VictoriaPlum V6Q760 User manual

V01/07/2015
This product is universal, not handed
ASSEMBLY INSTRUCTIONS
SIMPLICITY QUADRANT

1
BEFORE YOU START, HERE IS SOME IMPORTANT INFORMATION
1) General Information
2) Additional Notes
Please inspect this product upon delivery. any missing parts or manufacturing
defects must be reported immediately to the supplier. Damage or defects reported
later will not be accepted. TAKE CARE WHEN HANDLING GLASS PARTS-AVOID
HEAVY CONTACT BETWEEN THE GLASS EDGES AND ANY HARD SURFACE.
Glass breakage claims will not be accepted after the product has been unpacked.
Please note: Aluminium is a soft metal, and undergoes a series of extrusion.
fabrication, polishing and anodising processes in order to create your finished
shower enclosure. Some light surface marks are normal, and is a result of the
manufacturing processes. Quality control has ensured that this item is of a good
standard, and is fit for purpose.
Please read these instructions carefully before starting installation.
Special care should be taken when drilling walls to avoid hidden pipes or electrical cables.
Note: this product is heavy and may require two people to install.
TOOLS REQUIRED
This product is heavy and may require two people to install.
Ø3mm Drill bit
Ø6mm Drill bit
Pencil
Spirit level
Tape measure
DESCRIPTION DESCRIPTIONPART IMAGE PART IMAGE
Drill
Flat-head
Screwdriver
Cross head
Screwdriver
Hammer
Silicone Sealant

2
ASSEMBLY INSTRUCTIONS-EXPLODED VIEW AND PARTS LIST
(1) 1xTop Horizontal Rail
(12) 2xBottom Rollers
(2) 2xWall Posts
(13) 1xBottom Horizontal Rail
(3) 6xWall Plugs
(14) 6xScrew Cover Cap Clips
(4) 1xFixed Panels A
(15) 6xScrews 4x12
(5) 1xVertical seal A (Fixed pane Al)
(16) 1xFixed Panels B
(7) 1xHandle (supplied separately)
(18) 1xVertical seal B (Fixed panel B)
(8) 6xChrome Screw Cover Caps
(19) 1xMoving Panel
(9) 4xScrews 3.5x30
(11) 4xGlass Clamps
(6) 6xScrew 4x30
(17) 1xVertical seal C (Moving panel)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(11)
(12)
(13)
(14)
(15)
(16)
(17)
(20)
(20) 4xScrews 4x10
(10) 2xBottom seals
(10)
(18)
(19)

3
ASSEMBLY INSTRUCTIONS
If you require help, we advise you to contact a competent plumber
THESE DIMENSIONS ASSUME THE WALLS ARE PLUMB AND THE SHOWER TRAY IS
Installation Steps
Step 1
LEVEL, AND THAT THE WALLS ARE TILED DOWN TO THE TOP OF THE TRAY USING
A 10mm TILE/WET WALL PANEL.

Round Screw
M4x30
MAKE SURE THE TRAY IS LEVEL, USING A SPIRIT LEVEL, BEFORE INSTALLING
THIS SHOWER PANEL / DOOR.
Step 2
4

1
3
Round Screw
M4x10
Do not over-tighten.
Round Screw
M4x30
Step 3
2c 1c
1c
2c
4
2
5

Step 4
Step 5
Gently squeeze the frame
into the other wall post.
6

Step 6
Step 7
b1
Fixed panel A Fixed panel B
Moving panel
Fitting Water Deflectors+Magnet Seals:
7

Step 8
Step 9
x6
x6
x6
Screw
M4x12
3mm
Take care not to drill
How to adjust the width of the Quad
into the glass
Allow 24 hours for silicone to dry before use.
Silicone on the outside edge only
Minimum 10mm
internal overlap required
Glass panel
Glass panel
Vertical profile
Vertical profile
Wall profile
Wall profile
Wall
Wall
Maximum adjustment
Minimum adjustment
b1
8

CARE AND MAINTENANCE
COMMITMENT TO QUALITY
1) AFTER CARE INSTRUCTIONS
2) MAINTENANCE
Regularly clean your shower product with warm soapy water
Clean the plastic parts with a cloth and mild detergent. Never
use any abrasive creams, dissolvents, acetone or detergents
and disinfectants that contain chlorine. The supplier accepts
no liability for any type of use of care other than those contained
in these instructions. The supplier reserves the right to introduce
technical changes without notice.
It is our intention that the quality and functions of this product
are of the highest standard. If you require help we advise you
firstly contact a competent plumber. However we understand that
this may not always be the case, so should you experience
any problems please contact out customer services quoting
the following:
Product name: 6mm One Door Quadrant
Product code: V6Q760 V6Q800 V6Q900 V6Q810 V6Q812 V6Q912
Customer help line number:0344 804 48 48
to prevent lime scale build up. Do not use abrasive cleaning
fluids or materials, or strong chemical cleaners as this will
damage the product surface.
9

INSTALLERS NOTES
10

The packaging you have received with your product is 100% recyclable.
It must be disposed of in a safe and environmentally friendly way.
We suggest you take it to the local landfill site and discard in the designated bins.
Shower enclosures with aluminium
profiles and safety glass
Victoria Plum Limited, Bridgehead Business
Hessle, HU13 0DG
Park
J150722001-1
15
Shower enclosures with aluminium
profiles and safety glass
DOP
