ViewSonic EP1032r-T User manual

Touch Interactive Custom Messaging
10.1" Multi-Touch All-in-One
Electronic Mini Billboard
EP1032r-T
Perfect Size for Up-close, High-impact Messaging
The ViewSonic EP1032r-T all-in-one electronic mini billboard has a 10.1"
LED display area with 1280 x 800 resolution. With its compact design, the
EP1032r-T can be deployed anywhere, including retail shelf edges, hotel front
desks, in meeting rooms, or on classroom doors. The EP1032r-T features
300-nit brightness and a 500:1 contrast ratio to deliver high-impact, quality
messaging that will attract the attention of passersby.
The ViewSonic®EP1032r-T is a 10.1" multimedia all-in-
one interactive electronic mini billboard. It delivers eye-
catching touch-interactive commercial messaging at
retail POS, hotel lobbies and front desks, conference
and exhibition venues, and other high-visibility locations.
The EP1032r-T features wireless b/g/n network and LAN
connectivity for easy loading of content, and supports
Power over Ethernet (PoE) for convenient one-wire
installation. Multi-touch compatibility with HTML5 and
SMIL formats delivers a 2-way interactive platform for
dynamic, customized content. Its built-in media player,
4GB internal storage, and integrated speakers enable
the playback of video clips, as well as photos and music,
from a USB hard drive or SD/SDHC memory card.
Bundled with Signage Manager Express software, the
EP1032r-T effectively delivers customized messaging
to target audiences. With VESA-mount compliance, the
EP1032r-T is installation-ready for any high-visibility,
high-trafc locations.
Convenient One-wire Installation via Power over Ethernet
The EP1032r-T utilizes state-of-the-art Power over Ethernet (PoE)
technology for one-wire installation. This allows you to easily power and
connect your displays with just a single cable. PoE also allows you to create
multi-display digital signage installations, while reducing installation costs.
4GB of Internal Memory and SD/SDHC Card Slot
The EP1032r-T is capable of storing and playing hours and hours of high-
definition multimedia content thanks to its 4GB of built-in, shock-resistant,
solid-state memory. This reliable all-in-one electronic mini billboard will display
dynamic content with no crashes, freezes, or lost content..
Interactive On-demand Messaging
The EP1032r-T delivers on-demand advertising and messaging while
increasing two-way communication with customers. With 2-point multi-touch
capability, the EP1032r-T is the perfect interactive e-catalog display solution
for shelf edges, retail counters, and information kiosks in high-trafc venues.

Specications
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
Programs, specications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property
of their respective companies. HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Copyright © 2013 ViewSonic Corporation.
All rights reserved. [16926-00B-11/13]
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
EP1032r-T
EP1032r-T ePoster, AC adapter, ethernet cable, 3.5mm to RCA AC adapter, display stand and screws,
Quick Start Guide, Software Setup Guide, ViewSonic Wizard CD (User Guide and Signage Manger
Express software)
What's in the box?
Easy Loading of Content
through Wireless/ RJ45 Ethernet
The EP1032r-T integrates wireless 802.11 b/g/n network
and RJ45 Ethernet connectivity, providing a convenient
and efficient way to load content from a PC or laptop
connection. Wireless/LAN connectivity can also be used to
remotely load content to multiple displays.
HDMI
LAN
Audio Out SD Card Reader
10.9"
VESA®Wall Mount
75mm x 75mm
1.6"
7.3" 10.1"
Wireless Antenna
USB Type A
(x2)
USB Type B
DC In
Kensington®
Lock Slot
Support for Dynamic
W3C/SMIL-format Presentations
With the bundled Signage Manager Express software, the
EP1032r-T can display W3C, HTML5, and SMIL content
retrieved from the Internet. Display fresh and interesting
content such as news, weather information, stock market
trends, sports scores, social networking, or RSS feeds on
multiple screens.
10.1" Multi-Touch All-in-One
Electronic Mini Billboard
PANEL Type 10.1" TFT LCD Module with LED Backlight
Display Area 8.6" horizontal x 5.2" vertical; 10.1" diagonal
Optimum Resolution 1280 x 800
Contrast Ratio 700:1 (typ)
Viewing Angles 170º horizontal, 160º vertical
Response Time 25ms
Light Source Long life, 50,000 hrs. (typ)
Brightness 300 cd/m2(typ)
Panel Surface Anti-glare
CONNECTIVITY Digital HDMI 1.3
USB Type A x2 (content loading, F/W upgrade, keyboard/mouse)
Type B x1 (for F/W troubleshooting)
LAN RJ45
Audio Output 3.5mm mini jack
Card Reader SD/SDHC
FILE FORMATS Video MPEG 1,2,4, WMV
Audio MPEG L2, MP3
Photo JPG, PNG
Dynamic W3C HTML5, W3C SMIL 3.0
AUDIO Speakers 2W (x2)
WALL MOUNT VESA 75 x 75mm
POWER Voltage AC 100–240V (universal), 50–60Hz
Consumption 14.1W (typ)
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 5%–85% (non-condensing)
Altitude 0~6,561 ft (2,000m)
DIMENSIONS Physical 10.9 x 7.3 x 1.6 in. / 278 x 186 x 40 mm
(W x H x D) Packaging 12.6 x 10.0 x 3.5 in. / 320 x 255 x 89 mm
WEIGHT Net 1.7 lbs. / 0.8 kg
Gross 7.3 lbs. / 3.3 kg
REGULATIONS FCC, CE
WARRANTY 1-year limited warranty on parts and labor
