VetTech Australia VT7498 User manual

The pictures in user guide is just for reference,the real shape see your bought product.
Patient Warming and Cooling System
User Guide
Distributed and Serviced by -
VetTech Australia
Unit 23/7 Hoyle Avenue
CASTLE HILL NSW 2154
1300 339 139
www.vtaus.com.au
Please carefully read the user guide before use.

Remarks The meanings of various icons in user guide
It means the content of [possibility of causing hurt or property damage.]
It means to oblige the user to act exact as content of [constraint]
It means user can not act the content of [prohibition]
11
1
1
2
2
2
3
3
3
4
4
6
8
9
11
12
Function introduction
Control unit main tech-parameter
Control unit and mattress installation instruction
A. Control unit appearance instruction
B. Mattress installation
Set up
A. Installation instruction
B. Collection between pad and machine
C. Turn on and add water
D. Control unit/remote control marks and directives
E. Control unit/remote control function reset
Usage notes
Maintenance
Troubleshooting
Accessories
TABLE OF CONTENTS
Trouble Possible reason Troubleshooting
Can not start
no power supply with power
not connect the power connect power
fuse burnt up a new fuse is needed
remote is not so sensitive new battery is needed
can not start but led is on it shows lack of water, pleaseadding water
into the tank
can not work with all lights on shut down the power, clean and dry the
operation board and restart
Bad effect of
warming and
cooling
have noise come from controlunit
when running with not enough water
in the tank
check the water level in the tank is under
warning line or not, please adding water if
under the warning line.
adjust the temperature wrongly adjust the temperature to higher or lower
heat-absorber was covered and
blocked by dirty and dust take off the lid and clean it
Can not warm up
and cool down
have stiff substance block the expire
or inspire window of control unit clean them
have filar substance block expire
inspire window of control unit clean them
water isn't enough in tank adding water
If such condition like herebelow happens, please cease using the control unit prompty and cut off
the power
Troubles
fuse burnt up frequently
outside substance and water go to inside of control unit
remote lost sensitive or buttons is unnormal
control unit have unnormal smell or noise
If such condition like herebelow happens when consumer use the product, please solve
them as exact herebelow tells. If still can not make it, please contact us and tell us detail of the
condition.
TROUBLESHOOTING

1
AC220V 50~60Hz
180W 10% 200W 10%
45dB
80W 10% 80W 10%
10
dry cloth
In cold winter, the moving human body wear many clothes is easy to produce
electrostatic, therefore please contact some conductable metal substance to release
the electronstatic before operating the control unit.
Clean control unit with wet clean
cloth or anti-electrostatic cloth
Human body has electrostaticUsing some chemical or dry
cloth to clean the control unit
is prohibited
5 year
Adjustable warm and cool,care health and sleeping
FUNCTION INTRODUCTION
Our machine has frequency conversion microcomputer control system, it can adjust temperature from
20 -48 that human body needs, the mattress inside has pipe system made of silicone material for
liquid circulation, it makes a space between human body and mattress which not only hasten circulation
of blood, release strain of spine and bones, but also massage muscles to direct people into sleeping and
eliminate troubles that caused by long time lying in the hospital after operation.
Warm in winter, cool in summer, safety and trustworth
The liquid become warm and cool by semi-condictor chip. It can adjust the temperature that people
needs in short time, it not only can cool down but also can replace traditional electric wire blanket, it not
only can prevent bacteria reproduction, kill acarus, avoid weakness of sweating, eczema, waist sore
caused by long time lying, but also avoid the danger from magnetic-wave produced by electric wire
blanket , completely solve the problem of nose dry, skin itch and shed, chest frowsty and dizzy feeling
etc.
Magnetization system, environment protect
Machine magnetized system magnetize the circulating liquid, produce magnetic atmosphere, stimulate
body point cure in magnetization, and speeding up blood circulation to hasten physical and chemical
reaction of human body, help to cure heart disease, hypertension, spirit enervation etc, the liquid keeps
circulating without any magnetic declination, improve many kinds of disease, physical therapy to built
strong body, also running periodic disinfection.
MACHINE MAIN TECH-PARAMETER.
Input voltage
Start cooling watt
Stay cooling watt
Noise
Rated frequency
Start warming watt
Stay warm watt
Life span
If keep using please clean the control unit with clean wet cloth or electrostatic-proof
cloth, do not use chemical reagent(rot components) or dry cloth(with electrostatic) to
clean the control unit.
Store control unit and mattress in the clean and dry place to prevent components
from rotting or outside substances going into the control unit to affect its function.
chemical

ON/OFF
2
ON/OFF
ON/OFF
9
MAINTENANCE
A. Clean dirt of inspire window of control unit.
Control unit has lots dirt and dust around the fan if used for a long time which will affect function of
control unit, user can take off the fan lid to clean or wash, then dry it up and refix to the control unit.
B. Release water from control unit and mattress
If control unit is not used for a long time, there has dirt or deposit in the water tank, at this time
please release the water and fill with new water. Turning on the control unit and let water circulate in
mattress for couples of minutes, then release the water with the plastic key, after finish the release,
re-fill the tank with new water, then release again and again repeat twice or 3 times.
If mattress pad is not used for long time, please release the water in the mattress with the plastic
key .
Release water for
control unit
Release water
for mattress
CONTROL UNIT AND MATTRESS INSTALLATION INSTRUCTION
A. Machine appearance instruction
B. Installation step
water
tank
water
input inspire
window handle
power
wire
operation
board
pipe
connector
switch
heat release
window
pad
Mattress pad put on the right place as Fig under the cover.
Place control unit besides bed(on the floor)
Bed
Mattress pad
Pillow
Connect
terminal(female) Tube
Connect
terminal(male)
Connect
terminal(male)
Connect
terminal(female)

8
3
USAGE NOTES
Remote
Tube connecter Mattress
accessories
SET UP
A. Installation instruction
B. Collection between pad and machine
1) Plug the male terminal of tube connector to female terminal of control unit
2) Plug the female terminal of tube connector to male terminal of mattress
Power
Control unit
pouring clean water into control unit
and on the buttons is prohibited
Pressing under button of control unit
before unpluging the pipe
Placing other substances in 15 cm
around the heat-releasing windows
is prohibited.
Be sure of pluging the power
plug thoroughly Do not break the electrical cable
Do not change the cable and
place around the heating
substances, do not twist, bend tie
with the cable, it may cause fire
disaster, short circuit, electric
shock event if use a broken power
plug.
put the control unit on the mattress
pad is prohibited, do not bend and
twist the pipe.
sharp substances like needles put
on the mattress pad is prohibited
sharp substances like needles put
into the control unit is prohibited

4(2) GR08-3-A(1) GR08-1-A
7
Special reminds:
User can adjust the temperature of mattress to the perfect health number according to
indoors temperature and human body request.
Our suggested perfect temperature In summer is 31 1 , in winter is 35 2 .
lower than 31 or higher than 37 is not suitable for long time sleeping, but good for
medical therapy.
The mattress can be set to keep working on same temperature as to go well human
body temperature to improve quality of sleeping and life
The sleeping mode function can be used if user have no idea about his suitable
temperature, and the bunches of children, elders and disables who can not help
themselves, but it can only be started on condition of set the control unit temperature to
be higher or lower protect temperature range before you choose this mode.
Can not put the control unit works upon the mattress pad, and control unit is just for
this mattress, for other purpose is prohibited.
Must keep for at least 5 minutes on switch between warming and cooling.
1.
2.
3.
4.
5.
6.
SET UP
ON/OFF
20
23
25
28
30
33
35
38
40
43
45
48
D Control unit/remote control marks and directives
1. Control unit/remote control marks
singnal receiver
dynamic vision
stop state light
warning light of water temperature bring up
f/c shift button
temperature bring down
sleep mode
enter confirm timer button on/off dynamic vision power indictor cooling stop heating rotating adjust
button
warning light of water
C. Turn on and add water
Connect the power plug to AC220V/50HZ power, at the state of control unit not working, spin off
the lid of water tank and fill water until the tank is full, then press power button to start control unit, and
keeping adding water until the tank is full again, finally close the month with lid.
Notes : 1. Water spill into inside of control unit and operation board is prohibited.
2. Must refill water when water level in water tank is under warning level (2/3 of tank) or warning
light is on, make sure control unit can work normally.
liquid must be clean water alcohol and antifreezing liquid
so on as chemic is prohibited
clean
water chemic

OFF/ONOFF/ON Ë®ÎÂ
Ë®ÎÂ
Ë®ÎÂ
on/off
timer
warming
cooling
shift
sleep
enter
enter
enter
When control unit is not working, press button one press an hour to time the
control unit to user requirement like 12, 11, 10, ........ 2,1 hours, then press to
confirm, the control unit will utter a beep sound when it receive the signal, the
control unit will power on automatically as user seted time, if user want to cancel,
just need to set the number to 00, and press to confirm.
When control unit is working, press button one press an hour to time the control
unit to user requirement like 12, 11, 10, ........2,1 hours, then press to confirm,
the control unit will utter a beep sound when it receive the signal, the control unit will
power off automatically as user seted time, if user want to cancel, just need to set
the number to 00, and press to confirm.
6
ON/OFFON/OFF
5
SET UP SET UP
Note: please cut off the power if user do not use for long time.
Turn on the control unit and set the temperature according to environmental temperature
and personal requirement, press button to bring up temperature, press to
bring down the temperature, press once is bring up or down 1 degree, if keep pressure
on is going up or down non-stop to user demanded temperature, and then
press button.
Rotating button adjust type is rotate the button to user demanded
temperature
In hot summer, no matter how cold user set the control unit, as long as you press
button, the control unit will go back to above 31 from cooling state.
In cold winter, no matter how warm user set the control unit, as long as you press
button, the control will go back to under 36 from warming state.
Press button, the control will shift between Fahrenheit and celsius when control
is working normally. ( do not need to press enter button)
ON/OFFON/OFF
Press button to control the power on or off rotating button adjust type press boat
shape button to turn on or off
E. Machine/remote controller function reset
warming
display
cooling
on/off timer
enter 2 AAA ( No.7) batteries
Battery lid
sleep
shift
2. Control unit/remote control operation
3. Control unit marks and light.
Control unit marks and light.
twinkle
stop
state
water
warning power timer warming enter frequency shift sleeping
mode
cooling
