Vestil LO-DC-MR-A User manual

1
VESTIL MANUFACTURING CORPORATION
2999 North Wayne St., Angola, IN 46703
Phone [phone] · Fax [phone]
E-mail: [email protected] · www.vestil.com
SAFETY PRECAUTIONS
Read owner's manual completely before operating unit!
• Never exceed the maximum capacity of 1,000 pounds.
• Never load more than one drum at a time.
• Never load the unit unless you are watching it.
• Stand clear of drum while loading and unloading.
• Drum must be pushed all the way to the back of the
craddle before moving.
• Use caution in moving a loaded unit; avoid obstructions
and floor defects.
• Wear steel-toe shooes when operating.
RECEIVING INSTRUCTIONS
Every unit is thoroughly tested and inspected prior
to shipment. However, it is possible that the unit may incur
damage during transit. If damage is noticed when unloading,
make a note of it on the BILL OF LADING. Remove all
packing and strapping material, then inspect the unit again
for damage. IF DAMAGE IS EVIDENT, FILE A CLAIM WITH
THE CARRIER IMMEDIATELY!
WARRANTY
This product is warranted for 90 DAYS from date of
purchase to be free of manufacturing defects in material and
workmanship.
This warranty does not cover normal wear of parts
or damage resulting from any of the following: negligent use
or misuse of the product, use or application contrary to
installation instructions, or disassembly, repair or alteration
by any person prior to authorization from a factory
representative.
LO-PROFILE DRUM CADDIES
MODELS LO-DC-MR-A, LO-DC-PU-A & LO-DC-CI-A
MODELS LO-DC-MR, LO-DC-PU, LO-DC-CI & LO-DC-PH
OWNER'S
MANUAL
Revised 0507 16-126-104
A company dedicated to solving ergonomic and material
handling problems since 1955
.
LO-PROFILE DRUM CADDIES
MODELS LO-DC-MR-A, LO-DC-PU-A
& LO-DC-CI-A
Ergonomic Solutions
ASSEMBLY INSTRUCTIONS
1) Attach casters using hardware included.
2) Bolt wheel assembly to cradle using hardware included.
3) Slide Handle into Wheel Assembly
(Please refer to the next page for the assembly drawing)
OPERATION
1) Align unit in front of drum, remove handle, grip drum with
handle.
2) Tip drum up while guiding the cradle under the drum.
3) Reattach handle and transport drum to desired location.
Contents
Safety Precautions ........................................ 1
Receiving Instructions ...................................1
Warranty ........................................................1
Assembly Instructions .................................... 1
Operation ....................................................... 1
Parts List & Drawing ................................2 & 3

2
LO-PROFILE DRUM CADDIES • MODELS LO-DC-MR-A, LO-DC-PU-A & LO-DC-CI-A
Assembly & Parts Drawing
PARTS IDENTIFICATION
LO-PROFILE DRUM CADDIES • MODELS LO-DC-MR-A, LO-DC-PU-A & LO-DC-CI-A
ITEM NO.
1
2
3
4
5
6
7
8
9
9
9
A
B
C
D
ENGINEER NO.
16-025-007
16-025-026
N/A
N/A
16-538-003
N/A
16-514-097
N/A
16-132-058
16-132-161
16-132-162
16-154-024
16-154-021
16-154-022
16-154-023
QTY.
2
1
4
4
1
4
2
2
2
2
2
1
1
1
1
DESCRIPTION
Handle grip
Handle
Lock Nut, M8-1.25
Bolt, M8 - 1.25 x 20 mm
Craddle Assembly
Washer, 13mm ID x 35mm OD x 2mm
Rear Caster (1-3/8" x 3")
Lock Nut, M12-1.75
Mold-on-Rubber Wheel (2" x 6")
Cast Iron Wheel (2" x 6")
Poly-on-Steel Wheel (2" x 6")
Hardware Kit (includes 1,3,4,6,8)
Mold-on-Rubber Wheel Kit (includes 6A-9B)
Cast Iron Wheel Kit (includes 6A-9C)
Poly-on-Steel Wheel Kit (includes 6A-9D)
KIT NO.
A
A
A
A,B,C,D
B,C,D
A,B,C,D
B,C,D
B,C,D
B,C,D

3
LO-PROFILE DRUM CADDIES • MODELS LO-DC-MR, LO-DC-PU, LO-DC-CI & LO-DC-PH
Assembly & Parts Drawing
PARTS IDENTIFICATION
LO-PROFILE DRUM CADDIES • MODELS LO-DC-MR, LO-DC-PU, LO-DC-CI & LO-DC-PH
ITEM NO.
1
2
3
4
5
6
7
8
9
9
9
9
A
B
C
D
E
ENGINEER NO.
16-025-007
16-025-026
N/A
N/A
16-538-003
N/A
16-514-097
N/A
16-132-058
16-132-161
16-132-162
16-132-817
16-154-024
16-154-021
16-154-022
16-154-023
16-154-026
QTY.
2
1
4
4
1
4
2
2
2
2
2
2
1
1
1
1
1
DESCRIPTION
Handle grip
Handle
Lock Nut, M8-1.25
Bolt, M8 - 1.25 x 20 mm
Craddle Assembly
Washer, 14mm ID x 37mm OD x 3mm
Rear Caster (1-1/4" x 3")
Lock Nut, M12-1.75
Mold-on-Rubber Wheel (1-1/2" x 6")
Cast Iron Wheel (1-1/2" x 6")
Poly-on-Steel Wheel (1-1/2" x 6")
Phenolic Wheel (1-1/2" x 6")
Hardware Kit (includes 1,3,4,6,8)
Mold-on-Rubber Wheel Kit (includes 6A-9B)
Cast Iron Wheel Kit (includes 6A-9C)
Poly-on-Steel Wheel Kit (includes 6A-9D)
Phenolic Wheel Kit (includes 6A-9E)
KIT NO.
A
A
A
A,B,C,D
B,C,D
A,B,C,D
B,C,D
B,C,D
B,C,D
B,C,D

4
Scissor LiftTable
XII
II
I
XI
X
VI
VII
VIII
VI
V
III
IX
Time is money.
Increased productivity
equals greater profitability,
cost minimization and worker
compatibility. Ergonomic
products will assist you
with your production and
safety goals.
Mobile Lift &Tilt
Work Stand
Pallet Server
Material Handling Problem Solvers
Ground LiftTilter
High Rise Lift
Drum Carrier/Rotator
Copyright 2007 VESTIL MANUFACTURING CORPORATION
