Victure AC800 User manual

Language
1English
20Deutsch
39Français
58Italiano
77Español
97日本語

1
Content
Foreword
Product Introduction
Installation Guide
Waterproof Case Open&Close
Dust-proof Cover Replacement
Battery Charging and Installation
SD Card Insertion and Formatting
Mode Operation Instructions
Settings Table
Wifi Connecting
Computer Connecting
TV Connecting
Specifications
Warranty
2
3
4
4
5
6
7
9
11
15
16
17
18
19

2
Foreword
Thank you for your purchase of Victure AC800 and welcome to Victure’s
world of photography. The AC800 Series action camera adopted 6-layers
optical lens to record 4K / 24fps FHD videos and shoot maxim 20MP high
quality pictures. With Gyroscope or Anti-shake function ON, the AC800
can reduce the impact of shake on the screen significantly.
Victure consistently attaches great importance to product quality and high
customer satisfaction. We sincerely hope you can make a few suggestions
during your use to help us improve our products. Your precious
suggestions will help us shape our products to perfectly fit your standards.
If you encountered any problem during your use, please contact us via:
[email protected]. Please be assured that seller support is just a
mail away from you in case you find any difficulty. Do not hesitate to write
to us by email if you need any kind of help. There will be seller support
reaching to you as soon as we can. Please note that all items purchased
from Victure are covered by 1 year warranty from the date of purchase.
We thank you infinitely for choosing our camera. We wish you all the best.
Kind regards,
Victure Support Team

3
Product Introduction
Power/MODE Button Lens Up/Wi-Fi
Speaker
Down/Audio
Recording Switch
MICRO USB
MIC
MICRO SD
MICRO
HDMI
Working Indicator
(Flashes BLUE during working)
Charging Indicator
(Flashes RED during charging)
LCD Screen
Wifi Indicator
(Flashes ORANGE when wifi is ON)
Battery coverOK Button

4
Installation Guide
Waterproof Case Open&Close
Waterproof Case Open:
Waterproof Case Close:
①
③
③
②
2. Pull up the buckle of water-
proof case;
3. Open the back cover of the
waterproof case.
1. To open the waterproof case,
firstly take the switch on the top
to right as indicated by the arrow.
1. To close the waterproof case.
Firstly please compress the back
cover of the waterproof case as
arrow 1 shows;
2. Please pull down the buckle,
and connects it to the back cover
as arrow 2 shows.
3. Pull down the buckle of the
waterproof case as arrow 3
shows.
②
①

5
Tips:
1. Please tear the protective films on the waterproof case lens before
shoot/record;
2. To achieve better waterproof performance, the voice record within
waterproof case will be weakened.
Dust-proof Cover Replacement:
Step 1 Step 2 Step 3
1. To replace the dust proof case, first please find the slot of the waterproof
case as circled place showed in step 1.
2. Hold the case with your hands as step 2 picture shows, face the slot on the
case front, tear the waterproof back cover off.
3. Find the dust proof back cover in your accessories, which has two
inter-spaces in left and right side. Insert the lower half of the cover in the slot,
then push the upper half into the slot until the whole back cover being totally
installed.
Tips:
1. This usage can be operated based on your own needs.
2. The dust proof case can not be used under water.

6
Battery Charging and Installation
The battery and the camera are packaged separately, so please make sure
that the battery is charged with power, inserted into the camera before
getting the camera started.
Battery Charging:
The battery charging steps are as below:
1. Find the dual USB battery charger in the camera’s accessories.
2. Connecting the charger with USB cable, you can charge it with power plug
or with computer. Charging with computer may be slower than using a power
adapter due to lower power output of computer USB ports.
3. Insert the two batteries into the charging compartment. When the charger
is on working, the red light means its charging, the blue light means it has
been fully charged.
Battery Installation:
After the batteries have been fully charged, please install one battery into the
camera to get the camera’s power working. The battery installation steps are
as below:
1. Find the battery compartment part in the camera. Open the battery cover
as below picture shows. First, use your right thumb’s fingernail to push the
switch into right as arrow 1 shows. Second, lift the battery cover with your left
thumb’s fingernails as arrow 2 shows.

7
SD Card Insertion and Formatting
2. Install the battery cover after the battery has been inserted. Please note
the extended part of the battery cover should be inserted to the left of the
battery compartment first as below picture shown. Then press the right half
of the battery cover down into the battery compartment.
Tips:
Please note the directions of the battery and battery cover.
After the batteries fulled charged with power, a SD card is needed to get
the camera working. Our camera supports Class 10 micro SD card, maxim
support 64GB. Please note the SD card is NOT INCLUDED in the camera.
SD Card Insertion and Out :
1. Find the Micro SD card slot in the camera, inserting the card into the
camera as the direction mark shows on the camera until you hear a
insertion sound.
2. SD card out: Press down the SD card until you’ve heard a insertion
sound; Then the SD card will pop out along with a poping sound.
②
①

8
Tips: Please use your fingernails to push the SD card since the slot is a
little bit deep.
Formatting:
Considering the compatibility of the SD card, it should be formatted
before using. Formatting steps are as below:
1. Short press the “MODE” button to start up the camera. Press the
“MODE" button thrice to enter the settings mode;
2. Press “DOWN” button until you find “format” setting then press OK
button to confirm, the memory card will be formatted at once.
Tips:
1. Please make sure the SD card is class 10 micro card, and the memory
maxim supports 64 GB;
2. Please transfer your valuable files into other place to store before
format the SD card.

9
Mode Operation Instructions
The AC800 series has four kinds of mode: Video Mode, Photo Mode,
Playback Mode, Settings Mode. Below are the function instructions of
each button under these modes.
Short press「Power/MODE Button」: Turn on the camera;
Extended press「Power/MODE button」: Turn off the camera.
※Under each mode.
「OK Button」: Begin&Stop recording
「Up Button」(Short Press): Wifi switch
「Up button」(Extended Press) : Enlarge the focal length(Maxim 4X)
「Down Button」(Short Press): Audio recording switch
「Down button」(Extended Press): Narrow focal length
「Power/MODE Button」(Short Press): Shoot pictures(During recording)
「OK Button」: Shoot picture
「Up Button」: Enlarge the focal length(Maxim 4X)
「Down button」: Narrow focal length
「Power/MODE Button」(Short Press): Mode switch(Video→Photo→
Playback→Settings)
Under Playback
「OK Button」(Short Press): Play&Pause video
「Up Button」: Fast forward( Maxim 8X)
「Down button」: Rewind( Maxim 8X)
Turn ON/OFF
Video Mode
Photo Mode
Playback Mode

10
Non-playback time
「Up Button」: Page up
「Down button」: Page down
「Power/MODE Button」(Short Press): Mode switch(Video→Photo→
Playback→Settings)
「Up Button」: Page up
「Down button」: Page down
「OK Button」: Confirm
「Power/MODE Button」(Short Press): Mode switch(Video→Photo→
Playback→Settings)
Settings Mode

11
Settings Table
Camera Settings Page Explanation Table
※V＝Video Mode; P=Settings which effective under photo mode
Setting
Video
Resolution
Loop
Recording
Gyroscope
WDR
Time-lapse
Record
Motion
detection
Value V P Explanation
4K/2K/1080P/
720P/480P/240P ○
○
○
○
○
○
○
To set the video’s resolution.
Off/3 Minutes/
5 Minute/
10 Minutes
The file will be record by
segment based on the time
unit you’ve set.
Off/On
Off/On
Off/On
This setting can counteract
the hand-shake and vibration’s
effect to the recording.
Wide Dynamic Range
It can automatically adjust the
darkness in the image.
Off /
0.1 Second/
0.2 Seconds/
0.5 Seconds/
1 Second/
5 Seconds
Time-lapse photography is a
technique whereby the freq-
uency at which film frames
are captured (the frame rate)
is much lower than that used
to view the sequence. When
played at normal speed, time
appears to be moving faster
and thus lapsing.
※This function can not be
used under 4K video resolution.
Under standby mode, the
camera will record and save
a 10 seconds video when it
detects a moving object.
Audio
Recording Off/On
It decides whether there is an
audio record into the video.
※Use down button to turn on/
off the audio during recording.

12
○
○
○
○
○
○
○
○
○
○
○ ○
○ ○
○○
○Diving Mode Off/On
Off/On
The camera will adjust the
white balance automatically
when record/shoot under
water.
Night Scene
The screen brightness will be
automatically adjusted when
the camera shoot night scenes.
Interval Timer
Shooting Off/2s Timer/5s
Timer/10s Timer
The camera will take a picture
after the set interval timer.
Resolution
20M /16M /
12M /10M /8M /
5M/3M /VGA
To set the image’s resolution.
Continuous
Shooting Off/On
Press OK button without stop
to continuously shoot pictures
under photo mode.
Quality
High Quality /
Good/Normal
To adjust the image quality
of the pictures.
Sharpness
Level
Strong/
Standard/Soft
To adjust the object’s edge
pixels within the image.
White
Balance
Auto/Daylight/
Cloudy/
Tungsten light/
Fluorescent
To set the camera’s white
balance.
Color
Normal/
Black & white/
Brown
To set the image’s color.
ISO
Sensitivity
Auto/100/
200/400
To adjust the light
sensitiveness.
Exposure
Value
+2.0/+1.7/+1.3/
+1.0/+0.7/+0.3/
0/-0.3/-0.7/-1.0/
-1.3/-1.7/-2.0
To adjust the exposure value
※+(Brightness)/-(Darkness)
adjustment.
○
○
○Off/OnDate Stamp Date stamp on the videos or
pictures.
Angle 170°/140°/
110°/70°
The angle of the camera’s
lens is adjustable.

13
Protect
Lock Current File/
Unlock Current File/
Lock All the Files/
Unlock All the Files
To prevent files overwriting
caused by loop recording
under car mode.
WIFI Off/On Press up button to turn on/
off the wifi with one key
button.
WIFI SSID To set the name of the Wifi.
WIFI
Password WIFI Password
Date&Time
To set the system’s date.
※1. Please note to set the
date during first time using.
2.It will be changed into
default date after you
exchanged the battery.
○ ○
○
○
○
○ ○
Automatic
Shutdown
Off/
1 Minute/
3 Minutes/
5 Minutes /
10 Minutes
The camera will enter into a
screen saver mode then
automatically shutdown under
no operation.
※Except in video mode.
Key Volume Off/On The key volume during
operation.
Voice Prompts Off/On
The camera will voice
prompting video start/video
stop when doing its operations.
OSD Off/On The display of the function
menu parameters on the screen.
○Anti-Shaking Off/On
To counteract the hand-
shake/vibration‘s influence
to taking pictures.
Delete Delete Current
File/Delete All To delete the files.

14
Language
English / Français /
Español / Polski /
Deutsch / Italiano /
繁體中文 /
Pусский / 日本語 /
한국어 / Cesky /
Português
○
○
○
○ ○
○ ○
To set the system’s language.
TV mode NTSC/PAL Video output format.
TV Off/On FPV function
Screen Saver
Off/
30 Seconds/
1 Minute/
3 Minutes
To set the screen saver’s time
interval.
※Short press any key button
to wake up the screen under
this setting.
Power
Frequency 50 Hz/60 Hz
To set the power frequency
Europe: 50Hz/
North America: 60Hz
Format SD card
To format the SD card.
※When you confirm OK,
the memory card will be
formatted shortly.
Default
Settings Settings To restore the camera into default settings
Hardware
information
Model:
Victure AC800
Version: 1.0
The display of the model of
the product and the hardware
version.
○Car Mode Off/On
Connect to the car charger,
the camera will automatically
start recording once the en-
gine is turned on. And auto-
matically saving recording files
and shut down once the engine
is turned off.

15
Wifi Connecting
Download the App
Download the ‘OKCAM’ app from the App Store(iOS)/ Google Play(An-
droid).
Wifi Connecting
After the download step finished，you can use your phone to control the
camera through App, view the video or pictures on your phone, and
download the recordings from the camera. The connecting steps are as
following:
1. Short press MODE button to turn on the camera;
2. Short press Up button to turn on the wifi(when the camera under Video
mode);
3. Find and connect the wifi through your phone with the wifi’s name and
password displayed on the camera;
4. Enter the app after the wifi is connected, you’ll find the camera is
controlled by your phone.
5. To disconnect wifi, short press Up button again.
Tips:
1. The wifi information display will be shorten into a wifi mark in the lower
left of camera’s screen once the wifi is connected with your phone;
2. The camera can only connect to one device at a time;
3. The wifi connection is a little bit power consuming, so please avoid
connecting wifi when the camera is low in battery.

16
Computer Connecting
There are two options when you use the included micro-USB cable to
connect to a computer: Mass Storage and PC Camera. Press Up/Down
button to switch between these two modes.
Mass Storage: Access to the files which stored in camera’ s micro SD card
to copy or view them on a computer. This function can also achieved by a
micro SD card reader.
PC Camera: Use as a web cam for video chats and video recording on your
computer. You may need to allow Adobe Flash Player to run in your video
chat software before display the video.
