Installation instructions
for heating engineers
Vitodens 333
Type WS3A, 6.6 to 26.0 kW
Compact gas fired condensing boiler
natural gas and LPG version
VITODENS 333
5862 566 GB 3/2004 Dispose after installation

Please follow these safety instructions closely to prevent accidents and
material losses.
Safety instructions explained
!Important information
This symbol warns against the
risk of material losses and
environmental pollution.
Note
Details identified by the words "Note"
contain additional information.
Safety regulations
Installation, initial start-up, inspection,
maintenance and repairs must be car-
ried out by a competent person
(heating engineer/installation contrac-
tor).
Observe all current safety regulations
as defined by DIN, EN, DVGW, TRGI,
TRF, VDE or all locally applicable
standards.
See also the "safety instructions" in
the "Vitotec Technical Guide" folder.
Before working on the equipment/
heating system, isolate the mains
electrical supply (e.g. by removing a
separate mains fuse or by means of a
mains electrical isolator) and safe-
guard against unauthorised reconnec-
tion.
Close the main gas shut-off valve and
safeguard against unauthorised
reopening.
Electrical assemblies provided on site
must be type-approved.
Work on gas equipment
This must only be carried out by an
approved gas fitter.
Observe all commissioning work spe-
cified for gas installations to TRGI or
TRF and all local regulations.
Safety instructions
2
5862 566 GB

Preparing for installation
Product information .................................................................................... 4
Preparations for boiler installation ............................................................... 5
Installation
Installing the boiler and making all connections ........................................... 7
Flue gas connection.................................................................................... 8
Gas connection .......................................................................................... 8
Checking anode connection........................................................................ 9
Opening the control unit housing................................................................. 10
Electrical connections................................................................................. 11
&Routing connecting cables ....................................................................... 13
Closing control unit housing and inserting user interface ............................. 14
Front panel installation................................................................................ 15
Commissioning and adjustments................................................................. 15
Index
3
5862 566 GB

Vitodens 333, Type WS3A
Set up for operation with natural gas E.
The natural gas E version can be converted to natural gas LL or LPG P using a
conversion kit.
Product information
4
5862 566 GB

On-site preparations when using a connection set (accessory), see the
installation instructions of the connection set.
ACold water G¾"
BHeating flow G¾"
CGas connection G¾"
DHeating return G¾"
EDHW G¾"
FDHW circulation G1"
GDrain outlet kit (accessory)
HCable arrangement area
KWall clearance with connection
set (accessory)
LWall clearance with on-site con-
nection
Preparations for boiler installation
5
5862 566 GB

1. Prepare the primary connections.
Thoroughly flush the heating sys-
tem.
Note
Should an on-site diaphragm
expansion vessel be required,
install this into the heating return. If
no connection set (accessory) is
used, install the on-site fill tap into
the heating return.
2. Prepare the secondary connec-
tions. Install the safety assembly
(accessory or on-site provision) to
DIN 1988 [or local regulations] into
the cold water supply line.
3. Equip the DHW circulation pipe
with circulation pump, check valve
andtimeswitch.
4. Connect the condensate drain with
apipeventtothepublicsewer.
5. Prepare the gas connection
accordingtoTRGIorTRForall
local regulations.
6. Prepare the electrical connections.
&Mainscable:NYM-J3x1.5mm
2
,
fuse max. 16 A, 230 V~, 50 Hz.
&Accessory cables: NYM with the
required number of conductors
for the external connections.
&Allcablesinarea"H" should
protrude 2 000 mm from the wall.
Preparations for boiler installation (cont.)
6
5862 566 GB

Note
Connect the condensate drain and drain lines from the safety valves with a
slopeandapipeventtothepublicsewer.
AConnection set (accessory)
Installing the boiler and making all connections
7
5862 566 GB

Connect the balanced flue pipe. Flue gas system installation
instructions.
Gas connection
AGas connection
Conversion to other gas
types:
Conversion kit installation
instructions
Information regarding operation
with LPG
We recommend the installation of an
external safety solenoid valve when
installing the boiler in rooms below
ground level.
1. Carry out a leak test.
!Important information
Excessive test pressure
leadstodamagetotheboi-
ler and gas train.
Max. test pressure
150 mbar. If a higher pres-
sure is required for leak
tests, separate the boiler
and the gas train from the
mains gas supply (undo fit-
tings).
2. Purge the gas supply pipe.
Flue gas connection
8
5862 566 GB

AMagnesium anode BEarth cable
1. Removetheflangelidcover. 2. Check whether the earth cable is
connected on the magnesium
anode.
Checking anode connection
9
5862 566 GB

Opening the control unit housing
10
5862 566 GB

Notes regarding the connection of accessories
For details of accessories, also observe the separate installation instruc-
tions provided.
ARadio clock connection BVitotrol 100 UTD (only for control
units operating with a constant
temperature)
CVitotrol 100 UTA (only for control
units operating with a constant
temperature)
Electrical connections
11
5862 566 GB

Plug 230 V~
fÖ Power supply
&Never interchange cores "L1"
and "N".
&Install an isolator in the mains
supply line which simulta-
neously separates all non-
earthed conductors from the
mains with at least 3 mm contact
separation.
&Max. fuse rating 16 A.
lH &Mains supply - accessories
(230 V ~ 50 Hz). Where the boi-
ler is installed in a bathroom or
shower room, the mains supply
of accessories outside the wet
area must not be connected to
the control unit. The power sup-
ply connection for accessories
canbemadeimmediatelyatthe
control unit, if the boiler is
installed outside damp areas.
This connection is directly con-
trolled with the system ON/OFF
switch (max. 3 A).
&Vitotrol 100 UTA
&Vitotrol 100 UTD
Low voltage plug
!Outside temperature sensor
(only for weather-compensated
mode)
Installation
&North or northwestern wall, 2
to2.5mabovegroundlevel.In
multi-storey buildings, in the
upper half of the second floor
&Not above windows, doors or
ventilation outlets
&Not immediately below balcony
or gutter
&Do not render over
&Twocorecablewithamaxi-
mum length of 35 m and a
cross-section of 1.5 mm
2
?Flow temperature sensor for low
loss header (accessories)
%DHW cylinder temperature sen-
sor (fitted in the delivered condi-
tion)
aVG KM BUS user (accessory)
&Vitotrol 200 or 300 remote con-
trol
&Vitocom 100
&Extension kit for one heating
circuit with mixer
&Vitosolic
&External extension
Electrical connections (cont.)
12
5862 566 GB

Routing connecting cables
!Important information
Connecting cables are damaged if they touch hot components.
When routing and securing connecting cables on site, ensure that the
maximum permissible cable temperatures are not exceeded.
ALow voltage connections
B230 V connections
CInternal extension
DMain PCB
ECommunications module
Electrical connections (cont.)
13
5862 566 GB

Closing control unit housing and inserting user interface
14
5862 566 GB

Commissioning and adjustments
For commissioning and adjustment, see service instructions.
Front panel installation
15
5862 566 GB

16
Printed on environmentally-friendly, chlorine-free bleached paper
5862 566 GB Subject to technical modifications
