VIA Technologies DSP-A45 User manual

Introduction
1.1 Feature
◎Server-less architecture / Power-on and play
◎Support Mobile APP
◎Support various types of display unit
◎Support 4K video playback and video switch
DSP-A45
Distributed media player
v1.01-090519-152900
DSP-A45 MANUAL
DSP-A45 MANUAL DSP-A45 MANUAL
○
1
○
2○ 3
1.2 Specification
ZX-2800M Cortex-A17 quad-cord processor
2GB
16GB eMMC
Highly integrated Elite2000S1 2D/3D graphics processor
Support DX11 Level 9.3
Support H.265(4K@60fps) or H.264(4K@30fps) video decod-
ing
Support AAC/PCM audio decoding
1 x power indicator
1 x DC-in jack
1 x Ethernet Lan port
2 x USB 3.0 port
1 x HDMI 2.0 port
1 x RS232
1 x Line Out
1 x Micro SD slot
1 x WIFI antenna
12V DC-in
-20oC ~ 45oC
Aluminum alloy chassis
152(L)x29(H)x112.5(W) mm
290 g
2 x brackets

1.3 I/O Interface
DSP-A45 MANUAL
DSP-A45 MANUAL
○
5
○
6
Ready to use DSP-A45
DSP-A45 MANUAL
○
4
Figure :：Dimension(Front)
Figure 1: Front
Acvate the system
Scan the QR code and download
MagicView®mobile APP
VIA TECHNOLOGIES (SHENZHEN) CO., LTD
VIA Building 4F, NO. 9966, Shennan Avenue, Nanshan District, Shenzhen, PR
China, Shenzhen, 518057
Contact number: 400-818-5166
Mailbox: [email protected]
FCC Warning
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any inte rference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interferenceto radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
To comply with FCC RF exposure compliance requirements, this grant is applicable
to only mobile configurations. The antennas used for this transmitter must be
installed to provide a separation distance of at least 20cm from all persons and must
not be co-located or operating in conjunction with any other antenna or
transmitter.
