ViewSonic VX1935wm-3
Model No. VS11444
19” Color TFT LCD Display
(VX1935wm-3_SM Rev. 1a Oct. 2006)
ViewSonic 381 Brea Canyon Road, Walnut, California 91789 USA - [phone]
Service Manual

ViewSonic Corporation Confidential - Do Not Copy VX1935wm-3
i
Copyright
Copyright © 2006 by ViewSonic Corporation. All rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written permission of ViewSonic
Corporation.
Disclaimer
ViewSonic makes no representations or warranties, either expressed or implied, with respect to
the contents hereof and specifically disclaims any warranty of merchantability or fitness for any
particular purpose. Further, ViewSonic reserves the right to revise this publication and to make
changes from time to time in the contents hereof without obligation of ViewSonic to notify any
person of such revision or changes.
Trademarks
Optiquest is a registered trademark of ViewSonic Corporation.
ViewSonic is a registered trademark of ViewSonic Corporation.
All other trademarks used within this document are the property of their respective owners.
Revision History
Revision SM Editing Date ECR Number Description of Changes Editor
1a 10/26/2006 Initial Release Jamie Chang

ViewSonic Corporation Confidential - Do Not Copy
ii
TABLE OF CONTENTS
1. Precautions and Safety Notices 1
2. Specification 4
3. Front Panel Function Control Description 13
4. Circuit Description 21
5. Adjustment Procedure 33
6. Troubleshooting Flow Chart 45
7. Recommended Spare Parts List 53
8. Exploded Diagram and Exploded Parts List 56
9. Block Diagram 60
10. Schematic Diagrams 61
11. PCB Layout Diagrams 68
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
1
1. Precautions and Safety Notices
1. SAFETY PRECAUTIONS
This monitor is manufactured and tested on a ground principle that a user’s safety comes first. However,
improper used or installation may cause damage to the monitor as well as to the user.
WARNINGS:
This monitor should be operated only at the correct power sources indicated on the label on the
rear of the monitor. If you’re unsure of the power supply in you residence, consult your local
dealer or Power Company.
Use only the special power adapter that comes with this monitor for power input.
Do not try to repair the monitor by yourself, as it contains no user-serviceable parts. Only the
qualified technician can repair it.
Do not remove the monitor cabinet. There are high-voltage parts inside that may cause electric
shock to human bodies.
Stop using the monitor if the cabinet is damaged. Have it checked by a service technician.
Put your monitor only in a lean, cool, dry environment. If it gets wet, unplug the power cable
immediately and consult your closed dealer.
Always unplug the monitor before cleaning it. Clean the cabinet with a clean, dry cloth. Apply
non-ammonia based cleaner onto the cloth, not directly onto the glass screen.
Do not place heavy objects on the monitor or power cord.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety visual inspections and the
protection afforded by them cannot necessarily be obtained by using replacement components
rated for higher voltage, wattage, etc. Before replacing any of these components read the parts
list in this manual carefully. The use of substitute replacement parts, which do not have the
same safety characteristics as specified in the parts list, may create shock, fire, or other
hazards.
3. SERVICE NOTES
When replacing parts or circuit boards, clamp the lead wires around terminals before soldering.
Keep wires away from high voltage, high temperature components and sharp edges.
Keep wires in their original position so as to reduce interference.
Adjustment of this product please refers to the user’ manual.
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
2
Handling and Placing Methods
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
3
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
4
2. Specification
1. INTRODUCTION
FEATURES VX1935wm-3
Size 19 " wide
Luminance (Typ) 300 cd/㎡
Contrast Ratio (Typ) 700:1
Colors 16.2 M (6 bits + 2 bits FRC)
Response Time 5 ms(on/off)
Viewing Angle (H/V) 160 ° / 160 °
TFTLCD PANEL
1st
Innolux
MT190AW01 V.0
Recommend resolution 1440x900@60Hz
Analog Yes (75ohms, 0.7/1.0 Vp-p)
Input Signal
Digital Yes
Separate Sync Yes
Composite Sync Yes
Sync Compatibility
Sync on Green Yes
PC Yes
Power Mac Yes
Compatibility
TV Box (NextVision 6) Yes
Power Voltage AC 100-240V, 50/60Hz Yes
On Mode(Max / Typ) 42 W / 35 W
Power Consumption
Off Mode (Max) ≦1 W
Audio 2W / THD 10% (Max) Yes
Tilt ( 20 ° - -5 °) Yes
Swivel No
Pivot No
Ergonomics
Height Adjust No
OSD Control [ 1 ] [ 2 ] [ ][▼] [▲] Yes
Physical (W x H x D) 450 x 434 x 209mm
Dimension
Package (W x H x D) 545*515*162mm
Physical (Net Weight) 5.2 Kg / 11.5 lbs
Weight
Package (Gross Weight) 6.7 Kg / 14.8 lbs
Temperature (℉/℃) 32℉-104℉/ 0℃-40℃
Operating Condition
Humidity (%) 20 % - 80 %
Temperature (℉/℃) -4℉-140℉/ -20℃-60℃
Storage Condition
Humidity (%) 10% - 90 %
Regulation
Global: CB, MPR II, WEEE,ROHS , ISO13406-2
VSA:UL, cUL, FCC-B, TUV-S, NOM, Energy Star
VSE:TUV/ERGO,CE ,GOST-R+Hygienic ,SASO , ENERGY
VSI: BSMI, CCC, PSB, C-TICK, MIC
VSCN:CCC
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
5
2. GENERAL specification
Test Resolution & Frequency 1440x900 @ 60Hz
Test Image Size Full Size
Contrast and Brightness Controls Factory Default:
Contrast = 70%, Brightness = 100%
3. VIDEO INTERFACE
Analog Input Connector DB-15 (Analog),
Digital Input Connector DVI-D (Digital),
Default Input Connector Defaults to the first detected input
Video Cable Strain Relief Equal to twice the weight of the monitor for five minutes
Video Cable Connector DB-15 Pin out Compliant DDC 1/2B
Video Signals
1. Video RGB (Analog)
Separate, Composite, and Sync on Green
2. TMDS (Digital)
Video Impedance 75 Ohms (Analog), 100 Ohms (Digital)
Maximum PC Video Signal 950 mV with no damage to monitor
Maximum Mac Video Signal 1250 mV with no damage to monitor
Sync Signals TTL
DDC 1/2B Compliant with Revision 1.3
Sync Compatibility Separate Sync, Composite Sync, SOG
Video Compatibility Shall be compatible with all PC type computers, Macintosh
computers, and after market video cards
Resolution Compatibility
640 x 350*, 640 x 480, 720 x 400* (640 x 400*), 800 x 600, 832 x
624, 1024 x 768, 1152 x 864, 1152 x 870, 1280 x 720, 1280 x
960, 1280 x 1024 , 1400 x 1050 , 1440 x 900
* The image vertical size might not be full screen.
But the image vertical position should be at the center.
Exclusions Not compatible with interlaced video
4. POWER SUPPLY
Internal Power Supply Part Number:ILPI-024
Input Voltage Range 90 to 264 VAC (100~240VAC ±10%)
Input Frequency Range 47 to 63 Hertz
Short Circuit Protection Output can be shorted without damage
Over Current Protection 5.0 A typical at 14.0 VDC
Leakage Current 3.5mA (Max) at 254VAC / 60Hz
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
6
Efficiency (at 115VAC Full Load) Typical: 80%
Minimum: 75%
Fuse Internal and not user replaceable
Power Output 35 Watts (typ)
Ripple and Noise Ripple: <3%
Max Input AC Current 1.2 Arms @ 100VAC, 0.6 Arms @240VAC
Inrush Current (Cold Start) 40 A (max) @ 120VAC
60 A (max) @ 220VAC
Power Supply Cold Start
Shall start and function properly when under full load, with all
combinations of input voltage, input frequency, and operating
temperature.
Power Supply Transient Immunity
Shall be able to withstand an ANSI/IEEE C62.41-1980 6000V 200
ampere ring wave transient test with no damage.
Power Supply Line Surge Immunity
Shall be able to withstand 1.5 times nominal line voltage for one
cycle with no damage.
Power Supply Missing Cycle Immunity
Shall be able to function properly, without reset or visible screen
artifacts, when ½ cycle of AC power is randomly missing at
nominal input.
Power Supply Acoustics
The power supply shall not produce audible noise that would be
detectable by the user. Audible shall defined to be in
compliance with ISO 7779 (DIN EN27779:1991) Noise
measurements of machines acoustics. Power Switch noise shall
not be considered.
Power Saving Operation(Method) VESA DPMS Signaling
Power Consumption
Mode LED Power Consumption
On Green 35 W (Typ)
42 W (max)
Stand By Amber < 2 W
Active Off Off < 1 W
Recovery Time On Mode = N/A, Active Off < 3 sec
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
7
5. ELECTRICAL REQUIREMENT
Horizontal / Vertical Frequency
Horizontal Frequency 30 – 82 kHz
Vertical Refresh Rate 56 – 75 Hz
Maximum Pixel Clock 135 MHz
Sync Polarity Independent of sync polarity
Timing Table
Analog
Item
Timing
Separated
Composite
SOG
Digital - TMDS
Remark
1 640 x 350 @ 70 Hz, 31.5 KHz 



For Analog sync, the image vertical size image
will be not full screen (Still at the center)
2 640 x 400 @ 60 Hz, 31.5 KHz 



For Analog sync, the OSD will be
640x480@60Hz
3 640 x 400 @ 70 Hz, 31.5 KHz




For Analog sync, the image vertical size image
will be not full screen (Still at the center), And the
OSD will be 640x400/720x400 (primary=
720x400).
4 640 x 480 @ 50 Hz, 24.7 KHz 


5 640 x 480 @ 60 Hz, 31.5 KHz 



6 640 x 480 @ 67 Hz, 35 KHz 



7 640 x 480 @ 72 Hz, 37.9 KHz 



8 640 x 480 @ 75 Hz, 37.5 KHz 



9 640 x 480 @ 85 Hz, 43.3 KHz 



10 720 x 400 @ 70 Hz, 31.5 KHz




For Analog sync, the image vertical size image
will be not full screen (Still at the center), And the
OSD will be 640x400/720x400 (primary=
720x400).
11 720 x 480 @ 60 Hz, 31.5 KHz 



For Analog sync, the information OSD shows
640x480
12 720 x 576 @ 50 Hz, 31.3 KHz 



13 800 x 600 @ 56 Hz, 35.1 KHz 



14 800 x 600 @ 60 Hz, 37.9 KHz 



15 800 x 600 @ 72 Hz, 48.1 KHz 



16 800 x 600 @ 75 Hz, 46.9 KHz 



17 800 x 600 @ 85 Hz, 53.7 KHz 



18 832 x 624 @ 75 Hz, 49.7 KHz 



19 1024 x 768 @ 50 Hz, 39.6 KHz 



For Analog sync, Switch 1024x768@50Hz and
1280x768@50Hz by [1]+[2] short cut key
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
8
20 1024 x 768 @ 60 Hz, 48.4 KHz 



21 1024 x 768 @ 70 Hz, 56.5 KHz 



22 1024 x 768 @ 75 Hz, 60 KHz 



23 1024 x 768 @ 75 Hz, 60.02 KHz 



24 1024 x 768 @ 85 Hz, 68.7 KHz 



25 1152 x 864 @ 75 Hz, 67.5 KHz 



26 1152 x 870 @ 75 Hz, 68.7 KHz 



27 1280 x 768 @ 50 Hz, 39.6 KHz 



For Analog sync, Switch 1024x768@50Hz and
1280x768@50Hz by [1]+[2] short cut key
28 1280 x 768 @ 60 Hz, 47.4 KHz 

29 1280 x 768 @ 60 Hz, 47.8 KHz 



30 1280 x 768 @ 75 Hz, 60.3 KHz 



For Analog sync, Switch 1024x768@75Hz and
1280x768@75Hz by [1]+[2] short cut key
31 1280 x 960 @ 50 Hz, 49.4 KHz 



32 1280 x 960 @ 60 Hz, 60.0 KHz 



33 1280 x 960 @ 75 Hz, 75.2 KHz 



34 1280 x 1024 @ 50 Hz, 52.7 KHz 



35 1280 x 1024 @ 60 Hz, 64 KHz 



36 1280 x 1024 @ 70 Hz, 74.8 KHz 



37 1280 x 1024 @ 72 Hz, 76.8 KHz

38 1280 x 1024 @ 75 Hz, 80 KHz 



39 1360 x 768 @ 60 Hz, 47.7 KHz 

40 1400 x 1050 @ 50 Hz, 54.1 KHz 



41 1400 x 1050 @ 60 Hz, 64.7 KHz 

42 1400 x 1050 @ 60 Hz, 65.3 KHz 


43 1400 x 1050 @ 75 Hz, 82.3 KHz 



44 1440 x 900 @ 60 Hz, 55.5 KHz 

45 1440 x 900 @ 60 Hz, 55.9 KHz 



46 1440 x 900 @ 75 Hz, 70.6 KHz 



*1. Tolerance ≧±2KHz.
*2. Any timing not in the list, it should display as normal or show on “OUT OF RANGE” OSD message without
blanking.
*3. The image quality of 85Hz mode might be worse than 75Hz.
Primary Presets
1440x900 @ 60Hz
User Presets
Number of User Presets (recognized timings) Available: 10 presets total in FIFO configuration
Changing Modes
● Maximum Mode Change Blank Time for image stability : 5 seconds (Max), excluding “Auto Adjust” time
● Under DOS mode (640 x 350, 720 x 400 & 640 x 400), it should recall factory setting when execute “Auto
Adjust”
● The monitor needs to do “Auto Adjust” the first time a new mode is detected
(see section “0-Touch™ Function Actions”)
● While running Change Mode, Auto Adjust or Memory Recall, the image shall blank
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
9
2.6 FRONT PANEL CONTROLS AND INDICATORS
Front Panel Hardware Controls
Power Switch (Front Head) Power Control, soft Power Switch.
Power LED (Front Head) Blue – ON
Orange –Power Saving Mode
Dark = Soft Power Switch OFF
Front Panel Controls (Head)
[ 1 ] [ 2 ] [ ] [▼] [▲]
[ 1 ] BUTTON 1
[ 2 ] Button 2
[] Power
[▼] DOWN ARROW BUTTON
[▲] Up arrow button
Note: Power Button, Button 1 and Button 2 must be one-shot
logic operation. (i.e. there should be no cycling)
Reaction Time OSD must fully appear within 0.5s after pushing Button 1
Short Cuts Function from the button(s)
[1] Main Menu
[2] Input toggle (Analog or Digital)
[▼] or [▲] To immediately activate Brightness /Contrast menu.
[▼]+ [▲] Recall both of Contrast and Brightness to default
[1] + [2] Toggle 720x400 and 640x400 mode when input 720x400 or 640x400 mode
[1] + [▼] + [▲]
(Keep pushing 3 sec)
White Balance. (Not shown on user’s guide)
[1] + [▼] Power Lock
[1] + [▲] OSD Lock
[2] + [ ] Factory Mode
Remark : All the short cuts function are only available while OSD off
Function descriptions
OSD Lock short cuts function for the buttons
The OSD lock will be activated by pressing the front panel control buttons "(1), & (▲)" for 10 seconds. If the user
then tries to access the OSD by pressing any of the buttons "1", "▼", "▲", "2" a message will appear on the screen
for 3 seconds showing "OSD Locked". The OSD lock will be deactivated by pressing the front panel control buttons
"(1), & (▲)" again for 10 seconds.
Note1: When the OSD is locked will lock all functions, including “Volume” and “Mute”
Note 2: Status bar indicating OSD Lock or Unlock is in progress and when complete it will indicate “OSD Locked”
Note 3: OSD Lock should not lock Power Button and Power Lock function
Power Lock short cuts function for the buttons
The power button lock will be activated by pressing the front panel control buttons "(1), & (▼)" for 10 seconds.
Locking the power button means that the user won't be able to turn off the LCD while the power button is locked. If
the user presses the power button while it is locked, a message will appear on the screen for 3 seconds showing
"Power Button Locked". It also means that with the power button locked, the LCD would automatically turn back
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
10
"On" when power is restored after a power failure. If the power button is not in the locked mode, then power should
return to it's previous state when power is restored after a power failure. The power button lock will be deactivated by
pressing the front panel control buttons "(1), & (▼)" again for 10 seconds.
Note 1: Status bar indicating Power Button lock or unlock is in progress and when complete it will indicate “Power
Button Locked”
Note 2: Power should only be lockable in the “On State”
Memory Recall Actions
Memory Recall action on the analog and digital mode as below
1. Recall white balance to factory setting
2. Set the factory defaults as shown in Section 4-8
3. Clean all the mode setting buffer
4. Execute Auto Image Adjust
Note: Memory Recall should have no effect for Language, Power Lock, User Color Settings or Input Priority
Resolution Notice Actions
1. Resolution Notice OSD should show on screen after changing to non-native mode for 30 sec
2. For auto input select function, it shall meet the requirement in Appendix D.
3. The OSD should disappear after 10 sec or by pushing button [1] or [2]
Resolution Notice function should be disabled when push button [2] under Resolution Notice OSD
0-Touch™ Function Actions
1. Execute Auto Image Adjust when new mode detected, and save the settings to buffer for further use
2. It should be reset by Memory Recall function(Should not reset by power off, power unplug and others)
OSD Auto Save
The OSD shall save new settings when it is turned off by the user or when it times out. There shall not be a
separate save
Factory Defaults
Item Defaults Item Defaults
Contrast 70% Input Priority N/A
Brightness 100% Resolution Notice Enabled
Color Temperature 6500K Volume N/A
Sharpness 100% Balance N/A
OSD H. Position 50% Treble N/A
OSD V. Position 50% Bass N/A
OSD Time Out 15 Sec
OSD Background Enabled
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
11
2.7 AUDIO INTERFACE (SPEAKER SPECIFICATION)
Line input signal 1 Vrms
Line input impedance 10 kOhm
Maximum Amp power output (Watt) 2.0 W (RL=8Ω)
Speaker Power rating(Ω/Watt) 8Ω/2 W (typ.) ; 8Ω/ 3 W (max)
THD 10% (Maxmum output @1KHZ)
Signal to Noise Ratio 75 dB
Frequency response 200 Hz – 20 Khz
SPL. 82 ± 3 dB
Line input connection 3.5 mm stereo jacks
Vibration
There should be no audible vibration resonance at
volume=100% & treble / bass in def. value
Screen image There should be no affect on the screen image stability under
any conditions
Connector PC99 requirement Audio in Lime Green pantone # 577C
Cable type / length 3.5mm stereo cable / 1.8m length
Audio DPMS
Speakers stay Off when the rest of the monitor is in power
saving
Note: There is no guarantee <2 W at power consumption in
Active Off mode, when the Audio Cable is connected
1
LCD PANEL
1st panel
source
Type:
Pixel Pitch
Color Filter
Glass
Viewing Angle
Contrast Ratio
Brightness
Response Time
Color Depth
Backlight Life
INL
CR > 10
19” wide Color TFT Active Matrix WXGA LCD. (MT190AW01 V.0)
0.285mm (H) x0.285mm(V)
RGB Vertical Stripe
Anti-Glare treatment and hard-coating 3H
Horizontal = 140 Degrees (Min), Vertical = 140 Degrees (Min)
Horizontal = 160 Degrees (Typ), Vertical = 160 Degrees (Typ)
700:1 (Typ), 500:1 (Min)
300 cd/m2 (Typ), 230 cd/m2 (Min),
Tr = 1.5ms (Typ), Tf =3.5ms (Typ). Tr+Tf = Total = 5ms (Typ)
Tr = 6.5ms (Max), Tf = 8.5ms (Max) Tr+Tf = Total = 15ms (Max)
16.2 million colors (6 bits + 2 bits FRC)
40,000 Hrs (Min)
2.
INPUT
SIGNAL
Video
Sync
RGB Analog (75 ohms, 0.7 Vp-p); DVI-D
H/V Separated (TTL), Composite, SOG
FH:30~82kHz, FV:50~85Hz
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
12
3.
COMPATIBILI
TY
PC
Mac
VGA up to 1440 x 900 non-interlaced
Power Macintosh up to 1440 x 900
RESOLUTIO
N
Max
1440 x 900 @ 60, 75 Hz NI
1400 x 1050 @ 60, 75 Hz NI
1280 x 1024 @ 60, 75,85 Hz NI
1024 x768 @ 60, 75,85 Hz NI
800 x 600 @ 60, 75 ,85Hz NI
640 x 480 @ 60, 75 Hz NI
CONNECTO
R
Signal
Power
Head
Head
15 pin mini D-sub
DVI-I
Audio in stereo Jack
3 Pin AC Plug, (CEE22)
POWER Voltage
Consumption
AC/DC
Internal
Power
AC 100 – 240 VAC 50-60 Hz (auto switch)
35W (Typ) / 43W (Max)
SPEAKER Stereo Speaker
2w x2 ,
ERGONOMIC
S
Tilt
Down
Up
5 Degrees
20 Degrees
CONTROLS Physical
OSD
LCD
Head
Main
Menu
[1], [2] , Power (Soft) , Down[▼], Up[▲]
Auto Image Adjust*1
Contrast/Brightness*2*4
Input Select
Analog, Digital
Audio Adjust
Volume*
4, Mute*4
Color Adjust
SRGB, 9300K, 7500K,6500K(default), 5400, User Color [R, G, B]
Information
Resolution, H Frequency, V Frequency, Pixel Clock, Serial Number,
Model Number,
“www.ViewSonic.com”
Manual Image Adjust
Horizontal. Size*1, H/V. Position*1, Fine Tune*1, Sharpness*3
Setup Menu
Language [English, French, German, Italian, Spanish, Finnish,
Japanese,
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
13
Short Cut
Traditional Chinese, Simplified Chinese], Resolution Notice, OSD
Position,
OSD Timeout, OSD Background
Memory Recall
[1]: Main Menu
[2]: Input Select
[▲] or [▼]: Brightness/Contrast
[▲] + [▼]: Recall Contrast and Brightness
[1] and [▼]: Power lock/unlock
[1] and [▲]: OSD lock/unlock
*1 These functions are not available in Digital Mode
*2 These functions are not available under sRGB Mode
*3 These functions are not available under Native Resolution Mode
*4 These functions setting can be recalled to default by [▼]+[▲]
BANDWIDTH Pixel Clock Digital 140 Mhz (Max) Analog 140 Mhz (Max)
DISPLAY
AREA
410.4 (H) x 256.5 (V)
OPERATING
CONDITION
Temperature
Humidity
32°F to 104°F (0°C to 40°C)
20% to 80% (no condensation)
STORAGE /
SHIPPING
CONDITION
Temperature
Humidity
-4°F to 140°F (-20°C to 60°C)°
10% to 90% (no condensation)
DIMENSIONS
Physical
Panel Only
Packaging
W/o
base
450 mm (W) x 434 mm (H) x 209 mm (D)
17.7” (W) x 17” (H) x 8.2” (D)
450 mm (W) x 341 mm (H) x 65.5mm (D)
17.7” (W) x 13.4” (H) x 2.6”(D)
545 mm (W) x 515 mm (H) x 162 mm (D)
21.5” (W) x 20.3” (H) x6.4” (D)
WEIGHT Net
Net(w/o stand)
Gross
5.2kg (11.5 lbs)
4.7kg (10.4 lbs)
6.7kg (14.8 lbs)
REGULATIO
NS
Global: CB, MPR II, WEEE,ROHS , ISO13406-2
VSA:UL, cUL, FCC-B, TUV-S, NOM, Energy Star
VSE:TUV/ERGO,CE ,GOST-R+Hygienic ,SASO , ENERGY
VSI: BSMI, CCC, PSB, C-TICK, MIC
VSCN:CCC
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
14
RELIABILITY MTBF
100,000hrs (demonstrated) excluding Light source
Light Source MTBF: 40K hrs (Min)
POWER
SAVING
FUNCTION
"On"
"Sleep"
"Off"
Green
Amber
Normal
<2W
<1W
LOGISTICS Container Load
Pallet Load
UPC-A Code
ITF-14 Code
Serial Format
Country of
Origin
20’/40’
Air/Sea
560/1120 pcs (Palletized)
56/56 pcs
7 66907 21621 9
0 07 66907 21621 9
QCXyywwxxxxx
China
SECURITY Kennsington lock on the bottom right side
Wall Mount VESA
100mm x 100mm
ACCESSORI
ES
Power Cable
15 Pin VGA Video Cable
DVI-D Cable
Audio Cable
Quick Start Guide
ViewSonic Wizard CD-ROM w/ 17 Language User Guide
EU Packaging
Information
1. Weight of the individual (empty) shipping carton. ---------- Weight =903 g/box
2. Weight and materials of the poly foam ------ Weight = 200g/piece, 2 pieces per box, Material
= EPS
3. Weight and material of the empty accessory plastic bags --------- Weight = 2g/bag, Material=
PE
4. Weight and material of the plastic handle ------- Weight = 10 g/piece, Material=PE Plastic
5. Weight and material of the PE bag that covers the monitor -------- Weight = 19g/bag,
Material=PE
6. Weight / Material of Pallets:
7. A/E/M/U/ S/G/J//K/P model -Weight =12+/-3kg, Material= Solid Wood (Fumigation)
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
15
3. Front Panel Function Control Description
Adjusting the Screen Image
Main Menu
with OSD controls
Front Control Panel
shown below in detail
Scrolls through menu
options and adjusts the
displayed control.
Also a shortcut to display
the Contrast adjustment
control screen.
Displays the control screen for
the highlighted control.
Also toggles between two
controls on some screens.
Also a shortcut to Auto Image
Adjust.
Standby Power On/Off
Power light
Blue = ON
Orange = Power Saving
Displays the Main
Menu or exits the
control screen and
saves adjustments.
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
16
Do the following to adjust the display setting:
1. To display the Main Menu, press button [1].
NOTE: All OSD menus and adjustment screens disappear automatically after about 15
seconds. This is adjustable through the OSD timeout setting in the setup menu.
2. To select a control to adjust, pressSorTto scroll up or down in the Main Menu.
3. After the desired control is selected, press button [2]. A control screen like the one shown
below appears.
4. To adjust the setting, press the up Sor down Tbuttons.
5. To save the adjustments and exit the menu, press button [1] twice.
The following tips may help you optimize your display:
• Adjust the computer's graphics card so that it outputs a 1440 x 900 @ 60Hz video signal to
the LCD display. (Look for instructions on “changing the refresh rate” in the graphics card's
user guide.)
• If necessary, make small adjustments using H. POSITION and V. POSITION until the
screen image is completely visible. (The black border around the edge of the screen should
barely touch the illuminated “active area” of the LCD display.)
The command line at the bottom of the
control screen tells what to do next from
this screen. You can toggle between control
screens, adjust the selected option, or exit
the screen.
VX1935wm-3

ViewSonic Corporation Confidential - Do Not Copy
17
Main Menu Controls
Adjust the menu items shown below by using the up Sand down Tbuttons.
Control Explanation
Auto Image Adjust sizes and centers the screen image automatically.
Contrast adjusts the difference between the image background (black level)
and the foreground (white level).
Brightness adjusts background black level of the screen image.
Input Select toggles between inputs if you have more than one computer
connected to the VX1935wm.
Audio Adjust
Vol ume increases the volume, decreases the volume, and mutes the audio.
Mute temporarily silences audio output.
Color Adjust provides several color adjustment modes, including preset color
temperatures and a User Color mode which allows independent adjustment of
red (R), green (G), and blue (B). The factory setting for this product is 6500K
(6500 Kelvin).
VX1935wm-3
