Vicpas TPC-651H User manual

TPC-651H/1251H
Industrial Touch Panel
Computers with Intel Atom
Processors
User Manual

TPC-651H/1251H User Manual ii
Copyright
The documentation and the software included with this product are copy-
righted 2010 by Advantech Co., Ltd. All rights are reserved. Advantech
Co., Ltd. reserves the right to make improvements in the products
described in this manual at any time without notice. No part of this man-
ual may be reproduced, copied, translated or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reli-
able. However, Advantech Co., Ltd. assumes no responsibility for its use,
nor for any infringements of the rights of third parties, which may result
from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of
Microsoft Corp.
All other product names or trademarks are properties of their respective
owners.
This Manual Covers the Following Models
• TPC-651H
• TPC-1251H
Part No.2003065102 3rd Edition
Printed in Taiwan November 2011

iii
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for two years
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous test-
ing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

TPC-651H/1251H User Manual iv
CE
This product has passed the CE test for environmental specifications
when shielded cables are used for external wiring. We recommend the use
of shielded cables. This kind of cable is available from Advantech. Please
contact your local supplier for ordering information.
FCC Class A
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interfer-
ence when the equipment is operated in a commercial environment. This
equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.
Technical Support and Assistance
Step 1. Visit the Advantech web site at www.advantech.com/support
where you can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
- Product name and serial number
- Description of your peripheral attachments
- Description of your software (operating system, version, appli-
cation software, etc.)
- A complete description of the problem
- The exact wording of any error messages

v
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning.
Use a damp cloth. Do not use liquid or spray detergents for clean-
ing.
4. For plug-in equipment, the power outlet socket must be located
near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Drop-
ping it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before con-
necting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or elec-
trical shock.
13. Never open the equipment. For safety reasons, the equipment
should be opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked
by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE MAY GO BELOW -

TPC-651H/1251H User Manual vi
20° C (-4° F) OR ABOVE 60° C (140° F). THIS COULD DAM-
AGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A
CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED BY THE
MANUFACTURER, DISCARD USED BATTERIES ACCORD-
ING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-
1:1982 is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1.
Advantech disclaims all responsibility for the accuracy of any statements
contained herein.
Caution!
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer's instructions.

vii Table of Contents
Contents
Chapter 1 General Information ....................................... 2
1.1 Introduction ....................................................................... 2
1.2 Specifications .................................................................... 3
1.2.1 System Kernel ................................................................ 3
1.2.2 I/O Ports ......................................................................... 3
1.2.3 Safety and Environment ................................................. 3
1.3 LCD Specifications ........................................................... 4
1.4 Touchscreen Specifications............................................... 4
1.5 Power................................................................................. 4
1.6 I/O Ports Arrangement ...................................................... 5
Figure 1.1:TPC-651H - I/O Port Arrangement .............. 5
Figure 1.2:TPC-1251H - I/O Port Arrangement ............ 5
1.7 Panel Mounting ................................................................. 6
Figure 1.3:Panel Mounting ............................................ 6
1.8 Dimensions and Cutout ..................................................... 6
Figure 1.4:TPC-651H Dimensions ................................ 7
Figure 1.5:TPC-1251H Dimensions .............................. 8
Chapter 2 System Setup.................................................. 10
Figure 2.1:Unpack the Package ................................... 10
Figure 2.2:Install CompactFlash Memory Card .......... 11
Figure 2.3:Power Connector and Power Lines ............ 11
Figure 2.4:Power Receptor & Button Pin Assignment 11
Chapter 3 Features in Windows XP Embedded........... 14
3.1 EWF ................................................................................ 14
3.2 HORM............................................................................. 15
Appendix A Serial Port Settings........................................ 18
A.1 COM1/ COM2 Connector Definition ............................. 18
A.2 RS-485 / RS-422 Setting................................................. 19
Appendix B Watchdog Timer Programming..... 24
B.1 Overview ......................................................................... 24
B.2 Watchdog Timer Programming....................................... 25
Figure B.1:Watchdog timer programming procedure .. 25
Table B.1:Watchdog Timer Registers ......................... 26
B.3 Example Programs .......................................................... 27
Appendix C Watchdog Timer Programming on WinCE 34
C.1 DeviceIOControl ............................................................. 34
C.1.1 Parameters .................................................................... 35
C.2 How to Use the Control Code ......................................... 36
C.2.1 IOCTL _WDT_ENABLE: ........................................... 36
C.2.2 IOCTL _WDT_DISABLE: .......................................... 36
C.2.3 IOCTL_WDT_STROBE: ............................................ 36

TPC-651H/1251H User Manual viii
C.2.4 IOCTL_WDT_GETTIMEOUT: .................................. 37
C.2.5 IOCTL_WDT_SETTIMEOUT: .................................. 37
C.2.6 IOCTL_WDT_REBOOT: ........................................... 37
C.3 Examples ......................................................................... 38

2
CHAPTER
1
General Information

TPC-651H/1251H User Manual 2
Chapter 1 General Information
1.1 Introduction
The TPC-651H and TPC-1251H Touch Panel Computers are state-of-the-
art Human Machine Interfaces featuring 5.7" and 12.1 displays with Intel
Atom eMenlow XL processors and the following key features:
• Fanless
By using a low-power processor, the system does not have to rely on
fans, which often are unreliable and causes dust to circulate inside the
equipment.
• Bright Display
The TFT LCD display suits industrial demands for clear interfaces.
• Wide Operating Temperature & Isolation Protection
These products provide a -20~60° C wide operating temperature solu-
tion and complete isolation protection for their serial ports.
• Windows CE Support
In addition to the OS support of Windows XP, Advantech offers plat-
form support for Windows CE and Windows XP embedded. The
optional Windows CE operating system specifically for Industrial
Touch Panel Computers is also available.
• Energy Star Approval

3 Chapter 1
1.2 Specifications
1.2.1 System Kernel
• CPU: Intel Atom Z520 1.33GHz
• BIOS: Award 4 Mbit flash BIOS
• System Chipset: eMenlow XL + Poulsbo
• VGA: Integrated in eMenlow XL
• Ethernet: 10/100/1000Base-T
• Watchdog Timer: W83627DHG watchdog timer; 1.6 second timeout
period
• Storage: CompactFlash slot or SATA HDD x 1
1.2.2 I/O Ports
• 2 serial ports: RS-232 x 1 (w/ isolation), RS-422/485 x 1 (w/ isolation)
• 2 RJ-45 Ethernet port
• 2 USB 2.0 Ports: compliant with USB 1.0 and 1.1. (Host)
1.2.3 Safety and Environment
Safety
• FCC Class A
• CE certificated
• The front bezel is compliant with NEMA 4 and IP65
Environment
• Operating Temperature: -20 ~ 60° C (-4 ~ 140° F)
• Storage Temperature:-30 ~ 80° C (-22 ~ 176° F)
• Humidity: 40° C @ 10~95% relative humidity (non-condensing)
• Vibration: 2 grms (5~500Hz)

TPC-651H/1251H User Manual 4
1.3 LCD Specifications
1.4 Touchscreen Specifications
• Touch Type: Resistive
• Base Glass Construction: Tempered Glass
• Resolution: 1024 x 1024
• Light Transmission: 80% ± 3% (Measured by BYK-Gardner
• Controller: RS-232 Interface
• Lifespan: 1 million touches at single point
1.5 Power
• Input Voltage: 18 - 32VDC (the fuse will become an open circuit if the
input level exceeds 33VDC)
• Typical: 24VDC@0.93Amp
TPC-651H TPC-1251H
Display Type TFT LCD TFT LCD
Size (diagonal) 5.7” 12.1”
Maximum Resolution 640 x 480 (VGA) 800 x 600 (SVGA)
Maximum Colors 262K
Viewing Angle 160°/140°
Luminance (cd / m2) 700 450
Contrast Ratio 800:1 700:1
Operating Temp. -30 ~ 85° C
Backlight LED
Backlight Life Time 50,000 hours
Note There might be several bright or dark pixels on
the LCD. This phenomenon is normal in today’s
LCD manufacturing.

5 Chapter 1
1.6 I/O Ports Arrangement
The arrangement of the I/O ports is shown in in Figure 1.1 and 1.2.
Figure 1.1: TPC-651H - I/O Port Arrangement
Figure 1.2: TPC-1251H - I/O Port Arrangement

TPC-651H/1251H User Manual 6
1.7 Panel Mounting
1. There is an adhesive waterproof gasket on the AL front bezel.
Make sure the waterproof gasket is in position before installing
TPC into the panel opening.
2. Install the TPC into the panel opening.
3. Find the eight clampers and eight long screws in the accessory
pack. Hook the clampers to the holes around the four sides of the
bezel. Insert the screws into every clamper and fasten them. These
screws will push the mounting panel and fix the unit.
4. The suggested mounting panel thickness is less than 6 mm
(0.236”).
Figure 1.3: Panel Mounting
1.8 Dimensions and Cutout
• Weight: TPC-651H - 1.43kg, TPC-1251H - 2.5kg
• Dimensions (W x H x D):
TPC-651H: 195 x 148 x 58 mm (7.68" x 5.83" x 2.28")
TPC-1251H: 311 x 237 x 52.3 mm (12.24" x 9.33" x 2.06")
• Cutout:
TPC-651H: 189.1 x 142.1 mm
TPC-1251H: 302.5 x 228.5 mm

7 Chapter 1
Figure 1.4: TPC-651H Dimensions
195
195
148
148
114.7
114.7
86.1
86.1
28.1
28.1
132
132
6
70.5
70.5
6
58
58
6
188.1
188.1
141.1
141.1

TPC-651H/1251H User Manual 8
Figure 1.5: TPC-1251H Dimensions
301.5
301.5
227.5
227.5
54
54
3.50
3.50
6.50
6.50
4
170
170
311
311
237
237
247.2
247.2
186.3
186.3
180
180
6.50
6.50
4

2
CHAPTER
2
System Setup

TPC-651H/1251H User Manual 10
Chapter 2 System Setup
You can easily get TPC started by following the below steps.
• Step 1: Unpack the TPC package. Check the packing list at the begin-
ning of this manual to make sure all items have been included.
Figure 2.1: Unpack the Package

11 Chapter 2
• Step 2: Install a CompactFlash card containing Windows CE, embed-
ded Windows XP or another operating system.
Figure 2.2: Install CompactFlash Memory Card
• Step 3: Connect the power connector to the 24 VDC power lines. The
power lines can either be of some power adapter or in-house power
source.
Figure 2.3: Power Connector and Power Lines
Figure 2.4: Power Receptor & Button Pin Assignment
Warning It is suggested to turn OFF system power as you
plug in or pull out the memory card, even though
the CompactFlash memory is hot swappable.

TPC-651H/1251H User Manual 12
• Step 4: Plug the power lines into the system power receptor.
• Step 5: Push the power button to power on the system (figure 2.4).
• Step 6: Calibrate the touchscreen (click "PM" in the bottom corner).
Installing the Drivers
After installing your system software, you will be able to set up the Ether-
net, SVGA, and touchscreen functions. All drivers are stored in a CD-
ROM disc entitled “TPC-651H or TPC-1251H” which can be found in
your accessory box.
The various drivers in the CD-ROM disc have their own text files which
help users install the drivers and understand their functions. These files
are a very useful supplement to the information in this manual.
Note: If you want to install the touchscreen driver & use
the touchscreen utility, please refer the user
manual which is "PenMount 6000 Installation
Guide" in the CD-ROM.
Note The drivers and utilities used for the TPC-651H and
TPC-1251H panel PCs are subject to change without
notice. If in doubt, check Advantech's website or contact
our application engineers for the latest information regard-
ing drivers and utilities.
