Vertex VAC-10 User manual
1
©2008 VERTEX STANDARD CO., LTD. Printed in Japan.
Service Manual
Desktop Rapid Charger
VAC-10
Specifications
Desktop Rapid Charger (CD-30):
Charging Current (approx): 1 A
Operating Temperature Range: +41 °F to +95 °F (+5 °C to +35 °C)
Case Size (W x H x D): 11.6” × 7.6” × 14.1” (294 × 193 × 358 mm)
Weight (approx.): 11.6 Ib (5.3 kg)
AC Adapter (PA-38):
PA-38B: Input: 120 VAC, 60 Hz / Output: 16 VDC, 600mA
PA-38C: Input: 230 VAC, 50 Hz / Output: 16 VDC, 600mA
PA-38U ( w/ UK plug): 230-240 VAC, 50 Hz / Output: 16 VDC, 600mA
PA-38H : 240 VAC, 50 Hz / Output: 16 VDC, 600mA
PA-38B (120VAC):AAE30X002
PA-38C (230VAC):AAE30X003
PA-38U (230-240 VAC, w/UK plug):AAE30X004
PA-38H (240VAC):AAE30X007
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
VERTEX STANDARD (AUSTRALIA)PTY., LTD.
Normanby Business Park, Unit 14/45 Normanby Road
Notting Hill 3168, Victoria, Australia
EAE75X90B
AAE29X001
CD-30
2
CD-30 Parts Layout
CD-30 Circuit Diagram
Component side Solder side
3
CD-30 Exploded Views & Mechanical Parts
S8002171
TOP CASE
S8002170
LIGHTGUIDE
S8002169 (x3pcs)
CONTACT
S8002172 (x5pcs)
RUBBER FOOT
4
CD-30 Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.
LOT
SIDE
LAY ADR
*** CD-30 ***
C 1 CHIP CAP. 20pF 50V 5% GRM1882C1H200JZ01D K22174218
C 2 AL.ELECTRO.CAP. 220uF 35V 10%
C 3 AL.ELECTRO.CAP. 220uF 35V 10%
C 4 CHIP CAP. 0.1uF 25V(50V) (10%) GRM188F11E104ZA01D K22145001
C 5 CHIP CAP. 0.1uF 25V(50V) (10%) GRM188F11E104ZA01D K22145001
C 6 CHIP CAP. 0.1uF 25V(50V) (10%) GRM188F11E104ZA01D K22145001
C 7 CHIP CAP. 0.1uF 25V(50V) (10%) GRM188F11E104ZA01D K22145001
C 8 CHIP CAP. 0.1uF 25V(50V) (10%) GRM188F11E104ZA01D K22145001
C 9 CHIP CAP. 0.1uF 25V(50V) (10%) GRM188F11E104ZA01D K22145001
C 10 CHIP CAP. 20pF 50V 5% GRM1882C1H200JZ01D K22174218
C 11 CHIP CAP. 0.01uF 50V 10% GRM188B11H103KA01D K22174823
D 1 DIODE 1N4007
D 2 DIODE 1N5819
D 3 DIODE 1N4148
DC 1 CONNECTOR DS-308
F 1 FUSE 1.25A/250V(UL,CSA)
J 1 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000
J 2 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000
J 3 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000
J 4 CHIP RES. 0 1/8W 5% RMC1/8T 000J J24215000
J 5 Metal lead 0.6x10.7mm
L 1 INDUCTANCE 105UH/2A
LED1 LED 5(ka.together)green/red
Q 1 TRANSISTOR 2SB772 G3207720Q
Q 2 TRANSISTOR 1N9014/SOT-23
Q 3 TRANSISTOR 1N9014/SOT-23
Q 4 TRANSISTOR 1N9014/TO-92
R 1 CHIP RES. 100 1/8W 5% RMC1/8T 101J J24215101
R 2 CARBON FILM RES. 5.1k 1/4W 5% RD14TJ512 J01245512
R 3 CHIP RES. 5.1k 1/16W 5% RMC1/16 512JATP J24185512
R 4 CARBON FILM RES. 560 1/2W 5% RD12TJ561 J01275561
R 5 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102
R 6 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102
R 7 CHIP RES. 300 1/16W 1% RMC1/16 301FTP J24183301
R 8 CHIP RES. 300 1/16W 1% RMC1/16 301FTP J24183301
R 9 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103
R 10 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103
R 11 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103
R 12 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103
R 13 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103
R 14 CHIP RES. 10k 1/16W 1% RMC1/16 103FTP J24183103
R 15 CHIP RES. 10k 1/16W 1% RMC1/16 103FTP J24183103
R 16 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473
R 17 CHIP RES. 100k 1/16W 1% RMC1/16 104FTP J24183104
R 18 CHIP RES. 8.87k 1/16W 1%
R 19 METAL FILM RES. 0.33 1/2W 2%
R 20 CHIP RES. 100 1/8W 5% RMC1/8T 101J J24215101
R 21 CHIP RES. 2k 1/8W 5% RMC1/8T 202J J24215202
U 1 IC TL431/TO92
U 2 IC S3F9454 SOL-20
