ViewSonic VA2223WM - 21.5" LCD Monitor User manual

ViewSonic’s 22" (21.5" viewable) VA2223wm delivers Full HD
1920x1080 resolution at a price that won’t break your budget.
This stylish 22-inch LCD delivers extreme clarity, amazing color
with 16,000:1 dynamic contrast ratio and fast ClearMotiv®5ms
video response. Enjoy beautiful graphics and view spreadsheets
in unbelievable clarity. Enjoy greater productivity with the ability
to view two full-size documents side-by-side or work in multiple
applications simultaneously on the widescreen display. Integrated
speakers in a stylish, slim-bezel design provide multimedia
enjoyment. Eco-mode conserves power and can extend backlight
life. VA2223wm fits seamlessly into any office décor. It’s great for
desktop applications at home, school or in the office.
The affordable Full
HD 1080p LCD.
FULL HD 1080P ENTERTAINMENT
Widescreen aspect ratio with 1920x1080 resolution
The widescreen aspect ratio allows you to view HD content
in its native format with no stretching or distortion.
16,000:1 dynamic contrast ratio
Provides darker black levels and better overall
front-of-screen performance.
ClearMotiv®5ms video response time
Fast 5ms video response enables digital HD
broadcast-quality video.
OptiSync®digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI) and analog
(VGA) signals for ultimate compatibility and configuration flexibility.
Eco-mode
Environmentally-friendly Eco-mode reduces power consumption
and extends backlight life.
Aspect ratio adjustment
Eliminates image distortion by maintaining correct image
proportions for both widescreen and native 4:3 content.
Stylish slim-bezel design
The thin bezel lets you see more without taking up
valuable desktop real estate. The floating head design
accentuates the visual experience.
>
>
>
>
>
>
>
VA2223wm
22" (21.5" VIEWABLE)
WIDESCREEN LCD
WITH FULL 1080P RESOLUTION
16,000:1

VA2223wm
22" (21.5" VIEWABLE) WIDESCREEN LCD WITH FULL 1080P RESOLUTION
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and
programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the
property of their respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved. [14417-00B-05/09] VA2223wm-1
LCD Type 21.5" Wide Color TFT Active Matrix LCD
Display Area 18.7" horizontal x 10.5" vertical; 21.5" diagonal
Pixel Pitch 0.248mm horizontal x 0.248 vertical
Optimum Resolution 1920x1080 WUXGA
Contrast Ratio 1000:1 (typ); 16,000:1 (dynamic)
Viewing Angles 160º horizontal, 160º vertical (CR ≧10)
Response Time 5ms (typ)
Color Support 16.7M (6-bits + Hi FRC) panel
Light Source Long life, 50,000 hrs. (typ)
Brightness 300 cd/m2(typ)
Panel Surface Anti-glare, hard coating (3H)
VIDEO INPUT Analog RGB analog (75 ohms, 0.7/1.0 Vp-p)
Digital DVI-D (TMDS, 100 ohms)
Frequency Fh: 24~82kHz, Fv: 50~85Hz
Sync H/V separated (TTL)
COMPATIBILITY PC VGA up to 1920x1080 non-interlaced
Mac®* Power Mac™up to 1920x1080 non-interlaced
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital DVI-D
Audio 3.5mm stereo audio line-in ????????????????
Power Built-in power adapter, 3-pin plug
POWER Voltage AC 100–240V (universal), 50/60Hz (auto switch)
Consumption 48W (typ), 50W (max)
Eco-mode 33W optimize, 24W conserve
Save-mode ≦1W
AUDIO Speakers 2x2-watt
CONTROLS Basic Power, menu [1], up [▲], down [▼], select [2]
OSD Auto image adjust, contrast, brightness, input select (D-sub,
DVI), audio adjust (volume, mute), ViewMatch®color adjust
(sRGB, 9300K, 7500K, 6500K, 5000K, user color RGB),
information (resolution, H/V frequency, pixel clock, model
number, serial number, website), manual image adjust (H/V
position, H size, fine tune, sharpness, dynamic contrast,
aspect ratio, eco-mode), setup menu (language, resolution
notice, OSD position, OSD timeout, OSD background),
memory recall
ERGONOMICS Tilt Down 5º, Up 20º
OPERATING Temperature 41–95º F (5–35º C)
CONDITIONS Humidity 20–80% (non-condensing)
DIMENSIONS Physical with stand 20.1" x 15.3" x 9.7" (512mm x 388mm x 246mm)
(W x H x D) Physical without stand 20.1" x 11.8" x 2.5" (512mm x 300mm x 63mm)
WEIGHT Net with stand 8.8 lb. (4.0 kg)
Net without stand 8.0 lb. (3.6 kg)
Gross 12.2 lb. (5.5 kg)
VESA®MOUNT 100mm x 100mm
REGULATIONS UL, CUL, FCC-B (ICES), CB, CE, CES-003B, ISO13406-2, GS,
ERGO, TUV-S, NOM, GOST-R, HYGIENIC (20 copies),
ENGERY STAR®, CCC, BSMI, PSB, C-TICK, MIC (KCC), SASO,
WEEE, RoHS, VCCI, Ukraine, EPEAT Silver
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
POWER MANAGEMENT Meets ENERGY STAR®standards
PACKAGE CONTENTS LCD display, VGA cable, power cable, audio cable,
Quick Start Guide, ViewSonic Wizard CD (User Guide & drivers)
WARRANTY Three-year limited warranty on parts, labor and backlight.
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
