ViewSonic VSR100 User manual

VSR100
Wireless Presentation Gateway
User Guide
Model No. VS17983
P/N: VSR100
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic®Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”

2
Thank you for choosing ViewSonic®
As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding
the world’s expectations for technological evolution, innovation, and simplicity.
At ViewSonic®, we believe that our products have the potential to make a positive
impact in the world, and we are confident that the ViewSonic® product you have
chosen will serve you well.
Once again, thank you for choosing ViewSonic®!

33
Contents
Overview..................................................................... 5
EZCast Pro Dongle II with Native Mirror Function ........ 6
Android ..................................................................................................................6
iOS ..........................................................................................................................6
Windows ................................................................................................................6
macOS ....................................................................................................................6
Multi-screen Broadcasting with ProCast ...................... 7
Download EZCast Pro App ........................................... 9
Android...................................................................................................................9
iOS ..........................................................................................................................9
Windows.................................................................................................................9
Mac.........................................................................................................................9
Chrome OS..............................................................................................................9
EZCast Pro App Introduction ..................................... 10
EZNote .................................................................................................................10
EZKeep .................................................................................................................10
EZChannel ............................................................................................................10
Photo ...................................................................................................................10
Camera ................................................................................................................10
Music ...................................................................................................................10
Video ....................................................................................................................11
Document (iOS only) ............................................................................................11
Web .....................................................................................................................11
Cloud Storage ......................................................................................................11
AirView ................................................................................................................11

4
Setting ...................................................................... 12
Scan 5G SSID and Connect ...................................................................................12
Language ..............................................................................................................12
Device Name ........................................................................................................12
Resolution ............................................................................................................12
EZAir Mode ..........................................................................................................12
AirView ................................................................................................................13
Castcode Control .................................................................................................13
Max Connections .................................................................................................13
Advanced Setting ...................................................... 14
Link Status ............................................................................................................14
Conference Control ..............................................................................................14
Device Management ............................................................................................14
Network Management .........................................................................................16
Admin Setting .......................................................................................................16
Reboot .................................................................................................................18
About....................................................................................................................18
Split Screen Mode .................................................... 19
Mirror ...................................................................... 20
Privacy Setting .......................................................... 21
Regulatory and Service Information .......................... 22
Compliance Information.......................................................................................22
Copyright Information ..........................................................................................26

5
Overview
EZCast Pro Dongle II improves on the exisng Pro Dongle technology with new
hardware and soware support. The new 802.11ac 5G 2T2R Wi-Fi transceiver
creates faster and more stable Wi-Fi performance.
• Brand New Hardware Design
GHz-level SoC with 1GB DDR3 memory to deliver a more powerful performance.
• Enhanced Wi-Fi Capability
Supports 802.11ac 5GHz Wi-Fi with 2T2R MIMO high sensivity antenna to
improve bandwidth to run resource intensive applicaons such as 4K video
streaming.
• 4K Compability
Screen mirror wirelessly to beauful UHD TV and projectors to enhance your
presentaon experience.
• Mul-screen Broadcasng
Easy-to-use ProCast app designed to wirelessly screen mirror 1-to-many screens
from your laptop. We are proud to say this is the most advanced wireless
presentaon applicaon ever, no more lousy and costly wiring installaons.
• Ecient Meeng with EZCast Pro App
Take realme notes with EZNote, stream documents and photos in wireless
presentaons. Control meeng agendas with Host Control.
• Cross Plaorm Support
Compable with both airplay screen mirroring and miracast without switching its
conguraon, ready for wireless screen mirroring from any smart device.

6
EZCast Pro Dongle II with
Nave Mirror Funcon
To provide nave casng experience, EZCast Pro Dongle II supports Miracast,
AirPlay, thus enabling user to do video streaming without installing any app.
Android
1. Click in your setting menu and select the SSID that matches with your dongle.
Please make sure your device supports Miracast protocol. Also, Cast Logo may
vary from different devices.
2. Once connected, user may see the mirror screen on the external display.
iOS
1. Connect your iOS device to EZCast Pro Dongle II in the Wi-Fi list. Or connect your
iOS device and Dongle to the same WAP (Wireless Access Point).
2. Click in your menu and select the SSID that matches your dongle.
3. Once connected, user may see the mirror screen on the external display.
Windows
1. Open your Windows Settings Menu, then enter the Display section.
2. User may find the SSID of the dongle. Once connected, user may see the mirror
screen on the external display. Based on different using scenarios, you may
select different methods, including Duplicate, Extend, etc.
macOS
1. Connect your iOS device to EZCast Pro Dongle II in the Wi-Fi list. Or connect your
iOS device and Dongle to the same WAP (Wireless Access Point).
2. Click in your menu and select the SSID that matches your dongle.
3. Once connected, user may see the mirror screen on the external display.

7
Mul-screen Broadcasng with
ProCast
User may use one laptop as casng source and mirror to other external displays.
Please note that Mulit-screen broadcasng is only compable with Windows and
Mac.
DO NOT open EZCast Pro App and ProCast at the same me.
Before using Mul-screen broadcasng, make sure all your dongles that connected
to external displays are using the same Wi-Fi.
Please note that with the rising number of connected devices, the lower bandwidth
will be.
For more details, please visit our website.
1. Download ProCast App from our website and install it.
2. Open ProCast App, and you’ll see the matching dongle SSID.
3. Click and your screen will be cast to the external displays.
Please make sure your laptop and the external displays are under the Same Network.

8
The following icons serves dierent purposes:
Mirror Disconnect
Silent mode Sound-on mode
By clicking , we provide users with seng opon and diagnosc tool.
1. Audio Buer
a. Long: With longer buer, may provide beer audio streaming experience
b. Short: May cause audio cracked more frequently
2. Diagnosc Tool:
Based on user’s CPU and Network performance, the Diagnosc Tool will calculate
the ideal number of connected external displays.
Please note that the mirror performance may change under dierent scenarios. For
example, stac presentaon will perform beer than 4K video streaming.

9
Download EZCast Pro App
We have built dierent versions of EZCast Pro App for mulple OS plaorms. With
EZCast Pro App, users may do custom conguraon for their dongles, including Wi-
Fi, Split Screen, etc.
Please refer to the following informaon. As for the App funcon intro, we’ll
elaborate on more details at the laer secons.
Android
You may download EZCast Pro App for Android from Google Play or our website.
iOS
You may download EZCast Pro App for iOS directly from App Store.
Windows
You may download EZCast Pro App for Windows from our website.
Mac
You may download EZCast Pro App for Windows from our website.
Chrome OS
You may download EZCast Pro App for Windows from our website.

10
EZCast Pro App Introducon
In the following secon, we’ll introduce the built-in funcon of EZCast Pro App.
Please note that some funcons are limited to certain OS plaorm.
EZNote
With EZNote, user may view all the devices’ casng content in the output screen,
then taking notes directly on their own mobile device.
EZKeep
User can review notes saved previously in EZKeep. Other than browsing note, a user
can also add bookmarks, eding notes informaon, making comments, deleng
notes, etc.
EZChannel
Gathering the most popular, latest online video at EZChannel home page, including
movies, TV series, 24-hour news. At the upper right corner, the user may see the
HQ/LQ button, which allows the user to alternate between High Quality (HQ) and
Low Quality (LQ) video.
Once the mobile device is connected to EZCast Pro Dongle II, user can browse
images that stored in their device. EZCast Pro App also supports slideshow mode,
providing four different timing transition options, which includes 3, 5, 10, 30 sec /
per photo.
Camera
With Camera function, EZCast Pro Dongle II provides Live Casting service by
transmitting Live image from a user’s device to external display.
Music
Streaming audio to the output device. Please note that when streaming music
to external display, EZCast Pro Dongle II only accepts one device as an audio
source.

11
Video
Casting video content to the external display. Please note that when using the
Video function during the Split Screen mode, all the connected devices will be
disconnected from network display mode.
Document (iOS only)
Reviewing document in EZCast Pro App, supporting mainstream document formats,
including Microsoft’s Word, Excel, PowerPoint, and Apple’s Pages, Numbers, and
Keynotes.
Web
User can browse Web content in EZCast Pro App, without using 3rd party browser.
To provide better browsing experience, EZCast Pro App already integrated web
portals like Google, Facebook, Yahoo, YouTube, etc. Users who already owned
EZCast account, may login first and browse bookmarks saved before.
Cloud Storage
EZCast Pro Dongle II has integrated mainstream cloud storage service, such as
Dropbox, Google Drive, etc. With this function, user may browse, edit, delete or
manage their cloud storage without leaving EZCast Pro App.
AirView
When turning on AirView mode, users may see all the external display on their
own device. This function also allows the user to choose the preferred refresh rate.
Please note that user may choose the preferred refresh rate in the Setting menu.

12
Seng
In Seng menu, user may do custom sengs for their EZCast Pro Dongle II,
including Wi-Fi, Language, Device Name, etc..
Scan 5G SSID and Connect
Connecng EZCast Pro Dongle II to preferred networking by selecng SSID and
entering Wi-Fi password. Aer seng up, the user may ulize wireless funcon
such as online video streaming, web browsing, etc.
Language
Supporng mainstream languages such as English, French, German, Chinese, etc.
Device Name
User may set new SSID for EZCast Pro Dongle II, deciding whether to show SSID at
the standby screen.
Please note that before turning off SSID function, making sure that EZCast Pro
Dongle II is connected to Wi-Fi router, otherwise would cause EZCast Pro Dongle II
to lose wireless connectivity. User will have to do hard reset for EZCast Pro Dongle
II to regain wireless connectivity.
Resoluon
EZCast Pro Dongle II will select the proper output resolution for the user
automatically. This function also supports manual selection.
EZAir Mode
EZAir mode is specifically designed for the iOS device, including iPhone and iPad,
which enables users to utilize AirPlay, native mirroring function provided by Apple.
User may choose “Mirror only” or “Screen Mirror+Video Streaming”. The former
can only mirror the screen content, while the latter can cast both screen and audio
content to external display.

13
AirView
When turning on AirView mode, with users’ own device, you may see all the casting
content captured from external display. This function also enables the user to
choose the preferred refresh rate.
Castcode Control
When turning on, the user may mirror the screen by entering castcode displayed
on the standby screen.
Max Connecons
Host may decide the number of devices that allowed to connect to EZCast Pro
Dongle II. The default setting is 8 users.
Please note that with the rising number of connected devices, the lower network
bandwidth would have for each user.

14
Advanced Seng
Admin Seng is designed for advanced users, including MIS Engineer, IT specialist,
Network admin, etc. In Admin Seng secon, QuaroPod provides users with
various custom conguraons.
Link Status
With this opon, the aendees may see all the device informaon that connected
to EZCast Pro Dongle II, including detailed informaon like device name, IP address,
and Role.
Conference Control
This funcon is only for Host user. With Host authorizaon, a user can assign each
device with their own casng area, disconnecng all device, or assigning Host
authorizaon to others.
Device Management
• Language
Supporting mainstream languages such as English, French, German, Chinese, etc.
• Device Name
User may set new SSID for EZCast Pro Dongle II. If the user doesn’t want to show
SSID at the standby screen, it could also be deactivated.
Please note that before turning off SSID function, making sure that EZCast Pro
Dongle II is connected to Wi-Fi router, otherwise would cause EZCast Pro Dongle
II to lose wireless connectivity. User will have to do hard reset for EZCast Pro
Dongle II to regain wireless connectivity.
• Resoluon
EZCast Pro Dongle II will select proper output resolution for the user
automatically. This function also supports manual selection.

15
• EZAir Mode
EZAir mode is specifically designed for the iOS device, including iPhone and iPad,
which enables users to utilize AirPlay, native mirroring function provided by
Apple.
User may choose “Mirror only” or “Screen Mirror+Video Streaming”. The former
can only mirror the screen content, while the latter can cast both screen and
audio content to external display.
• AirView
When turning on AirView mode, with users’ own device, you may see all the
casting content captured from external display. This function also enables the
user to choose the preferred refresh rate.
• EZNote
Through EZNote, a user can take note directly on the casting screen shot
provided by EZCast Pro Dongle II.
• Castcode Control
When turning on, the user may mirror the screen by entering castcode displayed
on the standby screen.
• Max Connecons
Host may decide the number of devices that allowed to connect to EZCast Pro
Dongle II. The default setting is 8 users.
Please note that with the rising number of connected devices, the lower
network bandwidth would have for each user.

16
Network Management
• Scan 5G SSID and Connect
Connecting EZCast Pro Dongle II to preferred networking by selecting SSID and
entering Wi-Fi password. After setting up, the user may utilize wireless function
such as online video streaming, web browsing, etc.
• WiFi IP Seng
With this function, EZCast Pro Dongle II will set up a default IP address, Netmask.
For an advanced setting, the user may manually configure the IP address,
Gateway, Netmask, and DNS for EZCast Pro Dongle II.
• WiFi Password
Setting Wi-Fi password for EZCast Pro Dongle II. A user may decide whether to
hide the Wi-Fi password from the standby screen.
• WiFi Channel
User may configure WiFi Channel manually, such as Country, Channel, and
Bandwidth. Please note that user won’t be able to switch WiFi Channel when
EZCast Pro Dongle II is connected with an external router.
Admin Seng
Admin Seng is built for advanced users like IT admins, MIS engineers. In this
secon, premium users are allowed to provide Digital cercate for EZCast Pro
Dongle II, seng SNMP for mass devices conguraon deployment, updang
EZCast Pro Dongle II through OTA Server, etc.
• Admin Password
Setting New Admin Password for EZCast Pro Dongle II.
• WiFi Enterprise
Wi-Fi Enterprise function allows user uploading Digital certificate.
• Host Authority
Specifying Host user authorization, including Conference Control, Device
manager control, Network setup control, and Reboot control.

17
• Internet Access Control
EZCast Pro Dongle II provide three options for Internet Access control.
All allowed:
Any device can access to Internet through EZCast Pro Dongle II.
Casting users allowed:
Device that casting through EZCast Pro Dongle II is allowed to access to the
Internet.
All denied:
None of the devices is allowed to access to the internet through EZCast Pro
Dongle II.
• SNMP
IT admin may apply the same configuration to many EZCast Pro Dongle II in
once, hence enriching IT management productivity.
• My Screen
Allow the user to choose wallpaper based on their preference. Please note that
the updated file must be JPEG format that smaller than 3MB, fitting in 1920x
1080.
• OTA URL
IT admin may facilitate OTA URL function for deploying a new firmware version
to many devices at once.
• Connecon
EZCast Pro Dongle II provides three different ways allowing a device to build the
connection with EZCast Pro Dongle II.
Via Router Allowed:
Device may connect to EZCast Pro through Router.
Direct Link Only:
Device can only connect to EZCast Pro Dongle II through Direct Link.
Via Router Only:
Device can only connect to EZCast Pro Dongle II through Router.

18
• Upgrade
Upgrading to latest firmware through this function. To utilize the latest function
provided by EZCast, please make sure your firmware version is up to date.
• Reset to default
Resetting EZCast Pro Dongle II to factory default. Please note that once clicking
OK, all your configuration will be reset.
Reboot
Reboong EZCast Pro Dongle II for troubleshoong.
About
Lisng detailed informaon about EZCast Pro Dongle II, including SSID, Firmware
version, Internet IP address, MAC address, etc.

19
Split Screen Mode
Based on the numbers of connected devices, host user may divide the external
display into one-half, one-quarter.
Null One-Half
One-Quater Full

20
Mirror
User may also cast with Mirror funcon. Please note that that under Mirror mode,
video is projected to external display, while audio coming out from your mobile
device.
