VERSARE MP10 User manual

MP10
Assembly Instructions (5 or 7 Panels)
Reserve Materials Take out and set aside 4 part B, 4 part Dand the 2 canvas end
panel covers with Velcro tabs.
Layout first plain canvas panel, Velcro closure facing up. Insert 2 part D, one for each side.
Connect the panel frame posts with 2 of part A, facing the two plain ends the same direction.
Use 4 Screws on the inside of corners to secure the frame. Pull canvas ends taut and seal
Velcro flaps to finish your outside panel.
Hardware included:
AA
D
D
Panel Assembly - Step 1
1.
2.
Screws Wheels End
Panel
Plates
Hinge
Plates
Parts included:
A - Outside Panel Frame Caps (4) B - End Panel Frame Caps (4) C - Center Panel Frame Caps
(8) 5-panel or (10) 7-panel
D - Panel Frame Posts (10) 5-panel or (14) 7-panel
Canvas panel covers (5) 5-panel or (7) 7-panel
(2 with Velcro Tabs are for end panels)
Panel Assembly - Step 2
Panel Assembly
1

Layout final plain
canvas panel, Velcro
closure facing up. (2
panels with Velcro tabs
are still set aside for
end panels). Insert 2
part D, one for each
side. Connect the panel
frame posts with the
two remaining part A,
facing the two plain
ends opposite the end
assembled in Step 2.
Use 4 more Screws on
the inside of corners to
secure the frame. Seal
Velcro flaps. Layout
panels in order of
assembly as pictured for
step 5.
A
A
DD
Center Panel
Outside Panel Outside Panel
Center Panel Center Panel
4.
Next, lay out second plain canvas panel, Velcro closure facing up. Again insert 2 part D, one
for each side. Connect the panel frame posts with 2 part Cand use 4 Screws on the inside of
corners to secure the frame. Pull ends taut and seal Velcro flaps to finish your center panel.
If you have a 7-panel MP10 repeat this step two more times so you have a total of 3 center
panels.
C C
D
D
Outside Panel
Center Panel
3.
Final Outside Panel
2

With panels laid out next to each other, all Velcro tabs facing up, use 1 Hinge Plate and 2
Screws for each connection point of the completed panels.
+
+
5.
When all the panels are connected, top and bottom, for a total of 4 secured hinge plates
(5-panel) or 8 secured hinge plates (7-panel), fold up screen like an accordion and set aside.
Assemble the end panels with the reserved materials in Step 1. Layout each of the two
remaining canvas panels, Velcro closures facing up. Insert 2 part D, connecting them with
the 4 part Bremaining. Secure frame with 4 Screws.
D
D
BB
End Panel
End Panel
6. End Panels
Connecting the Panels
With both end panels flat on the ground,
Velcro closures facing up, locate two
screw holes in each of the End Panel
Frame Caps below the canvas. Use 2
Screws per end panel frame cap to
secure each of the 4 End Panel Plates,
pointed end facing up.
7. Attach End Panel Plates
3

Unfold outside panel from top of panel stack and secure first end panel with 2 Screws
through remaining holes of each End Panel Plate. (Velcro closures of end panel should be
facing towards the bundle) Repeat to secure other end of end panel.
Carefully turn stack over so panels are positioned vertically on end, resting on the first
attached end panel.
+
+
+
+
+
+
+
+
+
+
8. Attach End Panels
+
+
+
+
+
+
+
+
+
+
+
+
+
+
Set final end panel on top of vertical stack, end panel plate pointing down. Using 4 Screws,
secure the final end panel, 2 screws for each End Panel Plate.
4

100008 REV B
Versare Solutions, LLC
3236 California St. NE • Minneapolis, MN 55418
1-855-457-1473 • [e-mail]
Assembly complete! Carefully stand unit up and enjoy!
We hope you enjoy your new MP10!
For questions regarding your MP10 please contact us at
1-855-457-1473 or
[e-mail]
Tap in Casters (or alternately feet), 2 in each end panel, 4 in center panels. Only 1 caster per
center panel is required, alternating sides of panels as you go.
+
+
+
+
+
+
+
+
+
+
+
+
+
+
9. Casters
