Preface
TheNextiva®HDR1800UserGuidepresentsinformationandprocedureson
installing,configuring,andusingtheHDR1800.
Documentation and Firmware
DownloadthedocumentationofNextivaIPcamerasandencodersfrom:
http://www.verint.com/solutions/video-situation-
intelligence/resources/index
DownloadthedocumentationoftheNextivaVMSsoftwareandthelatest
firmwarefromtheextranet:https://online.verint.com.
Sendyourquestionsorcommentsonthecurrentdocument,oranyother
Nextivauserdocumentation,toourdocumentationfeedbackteamat
[e-mail]
Contacting Verint
Verint®SystemsisaleadingproviderofActionableIntelligence®solutionsfor
enterpriseworkforceoptimizationandsecurityintelligence.Oursolutionshelp
governmentsandenterprisesmakesenseofthevastinformationtheycollectin
ordertoachievetheirperformanceandsecuritygoals.Todayoursolutionsare
usedbymorethan10,000organizationsin150countries.Verintis
headquarteredinMelville,NewYork,withofficesworldwideand2500
dedicatedprofessionalsaroundtheglobe.YoucanreadaboutVerintVideo
Solutionsandgetmarketingmaterialandproductinformationat
http://www.verint.com/solutions/video-situation-intelligence/index.html.
Tocontactusforsales,pricingandgeneralinquiries,refertothecoordinates
below:
Location Contact Information
Americas [e-mail]
+1866-639-8482forNextivaVMSandNextiva
IntelligentEdgeDevices
[phone]forNextivaIntelligentDVRs
Europe,MiddleEast,
andAfrica
[e-mail]
+44(0)1932839500
Asia/Pacific [e-mail]
+85227975678
© 2013 Verint Video Systems Inc. 5
Preface


Contacting Service and Support
Torequestthelatestversionsoffirmwareandsoftwareortodownloadother
product-relateddocuments,youneedaccesstotheVerintVideoIntelligence
Solutionspartnerextranet.Toregister,gotohttps://online.verint.com.
Ifyouencounteranytypeofproblemafterreadingthisguide,contactyour
localdistributororVerintrepresentative.Forthemainserviceandsupport
pageontheVerintwebpage,visithttp://www.verint.com/solutions/video-
situation-intelligence/Nextiva-Service-and-Support/index.Forassistance,
contactthecustomerserviceteam:
Location Contact Information
USAandCanada [phone]
[e-mail]
Open9:00amto5:00pm(EST)Mondayto
Friday
CentralandLatinAmerica [phone]
[e-mail]
Open9:00amto5:00pm(EST)Mondayto
Friday
Europe,MiddleEast,and
Africa
+44(0)845-843-7333
[e-mail]
Open8:30amto5:30pm(GMT)Mondayto
Friday
Asia/Pacific HongKong:+85227975678
Singapore:[phone]
[e-mail]
Open9:00amto6:30pm(Mondayto
Thursday)
9:00amto5:30pm(Friday)
6 © 2013 Verint Video Systems Inc.
Contents

Safety
Alwaysobservethefollowingprecautionstoreducetheriskofinjuryand
equipmentdamage:
TheNextivaHDR1800isforindooruseonly.
TheNextivaHDR1800shouldbeplacedonasecureflatsurfaceormounted
usingoptionalhardware.
TheNextivaHDR1800shouldonlybeoperatedinaclean,dryenvironment.
Theoperatingtemperatureis32to104°F(0to40°C),withmaximum
humidityat0to95%relative,non-condensingat104°F(40°C).
OnlyusetherecommendpowercableforpoweringtheNextivaHDR1800.
DonotinstalltheNextivaHDR1800inanenclosedcabinetorothersmall
areawithoutventilation.
© 2013 Verint Video Systems Inc. 7

Summary of Changes
ThissectionliststechnicalupdatesandnewmaterialaddedtotheNextivaHDR
1800UserGuide.
Revision 5 — February 2013
ThisisthefiftheditionoftheNextivaHDR1800UserGuide.
Updates
RemovedNextivaVMS6.1integration.
Revision 4 — April 2012
ThisisthefourtheditionoftheNextivaHDR1800UserGuide.
Updates
InNextivaVMS6.2,theconfigurationofMonitortypesisnowdoneinthe
AdvancedtaboftheHDR1800.
Youcannowselectwhatinformationisshownonthescreen.
YoucannowconfigurethefontanddisplaypropertiesoftheOn-Screen
Display.
Revision 3 — October 2011
ThisisthethirdeditionoftheNextivaHDR1800UserGuide.
Updates
SupportforNextivaVMS6.2andhigher.
Summary of Changes
8 © 2013 Verint Video Systems Inc.

Revision 2 — December 2010
ThisisthesecondeditionoftheNextivaHDR1800UserGuide.
Updates
TheU.S.EnvironmentalProtectionAgency(EPA)announcedthatasaresultof
majorsuccessinmovingtheexternalpoweradaptermarkettowardsgreater
andmoresustainableenergyefficiency,effectiveDecember31,2010,theEPA
iscancellingtheEnergyStarprogramforexternalpowersupplies(EPS).To
conformtotheEPArequirements,Verintisnowstatingtheefficiencylevelfor
allEPS.
Revision 1 — April 2010
ThisisthefirsteditionoftheNextivaHDR1800UserGuide.
Features
High-definitionvideodecoder/receiverforusewithNextivaVirtualMatrix
H.264/MPEG-4/MJPEGvideodecodingatupto1920x1080screenresolution
Includesthreevideooutputs:DVI,VGA(RGB),andBNC(Composite)
FullyconfigurableinNextivaVMS6.1,includingfullintegrationwithNextiva
S1800eencodersandNextivaS5000IPcameraswithH.264video
compressiontechnology.
Supportsallthird-partycamerasandCCTVKeyboardssupportedbyNextiva
VMS
Includestwoserialports:RS-232andRS-422
Summary of Changes
© 2013 Verint Video Systems Inc. 9

TheNextiva®HighDefinitionReceiver(HDR™1800isapowerfulenterprise-
class,H.264enabledvideodecoder/receiverdesignedforlarge-scale,
geographicallydistributedoperations.TheHDRTM1800combineexcellent
performance,high-definitiontechnology,andH.264videodecompressionto
enhancethefunctionalityandversatilityofNextivaVirtualMatrix
implementations.
TheHDR1800isidealforvideosurveillanceapplicationsthatcallforhigh-
definitionvideotobedisplayedatmultiplelocationsforbuildingsituational
awarenessandacoordinatedresponse.Compatiblewithtoday'sadvanced
videotechnologies,theHDR1800offerstheflexibilitytodecodecompression
formatsfromH.264toMPEG-4toMJPEGanduseawiderangeofmonitors
includingDVI,VGA,andtraditionalCCTVmonitors.
Thefollowingtopicsarediscussed:
HardwareOverview 11
MonitorConfiguration 12
FrameRateandPerformance 13
Chapter 1
Chapter 1: Overview of the HDR 1800

Hardware Overview
TheHDR1800integratesseamlesslywithNextivaVirtualMatrix,whichroutes
videotocomputers,videowalls,andmonitorsacrosslocalandwidearea
networks(LANs/WANs).WithNextivaVirtualMatrix,authorizedpersonnelcan
viewliveandrecordedhigh-definitionvideoondigitalmonitors,createcustom
videowalls,controlPTZcameras,assigncamerastomonitorsondemand,and
replayalarm-basedvideoatmultiplelocationssimultaneously.
TheHDR1800isalsofullyintegratedwithNextivaVideoManagementSystem
(VMS)andNextiva
intelligentedgedevices,includingthestate-of-the-artS1800eencodersand
S5000high-definitionIPcameraswithH.264videocompressiontechnology.In
addition,theHDR1800supportsallthird-partycamerasandCCTVKeyboards
supportedbyNextivaVMS.
Caution
TheNextivaHDR1800isenclosedinanon-weatherproofcasingandshould
beplacedinalocationthatisnotexposedtotheoutdoorenvironment.
Description
Hardware Overview
11 © 2013 Verint Video Systems Inc.

1. OnePower/StatusLED
2. Powerbutton
3. OneBNCconnectorforcompositevideo(NTSC/PAL)
4. OneRS-232(DB9)serialportforCCTVkeyboardconnection
5. OneDigitalDVI-Dconnector(withHDMIsupportusinganHDMImaletoDVI
maleconnector-not provided)
6. TwoRJ-45(Ethernet10/100/1000Base-T)networkconnectors
7. OneLine-out,1/8in(3.5mm)stereojackforconnectingexternalaudio
equipment
8. 19VDC+/-5%powerreceptacle
9. OneRS-422(DB9)serialportforCCTVkeyboardconnection
10. OneVGA(RGB)connector
11. FourUSB2.0ports
12. OneMic-in,1/8in(3.5mm)stereojack

Product Dimensions and Weight
11W×7.5D×1.7Hin.(280W×190D×44Hmm)
5.7lb(2.6Kg)
Monitor Configuration
Youcanconnecteitheronemonitor(Singlemonitorconfiguration)ortwo
monitors(Dualmonitorconfiguration)totheHDR1800.InaDualmonitor
configuration,thefirstmonitorintheconfigurationmustbeconnectedtothe
DVI-DconnectorontheHDR1800;thesecondmonitorcanbeconnectedto
eithertheVGAorBNCconnectors.
Note
IntheDualmonitorconfiguration,thetotalnumberofvideotilesonboth
monitorscannotexceed18tiles.
ThefollowingtableliststhemonitorconfigurationsettingsfortheHDR1800.
Monitor Connector
Type Tile Layout Options Maximum Screen Resolution
Single
Monitor
Monitor
1
DVI-D
VGA
1×1(1tile)
2×2(4tiles)
DVI-D:Upto
1920×1200
Chapter 1: Overview of the HDR 1800
© 2013 Verint Video Systems Inc. 12

Monitor Connector
Type Tile Layout Options Maximum Screen Resolution
BNC 3×2(6tiles)
3×3(9tiles)
4×3(12tiles)
4×4(16tiles)
VGA:Upto
1920×1200
BNC:480/576
lines
(NTSC/PAL)a
Dual
Monitor
Monitor
1
DVI-D 1×1(1tile)
2×2(4tiles)
3×2(6tiles)
3×3(9tiles)
4×3(12tiles)
4×4(16tiles)
DVI-D:Upto
1920×1200
VGA:Upto
1920×1200
BNC:480/576
lines
(NTSC/PAL)
Monitor
2
VGAorBNC

Frame Rate and Performance
TheHDR1800supportsH.264,MPEG-4,MJPEGvideodecodingatupto
1920×1080screenresolution.Ingeneral,theperformancefordisplayingvideo
onmonitorsvariesdependingonthetilelayout,screenresolution,compression
mode,andbitrate.Thefollowingtablelistsperformancevaluesforthe
maximumframerate:
Theperformancevalueslistedbelowareprovidedforreferenceonly.
Compression Mode
Tile Layout MPEG-4 H.264
1tile 1920×1080at30fps 1920×1080at30fps
4tiles 4CIFat30fps 4CIFat30fps
6tiles 4CIFat30fps 4CIFat30fps
9tiles 4CIFat30fps 2CIFat30fps
16tiles 2CIFat30fps CIFat30fps
18tiles CIFat30fps CIFat15fps
aForDVIandVGAmonitors,theHDR1800automaticallyadjuststhescreen
resolutiontothebestavailablesettingonthemonitor(uptoamaximumof
1920x1200).
Frame Rate and Performance
13 © 2013 Verint Video Systems Inc.

ThischapterfocusesonthephysicalinstallationoftheHDR1800.Networkand
otherphysicalsettingsfortheHDR1800areconfiguredinNextivaVideo
ManagementSystem(VMS).
Thefollowingtopicsarediscussed:
PackageContents 15
InstallingonaFlatSurface 15
InstallinginaRack 16
InstallingonaWall 16
PoweringtheHDR1800 17
ConnectingNetworkCables 17
ConnectingMonitors 18
ConnectingaCCTVKeyboard 19
Chapter 2
Chapter 2: Installing the HDR 1800

Package Contents
Caution
TheHDR1800isenclosedinanon-weatherproofsteelcasingandshould
onlybeplacedinanindoorenvironment.
Eachinstallationkitcomeswiththefollowing:
OneHDR1800featuringH.264technology
Onesetofrack-mountbrackets
Onesetofwall-mountbrackets
Sixscrews(PhilipsM4×6mmpanhead)
Fourbumpons
OneAC100-240V90W/+19Vpoweradaptor
OneNextivaHDR1800QuickInstallationGuide
Installing on a Flat Surface
ThissectionexplainshowtoinstalltheHDR1800onadesktoporflatsurface.
► To install on a flat surface
1. Removeanydebrisanddustfromthesurfaceaswellasthesurrounding
area.
2. Attachthefourbumpons(provided)toeachcorneroftheHDR1800using
theprovidedscrews.
3. Placethedeviceontheflatsurface.
4. Ensurethatyouhaveaccesstoboththefrontandrearofthedeviceandthat
thefanairflowisnotblocked.
Package Contents
15 © 2013 Verint Video Systems Inc.

Installing in a Rack
Thissectionexplainshowtoinstallthedeviceinarack.
► To install in a rack
1. Alignthemountingbracketswiththeholesonthesideofthedevice.
2. Screwtherack-mountbracketstothedeviceusingusing12in-lb(1.35N-
m)forcewith6screws(provided).
3. Slidethedeviceintothe1Umountingspaceintherackcabinetandensure
thatthefanairflowisnotblocked.
4. Securethedevicetotherackcabinetusingthescrewssuppliedwiththe
rack.
Installing on a Wall
ThissectionexplainshowtoinstalltheHDR1800onawall.
► To install on a wall
1. Alignthewall-mountbracketswiththeholesonthebottomoftheHDR1800.
2. Screwthewall-mountbracketstotheHDR1800using12in-lb(1.35N-m)
forcewith4screws(provided).
3. PlacetheHDR1800onthewallandensurethatthereisenoughspaceonthe
sidesoftheunitforventilation.
Note
EnsurethewallisstrongenoughtosupporttheweightoftheHDR1800:
5.7lb(2.6Kg).
4. SecuretheHDR1800tothewallusingfourwallscrews(notprovided)on
eachsideoftheHDR1800.
Chapter 2: Installing the HDR 1800
© 2013 Verint Video Systems Inc. 16

Powering the HDR 1800
TheHDRD1800consumesupto30Wofpower.
► To power the HDR 1800
1. Connectthe19VDC+/-5%,TerminalBlockpowerconnectortothepower
inputreceptacleonthebackoftheHDR1800.
2. Securethepowerconnectortothereceptaclebytighteningthescrewson
eachsideoftheconnector.
3. Plugthe19VDC+/-5%powercableintoanoutletorsurge-protection
device.
Connecting Network Cables
► To connect the network cables
1. Plugastraight-throughEthernetcabletotheLAN10/100connectoronthe
rear.
Powering the HDR 1800
17 © 2013 Verint Video Systems Inc.

Connecting Monitors
Youcanconnecteitheronemonitor(Singlemonitorconfiguration)ortwo
monitors(Dualmonitorconfiguration)totheHDR1800.InaDualmonitor
configuration,thefirstmonitorintheconfigurationmustbeconnectedtothe
DVI-DconnectorontheHDR1800;thesecondmonitorcanbeconnectedto
eithertheVGAorBNC-Composite(TVOut).
► To connect monitors
1. Plugthemonitorcableintothecorrespondingvideoinput(DVI-D,VGA,
BNC-Composite(TVOut))onthebackoftheHDR1800.
Note
InaDualmonitorconfiguration,thefirstmonitorintheconfigurationmustbe
connectedtotheDVI-DconnectorontheHDR1800.Youcanalsoconnecta
monitorthatusestheHDMIinterfacetotheDVI-DportontheHDR1800.You
willneedanHDMImaletoDVImaleadapter(notprovided).
Chapter 2: Installing the HDR 1800
© 2013 Verint Video Systems Inc. 18

Connecting a CCTV Keyboard
TheHDR1800supportsallRS-232andRS-422CCTVkeyboardssupportedin
NextivaVMS.TheHDR1800providestwoserialportsforconnectingCCTV
keyboards:
COM1:RS-232(DB9)
COM2:RS-422(DB9)
► To connect a CCTV keyboard
1. UsethefollowingwiringschemetoconnecttheCCTVkeyboard’sserial
cabletothecorrespondingserial(DB9)portonthebackoftheHDR1800.
RS-232 DB9
Pin Number
Signal on CCTV
Keyboard Cable RS-422 DB9
Pin Number
Signal on CCTV
Keyboard Cable
2 RxD  1 Tx-
3 TxD  2 Tx+
5 Signalground  3 Rx+
7 RTS  4 Rx-
8 CTS  5 Signalground
Oncetheconnectionisdone,youmustsetthebaudrate,parity,andother
parametersfortheserialportinNextivaVMSControlCenter.
Connecting a CCTV Keyboard
19 © 2013 Verint Video Systems Inc.

NextivaVMS,version6.2andhigherautomaticallydiscoversHDR1800s
installedontheNextivanetwork.TheHDR1800canbeinoneoftwostates:
Partially DiscoveredorDevice belongs to foreign site.Oncethenetwork
settingsisconfigured,addittoPhysicalandLogicalGroupsinNextivaVMS
usingtheSystemSetupWizard.
AddingtheHDR1800UsingtheSystemSetupWizard 21
AddingtheHDR1800Manually 22
ConfiguringtheHDR1800NetworkSettings 23
ConfiguringMonitorOutputSettings 25
DefiningVideoSources 27
DefiningMonitorsintheVirtualMatrix 28
ConfiguringOn-ScreenDisplayofAnalogMonitors 30
SettingUpScreens 34
DefiningCameraTours 36
DefiningSalvos 38
DefiningVirtualMatrixGeneralSettings 39
ConfiguringtheOn-ScreenDisplay 40
Chapter 3
Chapter 3: Configuring the HDR 1800 In
Nextiva VMS 6.2 and Higher
