Veris EP2 Series User manual

Z203044-0V Page 1 of 3 ©2020 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 0820
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classied locations.
•
Read and understand the instructions before installing this product.
• Turn o all power supplying equipment before working on it.
• The installer is responsible for conformance to all applicable codes.
If this product is used in a manner not specied by the manufacturer, the protection
provided by the product may be impaired. No responsibility is assumed by the
manufacturer for any consequences arising out of the use of this material.
Installation Guide
Pressure
Product Identication
Product Overview
The EP2 electropneumatic pressure transducer uses micro-controlled poppet valve technology for highly accurate
pressure sensing. The poppet valves consume no air, eliminating unnecessary air losses in the system and allowing
for stable and reliable operation. The EP2 comes installed on standard SnapTrack, and an optional cover is available
to protect from dust and other environmental factors. An LCD display and LED indicators make it easy to read
system status at a glance.
EP2 Series
Electropneumatic Transducer
Specications
Power Supply Class 2, 22 to 30 Vdc, 20 to 30 Vac, 47 to 63 Hz, 150 mA max.
Control Input 4 to 20 mA, 0 to 10 V, 0 to 5 V; jumper selectable
Input Impedance 4 to 20 mA, 250 ; 0 to 5/0 to 10V, 10 k
Manual Override Jumper selectable mode, digital pushbutton adjust
Alarm Contact 100 mA@30 Vac/dc (If equiped)
Accuracy 1% full scale; combined linearity, hysteresis, repeatability
Compensated Temperature Range -4 to 60 °C (25 to 140 °F)
Temp Coecient ±0.05%/°C
Operating Environment 10 to 90% RH, non-condensing; -4 to 60 °C (25 to 140 °F)
SCIM 523 in/min.@45 psi; 8520 cm/min@310.3 kPA;
333 in/min@20 psi; 5407 cm/min@137.9 kPA
Supply Pressure 45 psig max
Control Range 0 to 20 psig or 3 to 15 psig jumper selectable
Pressure Dierential 0.1 psig (supply to branch)
Pressure Indication Electronic, 3-1/2 digit LCD
Minimum Tubing Length 15 feet*
Port Connection 1/8-in. i.d. poly tubing
Media Connection Clean dry air or inert gas. Not for use with oxygen service.
WARRANTY
Limited Warranty 5 years
COMPLIANCE INFORMATION
Agency Approvals EMC Conformance*: EN 61000-6-3:2007 and A1:2011 Class B,
EN 61000-6-1:2007
EP2
Output
= Selectable 3-15/0-20 psi
Feedback
0 = None
1 = Pressure Loss Alarm
2 = Manual Mode Alarm
EP2
Failsafe
0 = None
1 = Vent on Power Fail
Option
Blank = none
2 = EP Cover Plate
S1
*For shorter tubing runs use AA45 Pneumatic Capacitor.
**EMC Special Note: Connect this product to a DC distribution network or an AC/DC power adaptor with proper surge protection
(EN 61000-6-1:2007 specication requirements)
*CE mark applies to models with cover only.
*

Z203044-0V Page 2 of 3 ©2020 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 0820
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
EP2 Series Installation Guide
Dimensions
1. Mount the transducer using the screws provided. Avoid damaging the electronic components.
2. Wire the transducer and congure the jumpers for desired operation as shown in the Wiring and Conguration section below.
3. Attach pressure tubing to the hose barbs. Observe MAIN and BRANCH port labels. Use exible ¼” O.D. poly tubing for the main
and branch pneumatic connections. Main supply pressure must not exceed 45 psig.
Installation
Wiring & Conguration
1.9"
(48 mm)
3.3"
(84 mm)
3.5"
(89 mm)
Observe precautions for handling static sensitive
devices to avoid damage to the circuitry that
is not covered under the factory warranty.
Jumper Configuration
Input Current (4 to 20 mA) orVoltage (0 to 5V or 0 to 10V)
Voltage For voltage mode of operation, select 0 to 5V or 0 to 10 V
Pressure Range Select 0 to 20 psi or 3 to 15 psi scaling
Operation Mode Select AUTO for normal operation or MANUAL to adjust pressure using the pushbuttons
Options
Alarm Mode Relay The alarm contacts open if the EP2 cannot obtain 80% of commanded pressure within two (2) minutes
Manual Mode Alarm Contacts open when manual mode is selected (auto mode contacts are closed)
Vent On Power Fail The EP2 vents the branch line pressure on power failure
Terminal Block Connections
GND/Common Power supply ground and signal common.
Input Signal 4 to 20 mA, 0 to 10Vdc, or 0 to 5Vdc input from the control system.
Power 22 to 30 Vdc, 20 to 30Vac. From the control system or external power supply or transformer.
Pressure Loss Alarm
(optional)
Normally closed, solid-state contacts open if the main supply pressure fails or if the transducer is otherwise unable to
produce the correct branch pressure. Connect to the digital input of the control system for alarm status indication. If
commanded pressure does not reach 80% within 2 minutes, the alarm contacts open.
• 0 to 20 psi alarm contact does not change state when the commanded pressure is 4 psi or less
• 3 to 15 psi alarm contact does not change state when the commanded pressure is 5.4 psi or less
NOTE: In 24 Vac transformer applications, one side of the transformer secondary is connected to the signal common. Some control systems may require a
dedicated power supply transformer or isolation transformer.

Z203044-0V Page 3 of 3 ©2020 Veris Industries USA 800.354.8556 or +1.503.598.4564 / suppor[email protected] 0820
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
EP2 Series Installation Guide
Wiring & Conguration
(cont.)
Configuration Diagram
ALARM
MODE
MANUAL ADJUST
ON
OFF
Auto
Manual
0-20psi 3-15psi
0-5V
0-10V
Current
Voltage
GND/COM
INPUT SIGNAL
POWER
PRESSURE
RANGE
PRESSURE
LOSS
ALARM
(OPTIONAL)
OPERATION
MODE
INPUT
MODE
VOLTAGE
MODE
Wiring Diagram
GND
INPUT
POWER
DIGITAL IN
DIGITAL INPUT
(CONTACT CLOSURE)
ANALOG OUT (0-5/0-10, 4-20mA)
COMMON
20-45 PSI OUT
REGULATOR
DUCT DAMPER
TO DAMPER
TRAP/FILTER
PRESSURE LOSS ALARM
POWER SUPPLY
24VAC/DC
VERIS PS-24 Series
CONTROL PANEL
AIR COMPRESSOR
EP21XX
+
-
