VEVOR CPS-5HP User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
DIGITAL PHASE SHIFTER
MODEL:CPS-5HP/CPS-7.5HP/CPS-10HP
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

- 1 -
MODEL:CPS-5HP/CPS-7.5HP/CPS-10HP
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
DIGITAL PHASE
SHIFTER

- 2 -
Warning-To reduce the risk of injury, user must read instructions
manual carefully.
CORRECT DISPOSAL
This product is subject to the provision of European Directive
2012/19/EC. The symbol showing a wheelie bin crossed through
indicates that the product requires separate refuse collection in the
European Union. This applies to the product and all accessories
marked with this symbol. Products marked as such may not be
discarded with normal domestic waste, but must be taken to a
collection point for recycling electrical and electronic devices
IMPORTANT SAFEGUARDS
BESURE TO READ AND FULLYUNDERSTAND THE FOLLOWINGS
BEFORE USE.
CAUTION
▪ This product should be used only for 3 phase 220-240V motor.
▪ One DPS unit should be used only for one motor that meets DPS specifications.
▪ 3 phase voltages are output when the motor is running.
▪ Connecting only U, W lines for control wires of electronic switch, brake, magnetic
contractor, etc.
▪ Only 1 phase of motor brake is allowed. (3 phase brake does not work.)
▪ If the motor overheats, check the current indicated on the motor nameplate. (Use
motor load less than 80% of rated capacity of the motor.)
▪ Never use DPS model that does not meet motor capacity. (causes motor
overheating)
※Never use DPS capacity 2 levels higher than rated motor capacity.
It may cause overheating or trouble.
▪ If you find smoke, strange smell or noise, turn off the switch immediately,
disconnect the plug from the power socket, and contact our service center.

- 3 -
Continued use may cause fire or electric shock.
WARNING
▪ Use this DPS only for operation 3 phase motor(220-240V) from single phase
power (220-240V) supply.
▪ As the DPS has no protection device, install safety circuit breaker at the
input terminal to use it
▪In the event of abnormality, cut off the power immediately.(There is a danger of
electric shock.)
▪ Do not move or install the product in the condition with the current flowing or
exposed. (There is a danger of fire or electric shock.)
▪ Be sure to cut off the power switch in the event of power failure during operation.
( When the power is restored, it restarts automatically, which may cause an
unexpected accident.)
▪ Do not disassemble, assemble, or modify the DPS.
▪ For 3 phase 220-240V motor only
SAVE THESE INSTRUCTIONS
FCC Information
CAUTION:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment!
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This product may cause harmful interference.
2)This product must accept any interference received, including interference that
may cause undesired operation.
WARNING:
Changes or modifications to this product not expressly approved by the party
responsible for compliance could void the user's authority to operate the product.

- 4 -
Note:
This product has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules, These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This product generates, uses and can radiate radio frequency energy, and if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this product does cause
harmful interference to radio or television reception,which can be determined by
turning the product off and on, the user is encouraged to try to correct the
interference by one or more of the following measures.
· Reorient or relocate the receiving antenna.
· Increase the distance between the product and receiver.
· Connect the product to an outlet on a circuit different from that to which the
receiver is connected.
· Consult the dealer or an experienced radio/TV technician for assistance.
Technical Parameter
Models
CPS-5HP
CPS-7.5HP
CPS-10HP
Capacity(HP)
4-5HP
5-7.5HP
7.5-10HP
Current (A)
15
23
30
Frequency(Hz)
50/60
50/60
50/60
Dimension
250*135*152mm
250*135*152mm
250*135*152mm
※Product specification are subject to change without prior notice purpose
to improve the quality.
If you use a DPS that is one step above your motor capacity. you can get
90 to 95% efficiency.
(65 to 70% efficiency when using DPS with the same capacity)
ex) in the case of 5HP motor:
If you use CPS-5HP model: 65 to 70% efficiency

- 5 -
If you use CPS-5HP model: 90 to 95% efficiency
Q/A USING FOR DPS
Question / Answer
1. Only 2 phases come out from the DPS's output voltage.
3 phase voltages are output only when the motor is running. When the motor is not
running, it is normal for only single phase output to come out.
2. DPS output voltage and current are irregular.
Initially, there may be voltage and current imbalances. but when the load take
more than 50%, the voltage and current will soon balance. This phenomenon
occurs in the process of making3 phases from single phase.
3. The motor runs well at first, then suddenly the breaker was tripped.
Check the capacity of the breaker. You need to select twice the capacity of the
motor rated current. e.g.Motor 15A: Breaker 30A.
4. The power of the DPS is checked,but the motor is not running.
Check the DPS and motor connections (check whether the magnetic control lines
are connected to U and W of DPS's output).
5. Connected the DPS to the motor and running the motor, but the voltages
and current value are too high.
Check the capacity of the DPS and motor. If the DPS capacity is too large for the
motor capacity. that happens. Or. please check whether two motors are installed in
the machine. It should be used only for one DPS per one motor.
6. Is DPS available when the machine has 2-3 motors?
Originally, you should use one DPS for only one motor. However, if the start and
stop times of the motor are the same, you could use one DPS for multiple motors.
7. The DPS LED power does not come on in spite of entering power.
Please contact the head office after checking the input power.
8. The motor runs well by connecting the DPS, but suddenly it doesn't
work well.
Check the magnet switch connection, overload capacity, and breaker capacity
(twice the motor rated current) And check for the overload.
9. And check for the overload.
Check if the input voltage and power volume are normal and check the motor

- 6 -
load.Also, make sure that the magnetic control line is connected to the U and W
positions of the DPS output.
10. How should the magnet switch, overload, and breaker capacities be
selected?
When using the above products, it should be selected as twice the capacity of the
rated current of the motor.
11. The motor slows down and does not run smoothly.
Please check the load volume of the motor and use the load less than 85% (over
current phenomenon caused by overloading).
12. There's a lot of noise when the motor is running.
Check the DPS and motor capacity (The motor is noisy and generates heat when
using a DPS with a specification higher than the appropriate capacity)
13. The current of Motor output is too high and overheating occurs.
Please check if the motor capacity and DPS capacity are properly selected. e.g.
MY-PS-15 model:Used for 10HP motor MY-PS-20 model:Used for 15HP motor
14. Is DPS available for sunbeds, welders, ovens, and tenning machines.
You can use it after contacting our head office. However, it is slightly less efficient
than when used in motors.
