VIA Technologies OPS-A45 User manual

Introduction
1.1 Feature
◎ Server-less architecture
◎ Support Mobile APP
◎ Connect all displays through LAN
◎ Standard OPS chassis
OPS-A45
Distributed media player
v1.00-120519-141900
OPS-A45 MANUAL
OPS-A45 MANUAL OPS-A45 MANUAL
○
1
○
2○ 3
1.2 Specification
ZX-2800M Cortex-A17 quad-cord processor
2GB
16GB eMMC
Highly integrated Elite2000S1 2D/3D graphics processor
Support H.265(4K@30fps) or H.264(video decoding
Support AAC audio decoding
1 x power indicator
1 x Micro SD slot
1 x Line Out
1 x RS232
3 x USB 2.0 port
1 x Ethernet Lan port
1 x Power button
1 x HDMI out
1 x audio
1 x UART
1 x USB 3.0
1 x USB 2.0
1 x power control
12V DC-in
0oC ~ 40oC
8% ~90% (Non-condensing)
200(L)x30(H)x120(W) mm
290 g

1.3 I/O Interface
OPS-A45 MANUAL
OPS-A45 MANUAL
○
5
○
6
Ready to use OPS-A45
OPS-A45 MANUAL
○
4
Figure :Dimension
Figure 1: External I/O
Acvate the system
Scan the QR code and download
MagicView®mobile APP
VIA TECHNOLOGIES (SHENZHEN) CO., LTD
VIA Building 4F, NO. 9966, Shennan Avenue, Nanshan District, Shenzhen, PR
China, Shenzhen, 518057
Contact number: 400-818-5166
Mailbox: [e-mail]
OPS-A45 installation
(reference only)
