Roughneck® V922D and V923D
Series Camera Domes
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
Vicon Industries Inc.
Tel: [phone] Fax: [phone] Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Document Number: 8009-8284-20-00
Product specications subject to change without notice.
Issued: 716
Copyright © 2016 Vicon Industries Inc. All rights reserved.
Quick Guide

WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT INSERTANY METALLIC OBJECT
THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
PRECAUTIONS
Safety -------------------------------------- Installation -------------------------------
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel before operating it any further.
Unplug the unit from the wall outlet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials (curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the rear
panel are for special adjustments by qualified
personnel only.
Before installation, carefully read the manual to ensure
correct operation and setup, heeding all warnings and
instructions.
Do not install the device near any heat sources such as
radiators, heat registers, stoves, or other equipment
(including amplifiers) that produce heat.
Only use attachments/accessories specified by the
manufacturer.
Do not install the device in a place where it is exposed
to gas or oil.
Cleaning ---------------------------------
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use strong
solvents such as thinner or benzene as they might
damage the finish of the unit.
Retain the original carton and packing materials for
safe transport of this unit in the future.
2

FCC COMPLIANCE STATEMENT
INFORMATION TO THE USER:THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC
RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL
INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT
INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
CAUTION:CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY
RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME NMB-003 DU CANADA.
CE COMPLIANCE STATEMENT
WARNING: This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
3

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
15. CAUTION –THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED
SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE OPERATING
INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power
source only.
17. ITE is to be connected only to PoE networks without routing to the outside plant.
4

1. Description
The information in this manual provides quick installation and setup procedures for the Roughneck® Series of
Camera Domes. These units should only be installed by a qualified technician using approved materials in
conformance with federal, state, and local codes. Read these instructions thoroughly before beginning an
installation. Always refer to Vicon’s website to assure you have the most up-to-date manual, www.vicon-
security.com.
The Roughneck® Series of HD IP Camera Domes is designed for demanding security installations. It offers a
number of fixed network camera versions that deliver crisp clear images to fit any installation need; models
with IR illuminators are available. The Roughneck® cameras are fully compatible with all ViconNet® systems;
its ONVIF certification provides an open-platform for integration into other video management systems.
The housing is designed for easy installation. PoE eliminates the need for power cables, providing a cost-
effective method of installation. The Roughneck® features an auto iris lens that adapts to changing outdoor
lighting; the true day/night camera includes a removable IR cut filter. The camera dome is IP66 rated with a
vandal-proof casing that withstands rain, dust and vandalism. It provides 3-axis adjustment. The alarm input
and alarm output can be used to connect various third party devices, such as door sensors and alarm bells.
1.1 Components
The system comes with the following components:
Camera unit Installation CD Installation Guide Template Sheet Accessory Kit
Note: The optional V920D-OSD OSD Controller and V920D-AUDIO audio cable assembly can be purchased
separately.
Check your package to make sure that you received the complete system, including all components shown
above.
5

2. Installation
For the network camera to operate, it is necessary to connect a network cable for data transmission and power
connection from supplied power adapter. Depending on operation methods, it is possible to also connect an
alarm cable.
2.1 Overview
Parts and Description
6

Accessory Kit
There is an accessory kit included with the Roughneck IP. The table below lists the contents.
Description
Quantity
Torx wrench (to remove tamperproof screws)
1
Pipe sealant tape (to seal pipe fitting to housing)
1
Screws, anchors and rubber washers (for some
appropriate installations)
4 of each
Vent plug (for outdoor installations)
1
Terminal blocks, 2-pin (12VDC power); 4-pin (alarm
output)
1, 1, 2
Cable access plug (black; for rear hole)
1
Cable access plug and tool (threaded; for side hole)
1 of each
Grommet (for routing cable; rear access)
1
Loosen the four (4) Torx screws securing the cover; allow the cover to hang.
Mark the location of the four mounting holes using the drilling template.
Two (2) cable access holes provided, one on the side and one on the rear. Drill a hole and route cables
to the selected location and through one of the cable access holes
If using the rear cable access hole, insert the vent plug provided in the side cable access hole. If the
side cable access hole is used, insert a Street Tee into the cable access hole. Refer to Notes below.
Route the conduit through the top hole and insert the vent plug provided into the bottom hole. Refer to
Figure that follows for installation options. Sealant tape is provided for the plug and Street Tee. Insert
the black plug provided into the rear cable access hole if the side access hole is being used; if the rear
cable access hole is being used, insert the provided plug into the side cable access hole and tighten
with tool provided.
Note: Failure to thoroughly coat threads will result in moisture entering the housing and eventual failure of the
unit.
Note: For outdoor installations, Vicon recommends that the vent plug should only be used if fogging
conditions exist. Additionally, if the side cable access hole is used, the base must be mounted so the
hole is pointed directly downward.
Installation Options
7

2.1 Connections
Connection Description
<V922D-A>
<V923D-A>
No.
Connector Name
Description
1
Micro-SD Slot
Micro-SD memory slot
2
Service Monitor Port
Service Monitor & OSD Controller Communication Port, Stereo Jack (V922D-A only)
3
Audio In & Out Port
Audio Input and Output ,Stereo Jack
4
Alarm In & Out Port
Alarm Input and Output, 4pin terminal.
Pin1,2: Alarm In#1,#2, Pin3: GND, Pin4: Alarm Out
5
Main Power
Main Power, 2pin terminal, Pin1: GND, Pin2: 12VDC
6
RJ-45 Port
Ethernet, RJ-45 port compatible with 10/100Mbps having PoE functionality
Set to NTSC
by default
8

Micro SD memory slot on the Board
Card Slot for Micro SD memory: Socket J2
•Connecting to the RJ-45
Connect a standard RJ-45 cable to the network port of the network camera. Generally
a cross-over cable is used for directly connection to PC, while a direct cable is used for
connection to a hub. You can also use a router featuring PoE (Power over Ethernet) to
supply power to the camera.
•Connecting Alarms
IN#1, IN#2 (Alarm In): You can use external devices to signal the network camera
to react on events. Mechanical or electrical switches can be wired to the IN#1, IN#2
(Alarm In) and GND (Ground) connectors.
GND (Ground): Connect the ground side of the alarm input and/or alarm
output to the GND (Ground) connector.
OUT (Alarm Out): The network camera can activate external devices such as buzzers or lights.
Connect the device to the OUT (Alarm Out) and GND (Ground) connectors.
Connecting Audio
Use the optional V920D-AUDIO cable assembly for ease of audio connections. The cables are labeled for Audio In
and Audio Out. Refer to diagram below.
Audio Out: Connect wire 1 and ground to speakers.
Audio In: Connect wire 2 and ground to microphone.
•Connecting the Power
Connect the power of 12VDC for the network camera. Connect the positive (+) pole
to the + position and the negative (-) pole to the - position for the DC power.
Be careful not to reverse the polarity when connecting the power cable.
A router featuring PoE (Power over Ethernet) can also be used to supply power to the camera.
The heater can be powered by a 12VDC, PoE power source.
For the power specifications, refer to the Appendix, Product Specification.
If PoE and 12 VDC are both applied, the camera will be supplied with power from PoE.
Heater
The heater comes preinstalled in the camera dome.
Power Supply
12 VDC
Power Consumption
3.5 Watt
Heater On
at 59°F (15°C)
Heater Off
at 77°F (25°C)
9

•Connecting Service Monitor Port (V922D-A only)
The Service Monitor output port (J8) is located on the board of the dome camera and is used for easy
OSD setup.
▶ID & IP assignment
To make changes in the OSD menu, the optional OSD controller (V920D-OSD) can be used to set Camera
Title and IP Address.
1. Connect the OSD Controller to the Service Monitor port of the network camera.
2. Connect Service Monitor and the Video Output port of the OSD Controller.
3. Press the SET button on the controller to access the Main Menu.
4. Change camera ID and IP address as needed. Additionally, the Name (or title) of the camera can be
changed. Use the ↑↓←→ buttons on the controller to change the parameters.
5. Select SAVE or CANCEL to exit the Main Menu.
The Video Output can also be used for easy zoom and focus control when adjusting the lens. Video Output
is restricted to 704x480 (576) resolution.
•Zoom & Focus Control (motorized lens versions only)
The camera enters Zoom and Focus control mode when the OSD Controller is connected to the Service
Monitor port.
- Zoom Control: ↑(Zoom In), ↓(Zoom Out)
- Focus Control: ←(Focus Near), →(Focus Far)
- Smart Focus: Press and hold the SET button for 2 or more seconds.
The camera readjusts focus automatically.
Note: The optional OSD Controller can be purchased separately.
:V922D-W39IR-A
10

2.3 Network Connection and IP assignment
The network camera is designed for use on an Ethernet network and requires an IP address for access. Most
networks today have a DHCP server that automatically assigns IP addresses to connected devices. By the
factory default, your camera is set to obtain the IP address automatically via DHCP server. If your network
does not have a DHCP server the network camera will use 192.168.1.100 as the default IP address.
If DHCP is enabled and the product cannot be accessed, run the “Smart Manager” utility on the CD to search
and allocate an IP address to your products, or reset the product to the factory default settings and then
perform the installation again.
1. Connect the network camera to the network and power up.
2. Start SmartManager utility (Start>All Programs>SmartManager>SmartManager); the main window
displays. After a short while any network devices connected to the network will be displayed in the list.
3. Select the camera on the list and click right button of the mouse. The pop-up menu below displays.
4. Select Assign IP. The Assign IP window displays. Enter the required IP address.
Note: For more information, refer to the Smart
Manger User’s Manual.
11

3. Operation
The network camera can be used with Windows® operating system and browsers. The recommended
browsers are Internet Explorer® , Safari® , Firefox® , Opera® and Google® Chrome® with Windows.
Note: To view streaming video in Microsoft® Internet Explorer, set your browser to allow ActiveX controls.
Note: Some screens may appear different (i.e., color scheme) depending on the firmware version, but the
functionality is the same or similar.
3.1 Access from a Browser
1. Start a browser (i.e., Internet Explorer).
2. Enter the IP address or host name of the network camera in the Location/Address field of the browser.
3. A starting page displays. Click Live View, Playback or Setup to select corresponding web page.
4. Click Live View for the network camera’s Live View page to appear in the browser.
12

3.2. Access from the Internet
Once connected, the network camera is accessible on your local network (LAN). To access the network camera
from the Internet you must configure your broadband router to allow incoming data traffic to the network
camera. To do this, enable the NAT-traversal feature, which will attempt to automatically configure the router
to allow access to the network camera. This is enabled from Setup > System > Network > NAT.
For more information, refer to section “3.5.6 System>Network>NAT” of the user manual.
3.3 Setting the Admin Password Over a Secure Connection
To gain access to the camera, the password for
the default administrator user must be set. This
is done in the “Admin Password” dialog, which is
displayed when the network camera is accessed
for setup the first time. Enter your admin name
and password, set by the administrator.
Note: The default administrator username is
“ADMIN” and password is “1234”. If the
password is lost, the network camera must be
reset to the factory default settings. See section
“3.6 Resetting to the Factory Default Settings” for
more details.
3.4 Live View Page
The Live View page provides several
screen modes: 2018x1536(3 MP only),
1920x1080, 1280x1024, 1280x720,
704x480 (576), 640x480, 352x240
(288), and 320x240. Select the most
suitable mode in accordance with your
PC specifications and monitoring
purposes.
1) General controls
Live View Page Search & Playback Page Setup Page Help Page
The video drop-down list allows the selection of a customized or pre-programmed video
stream on the Live View page. Stream profiles are configured under Setup > Basic Configuration > Video
& Image. For more information, see section “3.5.1 Basic Configuration > Video & Image” of this manual.
The resolution drop-down list allows the selection of the most suitable video
resolutions to be displayed on Live View page.
The protocol drop-down list allows the selection of the combination of protocols and
methods to use depending on your viewing requirements and on the properties of the network.
13

2) Control toolbar
The live viewer toolbar is available on the web browser page only. It displays the following buttons:
The Stop button stops the video stream being played. Pressing the key again toggles the
start and stop. The Start button connects to the network camera or start playing a
video stream.
The Pause button temporarily stops (pauses) the video stream being played.
The Snapshot button takes a picture (snapshot) of the current image. The location where the
image is saved can be specified.
The Digital Zoom button activates a zoom-in or zoom-out function for the video image on the live
screen.
The Full Screen button causes the video image to fill the entire screen area. No other
windows will be visible. Press the 'Esc' button on the computer keyboard to cancel full
screen view.
The Manual Trigger button activates a pop-up window to manually start or stop the event.
The Remote Focus button enables users to adjust focus and zoom remotely via network
(motorized lens models only).
The Fine Focus (one push focus) button readjusts focus automatically to set the focus to
the optimum position (motorized lens models only).
Use the Speaker icon scale to control the volume of the speakers.
Use the Microphone icon scale to control the volume of the microphone.
3) Video Streams
The network camera provides several image and video stream formats. Your requirements and the
properties of your network will determine the type you use.
The Live View page of the network camera provides access to H.264, MPEG-4 and Motion JPEG video
streams and to the list of available video streams. Other applications and clients can also access these
video streams/images directly, without going via the Live View page.
4) Focus and Zoom Control (motorized lens models only).
You can control Zoom and Focus from the Live View screen. Press the button on the left top in the
Live View screen to activate the Zoom and Focus control panel.
14

•Adjusting Zoom:
Click “<” button to zoom out and click “>” button to zoom in. The focus is moved slightly after adjusting
zoom; adjust the focus again, as necessary.
•Adjusting Focus:
Click “>” button for far focus and click “<” button to near focus.
•Fine Focus:
Click “Fine Focus” to fine tune and readjust focus automatically.
Note: Click the button in the Live View screen to set the focus to the optimum position.
3.5 Network Camera Setup
This section describes how to configure the network camera and is intended for product Administrators, who
have unrestricted access to all the Setup tools, and Operators, who have access to the settings for Basic, Live
View, Video & Image, Audio, Event, and System Configuration.
The network camera is configured by clicking Setup in the top right-hand corner of the Live View page. Click on
this page to access the online help that explains the setup tools.
When accessing the network camera for the first time, the “Admin
Password” dialog appears. Enter your admin name and password, set
by the administrator.
Note: If the password is lost, the network camera must be reset to
the factory default settings. See section “3.8 Resetting to the Factory
Default Settings”. The default administrator username is “ADMIN” and
password is “1234”.
15

3.6 Resetting to the Factory Default Settings
To reset the network camera to the original factory settings, go to the Setup > System > Maintenance web
page (described in “System > Maintenance” of User’s Manual) or use the Reset button on the network camera,
as described below:
•Using the Reset Button
Follow the instructions below to reset the network camera to the factory default settings using the Reset
button.
1. Switch off the network camera by disconnecting the power adapter.
2. Press and hold the Reset button with a straightened paperclip while reconnecting the power.
3. Keep the Reset button pressed until the Status indicator blinks.
4. Release the Reset button.
5. When the Power Indicator changes to Green (may take up to 40 seconds), the process is
complete and the network video camera has been reset.
6. The network camera resets to factory defaults and restarts after completing the factory reset.
CAUTION: When performing a Factory Reset, you will lose any settings that have been saved.
(Default IP 192.168.1.100)
System Requirement for Web Browser
Operating System: Microsoft® Windows® 98, Microsoft Windows ME, Microsoft Windows 2000, Microsoft
Windows XP, or Microsoft Windows Vista® , Windows 7, Windows 8.1 and Windows 10
CPU: Intel® Core™2 Duo 2GHz or higher, 1 GB RAM or more, 10 GB free disk or higher
VGA: AGP, Video RAM 32 MB or higher (1024x768, 24 bpp or higher)
50304099A
