1 9880021100-CU 30P VERONA PRO 040413040413
FREE STANDING RANGE
GAS AND ELECTRIC
APPLIANCES
EUROCHEF USA inc.
MOD.: VEFSGG30
MOD.: VEFSGG31
INSTRUCTION GUIDE
INSTALLATION
AND MAINTENANCE
IMPORTANT: SAVE THESE INSTRUCTIONS.
■IMPORTANT SAFETY INSTRUCTIONS ■
Read and follow all instructions before using this appliance to prevent
the potential risk of fire, electrical shock, personal injury or damage to the
appliance as a result of improper usage of the appliance.
WARNING: If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or death.
Do not store or use gasoline or other flammable vapours and liquids in
the vicinity of this appliance.
WHAT TO DO IF YOU SMELL GAS:
-Do not to light any appliance.
-Do not touch any electrical switch.
-Do not use any phone in your building.
-Immediately call your gas supplier from a neighbour’s phone. Follow
the gas supplier’s instructions.
-If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.

2 9880021100-CU 30P VERONA PRO 040413040413
To ensure proper and safe operation: Appliance must be properly installed
and grounded by a qualified installer. Have the installer show you the location
of the gas shut off valve and how to shut it off in an emergency.
Always disconnect power to appliance before servicing.
IMPORTANT SAFEGUARDS.
Warning: To reduce risk of tipping of the appliance from abnormal usage or
by excessive loading of the oven door, the appliance must be secured by a
properly installed anti-tip devices. To check if the device is installed properly,
remove lower storage drawer and look beneath the lower frame sheet at the
back area, and verify that the anti-tip device plate is properly engaged in the
rear cover slot just above the frame sheet. You should check this anytime the
range has been moved.
Proper installation. Be sure your appliance is properly installed and grounded
by a qualified technician.
Never use your appliance for warming or heating the room.
Do Not leave children alone. Children should not be left alone or unattended
in area where appliance is in use. They should never be allowed to sit or
stand on any part of the appliance.
Wear proper apparel. Loose fitting or hanging garments should never be worn
while using the appliance.
User servicing. Do not repair or replace any part of the appliance unless
specifically recommended in the manual. All other servicing should be
referred to a qualified technician.

3 9880021100-CU 30P VERONA PRO 040413040413
Storage in or on appliance. Flammable materials should not be stored in an
oven or near surface units.
Do Not use water on grease fires. Smother fire or flame by using dry chemical
or foam-type extinguisher.
Use only dry potholders. Moist or damp potholders on hot surfaces may result
in burns from steam. Do not let potholder touch heating elements. Do not use
a towel or other bulky cloth.
Use proper pan size. This appliance is equipped with one or more surface
units of different size. Select utensils having flat bottoms large enough to
cover the surface unit gas burner. The use of undersized utensils will expose
flames out of the pot bottom to direct contact and may result in ignition of
clothing. Proper relationship of utensil to burner will also improve efficiency.
Never leave surface units unattended at high heat settings. Boil-over causes
smoking and greasy spill-over that may ignite.
Protective liners. Do not use aluminium foil to line surface unit drip areas and
oven bottoms.
Glazed cooking utensils. Only certain types of glass, glass/ceramic, ceramic,
earthenware, or other glaze utensils are suitable for cooking range use
without breaking due to the sudden change in temperature.
Utensils handles should be turned inward and not extended over adjacent
surface units. To reduce the risk of burns, ignition of flammable materials, and
spillage due to unintentional contact with the utensil, the handle of a utensil
should be positioned so that it is turned inward, and does not extend over
adjacent surface units.
Do Not touch surface units or areas near units as well as oven gas burner or
interior oven surface. Surface units and oven gas burners may be hot even
though they have no flame. Areas near surface units and interior oven
surfaces may become hot enough to cause burns. Make sure hot areas have
had sufficient time to cool, before touching them.
Use care when opening door. Let hot air or steam escape before removing or
replacing food.
Do not heat unopened food containers. Build-up of pressure may cause
container to burst and result in injury. Keep oven vent ducts unobstructed.

4 9880021100-CU 30P VERONA PRO 040413040413
Placement of oven racks. Always place oven racks in desired location while
oven is cool. If rack must be moved while oven is hot, do not let potholder
contact hot heating element in oven.
Clean ventilating hoods frequently. Grease should not be allowed to
accumulate on hood and hood filter. (when a cooking hood is installed with
appliance).
When flaming foods under the hood, turn the fan off. The fan, if operating,
may spread the flame. (when a cooking hood is installed with appliance).
CAUTION: Do Not store items of interest to children in cabinets above a
range or on the backguard of a range, children climbing on the range to reach
items could be seriously injured.
■INSTRUCTION GUIDE FOR GAS RANGETOP AND GAS OVEN ■
■RANGETOP GAS BURNER IGNITION AND REGULATION
MOD: VEFSGG30 - VEFSGG31
For models with no electronic ignition, hold a lighted match to the desired
burner head. Push in and turn the knob counterclockwise to the LIGHT-HIGH
setting. After the burner lights, turn the knob to the desired flame size, fig. 01.
Caution: When lighting the burner, be sure all of the controls are in the OFF
position. Strike the match first and hold it in position before turning to knob to
LIGHT-HIGH.
For models with single action automatic ignition, place a pan on the burner
grate. Push in and turn the knob counterclockwise to the LIGHT-HIGH
setting. A clicking sound will be heard and the burner will light, fig. 02. (All
surface igniters will spark when any control knob is turned to the LIGHT-HIGH
position), keep it pushed in till burner lights. After the burner lights, turn the
knob to the desired flame size, fig. 01.
GAS RANGETOP AND OVEN BURNER IGNITION WITH FLAME FAILURE
SAFETY DEVICE
For models equipped with both electronic ignition and safety device, follow
the same procedure as for models with automatic ignition described on last
paragraph. But you have to keep pushing in for at least 5 seconds to allow
thermocouple to heat up. Then release the knob and the burner should
remain on.

5 9880021100-CU 30P VERONA PRO 040413040413
■INSTRUCTION GUIDE FOR GAS GAS OVEN ■
■INSTRUCTION GUIDE FOR GAS OVEN, CONTROL FEATURES
OVEN GAS BURNER IGNITION, REGULATION AND THERMOSTAT
Open the oven door completely, and them push in and turn the thermostat
knob counterclockwise to 500 °F setting. See fig. 03 and 04. A clicking sound
will be heard and the burner will light. Look through orifice “F” for burner
ignition. Keep pushing knob to allow thermocouple to safety device to warm
up enough, for about a period of 5 seconds. Then release the knob and turn it
to desired temperature setting.
Attention: During first oven gas burner for the first time, or after a long non
working period, the burner may not ignite at once, so try again till gas comes
out to allow ignition. If problem persist, call an authorised technician for
repair.
GAS BROIL BURNER USE
Set thermostat to Broil mode by turning knob clockwise. See fig. 05.
Follow oven gas burner ignition procedure paragraph. Once broil burner is on,
allow a period of time for preheating the oven cavity before broiling food.
Attention: use the Grill with the oven door open and for a maximum time of
15 minutes.
MINUTE MINDER
Set required time by turning knob clockwise. As the time set elapses, a bell
signal will sound for a few seconds. This timer has only a function of time
reminder. It does not stop any oven or rangetop functions. See fig. 06
SELECTOR SWITCH
This control allows you to turn on the Oven Internal Light or Oven Forced Air
Convection Fan for cooking or defrosting purposes. See fig. 07.
OVEN LIGHT ;
Use this setting to turn on Oven light, light also remains on in all
other modes.
FORCED AIR CONVECTION FAN OR DEFROST ;
Use this setting when forced air convection is necessary for a
more even cooking finish. Also, use this setting to defrost frozen
food by speeding up air circulation.

6 9880021100-CU 30P VERONA PRO 040413040413
ON AND OFF PILOT LIGHT
Whenever one of the above functions is selected, the red light goes on.
CAUTION:
1) Do not store or use gasoline or other flammable vapours, liquids
or items in the vicinity of this or any other appliance.
2) Never use appliance as a space heater to heat or warm a room.
3) Do not obstruct the flow of combustion and ventilation air by blocking the
room vents or air intakes. Restriction of air flow to the gas appliance prevents
proper performance and increases carbon monoxide emission to unsafe
levels.
4) Continuously use of the appliance may need extra ventilation, this can be
solved by just opening a window or increasing exhaust power of a cooking
hood.
5) If flame should go out during operation, turn the burner off. If a strong gas
order is detected, open a window and wait five minutes before relighting the
burner.
6) Be sure all control knobs are set in the OFF position prior to supplying gas
to the hob.
COOKWARE
To achieve optimum surface cooking performance, select heavy gauge, flat,
smooth bottom pans that conform to the diameter of the cooking area as well
as straight sides.
Pan size should match the size of the cooking area. Pan should not extend
more that 2” beyond the cooking area on gas cooking surface.
Proper pans will reduce cooking times, use less energy and cook food more
evenly.
Remember to use pans with flat bottoms and handles that are easily grasped
and stay cool. To minimise burns, ignition of flammable materials and spillage
due to unintentional contact with the utensil, do not extend handles over
adjacent surface burners. Always turn pan handles toward the side or back of
the appliance, not out into the room where they are easily hit or reached by
children.
NOTES FOR COOKWARE ON GAS BURNERS
We recommend the following pan size per each type of burner, fig. 08:
BURNER TYPE COOKING PAN BOTTOM SIZE
Small (7000 BTU), on VEFSGG30SS from 4 to 6 in Ø
High (12500 BTU), on VEFSGG30SS from 6 to 8 in Ø
Power (14000 BTU), on VEFSGG31SS from 6 to 8 in Ø
U-Power (18000 BTU), on VEFSGG31SS from 8 to 10 in Ø

7 9880021100-CU 30P VERONA PRO 040413040413
Burner operational Notes, fig. 08A:
-A properly adjusted burner with clean ports will light within a few seconds.
If using natural gas the flame will be blue with a deeper blue inner cone.
-If the burner flame is yellow or is noisy the air/gas mixture maybe incorrect.
Contact a service technician to adjust.
-With LP gas, some yellow tips on the flames are acceptable. This is
normal and adjustment is not necessary.
-If sooty is noticed on pan bottom, contact a service technician to adjust.
-If the control knob is turned very quickly from HIGH to LOW, the flame may
go out, particularly if the burner is cold. If this occurs, turn the knob to the
OFF position, wait several seconds and relight the burner. Refer to LOW
SETTING VALVE ADJUSTMENT chapter to adjust LOW setting, if
needed.
-The flame should not extend beyond the edge of the pan, fig. 08B .
MAINTENANCE
CLEANING SAFETY
Turn off all controls and wait for appliance parts to cool before touching or
cleaning them. Do not touch the burner grates, oven inner surface or
surrounding areas until they have had sufficient time to cool.
Clean appliance with caution. Use care to avoid steam burns if a wet sponge
or cloth is used to wipe spills on a hot surface. Some cleaners can produce
noxious fumes if applied to a hot surface.
RANGETOP GAS BURNERS
Take off the removable parts and put them for 10 minutes in soapy
warm water. Eventual stubborn soils can be removed by using a
nonabrasive pad or a plastic scouring pad, then rinse making sure that
all openings are free of dirt, fig. 09.
ATTENTION: After cleaning the burner cup, on model VEFSGG31SS, make
sure to place the burner cup in the right position, figure 10A.
SURFACE AND OVEN COOKING CAVITY CLEANING

8 9880021100-CU 30P VERONA PRO 040413040413
This is easily done using a damp cloth and a non-abrasive detergent,
wipe using a soft dry cloth. For stainless steel parts with stubborn soils. Use
only plastic scrubbing pad or a sponge with vinegar and warm water.
Because of many new cleaning products introduced in the marketplace each
year, it is not possible to list all products that can be safely be used to clean
this appliance. Read carefully the cleaner manufacture’s instructions to be
sure the cleaner can be safely used on this appliance. Although, to determine
if a cleaning product is safe, test a small inconspicuous area using a very light
pressure to see if the surface may scratch or discolour. This particular
important for porcelain enamel, highly polished, shiny, painted or plastic
surfaces.
ABNORMAL OPERATION
Any of the following are considered to be abnormal operation and may
require servicing:
- Burner flame with yellow tips.
- Sooty on pan bottom.
- Difficult burner ignition.
- Burners fail to remain lighted.
- Burner will flame out.
- Difficult on turning gas valves.
NOTES:
Control regularly the correct functioning of cooktop gas valves, oven gas
thermostat and selector switch.
In case of abnormal functioning of these devices, you must immediately
call a qualified technical assistance service.
OVEN DOOR
TO REMOVE OVEN DOOR
1) Fully open the oven door.
2) Raise and open the U-clip (B) over the hook on each of the hinges (A) all
the way to the front, see figure 11.
3) Grasp the door by the sides toward the back. Raise the front of the door a
few inches and make sure the U-clip (B) is locked by the door frame. This
will prevent the hinge from snapping closed when the door is removed.
(there will be some spring resistance to overcome because of the hinge

9 9880021100-CU 30P VERONA PRO 040413040413
being locked). When the front of the door is high enough and hinges are
locked, you will be able to lift the hinges to clear the slots
4) Pull the hinges out of the slots in the oven front frame.
TO REPLACE THE OVEN DOOR
1) Grasp the sides of the door at the centre and insert the ends of the hinges
(A) and fix the slots in the oven front frame.
2) With the door open all the way, push-back the two U-clips (B) into the
hinge (A).
3) Raise the oven door and make sure that it fits evenly with the front sides.
WARNING: Never release the U-clip levers when the door is off. Do not close
the hinges without the weight of the door, the powerful springs will snap the
hinges closed with great force.
CAUTION: Do not place excessive weight on or stand on an open oven door.
This could cause the range to tip over, break the door, or injure the user.
Also, do not attempt to open or close door or operate oven until door is
properly replaced.
REPLACING THE OVEN LIGHT
WARNING; To prevent electrical shock and or personal injury:
1) Before replacing the light bulb, be sure the electric power is turned off at
the circuit breaker.
2) Do not operate the oven unless the light cover is securely in position.
3) Be sure the oven and light bulb are cool.
4) Do not touch hot bulb with a damp cloth as this may cause the bulb to
break.
5) If the light cover is damaged or broken, do not use the oven until a new
cover is in place.
To replace oven light bulb:
1) Before replacing light bulb, disconnect oven electric circuit.
2) Remove oven racks.
3) Remove, unscrewing, lens bulb cover and light bulb.
4) Replace bulb with a 25 W – 120 Vac appliance bulb only.
5) Replace lens bulb cover.
6) Reconnect power to range. Reset electronic clock.

10 9880021100-CU 30P VERONA PRO 040413040413
INSTALLATION INSTRUCTIONS
SPECIAL WARNING:
ONLY QUALIFIED AND AUTHORIZED PERSONNEL SHALL INSTALL OR
SERVICE THIS RANGE.
READ “SAFETY INSTRUCTIONS” IN THIS BOOK BEFORE USING
RANGE.
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE,
MAINTENANCE OR USE OF RANGE CAN RESULT IN SERIOUS INJURY
OR PROPERTY DAMAGE, AND SO THE MANUFACTURE WILL NOT BE
RESPONSIBLE.
This appliance shall be installed in accordance with the manufacturer’s
installation instructions, local gas fitting regulations, ANSI & NF Gas code
Z223.1 & CAN-B149.1 02 as well as ANSI & NFPA 70 or Canadian Electrical
Code.
CLEARANCE DIMENSIONS
Range may be installed with zero inches clearance adjacent to (against)
combustible construction at the rear and on the sides below the cooktop. For
complete information in regard to the installation of wall cabinets above the
range and clearances to combustible wall above the cooking top see the
installation drawing fig. n°12 and 13. For Safety Considerations do not install
a range in any combustible cabinetry which is not in accord with the
installation drawings.
NOTE: 42 inch dimension between cooking top and wall cabinet shown on
illustration does not apply to ranges with an elevated oven. The “A” 36 inch
dimension may be reduced to not less than 36 inches when the wall cabinets
in a domestic home are protected with fireproof materials in accordance with
American National Standards – National Fuel Gas Code. “B” has to be not
less than 8 inch from the top surface to a vertical side combustible wall.
The “C” dimension is the total of product’s width plus
To eliminate the risk of burns or fire by reaching over heated surface units,
cabinet storage space located above the surface units should be avoided.

11 9880021100-CU 30P VERONA PRO 040413040413
If cabinet storage is to be provided, the risk can be reduced by installing a
range hood that projects horizontally a minimum of 5 inches beyond the
bottom of the cabinets.
CAUTION: SOME CABINETS AND BUILDING MATERIALS ARE NOT
DESIGNED TO WITHSTAND THE HEAT PRODUCED BY THE NORMAL
SAFE OPERATION OF A LISTED APPLIANCE. DISCOLORATION OR
DAMAGE, SUCH AS DELAMINATION, MAY OCCUR.
LOCATING THE RANGE
Do not set range over holes in the floor or other locations where it may be
subject to strong drafts. Any opening in the wall behind the range and in the
floor under the range should be sealed. Make sure the flow of combustion or
ventilation air is not obstructed.
NOTE: A range should not be installed over kitchen carpeting.
VENTILATION
Ventilation must be in accordance with local installation code. The appliance
must be install in a well-ventilated environment to guarantee a correct
combustion gases exchange, proper air circulation and working temperature
within safety limits.
MODEL NUMBER PLATE
The Model Number Plate is located on the underneath case. A second Model
Number Plate is applied on the front page of the instruction booklet.
ANTI-TIP DEVICE INSTALLATION INSTRUCTIONS
NOTE: A risk of range tip over exists if the appliance is not installed in
accordance with the installation instructions provided. The proper use of this
device minimises the risk of TIP-OVER . In using this device the consumer
must still observe the safety precautions as stated in the Instruction Manual
and avoid using the oven door and/or lower drawer as a step stool.
Installation instructions are provided for wood and cement wall. Any other
type of construction may require special installation techniques as deemed
necessary to provide adequate fastening of the ANTI-TIP bracket to the wall.
STEP 1 – Locating The Bracket (see fig. 14)
A. Mark the wall from either the right or left rear “EDGE” of the range is to be
located.

12 9880021100-CU 30P VERONA PRO 040413040413
B. Place the Anti-Tip Bracket 8 5/8” for this Range from the marked “EDGE”
toward centre of opening and against the back wall with a first hole height
of 1 ¾” plus “A” (distance between side wall bottom edge and floor after
range levelling) as shown in figure 14.
C. Use the bracket as a template and mark the required holes, as shown in
figure 14, for the type of construction you will be using.
STEP 2 – Anti-Tip Bracket Installation
Locate the centre of the two holes to be drilled on the wall. Drill a 1/8” pilot
hole in the centre of each hole. (A nail or awl may be used if a drill is not
available). On Wood Construction Wall secure the Anti-Tip bracket to the wall
with the two 3/8” x 1 ½” self-drilling screws provided, and on Cement or
Concrete Construction Wall secure the Anti-Tip bracket to the wall by drilling
two holes with a 4/8” drilling bit and using the two 3/8” x 1 ½” wall plugs with
screw.
NOTE: Be aware of not drilling the wall hole in proximity of steel pipes or
other components inside the wall that may be damaged. As shown in figure
14 you have two slots in the rear cover to choose from. Also, use a minimum
of 2 screws to install bracket to the wall.
STEP 3 – Range Installation
A. Align the range to its designated location and slide it back into position.
Make sure that the Anti-Tip bracket plate is fully inserted into the range
rear cover slot and above the lower frame plate.
B. For Safety Considerations as well as optimum performance adjust the
range so it is level. This may be checked by placing a spirit level or a large
pan of water on the rangetop or on the oven rack. If an adjustment is
required on free standing, pull the range forward, tip the range and rotate
the levelling feet as required. Slide-in ranges require total removal from
cabinet before an adjustment can be made.
C. To check the range for proper installation of the anti-tip bracket: Remove
lower storage drawer, by pulling downward the lever A on the right hand
side and pulling upward the lever B on the left hand side, while pulling
both levers pull out the drawer or in case that a lower storage drawer is
not supplied remove the lower foot cover by lifting it up and pulling. Use a
flashlight and look beneath lower frame plate and verify that the anti-tip
device horizontal side is properly engaged in the rear cover slot and just
above the lower frame plate.

13 9880021100-CU 30P VERONA PRO 040413040413
D. Proceed with the reminder of the installation instructions.
CONNECTING THE RANGE
ELECTRICAL SUPPLY
The appliance, when installed, must be electrically grounded in accordance
with local codes or, in absence of local codes, with National Electrical Code,
ANSI/NFPA 70
In Canada the appliance must be installed in accordance with the current
CSA Standard C22.1 - Canadian Electrical Code part 1.
IMPORTANT: The appliance must only be installed by a qualified and
specialised electrician,
ELECTRICAL INSTALLATION
This appliance is equipped with a three-prong grounding plug, which must be
plugged directly into a properly grounded three-hole single-phase 120 VAC -
60 Hz 15 amps electrical outlet.
NOTE: House wiring and fusing must comply with local codes. If no local
codes are applicable, wire in accordance with the National Electrical Code,
ANSI/NFPA 70 latest edition.
The three-prong grounding plug offers protection against shock hazards. DO
NOT CUT OR REMOVE THE THIRD GROUNDING PRONG FROM THE
POWER CORD PLUG.
If an ungrounded, two-hole or other type of electrical outlet is encountered, it
is the personal responsibility of the appliance owner to have the outlet
replaced with a properly grounded three-hole electrical outlet.
The cable cord connected to the appliance, it’s a flexible type of cable. Pass it
through hole prepare in cabinet to plug it to wall socket.
To facilitate service, the flex cable must not be shortened and should be
routed to permit temporary removal of the appliance.
GROUNDING
IMPORTANT: Local codes might vary, installation, electrical connections and
grounding must comply with all applicable local codes.

14 9880021100-CU 30P VERONA PRO 040413040413
WARNING: This appliance requires ground connection for your protection
against shock hazard and should be connected directly into a properly
grounded receptacle.
WARNING: DISCONNECT ELECTRICAL SUPPLY BEFORE
SERVICING THE APPLIANCE.
When the flexible cord has to be changed it is necessary to follow
the procedure hereafter described:
-Turn off main gas shut-off valve and disconnect electrical supply
-Pull out entire range from the counter.
-Disconnect gas supply connector from appliance gas manifold
-Open up connecting terminal block cover.
-Open flexible cord lock and loosen up old cord prongs from terminal block
-Connect new flexible cord prongs to terminal block and fix flexible cord lock,
remember earth wire, yellow and green, must be longer by one inch that the
other ones. For Line and Neutral wire connection, follow signs on terminal
block.
-The flexible cord must be hold tight by the cord lock, in such a way that it
may not pulled out. The flexible cord path must not be in proximity or in
contact with hot surfaces that may damage the cord itself.
ATTENTION: the flexible cord must be in accordance with National
Electrical Codes and suitable for the hob technical characteristics
electrical ratings. A 18 AWG three-prong grounding plug flexible cord,
type SJT 3x18 AWG.
THE MANUFACTURES DECLINE ANY RESPONSIBILITY FOR IMPROPER
INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE,
MAINTENANCE OR USE OF RANGE WHICH CAN RESULT IN SERIOUS
INJURY OR PROPERTY DAMAGE.

15 9880021100-CU 30P VERONA PRO 040413040413
GAS SUPPLY
Installation of this range must conform with local codes or, in the absence of
local codes, with the National Fuel Gas Code, ANSI Z223.1 latest edition.
In Canada the range must be installed in accordance with the current CGA
Standard CAN/CGA-B149 – Installation Codes for Gas Burning Appliances
and Equipment and/or local codes.
GAS SUPPLY CONNECTION: (SEE FIGURE 15)
A TRAINED SERVICEMAN OR GAS APPLIANCE INSTALLER MUST
MAKE THE GAS SUPPLY CONNECTION. Leak testing of the appliance
shall be conducted by the installer according to the instructions given
in section (h).
Natural gas supply line must have a natural service regulator. Inlet pressure
to this appliance should be reduced to a maximum of 7 inches water column.
Liquefied Petroleum L.P. / Propane gas supply line must have a L.P. gas
pressure regulator. Inlet pressure to this appliance should be reduced to a
maximum of 14 inches water column.
Inlet pressure in excess of 14 in. W.C. can damage the appliance pressure
regulator, or other gas components in this appliance and can result in a gas
leak.
a) A gas cut-off valve should be put in an accessible location in the supply
line ahead of the range, for turning on and turning off gas supply. If hob is
to be connected to house piping with flexible or semi-rigid metal
connectors for gas appliances, connectors nuts must not be connected
directly to pipe threads. The connectors must be installed with adapters
provided with the connector.
b) The house piping and/or range connector used to connect the hob to the
main gas supply must be clean, free of metal shavings rust, dirt and liquids
(oil or water). Dirt, etc in the supply lines can work its way into the range
manifold and in turn cause failure of the gas valves or controls and clog
burners and/or pilot orifices.
CAUTION: DO NOT LIFT OR MOVE RANGE BY DOOR HANDLES OR
BACKGUARD.
c) Turn off all pilots and main gas valve of other gas appliances.
d) Turn off main gas valve at meter.
e) Before connecting range apply pipe thread compound approved for LPG
to all threads.

16 9880021100-CU 30P VERONA PRO 040413040413
f) Connect range to gas supply at appliance pressure regulator using
adapters supplied with flexible connector. Rigid pipe may also be used.
See rating plate for type of gas range has been manufactured for.
g) Turn on main gas valve at meter, and relight pilots at other gas
appliances.
h) Apply a non-corrosive leak detection fluid to all joints and fittings in the gas
connection between the supply line shut-off valve and the range. Include
gas fittings and joints in the range if connections were disturbed during
installation. Check for leaks!. Bubbles appearing around fittings and
connections will indicate a leak. If a leak appears, turn off supply line gas
shut-off valve, tighten connections, turn on the supply line gas shut off
valve, and retest for leaks.
CAUTION: NEVER CHECK FOR LEAKS WITH A FLAME.
WHEN LEAK CHECK IS COMPLETE, WIPE OFF ALL RESIDUE.
i) Remove shipping polystyrene from ALL rangetop burners. This is to hold
the burners in place on the burner base for shipping purposes only.
CHECKING PRESSURE OF HOUSE PIPING SYSTEM
1) The appliance and its individual shutoff valve must be disconnected from
the gas supply piping system during any pressure testing of that system at
test pressure in excess of ½ lbs./sq. in. (3.5 kPa or 13.8 in. water column).
2) The appliance must be isolated from the gas supply piping system by
closing its individual manual shutoff valve during any pressure testing of
the gas supply piping system at test pressure equal to or less than ½
lbs./sq. in. (3.5 kPa or 13.8 in. water column).
GAS CONVERSION
All Ranges are equipped with both Natural Gas and LP Gas injectors as well
as a convertible appliance pressure regulator. The unit model number plate
states which gas it was adjusted for at the factory. To convert the unit to
either Natural gas or LP gas will require switching burner injectors, burner
adjustment for low flame and adjustment of the appliance pressure regulator
converter cap.
Inlet pressure to the appliance pressure regulator should be as follows for
both operation and checking of appliance pressure regulator setting:

17 9880021100-CU 30P VERONA PRO 040413040413
INLET PRESSURE IN INCHES OF WATER COLUMN.
PRESSURE
Minimum Maximum
Natural gas 4 7
LP gas 11 14
GAS BURNER INJECTOR CONVERSION
To switch injectors, it is enough to unscrew fixed injector using a proper
7 Hex. key tool and replace it with new injector for new gas setting.
For proper injector size, follow Rangetop and Oven Technical Data chart and
fig. 09.
On Gas Oven Burner, adjust burner air shutter to the widest opening that will
not cause the flame to lift or blow off the burner when cold. In case of yellow
flame on burner, open burner air shutter making sure the flame does not lift or
blow off. In case of distinct blue flame but lifting, close burner air shutter to
the point where it will not cause a yellow flame, figure 16.
APPLIANCE PRESSURE REGULATOR CONVERSION
The unit appliance pressure regulator must be set to match the type gas
supply used. If converting from natural gas to LP gas, the appliance pressure
regulator must be converted to regulate LP gas. If converting from LP gas to
natural gas, the appliance pressure regulator must be converted to regulate
natural gas. To install the gas regulator you must you a CSA certified Pipe
Sealant only.
To convert the appliance pressure regulator from one gas to another; remove
the cap, push down and turn counter-clockwise. Turn the cap over and
reinstall, follow the NAT or LP indication (figure 17).
NOTE: THE GAS TYPE YOU ARE CONVERTING TO MUST BE
VISIBLE ON THE TOP OF THE INSTALLED APPLIANCE PRESSURE
REGULATOR CAP.
SERVICE – PARTS INFORMATION
When your range requires service or replacement parts, contact your dealer
or authorised service agency. Please give the complete model and serial
number of the range which is located on the range model number plate.

18 9880021100-CU 30P VERONA PRO 040413040413
LOW SETTING VALVE ADJUSTMENT
The LOW setting should produce a stable flame when turning the knob from
HIGH to LOW. The flame should be 1/8 inch or lower and must be stable on
all ports on LOW setting.
To adjust: Operate burner on HIGH for about five minutes to preheat burner
itself. Turn knob back to LOW; remove knob, and insert a small flat tip
screwdriver into the centre of the valve stem. Adjust the flame size by turning
adjustment screw in either direction, while holding the stem (figure 18). For
Gas Oven adjustment remove knob and insert a small flat tip screwdriver on
left side slot (figure 19).
Flame must be of sufficient size to be stable on all burner ports. If flame
adjustment is needed, adjust ONLY on the LOW setting. Never adjust flame
size on higher setting.
NOTE: All gas adjustment should be done by a qualified service
personnel only.
RANGETOP AND OVEN BURNER TECHNICAL DATA
VEFSGG31SS (NATURAL GAS)
MAX POWER BTU/HR Injector Valve by-pass
BURNER
Natural HIGH SMALL HIGH SMALL
U-POWER 18000 1.93 0.81 0.66 – open 180° 0.66 – close
POWER 14000 1.65 0.78 0.66 – open 180° 0.57 – close
OVEN 12000 1.60 0.40 – open 230°
BROIL 12000 1.60 /
VEFSGG31SS (L. PROPANE GAS)
MAX POWER BTU/HR Injector Valve by-pass
BURNER
PROPANE HIGH SMALL HIGT SMALL
U-POWER 17000 1.07 0.50 0.66 – open 60° 0.50 – close
POWER 13000 0.93 0.45 0.57 – close 0.39 – close
OVEN 11000 1.00 0.40 – open 90°
BROIL 11000 1.00 /
VEFSGG30SS
MAX POWER BTU/HR Injector Valve by-pass
BURNER
Natural Propane NATURAL
GAS
PROPANE
GAS
NATURAL
GAS
PROPANE
GAS
HIGH 12000 11000 1.60 1.00 open 220° open 60°
SMALL 7500 7000 1.25 0.80 open 220° open 60°
OVEN 12000 11000 1.60 1.00 open 230° open 90°
BROIL 12000 11000 1.60 1.00 / /

19 9880021100-CU 30P VERONA PRO 040413040413
OVEN TECHNICAL DATA
ELECTRICAL DATA VEFSGG30SS
30 in.
CONVECTION
GAS OVEN
VEFSGG31SS
30 in.
CONVECTION
GAS OVEN
VOLTAGE 120 Vac ~ 60Hz.
TOTAL POWER 12000 BTU 12000 BTU
BROILING GAS BURNER 12000 BTU 12000 BTU
BOTTOM GAS BURNER 12000 BTU 12000 BTU
OVEN LIGHT 25 W 25 W
OVEN FAN 25 W 25 W
COOLING FAN 30 W 30 W
USEFUL OVEN INTERIOR DIMENSIONS
HEIGHT 12
1/2
in 12
1/2
in
WIDTH 16
1/2
in 16
1/2
in
DEPTH 16 in 16 in
OVERALL SIZE 2.0 cu. ft. 2.0 cu. ft.
ENERGY POWER PERFORMANCE
Consumption to reach 350 °F
Consumption to maintain 350 °F for one hour
Total consumption
Consumption to reach 390 °F
Consumption to maintain 390 °F for one hour
Total consumption
BROILING AREA
OVEN ACCESSORIES
One Dripping Tray
Two Cooking Racks, four rack positions
DIMENSIONS OF THE APPLIANCES
Series Width (in) Height (in) Depth (in)
VEFSGG30SS 29 7/8 35 – 36 27 ½
VEFSGG31SS 29 7/8 35 – 36 27 ½
In our continuing effort to improve the quality and performance of our cooking
products, it may be necessary to make changes to the appliance without
revising this guide. The manufacturer does not take any responsibility on
booklet printing mistakes.

20 9880021100-CU 30P VERONA PRO 040413040413
FIGURES
Fig. n°01 Fig. n°02
Fig. n°03
Fig. n°04
Fig. n°05 Fig. n°06 Fig. n°07
