the device’s ecacy and long life.
CONTRAINDICATIONS :
• Do not use this device if you have a cardiac pacemaker, implant-
ed debrillator or other implanted metal or electronic device.
• Do not use this device to treat undiagnosed chronic pain.
• Do not use this device if you have suspected or diagnosed heart
problem.
• Do not use this device if you have suspected or diagnosed
epilepsy.

ENGLISH • 7
IMPORTANT SAFEGUARDS
WARNINGS & CAUTIONS
• Do not use this device if you have a tendency to bleed internally
following an injury.
• Do not use this device during pregnancy.
GENERAL WARNINGS PRIOR TO USE
• If you are under the care of a Physician, consult with your Physi-
cian before using this device.
• Long-term eects of this device are not known.
• Do not place the device on or close to your heart.
• Take care when applying device close to the neck; do not place
this device on the front or sides of the neck. Severe spasm of the
muscles may occur and the contractions may be strong enough
to close the airway or cause diculty in breathing. Stimulation
over the neck could also aect hearing or blood pressure.
• Do not apply stimulation across the chest because the intro-
duction of electrical current into the chest may cause rhythm
disturbances to the heart.
• Do not place the device on or around your head. The eects of
stimulation of the brain are unknown.

8 • ENGLISH
IMPORTANT SAFEGUARDS
WARNINGS & CAUTIONS
• Do not use this device while sleeping.
• Do not use if you feel numbness.
• Do not use this device in or close to water.
• Use only on normal, healthy, clean skin. Do not use on or close
to open wounds or rashes, or over swollen, red, infected or
inamed skin.
• Do not apply stimulation over, or in proximity to, cancerous
lesions.
• Do not use the device on children or incapacitated persons.
• Consult with your physician before using this device, because
the device may cause lethal rhythm disturbances to the heart in
susceptible individuals.
GENERAL CAUTIONS PRIOR TO USE
• Read this manual before using this device for the rst time.
• Keep this manual available whenever you use this device.
• This device is intended for individual person use only.
• This device is not eective for pain associated with Central Pain
Syndromes, such as headaches.

ENGLISH • 9
IMPORTANT SAFEGUARDS
WARNINGS & CAUTIONS
• This device is for pain caused by muscle soreness, and should be
placed only around muscles where pain originates.
• The pain may indicate that you have some other health problem.
You should know the reason and source of your pain before
using these devices.
• The safety of using this device during pregnancy or birth has not
been established.
• The eectiveness of this device depends greatly on a person’s
individual physical condition. It may not always be eective for
every user.
• If you have had medical or physical treatment for your muscle
pain, consult with your treatment provider before using this de-
vice. You should contact your physician prior to using this device
following recent surgical procedures. Stimulation may disrupt
the healing process.
OPERATING WARNINGS & CAUTIONS
CONSULT WITH YOU PHYSICIAN IFYOU HAVE ANY OF THE FOLLOWING:
• If you have suspected or diagnosed heart problem.

10 • ENGLISH
IMPORTANT SAFEGUARDS
WARNINGS & CAUTIONS
• If you have suspected or diagnosed epilepsy.
• If you have a tendency to bleed internally following an injury.
• If you recently had surgery, or have ever had surgery on your
back.
• If areas of skin lack normal sensations, such as skin that tingles
or is numb.
• During menstruation or during pregnancy.
• The unit is intended for the temporary relief of pain caused by
muscle soreness. The source or cause of the pain should be
addressed by a healthcare professional. Pain could indicate an
injury or condition that requires treatment.
• Some people may feel skin irritation or experience a very sensi-
tive feeling in the skin due to electrical stimulation. If this occurs,
stop using these devices and consult your physician.
• If skin under the pad(s) feels irritated after using the stimulator
for a long period of time, use the stimulator for a shorter period
of time.
• Minor redness at stimulation placement is a normal skin
reaction. It is not considered a skin irritation, and it will normally
disappear within 30 minutes after the electrodes are removed.
