Vertiv Liebert XDP User manual

Liebert® XDP
User Manual
High Heat Density Precision Air Conditioning

Copyright by Vertiv Co. Ltd.
The content in this document is subject to change without notice. All rights, including rights of translation,
reproduced by printing, copying or similar methods, and even of parts, are reserved. Violators will be liable for
damages. All rights, including rights deriving from patent license or registration of a utility model or design, are
reserved. No part of this document may be reproduced or transmitted in any form or by any means without the
prior written consent of Vertiv Co. Ltd.
Notice
The purchased products, services, and features are stipulated by the contract made between Vertiv Co.,
and the customer. All or part of the products, services, and features described in this document may not be
within the purchasing scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided “AS IS” without warranties, guarantees or
representations of any kind, either express or implied. The information in this document is subject to change
without notice. Every eort has been made in the preparation of this document to ensure the accuracy of the
contents, but all statements, information, and recommendations in this document do not constitute a warranty
of any kind, express or implied.
Vertiv Co., Ltd.
China
Homepage: www.vertiv.com
E-mail: [e-mail]
Customer service hotline: [phone]
Asia Pacific
Homepage: www.vertiv.com.
E-mail: [e-mail]
For Technical Support, users may contact the nearest Vertiv Co. local sales oice or service centre.

Purpose of the Document
This document applies to the series of precision air conditioners and cooling solutions which maintain optimal
environmental control of technological ecosystems at minimal operating costs. This document gives an overview
of the specifications, installation, commissioning, and maintenance procedures with troubleshooting from the
user perspective. The figures used in this document are for reference only.
Please read this manual carefully before installing, maintaining, and troubleshooting.
Liebert XDP precision air conditioners is professional device, it is only for professionals and they are adapted to
the place where entry is restricted for normal people.
Styling used in this Guide
The styles used in the manual will be defined as mentioned in the following table:
Situation Description
Warning/Danger/Cauon • The Warning/Danger/Caution note indicates a hazardous or potentially
harmful situation that can result in death or injury. It also indicates in-
structions that need to be adhered to, failing which may result in danger
and safety issues thereby having an adverse eect on the reliability of
the device and security. Even for practices not related to physical injury,
to avoid equipment damage, performance degradation, or interruption in
service, follow the warning instruction.
Note
• The Note section indicates additional and useful information. It also calls
attention to best practices and industry-best protocols that are stan-
dardized and help make maximum utilization of the resources at hand.
Helpful information related to the product also comes under the Note
heading, helping the users with the definitions, concepts, and terminolo-
gies used in the manual.
Version History
Version Revision Date Issue Changes
1.0 26.03.2019 ---

Safety Precautions and Measures
The important safety precautions and measures that should be followed during the installation and
maintenance are described in the following sections.
Read the manual prior to installation and operation of the unit. Only qualified personnel should move, install, or
service this equipment.
The user reads and considers all the precautions, compliance, and safety measures before working on
the equipment. The unit control must be used exclusively for the purpose which it is intended for; the
manufacturer takes no liability for incorrect use or a modification to the unit control.
Adhere to all the Warnings and Cautionary measures included in the manual.
Please read this manual carefully before installing, maintaining and troubleshooting; especially the
Warning/Danger/Caution information in the User Guide. Apart from the User Guide, also pay attention to
the warning labels on the unit and its components.
This manual is retained for the entire service life of the unit. The user must read all the precautions, danger,
warnings, and cautionary measures mentioned in the manual prior to carrying out any operations on the unit.
Each unit is equipped with an electric insulation which allows the users to work in safe conditions. The main
switch is positioned on the electrical panel cover; Open the right door to access it. Before any maintenance
operation, switch o the unit with this electrical insulation device to eliminate risks such as electrical shocks,
burns, automatic restarting, moving parts, and remote control. The panel key, supplied along with the unit,
must be kept by the personnel responsible for the maintenance. The protective covers can be removed after
the electric power has been cut o by opening the main switch.
In the following sections, notice the various cautionary measures and warnings that need to be read carefully
prior to installing or operating the system.
Disconnect the local and remote power supplies prior to working with the unit.
Prior to the installation process, read all the instructions, verify if all the parts are in place, and check the
nameplate to ensure the voltage matches the available utility power for the unit.
The controller doesn’t isolate power from the unit even in the O mode, and some internal components still
require and receive power during the O mode.
If the unit door is open while the fans are operating, the airflow may result in abrupt slamming of the door
resulting in injury. Another aspect is the presence of small objects in the fans bay which may result in object
ejection during the fan start-up and there is a probable risk of being hit by these objects leading to grievous
injury as well as causing equipment damage.
The unit contains fluids and gases under high pressure. Therefore, the pressure should be relieved before
working with the piping.

Some components can be extremely hot during the unit operation. Therefore, allow suicient time for the unit to
cool down before working with the unit cabinet. Handle the unit with extreme caution and wear safety equipment
such as protective gloves, safety shoes, and arm protection while working with the hot components.
There is a risk of leaking water that can cause damage to the equipment as well as the building. There should
be an eective water drain connection and facilities. Installation should be precise. Implementation of the
application and service practices should be suitable and fault-free. Not complying with these norms will result
in water leakage from the unit. Water leakage can result in massive damage and loss of critical equipment in the
hosting ecosystem. Therefore, care should be taken to ensure that the unit must not be located directly above
any equipment that could sustain damage due to water and excessive moisture. Using a leak detection system
for the unit and system supply lines are recommended by Vertiv Co.

Vertiv | Liebert XDP | User Manual i
Table of Contents
Chapter 1: Product Overview.................................................................................................................................................................................1
1.1.Product Introduction................................................................................................................................................................................................... 1
1.2.Model Description........................................................................................................................................................................................................ 1
1.3.Model Nomenclature................................................................................................................................................................................................ 3
1.4.Components ..................................................................................................................................................................................................................... 3
1.4.1.Inverter pump......................................................................................................................................................................................................3
1.4.2.Plate Heat Exchanger................................................................................................................................................................................4
1.4.3.Fluid Reservoir...................................................................................................................................................................................................4
1.4.4.Two-port Valves...............................................................................................................................................................................................4
1.4.5.Micro-processor Controller ..................................................................................................................................................................4
1.4.6.Graphical Color Screen.............................................................................................................................................................................4
1.4.7.Variable Frequency........................................................................................................................................................................................4
1.5.Optional Components.............................................................................................................................................................................................. 5
1.6.Performance Parameters...................................................................................................................................................................................... 5
Chapter 2: Pre-Installation......................................................................................................................................................................................6
2.1.Equipment Room Requirements...................................................................................................................................................................6
2.2.Installation Space Requirements.................................................................................................................................................................6
2.2.1.Maintenance Space Requirements...............................................................................................................................................7
2.2.2.Side Outlet Holes for Water Pipes.................................................................................................................................................8
2.3.Environmental Requirements .........................................................................................................................................................................9
2.3.1.Operating Environment.............................................................................................................................................................................9
2.3.2.Storage Environment.................................................................................................................................................................................9
2.4.Refrigerant Requirements................................................................................................................................................................................10
2.5.Transportation, Unpacking and Inspection......................................................................................................................................10

Vertiv | Liebert XDP | User Manual ii
2.5.1.Transportation and Movement .......................................................................................................................................................10
2.5.2.Unpacking............................................................................................................................................................................................................11
2.6.Inspection.........................................................................................................................................................................................................................12
Chapter 3: Mechanical Installation (Site Preparation)...........................................................................................................13
3.1.Installation Notes........................................................................................................................................................................................................13
3.2.System Installation Layout...............................................................................................................................................................................13
3.2.1.Overall Layout of the System ............................................................................................................................................................13
3.2.2.Schematic System Installation Diagram .............................................................................................................................. 14
3.2.3.Ball Valves on XDP and Cooling Modules/ XDH Units ........................................................................................... 16
3.2.4.Mechanical Parameters.........................................................................................................................................................................17
3.2.5.Dimension of the Outlet Pipe on the Base Plate and the Top Plate.......................................................... 18
3.3.XDP Installation...........................................................................................................................................................................................................19
3.3.1.Leveling the Cabinet................................................................................................................................................................................. 19
3.3.2.Removing Leveling Feet and Fastening .............................................................................................................................. 20
3.3.3.Combined Cabinet Parts......................................................................................................................................................................22
3.4.Unit Piping Installation........................................................................................................................................................................................23
3.4.1.Dimension of the Internal Pipes.....................................................................................................................................................23
3.4.2.Brass Connection between the XDP and the Cooling Module/ XDH......................................................24
3.4.3.Refrigerant Pipe Connection between the XDP and the Cooling Module..........................................25
3.4.4.Connection of the Chilled Water Pipes of the XDP Unit.......................................................................................26
3.5.Post Installation Check.......................................................................................................................................................................................28
3.5.1.Blocking Holes on Top Plate of Cabinet.................................................................................................................................28
3.5.2.Leakage Detecting by Nitrogen...................................................................................................................................................29
3.6.Mechanical Installation Inspection..........................................................................................................................................................29

Vertiv | Liebert XDP | User Manual iii
Chapter 4: Electrical Installation...................................................................................................................................................................30
4.1.Task Introduction and Notes..........................................................................................................................................................................30
4.1.1. Wires and Cables to Connect On-site ....................................................................................................................................30
4.1.2.Installation Notes........................................................................................................................................................................................30
4.2.XDP Cable Connection .......................................................................................................................................................................................31
4.2.1.Positions of Electrical Interfaces of the XDP Unit.........................................................................................................31
4.2.2.Connecting the Power Cable of the XDP Unit................................................................................................................32
4.2.3.Connecting Control Cables...............................................................................................................................................................32
4.3.Electrical installation Inspection...............................................................................................................................................................35
Chapter 5: Startup Commissioning ............................................................................................................................................................36
5.1.Start-up Commissioning.....................................................................................................................................................................................36
5.1.1.Preparations Before Commissioning......................................................................................................................................... 36
5.2.Commissioning Procedure..............................................................................................................................................................................36
5.2.1.Maintaining the Pressure .................................................................................................................................................................... 36
5.2.2.Evacuating the System.........................................................................................................................................................................37
5.2.3.Charging the Refrigerant.................................................................................................................................................................... 39
5.3.Post Commissioning Inspection .............................................................................................................................................................. 40
Chapter 6: Color Screen Operation Guide...........................................................................................................................................41
6.1.Features...............................................................................................................................................................................................................................41
6.2.Appearance....................................................................................................................................................................................................................41
6.3.Main Screen of the Display.............................................................................................................................................................................42
6.3.1.Startup Screen................................................................................................................................................................................................42
6.3.2.Main Screen Display................................................................................................................................................................................42
6.3.3.Operation Instances................................................................................................................................................................................ 45
6.3.4.Password Screen........................................................................................................................................................................................ 45

Vertiv | Liebert XDP | User Manual iv
6.4.Alarm Menu...................................................................................................................................................................................................................46
6.5.System Setup...............................................................................................................................................................................................................49
6.5.1.System Parameter Settings..............................................................................................................................................................49
6.5.2.Water Valve Parameters......................................................................................................................................................................50
6.5.3.Pump Parameters........................................................................................................................................................................................51
6.6.XDP and XDH Parameters..............................................................................................................................................................................52
6.6.1.XDP Parameters............................................................................................................................................................................................52
6.6.2.XDH Parameters .........................................................................................................................................................................................52
Chapter 7: Variable Frequency Controller...........................................................................................................................................55
7.1.Wiring Terminal............................................................................................................................................................................................................55
7.2.Human Machine Interfaces ............................................................................................................................................................................56
7.3.Human Machine Operations ............................................................................................................................................... 59
7.3.1.Initial Power-On Screen......................................................................................................................................................................... 59
7.3.2.Main Menu......................................................................................................................................................................................................... 59
7.3.3.Main Menu of the Running Status Parameters..............................................................................................................60
7.3.4.Current Alarm Quantity Menu......................................................................................................................................................... 61
7.3.5.Historical Alarm Quantity Menu....................................................................................................................................................62
Chapter 8: System Operation and Maintenance ..........................................................................................................................66
8.1.Routine Inspection Items (Monthly).......................................................................................................................................................66
8.2.Routine Inspection Items (Semi-Annually).....................................................................................................................................67
8.3.System Diagnosis Testing...............................................................................................................................................................................67
8.4.Electrical Connection Inspection.............................................................................................................................................................68
8.4.1.Electrical Maintenance.......................................................................................................................................................................... 68
8.4.2.Control Part Maintenance.................................................................................................................................................................68
8.5.Pump Maintenance................................................................................................................................................................................................69

Vertiv | Liebert XDP | User Manual v
8.6.Plate Heat Exchanger Maintenance.......................................................................................................................................................72
8.7.Two-port Water Valve Maintenance........................................................................................................................................................72
8.8.Liquid Reservoir Maintenance.....................................................................................................................................................................72
8.9.System Piping Maintenance...........................................................................................................................................................................72
Appendix I: Menu Structure of Micro Processor Controller............................................................................................73
Appendix II: Alarm Output Menu...................................................................................................................................................................74
Appendix III: Monthly Maintenance Checklist................................................................................................................................75
Appendix IV: Routine Maintenance Checklist (Semi-Annual) ......................................................................................76
Appendix V: Table Names and Content of Harmful
Substances in Products...........................................................................................................................................................................................77

Vertiv | Liebert XDP | User Manual 1
Product Overview
Chapter 1: Product Overview
This chapter introduces the product description, model description, product appearance, and main components
of the Liebert XDP precision air conditioner.
1.1.Product Introduction
The Liebert XDP refrigerant distribution unit is an interface between the building chilled water system and
the cooling modules in the Liebert XD system. It is designed to circulate and control refrigerant to the cooling
modules that are in the room with heat-producing equipment.
The Liebert XDP is available in two versions one prevents coil condensation by maintaining the refrigerant
being pumped to the cooling modules at a temperature above the room’s dew point and other supports
dehumidifications. It also monitors room conditions. All functions, such as switching pumps (if applicable),
controlling refrigerant temperature, etc., are automatic.
1.2.Model Description
The physical appearance of XDP is shown in Figure 1-1, and Figure 1-2 shows main components of the XDP unit.
Figure 1-1 Appearance of the Liebert XDP Precision Air Conditioner

Vertiv | Liebert XDP | User Manual 2
Product Overview
No. Description No. Description
1 Fluid Reservoir 3 Plate heat exchanger
2 Two-way valve 4 Inverter pump
Figure 1-2 Main Components of XDP Unit

Vertiv | Liebert XDP | User Manual 3
Product Overview
1.3.Model Nomenclature
The model of the XDP is fully-defined by eleven digits, as represented in Table 1-1.
Table 1-1 Nomenclature of XDP Unit
1 2 3 4 5 6 7 8 9 10 11
XD P 2 0 0 R M 1 L 2 0
Digit 1,2 Product Model Digit 8 Refrigerant Type
XD X-treme Heat Density System 1 R410A
P Pump 2 R134a
Digit 3 Cooling Capacity kW Digit 9 Installation Type
0-9 Nominal Net Cooling Capacity - kW L In-row Type
Digit 4 Cooling Capacity kW 5 Room Type
0-9 Nominal Net Cooling Capacity - kW Digit 10 System Configuration
Digit 5 Cooling Capacity kW 2 Two-way Valve
0-9 Nominal Net Cooling Capacity - kW 3 Three-way Valve
Digit 6 Module Size Digit 11 Version
R Pump Redundancy 0 Non-dehumidification
Digit 7 Power Supply 1 Dehumidification
M380 V to 415 V/ 3 Ph/ 50 Hz+N,
380 V to 415 V/ 3 Ph/ 60 Hz+N
1.4.Components
This section provides an overview of the major components and their features of the XDP. Liebert XDP includes
inverter pump, plate heat exchanger, fluid reservoir, two-port valve, microprocessor controller, graphical color
screen, and variable frequency controller.
1.4.1.Inverter pump
As the core of the entire system, the inverter pump circulates refrigerant to each cooling module. It adopts the
eicient fully-closed variable speed pump which can adjust the refrigerant flow on demand. It features low power
consumption, anti-cavitations, anti-reverse impact capability, higher reliability and energy-saving ability.

Vertiv | Liebert XDP | User Manual 4
Product Overview
1.4.2.Plate Heat Exchanger
The unit is equipped with a water-refrigerant heat exchange brazing plate. This plate heat exchanger has a
special heat exchanging channel, which features higher heat exchange eiciency, higher compact pattern, lower
pressure drops, greater cooling capacity, corrosion resistance, and safe and leakage-free operation.
1.4.3.Fluid Reservoir
The system facilitated with a large-capacity fluid reservoir to store enough refrigerant. Three fluid sight glasses
at the side of the reservoir are used to observe the internal liquid level. The safety valve on the top is used to
safely relief the excess pressure, thus ensures stable and reliable operation of the system.
1.4.4.Two-port Valves
The system equipped with a well-known brand two-port valve with an equal flow percentage. A large-torque
valve actuator is also installed to achieve the valve opening in real time, that ensures accurate and reliable water
flow regulation. By default, the unit is configured with the two-port valve.
1.4.5.Micro-processor Controller
The Liebert XDP precision air conditioner is equipped with a microprocessor controller that adopts the advanced
PID based technology. Multi-level password protection can eectively prevent unauthorized operations. The
microprocessor controller provides the self-recovery function against power failure. The runtime of major
components can be accurately understood through the menu. The professional-level fault diagnosis system can
automatically display the current fault and facilitates easy device maintenance. The microprocessor controller
can store up to 2000 historical events. The microprocessor controller provides RS485 interface and can also
adopt the Modbus protocol.
1.4.6.Graphical Color Screen
The 7-inch LED color screen supports sensitive touch, tree-type menu, user-friendly screen, and simple
operation. User can view the operational status and parameters of the XDP and the cooling module in real time.
By configuring the RS485 interface, the system can store up to 2000 historical events.
1.4.7.Variable Frequency
The variable frequency controller controls the pump frequency in a variable manner, accurately adjusts the
refrigerant flow, and communicates with the main controller. It timely uploads alarm information and protects the
system. This feature helps in reliable operation.

Vertiv | Liebert XDP | User Manual 5
Product Overview
1.5.Optional Components
• Coolant - R134a
• Non-standard air and water temperature
• Fin & tube type heat exchanger
• Wooden box for abroad
• Dual-power in XDP
• Three-way valve
1.6.Performance Parameters
Table 1-2 describes the performance parameters of XDP unit.
Table 1-2 Performance Parameters
Parameters Liebert XDP
Model XDP200
Total Capacity (kW) 200 160
Controller PACC
Refrigerant R134a/ R410A R134a/ R410A
Inlet/ outlet WT (°C) 7 °C/ 12 °C 10 °C/ 15 °C
Water flow rate (m3/h) 35.26 29.25
Pressure drop-waterside (kPa) 99 73
Power supply 380 V/ 415 V 3 Ph 50 Hz/ 60 Hz
Pump type Gear pump, variable speed
Pump power (W) 1600 1400
Dimensions (HxWxD) mm inch
1945x600x1100 76.6”x23.6”x43.3”
Operational Weight (kg) 420

Vertiv | Liebert XDP | User Manual 6
Pre-Installation
Chapter 2: Pre-Installation
XDP precision air conditioner is a distinctly engineered equipment which requires preliminary preparation
before installation. This chapter provides the pre-installation details, including how to prepare the installation
environment, space and reserve the maintenance area. It also gives the air conditioner operational and storage
environment requirements, followed with the procedure to unpack the unit and placement strategies.
2.1.Equipment Room Requirements
The requirements are as follows:
1. Before installation, the equipment room must be prepared to ensure a smooth operating flow and to achieve
the expected results. The data center must meet the standards, to obtain proper ventilation and heating. The
design specifications for the air conditioners must be ideal and should be in-line with the energy-eicient
design standards.
2. To ensure the normal operation of environmental control system, the room should be moisture proof and the
equipment room should have a sealed damp-proof layer. Polyethylene film should be used for the damp proof
layer on the ceiling and walls. Alternatively, the same eect similar to polyethylene can be simulated with
moisture-proof paint. It is important to ensure that the coating on the concrete wall and floor is damp-proof.
3. The equipment room should be free of air leakage, reduced to a minimum because outdoor air can increase
the system load and de-stabilize the temperature gradient. It is recommended that the leakage rate of outdoor
air be kept below 5% of the total indoor airflow.
4. To avoid any outside air infiltration into the room, all the doors and windows should be properly closed.
• Avoid locating the indoor unit in concave or narrow areas which can aect the airflow. It is prohibited to use
the XDP precision air conditioner in an unconducive outdoor environment.
• Vertiv recommends that the site preparation is defined as per the requirements. However, if these
requirements are not met, Vertiv recommends that rectifications be made on the site in order to comply with
the specified requirements and conditions.
• However, if the rectifications or modifications are not implemented, then Vertiv does not guarantee the
accuracy and precision of the temperature and humidity provided by the unit.
2.2.Installation Space Requirements
The Liebert XDP consists of a cabinet that includes a heat exchanger, circulating pump (s), control valve,
receiver, controls, valves and piping. Cooling module can be chosen according to the application and to the
appropriate scenarios.

Vertiv | Liebert XDP | User Manual 7
Pre-Installation
2.2.1.Maintenance Space Requirements
In column installation or room installation mode, user needs to open the front or rear door for maintenance. A
provision space of 600 mm in the front, at the rear, and at the screen side should be reserved for maintenance
activities, as shown in Figure 2-1. Table 2-1 describes the requirements for minimum maintenance space.
Figure 2-1 Space Clearance for Maintenance for XDP Unit
Table 2-1 Minimum Maintenance Space (unit: mm)
Space locations
XDP200RM1L20
XDP200RM1L21
XDP200RM1R20
XDP200RM1R21
mm inch
Front 600 23.62”
Rear 600 23.62”
Screen side 600 23.62”

Vertiv | Liebert XDP | User Manual 8
Pre-Installation
• The space is used for routine maintenance of the unit, the front of the unit is the side of the control box, the
opposite side of the rear is the back door.
• The XDP screen is at the front in column installation mode. Therefore, on both sides, user must reserve
enough maintenance space.
• Contact Vertiv local representative for any special application.
2.2.2.Side Outlet Holes for Water Pipes
The location of the holes on the side panel of XDP unit is shown in Figure 2-2.
Figure 2-2 XDP Side Panel with Holes
Four circular holes are provided in the side panel of XDP to support the side installation for water piping.
However, some customers prefer the down pipeline, and do not need these four holes. In such case, the side
panel with holes can be moved against the wall of the building. Consult Vertiv local representative for any
special application.

Vertiv | Liebert XDP | User Manual 9
Pre-Installation
2.3.Environmental Requirements
2.3.1.Operating Environment
The operating environment of Liebert XDP precision air conditioner meets the requirements of GB4798.3- 2007.
See Table 2-2 for details.
Table 2-2 Operating Environment Requirements
Item Requirements
Ambient temperature Indoor 18 °C to 40 °C, RH<60%
XDP protection level IP20
Altitude <1000 m, Derating is required when the altitude higher than 1000 m.
Operation voltage range 380 V±10%, 3N~, 50 Hz/ 60 Hz
Contamination level Level II
2.3.2.Storage Environment
The storage environment of Liebert XDP precision air conditioner meets the requirements of GB4798.1-2005. See
Table 2-3 for details.
Table 2-3 Storage Environment Requirements
Item Requirements
Storage environment Indoor, clean, no dust
Ambient temperature <95%RH
Ambient humidity -25 °C to +55 °C
Storage time Total transportation and storage time should not exceed six months,
otherwise the performance of the system needs to be re-calibrated.

Vertiv | Liebert XDP | User Manual 10
Pre-Installation
2.4.Refrigerant Requirements
• Do not use sub-standard quality inferior refrigerant as it may cause an extensive damage to the system.
Vertiv does not undertake any responsibility for all the related consequences that result from using a low
quality inferior refrigerant.
2.5.Transportation, Unpacking and Inspection
2.5.1.Transportation and Movement
Railroad and shipping are the preferable transportation options, if transport by rail or by ship is unavailable, then
transport by road is recommended. When selecting road transport, roads without too many bumps are highly
recommended.
• Liebert XDP unit is heavy (see Chapter 3 Table 3-1 for the weight parameters), it is recommended to use the
mechanical equipment like electrical forklift to move the unit.
• Move the equipment to the location near the installation site.
• If an electric forklift is used, insert the tines of the forklift below the pallet as displayed in Figure 2-3.
• Figure 2-3 shows how the forklift tines are inserted underneath the pallet and the illustration to the right in the
same picture shows that the lines should be aligned with the center of gravity to prevent the equipment from
falling over.
Figure 2-3 Forklift Removal
While moving the indoor unit, keep the obliquity within the range of 75° to 105°, as shown in Figure 2-4.
