ViewSonic VOT133 User manual

VOT133
PC Mini
User Guide
Model No. VS14165

i
Preface
Compliance Information
For U.S.A.
This device complies with part 15 of FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Warning:Youarecautionedthatchangesormodicationsnotexpressly
approved by the party responsible for compliance could void your authority
to operate the equipment.
For Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low
Voltage Directive 2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste
Electrical and Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment
as unsorted municipal waste, but use the return and collection

ii
systems according to local law.
If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery
has a heavy metal content of more than 0.0005% Mercury or more than,
0.002% Cadmium, or more than 0.004% Lead.
FCC Radiation Exposure Statement
This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
Industry Canada Notice
This wireless module device complies with Canadian RSS-210.To prevent
radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding.
Equipment (or its transmitting antenna) that is installed outdoors is subject to
licensing. The installer of this radio equipment must ensure that the antenna
islocatedorpointedsuchthatitdoesnotemitRFeldinexcessofHealth
Canada limits for the general population; consult Safety Code 6, obtainable
from Health Canada’s web site www.hc-sc.gc.ca/rpb.
R&TTE Compliance Statement
This wireless module device complies with the Essential Requirements of the
R&TTE Directive of the European Union (1999/5/EC). This equipment meets
the following conformance standards:
ETSI EN 300 328
EN 301 489-01
EN 301 489-17
Notied Countries: Germany, UK, Netherlands, Belgium, Sweden,
Denmark, Finland, France, Italy, Spain, Austria, Ireland, Portugal, Greece,
Luxembourg, Estonia, Latvia, Lithuania, Czech Republic, Slovakia, Slovenia,
Hungary, Poland and Malta.

iii
Important Safety Instructions
1. Read these instructions completely before using the equipment.
2. Keep these instructions in a safe place.
3. Heed all warnings.
4. Follow all instructions.
5. Donotusethisequipmentnearwater.Warning:Toreducetheriskofre
or electric shock, do not expose this apparatus to rain or moisture.
6. Do not block any ventilation openings. Install the equipment in
accordance with the manufacturer’s instructions.
7. Do not install near any heat sources such as radiators, heat registers,
stoves,orotherdevices(includingampliers)thatproduceheat.
8. Do not attempt to circumvent the safety provisions of the polarized or
grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade and the third prong are provided for
yoursafety.Iftheplugdoesnottintoyouroutlet,consultanelectrician
for replacement of the outlet.
9. Protect the power cord from being tread upon or pinched, particularly at
the plug, and the point where if emerges from the equipment. Be sure
that the power outlet is located near the equipment so that it is easily
accessible.
10. Onlyuseattachments/accessoriesspeciedbythemanufacturer.
11. Useonlywiththecart,stand,tripod,bracket,ortablespecied
by the manufacturer, or sold with the equipment. When a
cart is used, use caution when moving the cart/equipment
combination to avoid injury from tipping over.
12. Unplug this equipment when it will be unused for long periods of time.
13. Referallservicingtoqualiedservicepersonnel.Serviceisrequired
when the unit has been damaged in any way, such as: if the power-
supply cord or plug is damaged, if liquid is spilled onto or objects fall into
the unit, if the unit is exposed to rain or moisture, or if the unit does not
operate normally or has been dropped.

iv
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with
Directive 2002/95/EC of the European Parliament and the Council on
restriction of the use of certain hazardous substances in electrical and
electronic equipment (RoHS Directive) and is deemed to comply with the
maximum concentration values issued by the European Technical Adaptation
Committee (TAC) as shown below:
Substance
Proposed Maximum Concen-
tration
Actual Concentration
Lead (Pb) 0,1% < 0,1%
Mercury (Hg) 0,1% < 0,1%
Cadmium (Cd) 0,01% < 0,01%
Hexavalent Chromium (Cr6+) 0,1% < 0,1%
Polybrominated biphenyls (PBB) 0,1% < 0,1%
Polybrominated diphenyl ethers
(PBDE) 0,1% < 0,1%
Certain components of products as stated above are exempted under the
Annex of the RoHS Directives as noted below:
Examples of exempted components are:
1. Mercuryincompactuorescentlampsnotexceeding5mgperlamp
andinotherlampsnotspecicallymentionedintheAnnexofRoHS
Directive.
2. Leadinglassofcathoderaytubes,electroniccomponents,uorescent
tubes, and electronic ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by
weight, aluminium containing up to 0.4% lead by weight and as a cooper
alloy containing up to 4% lead by weight.

v
Copyright Information
Copyright © ViewSonic®Corporation, 2011. All rights reserved.
Microsoft®, Windows®, Windows NT®, and the Windows®logo are registered
trademarks of Microsoft®Corporation in the United States and other countries.
ViewSonic®, the three birds logo, OnView®, ViewMatch™, and ViewMeter®are
registered trademarks of ViewSonic®Corporation.
Intel®, Pentium®, and Atom™ are registered trademarks of Intel Corporation.
Award®is a registered trademark of Phoenix Technologies Ltd.
AMI®is a registered trademark of American Megatrends Inc.
ENERGY STAR®is a registered trademark of the U.S. Environmental Protection
Agency (EPA).
As an ENERGY STAR®partner, ViewSonic Corporation has determined that this
product meets the ENERGY STAR®guidelinesforenergyefciency.
Disclaimer: ViewSonic®Corporation shall not be liable for technical or editorial errors
or omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic®Corporation reserves
therighttochangeproductspecicationswithoutnotice.Informationinthisdocument
may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means,
for any purpose without prior written permission from ViewSonic®Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it
becomes available, please register your product on the Internet at: www.viewsonic.
com. The ViewSonic®Wizard CD-ROM also provides an opportunity for you to print
the registration form, which you may mail or fax to ViewSonic®.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
VOT133
ViewSonic PC Mini
VS14165
VOT133_UG_ENG Rev. 1A 04-26-11
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic
website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

Table of Contents
Chapter 1 Introducing the PC Mini
Top View........................................................................................................... 2
Front Side View ................................................................................................ 2
Back Side View ................................................................................................ 3
Bottom View ..................................................................................................... 3
Chapter 2 Placing and connecting the PC Mini
Placement of PC Mini
On the Desk ................................................................................................. 5
On the Display Back..................................................................................... 5
Connection of PC Mini
Connect the Antenna.................................................................................... 7
Connect the Monitor..................................................................................... 7
Connect the USB Devices............................................................................ 7
Connect the Network Cable ......................................................................... 8
Connect the Power Cord.............................................................................. 8
Chapter 3 Install Windows 7 in PC Mini
Install Windows 7 ........................................................................................... 10
Install Drivers in Windows 7 ........................................................................... 14
Chapter 4 Specications
Specications ................................................................................................. 15
Chapter 5 Other Information
Customer Support .......................................................................................... 16

1
Chapter 1
Introducing the PC Mini
The PC Mini is a compact and easy to use desktop. It features all the desktop capabili-
ties but with a slim body design which enables your to browse the internet in a relax
and comfortable way.
This chapter introduces PC Mini’s outlook :
■TopView
■ FrontSideView
■ BackSideView
■ BottomView

2
Introduction
PC Mini features all the desktop capabilities but with a slim body design which enables you to
browse the internet in a relaxable and comfortable way.
1-1 Top View
1-2 Front Side View
190mm
135mm
123 764 5
24mm
No. Name Description
1 Headphone Port Connects to a headphone
2 Microphone In and S/PDIF In
Port
Connects to a microphone or playback devices with
optical connectors(3.5mm jack)
3 Multi-Function Card Reader Support SD/SDHC/MS/MS Pro/MMC memory cards
4 USB 3.0 Ports Connect to USB devices
Caution: Before using it, you need to install the “AS-
Media USB3.0 driver” in the Driver CD.
5 HDD_LED Indicates hard disk states
6 Suspend Button Enter suspend mode in operating system
7 Power Button with
Integrated LED Indicator
Turning the power on/off, Indicates system states

3
1-3 Back Side View
1-4 Bottom View
No. Name Description
1 RF(Radio Frequency) Port Connects to antenna
2 USB 2.0 Ports Connects to USB devices
3 DVI Port Connects to display device
4 HDMI Port Connects to HDMI audio and video
5 Network Port Standard RJ-45 network port
6 Line Out and S/PDIF Out Port Connects to powered analog speakers or record-
ing devices with optical connectors(3.5mm jack)
7 Power Input Port Connects to the power adapter
1 3 5
476
2
No. Name Description
1 Sheet Metal Magnetic metal feet can be used for connection to optional
VDD100 CD/DVD RW drive
There are four Magnet-Metal-Feet in the package. Just align them to the sheet metal
on the bottom, then they can magnetize the PC Mini easily. The feet can seat and
protect PC Mini when it is placed on the tabletop.
CAUTION
!
1

4
Chapter 2
Placing and connecting the
PC Mini
In this chapter, the placement and the connection of some necessary peripherals will
be introduced.
This chapter includes the following information:
■PlacementofPCMini
■ ConnectionofPCMini

5
2-1 Placement of PC Mini
1. On the Desk
1. You can install your PC Mini in the mount like the right image.
2. If there is enough space on your desk, you can simply put your
PC Mini on the tabletop as shown below.
2-2 Connection of PC Mini
1. Connect the Antenna
Connect the antenna to the RF port of the PC Mini. You can fold the antenna and rotate it in dif-
ferent angle as you want.
12

6
3. Connect the USB Devices
Connect USB devices to the USB ports of the PC Mini, for example, mouse and keyboard.
4. Connect the Network Cable
Connect LAN cable to the RJ-45 port, with the other end connected to a hub or switch.
or
Hub
Switch
2. Connect the Monitor
Connect a VGA to the PC Mini through DVI/VGA adapter.

7
5. Connect the Power Cord
Connect the power adapter to the power input port of the PC Mini, and push the power button to
start it.
2
Outlet
1
3
The power adapter is dissipating heat during normal use, please make sure not to
cover it and keep it away from your body to prevent discomfort or injury from heat
exposure.
CAUTION
!

8
Chapter 3
Install Windows 7 in PC Mini
This chapter introduces the Windows installation :
This chapter includes the following information:
■InstallWindows7
■InstallDriversinWindows7
Note: Skip this section, if you have purchased a
PC Mini model with Windows 7 pre-installed.

9
Make sure you have these ready :
1. VDD100 . (It is an optional accessory. If there is no VDD100 in this package, you need other
purchase an external USB DVD-ROM drive.)
2. PC Mini driver CD. (In this package)
3. Windows 7 Install CD. (Other purchase)
Before we continue :
■ YourPCMinipowerisoff.
■  Connect the VDD100 or USB DVD-ROM drive to one USB port of PC Mini and power it on.
3-1 Install Windows 7
1. Push power on button to turn on your computer, then press <Del> key to enter BIOS Setup.
2. Put the Windows 7 Install CD into the VDD100 or USB DVD-ROM drive.
3. Select and go to the “Boot” menu, set the “Boot Option #1” to DVD drive, press <F4> key to
save change and exit BIOS.
Version 2.10.1206. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Boot
Boot Configuration
Quiet Boot [Disabled]
Fast Boot [Disabled]
Bootup Numlock State [On]
Boot Option Priorities
Boot Option #1 [USB: Optical DVD RW]
Boot Option #2 [TEAC DV-W28SS-R W.OA]
Hard Drive BBS Priorities
CD/DVD ROM Drive BBS Priorities
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enables/Disables Quiet Boot
option

10
4. Thecomputerwillreboot,anditwillstartloadingthelesforinstallingtheWindows7Operating
System.
5.AfterthecomputerrebootsitwillstartloadingthelesforinstallingWindows7.Click“Next”to
continue and click “Install now” button to start the setup.
6. When the license terms appear choose accept and click “Next” to continue.
7. It will then ask you to select the installation type. Click “Custom (advanced)” to install a new copy
of Windows.
8. The setup will the display the hard disk partitions (160GB, in this example) of your system. If
there were other systems (such as Linux) installed previously, you need select them and click
“Drive options (advanced)” to delete them. When all partitions are clean, setup will display the
biggest size of your hard drive.

11
9. In the hard disk size screen, you can click the “new” button to create partitions as you need.
Inthisexamplewearecreatinga70GBpartitiontoinstallWindows.Makeyourmodications
and click “Apply”.
To ensure that all Windows features work correctly, Windows might create additional
partitionsforsystemles. So you will see a 100MB partition reserved by system after you
create a partition. Select the 70GB partition and click “Next” to continue.

12
10. The setup program will then start to install Windows 7 on your hard disk. During the installa-
tion, your computer will restart several times.
11.Whentheinstallationiscomplete,setupwillprepareyourcomputerforit’srstuse.Youcan
then follow the steps to select system settings, create an account, set a password...etc, until
the whole process is complete.

13
3-2 Install Drivers in Windows 7
1. When the Windows 7 is completely installed, you have to install the necessary drivers before
using the PC Mini. Take out the Windows 7 Install CD from the USB DVD-ROM drive, and put
the PC Mini driver CD inside.
2. Waiting for a few seconds, the main menu will be displayed on the screen.
3. Use these options to install all the drivers for your system. You must click "AMD Chipset Driver"
toinstallitrst.Afterthat,you can click ”One Click Setup” and then choose the items you want
to install, or you can click on each individual driver to install it manually.
4. After all the drivers are installed, you need to restart your PC Mini, then you can start using it.
