Viessmann VITOCELL 100-V Quick guide

Installation and service instructions
for contractors
VIESMANN
Vitocell 100-E/100-W
Type SVWA
Heating water buffer cylinder
VITOCELL 100-E/100-W
6150632 GB 3/2020 Please keep safe.

2
Please follow these safety instruc-
tions closely to prevent accidents
and material losses.
Safety instructions explained
Danger
This symbol warns against the risk
of injury.
!Please note
This symbol warns against the risk
of material losses and environmen-
tal pollution.
Note
Details identified by the word "Note"
contain additional information.
Target group
These instructions are exclusively inten-
ded for qualified contractors.
■Work on electrical equipment may only
be carried out by a qualified electrician.
■The system must be commissioned by
the system installer or a qualified per-
son authorised by the installer.
Regulations to be observed
■National installation regulations
■Statutory regulations for the prevention
of accidents
■Statutory regulations for environmental
protection
■Codes of practice of the relevant trade
associations
■Relevant country-specific safety regu-
lations
Working on the system
■Isolate the system from the power sup-
ply (e.g. by removing the separate fuse
or by means of a mains isolator) and
check that it is no longer live.
■Safeguard the system against recon-
nection.
!Please note
Electronic assemblies can be dam-
aged by electrostatic discharge.
Prior to commencing any work,
touch earthed objects such as heat-
ing or water pipes to discharge
static loads.
Danger
Hot surfaces can cause burns.
■Before maintenance and service
work, switch OFF the appliance
and let it cool down.
■Never touch the hot surfaces of
uninsulated pipes and fittings.
Safety instructions
Safety instructions
6150632

3
Danger
Floors that are wet or damp with
water or glycol based liquids can
cause injury due to slipping and fall-
ing.
■Keep the floor clean and dry dur-
ing installation and maintenance
work.
■Wear non-slip shoes.
Danger
Broken-off fragments of insulation
material can cause death by suffo-
cation if inhaled or swallowed.
■Do not let children play in the
installation room.
■Keep the installation room clean
after installation and maintenance
work.
Repair work
!Please note
Repairing components that fulfil a
safety function can compromise the
safe operation of the system.
Replace faulty components only
with genuine Viessmann spare
parts.
Auxiliary components, spare and wearing parts
!Please note
Spare and wearing parts that have
not been tested together with the
system can compromise its func-
tion. Installing non-authorised com-
ponents and making non-approved
modifications or conversions can
compromise safety and may invalid-
ate our warranty.
For replacements, use only original
spare parts supplied or approved by
Viessmann.
Safety instructions
Safety instructions (cont.)
6150632

4
1. Information Disposal of packaging ............................................................................ 5
Symbols ................................................................................................. 5
Intended use .......................................................................................... 5
Product information ................................................................................ 6
■Vitocell 100-E/100-W, type SVWA ...................................................... 6
System examples .................................................................................. 6
Spare parts lists ..................................................................................... 6
2. Preparing for installation Unpacking and handling ........................................................................ 7
Connections ........................................................................................... 8
3. Installation sequence Cylinder installation ................................................................................ 9
■Cylinder incl. immersion heater .......................................................... 9
Connecting the equipotential bonding ................................................... 9
Fitting the cylinder temperature sensor and thermometer sensor (if
supplied) ................................................................................................ 10
4. Commissioning/service
reports
................................................................................................................ 11
5. Product characteristics ................................................................................................................ 12
6. Accessories Specification for immersion heater ........................................................ 13
7. Disposal Final decommissioning and disposal ..................................................... 14
8. Certificates Declaration of conformity ....................................................................... 15
Index
Index
6150632

5
Please dispose of packaging waste in line with statu-
tory regulations.
Symbols
Symbol Meaning
Reference to other document containing
further information
1.
Step in a diagram:
The numbers correspond to the order in
which the steps are carried out.
Warning of material losses and environ-
mental pollution
Live electrical area
Pay particular attention.
■Component must audibly click into place.
or
■Acoustic signal
■Fit new component.
or
■In conjunction with a tool: Clean the sur-
face.
Dispose of component correctly.
Dispose of component at a suitable collec-
tion point. Do not dispose of component in
domestic waste.
The steps in connection with commissioning, inspec-
tion and maintenance are found in the "Commission-
ing, inspection and maintenance" section and identified
as follows:
Symbol Meaning
Steps required during commissioning
Not required during commissioning
Steps required during inspection
Not required during inspection
Steps required during maintenance
Not required during maintenance
Intended use
The appliance is only intended to be installed and
operated in sealed unvented systems that comply with
EN 12828 / DIN 1988, or solar thermal systems that
comply with EN 12977, with due attention paid to the
associated installation, service and operating instruc-
tions. DHW cylinders are only designed to store and
heat water of potable water quality. Heating water buf-
fer cylinders are only designed to hold fill water of pot-
able water quality. Only operate solar collectors with
the heat transfer medium approved by the manufac-
turer.
Intended use presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial usage for a purpose other
than heating the building or DHW shall be deemed
inappropriate.
Any usage beyond this must be approved by the man-
ufacturer for the individual case.
Information
Disposal of packaging
6150632
Information

6
Incorrect usage or operation of the appliance (e.g. the
appliance being opened by the system user) is prohibi-
ted and results in an exclusion of liability.
Incorrect usage also occurs if the components in the
system are modified from their intended use (e.g.
through direct DHW heating in the collector).
Adhere to statutory regulations, especially concerning
the hygiene of potable water.
Product information
Vitocell 100-E/100-W, type SVWA
Steel cylinder for storing heating water in combination
with heat pumps and solid fuel boilers, with optional
electric heating (immersion heater)
Capacity: 200 l
Suitable for systems to EN 12828 and DIN 4753.
Vitocell 100-E: Vitosilver
Vitocell 100-W: White
System examples
Available system examples: See www.viessmann-
schemes.com.
Spare parts lists
Information about spare parts can be found at
www.viessmann.com/etapp or in the Viessmann
spare part app.
Information
Intended use (cont.)
6150632
Information

7
2.
1.
4x
5.
8.
9.
6.
7.
3.
4.
Fig. 1
Preparing for installation
Unpacking and handling
6150632
Service

8
B
A
Fig. 2 Front
AThermometer sensor retainer
BFemale connection for immersion heater (EHE)
Fig. 3 Back cover
AAir vent valve (EL)
BHeating water flow 1 (HV1)
to the heating circuits
CClamping device 1 (SPR1)
for cylinder temperature sensor
DHeating water flow 2 (HV2)
from the heat generator
EClamping device 2 (SPR2)
for cylinder temperature sensor
FHeating water return 2 (HR2)
from the heating circuits
GHeating water return 1 (HR1)
to the heat generator
HDrain outlet (E)
Preparing for installation
Connections
6150632
Service

9
!Please note
The thermal insulation must not come into con-
tact with naked flames.
Exercise caution when welding and brazing
!Please note
To prevent material damage, install the buffer
cylinder in a draught-free room free from the risk
of frost.
Otherwise the buffer cylinder will have to be
drained if there is a risk of frost and it is not in
use.
■Provide adequate clearance from the wall so that the
thermostat can be operated (if supplied).
■Placing the cylinder on a plinth will make the room
easier to clean.
■Level the buffer cylinder with its adjustable feet.
Note
Only use one or two of the adjustable feet to level the
cylinder. At least one of the adjustable feet must
remain fully screwed in.
≤35
Fig. 4
Never extend the adjustable feet beyond a total length
of 35 mm.
Cylinder incl. immersion heater
650
Fig. 5
Installation instructions, immersion heater
Note
Maintain the minimum clearance.
Note
The unheated length of any threaded immersion
heater installed on site must be at least 100 mm.
Cylinder capacity: 200 l.
Immersion heater output: 6 kW.
Connecting the equipotential bonding
Connect the equipotential bonding in accordance with
the requirements stipulated by your local power supply
utility and VDE [or local] regulations.
CH: Connect the equipotential bonding in accordance
with the requirements stipulated by your local power
supply utility and current SEV [or local] regulations.
Installation sequence
Cylinder installation
6150632
Installation

10
1.
2.
3.
6.
4.
5.
7.
A
Fig. 6
ARecess for thermometer cable
Note
The cylinder temperature sensor is supplied in the control unit pack.
01. Insert the cylinder temperature sensor as far as it
will go into the opening of the clamping device.
02. Hand-tighten the cylinder temperature sensor with
the screw provided.
Note
Hold the cylinder temperature sensor in place in
the sensor terminal until the screw is screwed in.
!Please note
Overtightening the fixing screw may dam-
age the cylinder temperature sensor.
Torque: Max. 2 Nm
03. Remove the top cover.
04. Clamp the thermometer sensor in the clamping
bracket.
05. Guide the thermometer cable through the groove
in the thermal insulation and the hole in the sheet
steel casing.
06. Secure the thermometer (accessory) to the wall.
Installation instructions for wall thermometer
07. Refit the top cover.
Note
The recess A in the top cover is intended for the
thermometer cable.
08. For heating water flow temperatures in excess of
95 ºC, remove the pipe collars from the pipe out-
lets (pipe collars have l.h. threads).
09. If no immersion heater is being installed, seal the
front female connection with the plug supplied and
fit the cover.
10. Affix supplied type plate to the back of the cylin-
der.
Installation sequence
Fitting the cylinder temperature sensor and thermometer sensor (if supplied)
6150632
Installation

11
Commissioning Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Maintenance/service Maintenance/service Maintenance/service
Date:
By:
Commissioning/service reports
Commissioning/service reports
6150632
Service

12
Vitocell 100-E/100-W, type SVWA
Cylinder capacity l 200
Standby heat loss
qB,S with 45 K temperature differential
kWh/24 h 1.39
Product characteristics
Product characteristics
6150632
Service

13
Rated output in standard mode kW 2 4 6
Rated voltage 3/N/PE 400 V/50 Hz
Rated current A 8.7 8.7 8.7
Heat-up time from 10 to 60 ºCh 4.7 2.4 1.6
Content that can be heated by the immersion heater l 163
Accessories
Specification for immersion heater
6150632
Service

14
Viessmann products can be recycled. Components
and substances from the system are not part of ordi-
nary household waste.
For decommissioning the system, isolate the system
from the power supply and allow components to cool
down where appropriate.
All components must be disposed of correctly.
Disposal
Final decommissioning and disposal
6150632
Appendix

15
We, Viessmann Werke GmbH & Co. KG, D-35107
Allendorf, declare as sole responsible body that the
named product complies with the European directives
and supplementary national requirements in terms of
its design and operational characteristics.
Using the serial number, the full Declaration of Con-
formity can be found on the following website:
www.viessmann.co.uk/eu-conformity
Certificates
Declaration of conformity
6150632
Appendix

16
Viessmann Limited
Hortonwood 30, Telford
Shropshire, TF1 7YP, GB
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Viessmann Werke GmbH & Co. KG
D-35107 Allendorf
Telephone: [phone]
Fax: [phone]
www.viessmann.com
6150632 Subject to technical modifications.
