Installation Guide
Pressure
Product Identication
Product Overview
The EP3 Series combines a microcontroller with high performance, low power coil poppet valve technology to
create a system with unparalleled accuracy and proven reliability. The poppet valves used in the EP3 consume
no air, eliminating unnecessary air losses in the system and allowing for ecient, long-term operation. The EP3
permits versatility, since all models feature manual override and a tri-state control option. The LCD provides easy
visibility and the LED indicators provide visual status of valve operation in manual or automatic mode. All models
come with SnapTrack housing and optional covers are available
EP3 Series
Electropneumatic Transducer
Specications
Power Supply Class 2, 22 to 30 Vdc, 20 to 30 Vac, 47 to 63 Hz, 150 mA max. average, 350 mA peak
Control Input 4 to 20 mA, (0 to 10 V, 0 to 5V; jumper selectable), Tri-State, PWM
Input Impedance 4 to 20 mA, 250 ; 0 to 5/0 to 10V, 10 k
Manual Override Digital pushbutton adjust, switch selectable mode
Alarm Contact 100 mA @ 30 Vac/dc (pressure loss, manual mode, jumper selectable)
Accuracy 1% F.S.; combined linearity, hysteresis, repeatability @ 20 °C ambient
Temperature Coecient ±0.1%/°C
Operational Temp. Range 5 to 60 °C (41 to 140 °F)
Operating Humidity Range 10 to 90% RH, non-condensing
SCIM 523 in/min @ 45 psi (8520 cm/min @ 310.3 kPa;)
333 in/min @ 20 psi (5407 cm/min @ 137.9 kPa)
Supply Pressure Minimum (0.1 psi plus user F.S. pressure), maximum (45 psig)
Control Range User programmable zero selectable from 0-25 psi: full scale 0-25 psi
Pressure Dierential 0.1 psig (supply to branch)
Pressure Indication Electronic, 3½ digit backlit LCD
Minimum Tubing Length 15 feet*
Port Connection 1/8-in. i.d. poly tubing
Media Connection Clean dry air or inert gas. Not for use with oxygen service.
WARRANTY
Limited Warranty 5 years
COMPLIANCE INFORMATION
Agency Approvals EMC Conformance: EN 61000-6-3 Class B:2007+A1 2011,
EN 61000-6-1:2007, EN 61000-3-2:2000, EN 61000-3-3:2001
EP3
Output Feedback
3 = Pressure Loss Alarm
or Manual Mode Alarm
EP3
Failsafe
0 = None
1 = Vent on Power Fail
Option
Blank = none
2 = EP Cover Plate
S3
*For shorter tubing runs use AA45 Pneumatic Capacitor.
**EMC Special Note: Connect this product to a DC distribution network or an AC/DC power adaptor with proper surge protection
(EN 61000-6-1:2007 specication requirements)
*CE mark applies to models with cover only.
*
0 = None
3 = Analog output: 0 to 10 Vdc
or 4 to 20mA (selectable)
