Videosec Cl-19 User manual
Cl-19
Cabinet Lock
User manual
•Power supply: 3 standard AA alkaline batteries.
•
Battery life:
About one year in normal state.
•Function card
：
Mother Card, Master Card and Temporary Guest Card . The Mother
Card is used to create Master Card and Temporary Guest Card. The Master Card and
Temporary Guest Card are the key of the lock.
1. Definition:
•Mother Card: Mother card is set by the cabinet lock. It’s used to create or terminate
the waiter card and uest card.
•Master Card: Master card is created by mother card, does as a key card to unlock the
lock.
•Temporary Guest Card: Create the temporary uest card when the lock is in the unlock
state.
Usua le Mifare devices
MF-1C card MF-1WB wristband MF-1KF keyfob
2. *Reset:
This cabinet lock default in uest self-help mode, the option switch is in the ri ht
side(next to the reset button). Please follow the operation to reset: Turn off power, keep
pressin the reset button. Turn on the power, buzzer of the lock sounds “beep…beep…beep…”
for short. Release the reset button when you hear the “beep” for 5 times, then the lock is
reset.
Tips: pls must release the reset button when you hear the “beep” for 5 times.
Otherwise, the cabinet lock will enter other working mode.
Explanation: Remove the option switch to the left side (far way the reset button), then
reset the lock. 1pcs uest key card can lock and unlock 2 cabinet locks at the same time.
Otherwise, 1 pcs uest key card can lock and unlock only 1 cabinet locks.
3. Create Mother Card (*This operation is necessary)
Connect the power line to the IC, press the “Reset Button” at the back, after a “beep”,
touch the RF Card which you want to become Mother Card li htly to the hole of lock, after a
lon “beep” and a short “beep”, the RF card is reco nized as Mother Card by the lock. Each
lock can have one Mother Card at the most; the last one replaces the prior one.
Operation
：
Press Reset Button + New Mother Card (1 time)
Note: One lock can e set only 1 mother card and this operation is necessary.
4. Create Master Card
Touch the Mother Card li htly to the lock, after a “beep” and the LED flashes in blue,
the lock is unlocked, touch the Mother Card li htly to the lock a ain, buzzer “beep” for a lon
sound and blue li ht flashin , touch the RF card which you want to become master card, create
master card successfully with a short “beep”. You can continue to touch the other RF Cards
before the LED stops flashin . After 6 seconds you touch the last card, the LED stops flashin
and finish creatin master cards.
Operation
：
Mother Card (2 times) + New Master Card (1 time)
Note: Each lock can create 15 master cards at the most. When you creating master card,
uzzer sound 4 times “ eep” for short means the num er of master card is full already.
5. Create Temporary Guest Card
Touch one RF card which you want to become a temporary uest card when the lock
is in unlock state. The lock will be locked and finish creatin temporary uest card.
Operation
：
New Temporary Guest Card(1 time when the lock is unlocked)
6. Terminate one Master Card
The operation of terminatin one master card is same as creatin a master card. Touch
the Mother Card li htly to the lock, after a ‘beep’ and the LED flashes in blue, the lock is
unlocked, touch the Mother Card li htly to the lock a ain, buzzer “beep” for a lon sound and
blue li ht flashin , touch the master card which you want to terminate, terminate master card
successfully with two short “beep”. You can continue to touch the other master cards before
the LED stops flashin . After 6 seconds you touch the last card, the LED stops flashin and
finish terminatin master cards.
Operation
：
Mother Card (2 times) + Master Card (1 time)
7. Terminate all Master Cards
Touch the Mother Card li htly to the lock for 3 times successively, all the master cards
will be terminated.
Operation
：
Mother Card (3 times)
8. Terminate Temporary Guest Card
•Terminate with new temporary Guest Card: Open the lock with old temporary uest
card. After this please touch the new RF card to reader. New temporary uest card
terminate the old temporary uest card
•Terminate with Master Card: Open the lock with one Master card. After this please
touch the new RF card to reader. New temporary uest card terminate the old
temporary uest card.
Important:
1. With secondary terminate mode, you never can able to add to this reader the old
temporary uest card. Even after reset to factory default too.
2. If you open the lock with one Master card and after that you read the latest temporary
uest card a ain, you never can able to add to this reader the old temporary uest
card. Even after reset to factory default too.
Operation
：
New Card (1 time when the lock is unlocked)
9. Open
•Open y mother card. Touch the Mother Card li htly to the lock, after a “beep” and
the LED flashes in blue, then the lock unlock. The lock locked automatically.
Operation
：
Mother Card (1 time)
•• Open y master card. Touch the Master Card li htly to the lock, after a “beep” and
the LED flashes in blue, then the lock unlock. The lock unlocked always.
Operation
：
Master Card (1 time)
Tips: If the lock is locked y temporary guest card, It will alarm with red flash of LED
when you use master card to unlock it. Just touch the master card one more time,
the lock will e unlocked.
•Open y temporary guest card. Touch the temporary uest Card li htly to the lock,
after a “beep” and the LED flashes in blue, then the lock unlock. The lock unlocked
always.
Operation
：
temporary guest Card (1 time)
Error message, when try to open with invalid card
•3 short „beep” and red flashin : this card didn’t added to this reader
•6 short „beep” and red flashin : this card finally disabled from this reader
10. Close
•Close y master card. Touch the Master Card li htly to the lock, after a “beep” and
the LED flashes in blue, then the lock is locked.
Operation
：
Master Card (1 time)
•Close y temporary guest card. Touch the temporary uest Card li htly to the lock,
after a “beep” and the LED flashes in blue, then the lock is locked.
Operation
：
temporary guest Card (1 time)
11. Low voltage warning: If the batteries’ volta e is low, touch RF Card, two lon “beep” from
the buzzer, LED flash red for two times, then the lock is unlocked. Please chan e 3 pieces of
new AA batteries as soon as possible.
12. Anti-theft Alarm Function: When the cabinet door is close, once the lock latch is picked
ille ally, buzzer will sound “beep” for 15 seconds continuously. Touch a valid key card can stop
alarmin .
Note: Make sure the key card can unlock the lock normally efore you close the door.
Technical details
Reader Mifare 13.56 MHz
Openin ways Cards / KeyFob / Wristband
Workin mode Standalone
Power 3 X AA alkaline batteries, appr: 12 months
Consumption Static 12 μA (static), 500 mA (dynamic)
Workin -10°C - +60°C, Humidity: 20%-80%
Size Size of Lock 165(L)x32(W)x18(H) mm
Size of mortise: 132(L) x 64(W) x 22(H) mm
Packa e include Lock + mortise + screews
Heavy 1.3 k
