Veridian 01-519 series User manual

Digital Blood Pressure
Wrist Monitor
Model
01-519 series, all colors
INSTRUCTION MANUAL • ENGLISH & ESPAÑOL

STOP!
PLEASE ENSURE YOU HA E ALL OF THE
FOLLOWING COMPONENTS BEFORE USING
YOUR DIGITAL BLOOD PRESSURE MONITOR
IF YOU ARE MISSING ANY PARTS, INCLUDING
INSERTS OR INSTRUCTION MANUALS, DO NOT
RETURN TO PLACE OF PURCHASE. CONTACT
CUSTOMER CARE AT 8663261313.
Digital Monitor 2 AAA Batteries Storage Case
Instruction Manual
Quick Start uide
Blood Pressure Reading Tracking Log
FAQ Information Sheet
2• ENGLISH

ENGLISH • 3
INDEX
Care & Safety Information............................................................4-5
Introduction........................................................................................6
Digital Blood Pressure Monitor Features .....................................7
etting Started...................................................................................8
Battery Installation ...........................................................................9
Setting Date and Time .............................................................10-11
Applying Your Blood Pressure Cu .......................................12-13
Taking Your Blood Pressure Reading....................................14-15
Interpreting Your Results.........................................................16-17
Memory Functions ...................................................................18-19
Care and Maintenance.............................................................20-21
Device & Label Symbols.................................................................22
Display Symbols...............................................................................23
Troubleshooting and Error Codes .........................................24-25
FCC Statement ...........................................................................26-27
Electromagnetic Compatibility..............................................28-31
Product Specications ...................................................................32
Warranty......................................................................................33-34
Instrucciones en Español.........................................................35-70
Toll-Free Customer Care Help Line: 1-866-326-1313
Monday – Friday 8:30 a.m. – 4:30 p.m. CST
Manufactured for:
Veridian Hea thcare
1175 Lakeside Drive
Gurnee, IL 60031
www.veridianhea thcare.com
Made in China
#93-1158 06/13
©2013 Veridian Hea thcare, LLC

4• ENGLISH
CARE & SAFETY INFORMATION
Note: Read all instructions carefully before use. The following basic
precautions are needed when using an electrical product.
Caution: Failure to read and observe all precautions could result in
personal injury or equipment damage.
Improper care or use of your blood pressure monitor may result in injury,
damage to the unit or ineective treatment. Following these instructions
will ensure the blood pressure monitor’s ecacy and long life.
General Cautions & Warnings
•Measurement results should be discussed with your physician or
healthcare professional; never self-diagnose or attempt treatment as
this may be dangerous
• Intended for adult use only; this device is not approved for infant or
child use
• Keep out of reach of children
• Do not use the unit if it has any damaged parts, if it has been
submersed in water or dropped
• If any abnormality occurs, discontinue use until the unit has been
examined and repaired
• Only use included attachments and parts; do not use attachments
from other brands or models as these may not be properly calibrated
for use with this device and may result in measurement error
• Do not disassemble the unit or attempt to repair it; substitution of a
component dierent from that supplied may result in measurement
error and will void manufacturer warranty

ENGLISH • 5
CARE & SAFETY INFORMATION
• Always follow local regulations for proper disposal of the monitor, cu
and batteries
Operating Cautions & Warnings
•Prolonged over-ination may cause congestion, swelling or bruising
in some people
• If you experience any discomfort or an abnormality occurs, stop using
the device immediately; to stop the device during operation, press
the START/STOP button and the cu will automatically deate
• Operation outside of stated operating temperature may result in
measurement error or device malfunction; operation environment
temperature is: 41°F – 104°F (5°C – 40°C); Humidity: 80% RH max
• Never use this unit while operating a vehicle or in the bathtub or
shower
Storage Cautions & Warnings
•Storage outside of stated storage temperature may result in
measurement error or device malfunction; storage environment
temperature is: -4°F – 140°F (-20°C – 60°C); Humidity: 10-93%
• Keep the unit out of reach of small children
• Always keep the unit unplugged while not in use; remove the
batteries if the unit will not be used for an extended period of time
Cleaning Cautions & Warnings
•Never immerse the unit in water to clean as it may damage the unit
• Follow the ‘Cleaning and Maintenance’ portion of this manual for
instruction on how to clean and care for your monitor

6• ENGLISH
INTROD CTION
PLEASE READ THIS INSTRUCTION MANUAL
COMPLETELY BEFORE OPERATING THIS UNIT.
It is recommended that you rst seek the advice and
recommendation of your physician or healthcare professional when
using home diagnostic devices, including blood pressure monitors.
Automatic digital blood pressure monitors use the oscillometric
method to electronically measure your blood pressure. The monitor
detects your blood’s movement through the artery in your arm and
converts the movements into a digital reading. The oscillometric
method does not require a stethoscope, making the monitor ideal
for home use.
Blood pressure readings determined with this device are equivalent
to measurements obtained by a trained healthcare professional
using the cu/stethoscope auscultation method, within the limits
prescribed by the American National Standard for Electronic or
Automated Sphygmomanometers.
Thank you for purchasing a Veridian Healthcare Digital Blood
Pressure Monitor. With proper care and use, your monitor will
provide you with many years of reliable readings.

ENGLISH • 7
MONITOR FEAT RES
DETAILS OF THE DISPLAY AND INTERPRETATION
OF THE SYMBOLS ARE INCLUDED THROUGHOUT
THIS MANUAL.
Wrist Cuff
Digital Display
MEM
Recall
Button
START/
STOP
Button
(on/off)
Battery Compartment
(underside)
SET
Button
Hypertension
Indicator Light

8• ENGLISH
GETTING STARTED
Before Taking a Measurement
1. Your readings should only be interpreted by your physician or
healthcare professional with access to your individual medical
history. Regular use of a home blood pressure monitor will allow
you to track and record your readings for discussion with your
physician.
2. Conduct your measurement in a quiet place while seated in a
relaxed position. Rest for 15 minutes before taking your reading.
If an error occurs or you desire to take a second reading, allow 15
minutes between readings for your blood vessels to return to
normal.
3. Avoid smoking, eating, taking medication, alcohol, physical
activity or any other stressful activity for 30 minutes prior to
taking a reading.
4. Always remove any jewelry or constrictive clothing that may
interfere with the cu placement.
5. Keep yourself and the monitor still during measuring; do not talk
during the reading.
6. It is recommended that you take your readings as the same time
each day to better monitor any indications in your results.
7. Record your daily measurement on the included chart or some
other written document to share with your physician.

ENGLISH • 9
BATTERY INSTALATION
This unit comes complete with 2 AAA batteries.
Replace the batteries when any of the following occur:
•Low Battery symbol and ‘Lo’ appears on the display
•The display backlight dims or does not illuminate
•Monitor does not turn on after the START button is pressed
1. The battery compartment is located on the underside of the
monitor as shown in the below illustration. Carefully slide the
cover away from the housing and the cover will open.
2. Insert or replace 2 AAA
batteries into the
battery compartment,
ensuring to match the
indicated polarity
symbols. Always use
new batteries.
3. Replace the battery
cover.
4. Dispose of batteries
according to local
disposal and recycling regulations.
It is recommended to remove the batteries if the unit will not be
used for an extended period of time.

The date/time feature is on the lower right
of the display screen, Fig 1. This unit stores
the date and time, including year, allowing
for a date/time stamp on all readings in the
memory recall function.
1. When the unit is o (a blank display
screen), press and hold the SET button
for 2-3 seconds to activate the display.
The display will illuminate and the hour
will begin ashing.
2. HOUR—press the MEM button to
advance the display to the desired hour,
press SET to conrm your selection.
Note, the ‘PM’ indication will only show
on the display if the time is shown as
PM; there is no AM display icon.
3. MINU ES—press the MEM button to
advance the display to the desired
minutes, press SET to conrm your
selection.
10 • ENGLISH
SETTING DATE/TIME
IT IS NECESSARY TO SET THE DATE AND TIME
FOR THE UNIT E ERY TIME BATTERIES ARE
INITIALLY INSTALLED OR REPLACED.

ENGLISH • 11
SETTING DATE/TIME
4. MON H / DA E / YEAR—repeat the
same sequence of steps 2 and 3 to
conrm the month, date and year
desired.
5. After selecting the year by pressing SET,
the display will briey show ‘done’ and
then automatically shut o.
The monitor is now ready for use.

12 • ENGLISH
APPLYING YO R WRIST C FF
Before applying your blood pressure
cu, be sure your wrist is within the
appropriate cu range: Wrist
Circumference Range Suitable for
5-1/2” – 7-5/8” (14 – 19.5 cm).
Reminder, it is important to avoid
smoking, eating, taking medication,
alcohol consumption or physical
activity 30 minutes prior to taking a
reading.
If for any reason you are unable to or should not use your left wrist,
please modify the instructions for cu application to your right wrist.
Your physician can help you identify which wrist is best for you to
take measurements from.
PROPER CUFF FIT AND PLACEMENT IS CRITICAL
IN OBTAINING ACCURATE BLOOD PRESSURE
MEASUREMENTS. PLEASE READ THESE
INSTRUCTIONS CAREFULLY AND CONSIDER
CONSULTING WITH YOUR PHYSICIAN FOR
FURTHER DIRECTION.

ENGLISH • 13
APPLYING YO R WRIST C FF
1. Remove any constrictive clothing or
jewelry that may interfere with cu
placement.
2. Be seated at a table or desk with your
feet at on the oor.
3. Hold your left arm in front of you with
your palm facing upward.
4. Apply the preformed cu to your left
wrist so that the digital display face is
positioned on the inside area of your
wrist facing you, Fig. 1.
5. Adjust the cu 1/4” - 1/2” from the edge
of the head of the ulna bone, Fig. 2.
6. The cu should t comfortably, yet
snugly around your wrist.
If you are not comfortable with applying
your cu, please seek the assistance of
another member of your household or work
with your physician to practice the cu
application. Incorrectly applied cus may
result in inaccurate readings.
Fig. 1
Fig. 2

Please read the preceding portions of this
manual prior to taking your rst reading.
Reminder, it is important to avoid smoking,
eating, taking medication, alcohol
consumption or physical activity 30 minutes
prior to taking a reading.
1. Rest your elbow on a solid surface with
your palm facing upward. Elevate your
arm so that the cu is at the same level
as your heart, Fig 1. Be certain that the
cu is elevated to the proper level; you
may choose to support your hand with
a folded towel or book. Relax your
hand.
2. Press the START button to turn the
unit on. The unit will run a brief self-
test, Fig 2, and the display will show ‘0’.
3. The cu will automatically begin
inating; the top numbers on the
display screen will begin to go up.
4. When the measurement is complete,
your blood pressure and pulse reading
results will show on the display screen
at the same time, Fig 3.
14 • ENGLISH
TAKING YO R MEAS REMENT
Fig. 2
Fig. 1
Fig. 3

ENGLISH • 15
TAKING YO R MEAS REMENT
5. The Hypertension Indicator light on the
right side of the display will illuminate
green, yellow or red, Fig 4. See page 17
for information regarding interpreting
the Hypertension Indicator results.
6. If an irregular heartbeat was detected
during the reading, the Irregular
Heartbeat Detector indicator will
appear ashing on the display, Fig 5.
See page 16 for more information on
the Irregular Heartbeat Detector
feature.
7. The reading will automatically be
stored in memory, up to 60 readings.
8. Select START to turn the unit o and
conserve energy and battery life. The
unit will automatically shut-o after
approximately 1 minute.
Fig. 5
YOU CAN STOP THE INFLATION OR DEFLATION
PROCESS AT ANY TIME BY PRESSING THE STOP
BUTTON.
Fig. 4

Irregular Heartbeat Detection
An irregular heartbeat is dened as a heartbeat rhythm that is more
than 25% slower or 25% faster than the average measurement
detected while the monitor is conducting the measurement. When
this device detects an irregular rhythm two or more times during the
reading, the IHB symbol will appear on the display screen.
This monitor will operate if the icon appears, but the results may be
compromised, especially if this symbol appears often. Please consult
with your physician or trained healthcare professional for further
information regarding an irregular heartbeat and if this symbol
appears frequently.
16 • ENGLISH
INTERPRETING YO R RES LTS
Pulse
Pulse
Blood
Pressure
Blood
Pressure
Normal Heartbeat
Irregular Heartbeat

American Heart Association Classifications
This chart can help you identify where a given blood pressure meas-
urement falls according to American Heart Association standards.
This chart should only be considered as a guideline; always consult
with your physician to interpret your individual results. Never adjust
your medication(s) dosage, or severely alter your diet or exercise rou-
tine without consulting with your physician.
ENGLISH • 17
INTERPRETING YO R RES LTS
Hypertension Indicator
The light bar on the right hand side of the
display screen will illuminate in color at the
completion of the reading, indicating
where the measurement falls according to
the American Heart Association standards.
reen Light
<120 120–129 130–139 140–159 160–179 ≥180
<80 80–84 85–89 90–99 100–109 ≥110
SYS
DIA
Yellow Light Red Light
Normal < 120 and <80
Prehypertension 120-139 or 80-89
High Blood Pressure, Stage 1 140-159 or 90-99
High Blood Pressure, Stage 2 ≥160 or <100
Hypertensive Crisis ≥180 or <110
Category Systolic Diastolic

18 • ENGLISH
MEMORY F NCTIONS
Recalling Measurements in Memory
This monitor stores and recalls up to 60 measurements, plus an
average of the last three measurements in memory. These
measurements can be shared with your physician or trained
healthcare professional for use in evaluating your overall health.
1. When the monitor is o, press and
release the MEM button. The average
blood pressure and pulse measurement
of the most recent three readings will
show with the M and AV icons on the
screen, Fig 1.
2. Press the MEM button again to begin
scrolling through all of the
measurements from most current to
oldest, Fig 2.
Each measurement will indicate the
date and time taken, the measurement
and pulse reading, Hypertension
Indicator results and Irregular Heartbeat
if present.
Fig. 1
Fig. 2

ENGLISH • 19
MEMORY F NCTIONS
Clearing Measurements from Memory
To delete all measurements in memory, follow these steps:
1. When the monitor is o, press and
release the MEM button to access the
memory bank feature.
2. Press and hold the MEM and SET
buttons 3–4 seconds, Fig 1
3. The display will briey show ‘dEL’ and
‘done’ and then shut o after three
seconds. The memory is now clear,
Fig 2. Fig. 1
Fig. 2

20 • ENGLISH
CARE & MAINTENANCE
Proper care and maintenance of your blood pressure monitor will
help ensure long life for the product; improper use of the monitor
may void the included warranty.
Monitor Care and Maintenance
• Do not use any liquids on the monitor; use a soft, dry cloth to
clean the monitor as needed
• Storage outside of stated storage temperature may result in
measurement error or device malfunction; storage environment
temperature is: -4°F – 140°F (-20°C – 60°C);
humidity: 10-93% RH
• Do not store in direct sunlight
• Always keep the unit unplugged while not in use; remove the
batteries if the unit will not be used for an extended period of
time
• Do not attempt to disassemble your monitor; disassembling your
monitor may void the manufacturers warranty
• Do not subject the monitor to strong shocks; take care not to
drop the monitor
• With proper care, the monitor will maintain performance for a
minimum of 10,000 measurements
