ViewSonic EP5542 User manual

EP5542/EP5542T
Multimedia Digital Poster
User Guide
Model No.: VS18153
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specic languages using the Regional selection
box in the upper right corner of our website. “Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic
As a world leading provider of visual solutions, ViewSonic is dedicated to
exceeding the world’s expectations for technological evolution, innovation,
and simplicity. At ViewSonic, we believe that our products have the
potential to make a positive impact in the world, and we are condent that
the ViewSonic product you have chosen will serve you well.
Once again, thank you for choosing ViewSonic !

i
Compliance Information
NOTE: This section addresses all connected requirements and statements regarding regulations.
Confirmed corresponding applications shall refer to nameplate labels and relevant markings on
unit.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A/
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own
expense.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: To comply with the limits for the Class A/Class B digital device, pursuant to Part 15 of
the FCC Rules, this device must be installed in computer equipment certified to comply with the
Class A/Class B limits. All cables used to connect the computer and peripherals must be shielded
and grounded. Operation with non-certified computers or non-shielded cables may result in
interference to radio or television reception. Changes and modifications not expressly approved by
the manufacturer could void the user’s authority to operate this equipment.
For Canada
CAN ICES-3 (A/B)/NMB-3(A/B)

ii
CE Conformity for European Countries
The device complies with the EMC Directive 2014/30/EU and Low Voltage Directive
2014/35/EU.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and Electronic
Equipment Directive 2012/19/EU (WEEE).
The mark indicates the requirement NOT to dispose of the equipment as unsorted
municipal waste, but use the return and collection systems according to local law.
If the batteries, accumulators and button cells included with this equipment, display the
chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content
of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004%
Lead.
Industry Canada Notice
This device complies with Canadian RSS-210.To prevent radio interference to the licensed service,
this device is intended to be operated indoors and away from windows to provide maximum
shielding. Equipment (or its transmitting antenna) that is installed outdoors is subject to licensing.
The installer of this radio equipment must ensure that the antenna is located or pointed such that it
does not emit RF field in excess of Health Canada limits for the general population; consult Safety
Code 6, obtainable from Health Canada’s website www.hc-sc.gc.ca/rpb.
R&TTE Compliance Statement
This device complies with the Essential Requirements of the R&TTE Directive of the European
Union (1999/5/EC). This equipment meets the following conformance standards:
ETSI EN 300 328
EN 301 489-01
EN 301 489-17
EN 62311
Notified Countries: Germany, UK, Netherlands, Belgium, Sweden, Denmark,
Finland, France, Italy, Spain, Austria, Ireland, Portugal, Greece, Luxembourg,
Estonia, Latvia, Lithuania, Czech Republic, Slovakia, Slovenia, Hungary, Poland and Malta.

iii
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive 2011/65/EU of the
European Parliament and the Council on restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum
concentration values issued by the European Technical Adaptation Committee (TAC) as shown
below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Bis (2-ethylhexyl) phthalate (DEHP) 0.1% < 0.1%
Butyl benzyl phthalate (BBP) 0.1% < 0.1%
Dibutyl phthalate (DBP) 0.1% < 0.1%
Diisobutyl phthalate (DIBP ) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex III of the RoHS2
Directives as noted below:
Examples of exempted components are:
1. Lead in glass of uorescent tubes not exceeding 0.2% by weight
2. Lead as an alloying element in aluminium containing up to 0.4% lead by weight
3. Copper alloy containing up to 4% lead by weight
4. Lead in high melting temperature type solders (i.e. lead-based alloys containing 85% by weight
or more lead)
5. Electrical and electronic components containing lead in a glass or ceramic other than dielectric
ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or ceramic matrix compound.

iv
Safety Precautions
FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND
USING THE LCD COLOR MONITOR:
• DO NOT REMOVE MONITOR BACK COVER. There are no user serviceable parts inside and
opening or removing covers may expose you to dangerous shock hazards or other risks. Refer
all servicing to qualied service personnel.
• Do not spill any liquids into the cabinet or use your monitor near water.
• Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage
points, which can be harmful or fatal or may cause electric shock, re or equipment failure.
• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or
re.
• Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall,
causing serious damage to the monitor.
• Do not place any objects onto the monitor and do not use the monitor outdoors.
• The inside of the uorescent tube located within the LCD monitor contains mercury. Please
follow the laws or rules of your municipality to dispose of the tube properly.
• Do not bend power cord.
• Do not use monitor in high temperature, humid, dusty, or oily areas.
• If monitor or glass is broken, do not come in contact with the liquid crystal and handle with
care.
• Allow adequate ventilation around the monitor, so that heat can properly dissipate. Do not
block ventilated openings or place the monitor near a radiator or other heat sources. Do not
put anything on top of the monitor.
• The power cable connector is the primary means of detaching the system from the power
supply. The monitor should be installed close to a power outlet, which is easily accessible.
• Handle with care when transporting. Save packaging for transporting.
• Please clean the holes of back cabinet to reject dirt and dust at least once a year because of
set reliability.
• If using the cooling fan continuously, it’s recommended to wipe holes a minimum of once a
month.
• When installing the remote control batteries;
- Align the batteries according to the (+) and (-) indications inside the case.
- Align the (-) indication of the battery rst inside the case.
WARNING:
Usage of other than specified head- or earphones can result in hearing loss due to excessive
sound pressures.

v
CAUTION:
Immediately unplug your monitor from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the monitor.
• If the monitor has been exposed to rain or water.
• If the monitor has been dropped or the cabinet damaged.
• If the monitor does not operate normally by following operating instructions.
Recommended Use
CAUTION:
• For optimum performance, allow 20 minutes for warm-up.
• Rest your eyes periodically by focusing on an object at least 5 feet away. Blink often.
• Position the monitor at a 90° angle to windows and other light sources to minimize glare and
reections.
• Clean the LCD monitor surface with a lint-free, nonabrasive cloth. Avoid using any cleaning
solution or glass cleaner!
• Adjust the monitor’s brightness, contrast and sharpness controls to enhance readability.
• Avoid displaying xed patterns on the monitor for long periods of time to avoid image
persistence (after image e󰀨ects).
• Get regular eye checkups.
Ergonomics
To realize the maximum ergonomic benefits, we recommend the following:
• Use the preset Size and Position controls with standard signals.
• Use the preset Color Setting.
• Use non-interlaced signals.
• Do not use primary color blue on a dark background, as it is di󰀩cult to see and may produce
eye fatigue due to insu󰀩cient contrast.

vi
Table Of Contents
1. Getting Started...........................................................................................................................1
1.1. Package Contents...............................................................................................................1
1.2. Fastening the poster ...........................................................................................................1
2. Parts and Functions ..................................................................................................................4
2.1. Remote Control...................................................................................................................4
2.1.1. Installing remote control Batteries ...........................................................................5
2.1.2. Aiming the remote control ......................................................................................5
3. Connections...............................................................................................................................6
4. Basic Operations .......................................................................................................................7
4.1. Turn on the display..............................................................................................................7
4.2. First initiation.......................................................................................................................7
4.3. Home Menu Overview.........................................................................................................8
5. System Settings.........................................................................................................................9
5.1. Home Menu Overview.......................................................................................................10
5.2. Home Menu Overview.......................................................................................................11
6. File Explorer.............................................................................................................................12
7. Menu List 14
8. Using Auto Play .......................................................................................................................16
9. Using USB multi media player................................................................................................17
9.1. Playing Photo....................................................................................................................18
9.2. Playing Music....................................................................................................................19
9.3. Playing Movie....................................................................................................................20
10. Supportedmedialesformat.................................................................................................21
11. Troubleshooting.......................................................................................................................24
12. Specications ..........................................................................................................................25
13. Other Information ....................................................................................................................26
Customer Support......................................................................................................................26
Limited Warranty .......................................................................................................................27
Mexico Limited Warranty ...........................................................................................................29

vii
Copyright Information
Copyright © ViewSonic Corporation, 2020. All rights reserved.
ViewSonic© and the three birds logo are registered trademarks of ViewSonic Corporation.
ENERGY STAR®is a registered trademark of the U.S. Environmental Protection Agency (EPA).
As an ENERGY STAR®partner, ViewSonic Corporation has determined that this product meetsthe
ENERGY STAR®guidelines for energy efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this
material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specifications without notice. Information in this document may change without
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com.
The ViewSonic®Wizard CD-ROM also provides an opportunity for you to print the registration form,
which you may mail or fax to ViewSonic.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
EP5542/EP5542T
ViewSonic Multimedia Digital Poster
VS18153
EP5542/EP5542T_UG_ENG_1a_20200520
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green. Thank you for
being part of Smarter, Greener Computing.
Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwan: https://recycle.epa.gov.tw/

1
1. Getting Started
1.1. Package Contents
The following items are included in your product box.
EP5542/EP5542T
Mul�media Digital Poster
數位多媒體廣告看板
Quick Start Guide
快速使用指南
2
3
1
For HDMI 1 For HDMI 2
HDMI 3
DP
VGA
Switch
EP5542/EP5542T
Mul�media Digital Poster
數位多媒體廣告看板
Quick Start Guide
快速使用指南
2
3
1
ForHDMI 1 For HDMI 2
HDMI3
DP
VGA
Switch
NOTE: The illustrations may di󰀨er slightly from the items shipped with your product.
1.2. Fastening the poster
120. 3 528 120. 3
2 - 15
As illustrated in gure, positioning 2 holes on the earth
and drill the holes at the corresponding position.
The diameter of the hole on the earth should be
smaller than the diameter of the screw.
Fit the two fastening screws, fastening the Poster to
earth.
NOTES:
1. The appearance of this product in these illustrations may di󰀨er from your actual product, and is for
comparative purposes only.
2. We may change the design and specications without notice.

2
321
Remote Sensor
1. USB 1 (DC 5.0V/0.5A)
USB for the poster. This USB port can’t not use for FW update.
2. USB 2 (DC 5.0V/0.5A)
USB for the poster. This USB port can’t not use for FW update.
3. RJ45
Enable connection to cable and log on to Internet.

3
2
134
11 12
Main board
S/PDIF
5
7
8
6
9
10
Open the door with the key.
NOTE: 1. Cut o󰀨 power before opening
the door.
2. Make sure that the door is
locked before turning on power.
Main
board
1. DP(DisplayPort) INPUT
Connect an external device to DP out jack.
2. HDMI1/2/3 Input
To connect with those equipments with HDMI or DVI interface.
HDMI 3(ARC): Connect an ARC-enabled home theater receiver to this jack.
3. USB 2.0
Connect USB devices to this port for Android.
NOTE: It must be used if you upgrade software.
4. TOUCH OUT1/2
Connect an external device to support touch control of the external device on the Poster.
NOTE: Touch out 1 corresponds to the HDMI 1, Touch out 2 corresponds to the HDMI 2,HDMI3, DP or VGA.
5. PC IN
Enable connection to PC or other external devices with VGA/AUDIO ports.
6. S/PDIF digital audio output
Connect a digital sound system to this jack.
7.
Connect headphones to this jack. The Poster is the current audio output.
8. RS-232
For remote control, service and other uses.
9. RJ45 (LAN IN)
Enable connection to cable and log on to Internet.
10. AC OUT
Only use one power supply, ~100-240V 50Hz/60Hz, Current Max. : 0.65A.
11. AC IN
Plug the AC cord into this jack and into a power outlet.(~100-240V 50Hz/60Hz).
12. Power Switch
Push to (1) to connect the power, push to (O) to cut o󰀨.
NOTE: Power switch can not be covered, and should keep the power switch can be conveniently operated.

4
2. Parts and Functions
2.1. Remote Control
HOME
MUTE
EXIT
MENU
INPUT
VOL
SOUND
1
7
4
2
8
5
0
3
9
6
A SPECT
FREEZE
SNA P
USB
SL EE P
SHORTCUT
INFO
OK
RC-1313-0A
Power On/O󰀨
Select the screen size
Return to previous menu or
exit the on-screen menu
Use OK button to conrm
selection or enter sub-menu
Use arrow buttons to move
the cursor
Open the menu mainly
for picture, audio and
schedule setting
Control buttons for USB
multimedia playback
/
/
: Previous/next
/
/
: Play/Pause button
/
/
: STOP button
/
/
: Fast forward/fast reverse
To list all recently used
Apps.
Set up the sleep timer
Take a screenshot and store to
USB drive or internal storage
if no USB drive connected.
Freeze the screen
Go to USB mode
VOLUME UP/DOWN
Select sound mode
Select picture mode
Mute the sound
Display desktop
(Home page)
Input source
information
0-9 number buttons
Input source select
Notes:
• For touch model, some functions could be performed through touch directly instead of remote control.

5
2.1.1. Installing remote control Batteries
To install remote control batteries:
1. Open the battery cover.
2. Insert two AAA batteries into the battery compartment. Make sure that the + and –
symbols on the batteries match the + and – symbols in the battery compartment.
3. Replace the cover.
Battery precautions:
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be
sure to follow the instructions below.
• Place batteries with their terminals corresponding to the (+) and (–)indications.
• Di󰀨erent types of batteries have di󰀨erent characteristics. Do not mix batteries of
di󰀨erent types.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the
life of new batteries and/or cause old batteries to leak chemicals.
• Remove batteries as soon as they are non-operable. Chemicals that leak from batteries can cause a
rash. If chemical leakage is found, wipe with a cloth.
• Dispose of batteries in a proper manner.
• If the remote control is not used for an extended period of time, remove the batteries.
• The batteries shall not be exposed to excessive heat such as sunshine, re or the like.
2.1.2. Aiming the remote control
Use the remote control by pointing it towards the remote sensor on the front of your display. Objects
between the remote control and the remote sensor may prevent proper operation.
Cautions regarding use of remote control
• Do not expose the remote control to shock. In addition, do not expose the remote
control to liquids, and do not place in an area with high humidity.
• Do not install or place the remote control under direct sunlight. The heat may cause
deformation of the unit.
• The remote control may not work properly if the remote sensor window of the main
unit is under direct sunlight or strong lighting. In such a case, change the angle of the
lighting or the display set, or operate the remote control closer to the remote sensor
window.
30
30
5m
HOME
MUTE
EXIT
MENU
INPUT
VOL
SOUND
1
7
4
2
8
5
0
3
9
6
ASPECT
FREEZE
SNAP
USB
SLEEP
SHORTCUT
INFO
OK
RC-1313-0A

6
3. Connections
• Turn o󰀨 the display and connected device.
• Check the plug type at the ends of cables.
• Make sure the fastened connection.
S/PDIF
Network cable Network cable
Audio input devices
Digital sound system
PC, etc.
PC, etc. PC, etc.
PC, etc.
VGA devices
Serial port cable
Audio cable
VGA cable
VGA cable
Audio cable
USB cable
USB cable USB cable HDMI cable HDMI cable HDMI cable DP cable
DP devices
HDMI devices
USB devices
Main board Headphone cable
S/PDIF cable
NOTE: Before using headphones, adjust the device volume so as to avoid excessive levels, as hearing
damage may result.
Connect TOUCH OUT with USB cable to PC USB port.
Connect PC with VGA cable, HDMI cable or DP cable. Please choose the proper method of connection
based on your device. (Only for PC, HDMI, DP signal)
Touch out 1 corresponds to the HDMI 1, Touch out 2 corresponds to the HDMI 2, HDMI3, DP or VGA.
NOTE: After installation of the driver, it can control the external computer by native touch control.

7
4. Basic Operations
4.1. Turn on the display
Plug the power cord and turn on the AC Power Switch.
4.2. First initiation
The following installation menu will pop up for rst-time power on.
Select desired menu language.
Press Next to go to the next page.
Select your Time Zone, press Finish to
nish the installation.

8
4.3. Home Menu Overview
1. Press HOME button to show desktop menu.
2. Use arrow and OK button for desired selection.
3. Press EXIT button to leave.
Input source
Mainly for network, Date
&Time, and Language setting.
Menu
Installed
application
list
External
USB
storage
File
manager
web Browser.

9
5. System Settings
1. Press  button to select desktop menu option, press OK to conrm.
2. Press EXIT button to return to previous menu or exit the menu.
Network setting
Sound setting
Show all apps
Set Screen saver, Video Settings
System storage & reset
Android system information
Set Date & time
Set on-screen language
Set Android keyboard
Set Accessibility
Add accessory
Turn on/o󰀨 Location status/Recent location requests
Set Security and Restrictions

10
5.1. Home Menu Overview
1. Press  button to select desktop menu option, press OK to conrm.
2. Press EXIT button to return to previous menu or exit the menu.
Network setting
Scanning WiFi signal
Scanning WiFi direct device
Setting Portable WiFi hotspot
Enable/disable Miracast
Plug the LAN-cable into the LAN-port, the Poster will be get
an IP address automatically and connect to the internet.
Proxy setting
IP setting

11
5.2. Home Menu Overview
1. Press  button to entry About and select System net update.
System net update
System net update can select
(1) Auto Update: When display power o󰀨, system will auto check the
new version from OTA server. If new version found, system will auto
update. After update complete, sytem will turn o󰀨.
(2) Set Schedule: User can set the update time.
(3) Manual update: User can update the OTA package manually.
